APRAL Telecom is a systems integration company that provides telecommunications solutions and consulting services in the Middle East. It selects the best products suited for customer needs and integrates different solutions. It offers implementation, maintenance, technical support, training, and other services. Some of the solutions it provides include data/voice networks, CCTV and surveillance systems, fiber management, and tactical electronics.

1. Presented By :- Engr. Loay Al-Baba

2. Our Philosophy As a system integrator in the Middle East markets, APRAL Telecom, always chooses manufacturers´ products objectively, selects equipment that is best suited for the respective system solution and the customer’s specific application. In addition , APRAL Telecom also provides the integration needed for solutions that include different products .In Addition APRAL Telecom provide extensive consulting services. Apart from a detailed analysis, this involves consulting as well as planning Due to the complex variety of similar products offering an assortment of features selecting the right telecommunications products has become increasingly difficult for customers. Also the integration between different products needed for one solution is important.

3. Main Activities A- services B- Turn Key Solutions

4. APRAL Telecom is a services company specializing in the field of * Implementation . * Maintenance * Technical support . * Technical Training * Logistics and network services . rab Filed work include :- Installation , Testing , Acceptance and Site Survey Office work include :- Documentation Preparation , Evaluation of field result And Analyzing Field Results A- services

5. B - Turnkey Solutions Data / Voice /Video Networks. HF ,VHF / UHF & Microwave CCTV & IP Surveillance Systems. Leased lines backup solutions through ISDN and DSL. Fiber Management . Avionics and air traffic control. VDSL – DSLAM solutions Safety and security Systems. IT , ERP Systems , . Access Control & SCADA. IVR Systems. Biometric identification Systems. Tactical Electronics for Critical Missions. Multiplexers and bandwidth chare AVL Solutions

6. HF single side Band Communication systems Vehicle applications ) GPS) tracking and location Marine transceivers Email fax and data Telephone interconnects & Phone patch Portable transceivers Military Applications

7. ويمكن تحقيق ذلك كما يلي :- F1 F2 F1 F2 قناة 1 قناة 1 F3 F4 F3 F4 UHF/VHF wireless communications

8. Analog Link or E1 Squematic Diagram of Linked Sites STATION B Similar A STATION C Similar A A P SA ISX-510 ISX-510 ISX-510 External Telephone lines External Telephone lines External Telephone lines STATION A 4 Repeaters, 4 ST-853 and 4 similar equipment in stand by

9. VHF telephone point to point and point to multipoint

10. GPS & AVL SYSTEMS X1 X2 X3 X4 X5

11. Microwave

12. Microwave SONET/SDH Digital Radio System

13. COFDM – coded orthogonal frequency division multiplexing most advanced video and sound transmission • COFDM is the broadcast technology of digital satellites and terrestic DVB • COFDM allows video and audio transmission in DVD-quality for police application or law enforcement • COFDM can transmit from flying planes,helecopters or racing cars • Several digital boosters are available for vehicle installations • Body worn transmitters with low power output are available Linier Polarization Circular Polarization

14. Total Fiber Connectivity DWDM Ring up to 32 high speed channels (2,5 Gbps) or 128 low speed channels (200Mbps) CWDM Ring up to 8 high speed channels (2,5 Gbps) or 32 low speed channels (200Mbps) CWDM Ring up to 8 high speed channels (2,5 Gbps) or 32 low speed channels (200Mbps) WavePilot with OFX- Module WavePilot WavePilot WavePilot with OFX- Module WavePilot with OFX- Module WavePilot with OFX- Module WavePilot with OFX- Module Mainframe Storage Disks Camera LAN TimePilot OFC OFB LAN Server Gigabit Router 100base T ATM ESCON Fibre Channel Gigabit Ethernet Redundant Fiber Link

15. APRAL Networked Video and communication Solutions IP-Video-Surveillance Network Voice-over-IP

16. IP-Network topology

17. APRAL VDSL Compounds & Hotels Best solution for Data connectivity

18. APRAL Ethernet Switching Everywhere Metro Area Networks Transport Corporate /SOHO LAN IP Access Carrier Edge Carrier Core IP DSLAM VDSL SW Ethernet SW Ethernet SW Ethernet SW Remote DSLAM Ethernet SW Ethernet SW Ethernet SW Ethernet SW Router SW Data Generation Aggregation Service Definition Switching Transport

19. SCADA & Control Sys. Oil & Gas Pipeline Electrical Water Building Monitoring Airport and En Route Aviation Equipment Monitoring

20. Aerospace & Defense APRAL Telecom Defense Solutions creatively adapts and integrates technologies to rapidly produce solutions for the homeland security and defense markets

21. IP Surveillance Face Recognition Behavior Watch 1 Behavior Watch2 Large enterprises Network Alarm Centrals Public Areas Residential & Government Transport & Logistics Retail & Shops Cameras and Sensors LAN Networks ISDN GSM/PSTN WAN Peripherals Sender Units Hardware: Receiver Units Software: Receiver Units Hardware:

22. Consultation APRAL Telecom Co. has been involved in Design & System Integration of Telecom Networks and Security Systems , to various customers, as a total solution for all the needs of customers, by providing Latest State-Of-The-Art Technology available in the market ,also by having business partnerships with most of well-known foreign firms. We have an enviable record for Design (Networks, Systems, Integration) with innovative solutions to customer requirements, Quality, and Timely completion of projects.

23. Fiber Sensors Intrusion Detection System Integrated Sensor system in the ground. Cannot be detected, as no emission is radiated. One server can cover up to 26 km of border line. All servers can be interconnected by TCP/IP. Remote maintenance Alarming time <100 msec. Interface for external sensors as laser beams, passive IR/sensors, etc

24. FMCW, the quiet naval radar system for sea and harbour surveillance The A/D -board is connected via PCI to the PC. The control as well as the signal processing of the echo will be performed in the PC. ATT (Kalman) is activated for all targets (option).

25. Apral Tactical Electronics for Critical Missions Remote monitoring and surveillance systems. Unmanned Tactical Aircraft Communications interception and jamming equipment. . Explosives, narcotics, biological and contraband detection . RF, optical, micro-wave and satellite surveillance systems . Radio Direction Finders Bug Fighter (Locate Hidden Transmitters ,Microphones) . Covert audio and video surveillance and detection systems التقنيات الدقيقة للمهام الصعبة

26. Thanks!
