MongoDB 2.2 이후 집계 파이프라인을 통한 데이터 분석을 강화하고 있습니다. 버전 4.2 에서는 더 많은 기능을 추가 했으며, 더 강력한 쿼리 및 업데이트 그리고 MView 기능까지 사용 할 수 있습니다. 집계파이프 라인을 포함한 해당 기능을 이용하여 단일뷰(SignleView), ETL, 데이터 롤업 및 MView 수행하는 방법을 설명합니다.

1. Aggregation Pipeline Power++
MongoDB 4.2 파이프 라인 쿼리 , 업데이트 및 구체화된 뷰 소개
김준 , 기술담당 상무, MongoDB

2. 파이프라인(PIPELINE)

3. 파이프라인(PIPELINE)
ps ax | grep mongod | head 1
*nix command line pipe
$match | $group | $sort
MongoDB Document Pipeline
Inputstream{}{}{}{} Result{}{}...

4. 파이프라인 스테이지
DATA PIPELINE

5. 파이프라인 스테이지
DATA PIPELINE
Stage 1 Stage 2 Stage 3 Stage 4
{}{}{}{}
{}{}{}{} {}{}{}{}
{"$stage":{ ... }}
Collection
View
Special stage

6. {title: "The Great Gatsby",
language: "English",
subjects: "Long Island"}
{title: "The Great Gatsby",
language: "English",
subjects: "New York"}
{title: "The Great Gatsby",
language: "English",
subjects: "1920s"}
{title: "The Great Gatsby",
language: "English",
subjects: [
"Long Island",
"New York",
"1920s"] },
{"$match":{"language":"English"}}
$match
{ _id:"Long Island",
count: 1 },
$group
{ _id: "New York",
count: 2 },
$unwind
{ _id: "1920s",
count: 1 },
$sort $skip$limit $project
{"$unwind":"$subjects"}
{"$group":{"_id":"$subjects", "count":{"$sum:1}}
{ _id: "Harlem",
count: 1 },
{ _id:"Long Island",
count: 1 },
{ _id: "New York",
count: 2 },
{ _id: "1920s",
count: 1 },
{title: "Open City",
language: "English",
subjects: [
"New York"
"Harlem" ] }
{ title: "The Great Gatsby",
language: "English",
subjects: [
"Long Island",
"New York",
"1920s"] },
{ title: "War and Peace",
language: "Russian",
subjects: [
"Russia",
"War of 1812",
"Napoleon"] },
{ title: "Open City",
language: "English",
subjects: [
"New York",
"Harlem" ] },
{title: "Open City",
language: "English",
subjects: "New York"}
{title: "Open City",
language: "English",
subjects: "Harlem"}
{ _id: "Harlem",
count: 1 },
{"$sort:{"count":-1} {"$limit":3}
{"$project":...}

8. 실행계획 ( Explain )

9. 스트리밍(Streaming) 자원 사용
INPUT STAGE RESULTSSTAGE
Each document is streamed through in RAM

10. 블럭킹(Blocking) 자원 사용
INPUT STAGE RESULTSSTAGE
Everything has to be kept in RAM (or spill)

11. PREVIOUSLY ...

12. Update 에서
집계 파이프라인
사용

13. Update
db.coll.update(
<query>,
<update>,
<options>
)

14. Update
db.coll.update(
<query>,
<update>,
<options>
)

15. Update
{
$set: { },
$inc: { },
$...
}
{
f1: <value>,
f2: <value>,
...
}

16. Update
{ } OR [ ]
[ <aggregation-pipeline> ]

17. { _id: 1 }
{ _id: 1, a: 10 }
{ _id: 1, a: 100 }
---
{ _id: 1, a: "10" }
db.coll.update({_id:1},
{$inc:{a:1}},
{upsert:true})
{ _id: 1, a: 1 }
{ _id: 1, a: 11 }
{ _id: 1, a: 101 }
{ _id: 1, a: 1 }
"errmsg" : "Cannot apply
to a value of non-numeric type."

18. { _id: 1 }
{ _id: 1, a: 10 }
{ _id: 1, a: 100 }
---
{ _id: 1, a: "10" }
db.coll.update({_id:1},
[ {$set:{a:{$sum:["$a",1]}}} ],
{upsert:true})
{ _id: 1, a: 1 }
{ _id: 1, a: 11 }
{ _id: 1, a: 101 }
{ _id: 1, a: 1 }
{ _id: 1, a: 1 }

19. { _id: 1 }
{ _id: 1, a: 10 }
{ _id: 1, a: 100 }
---
{ _id: 1, a: "10" }
db.coll.update({_id:1},
[ {$set:{a:{$add:["$a",1]}}} ],
{upsert:true})
{ _id: 1, a: 1 }
{ _id: 1, a: 11 }
{ _id: 1, a: 101 }
{ _id: 1, a: 1 }
"errmsg" : "$add only supports
numeric or date types, not string"

20. { _id: 1 }
{ _id: 1, a: 10 }
{ _id: 1, a: 100 }
---
{ _id: 1, a: "10" }
db.coll.update({_id:1},
[
],
{upsert:true})
{ _id:1, a: 21 }
{ _id: 1, a: 11 }
{ _id: 1, a: 101 }
{ _id:1, a: 21 }

21. { _id: 1 }
{ _id: 1, a: 10 }
{ _id: 1, a: 100 }
---
{ _id: 1, a: "10" }
db.coll.update({_id:1},
[ {$set:{a:{$cond:{
if:
then: , else: }} }}]
{upsert:true})
{ _id:1, a: 21 }
{ _id: 1, a: 11 }
{ _id: 1, a: 101 }
{ _id:1, a: 21 }

22. { _id: 1 }
{ _id: 1, a: 10 }
{ _id: 1, a: 100 }
---
{ _id: 1, a: "10" }
db.coll.update({_id:1},
[ {$set:{a:{$cond:{
if: {$eq:[{$type:"$a"},"missing"]},
then: , else: }} }}],
{upsert:true})
{ _id:1, a: 21 }
{ _id: 1, a: 11 }
{ _id: 1, a: 101 }
{ _id:1, a: 21 }

23. { _id: 1 }
{ _id: 1, a: 10 }
{ _id: 1, a: 100 }
---
{ _id: 1, a: "10" }
db.coll.update({_id:1},
[ {$set:{a:{$cond:{
if: {$eq:[{$type:"$a"},"missing"]},
then: 21, else: {$sum:["$a", 1]} }} }}],
{upsert:true})
{ _id:1, a: 21 }
{ _id: 1, a: 11 }
{ _id: 1, a: 101 }
{ _id:1, a: 21 }

24. { _id: 1 }
{ _id: 1, a: 10 }
{ _id: 1, a: 100 }
---
{ _id: 1, a: "10" }
db.coll.update({_id:1},
[ {$set:{a:{$cond:{
if: {$eq:[{$type:"$a"},"missing"]},
then: 21, else: {$sum:["$a", 1]} }} }}],
{upsert:true})
{ _id:1, a: 21 }
{ _id: 1, a: 11 }
{ _id: 1, a: 100 }
{ _id:1, a: 21 }

25. { _id: 1 }
{ _id: 1, a: 10 }
{ _id: 1, a: 100 }
---
{ _id: 1, a: "10" }
db.coll.update({_id:1},
[ {$set:{a:{$min:[ 100, {$cond:{
if: {$eq:[{$type:"$a"},"missing"]},
then: 21, else: {$sum:["$a", 1]} }}]} }}],
{upsert:true})
{ _id:1, a: 21 }
{ _id: 1, a: 11 }
{ _id: 1, a: 100 }
{ _id:1, a: 21 }

26. { _id: 1 }
{ _id: 1, a: 10 }
{ _id: 1, a: 100 }
---
{ _id: 1, a: "10" }
db.coll.update({_id:1},
[ {$set:{a:{$min:[ 100, {$cond:{
if: {$eq:[{$type:"$a"},"missing"]},
then: 21, else: {$sum:["$a", 1]} }}]} }}],
{upsert:true})
{ _id:1, a: 21 }
{ _id: 1, a: 11 }
{ _id: 1, a: 100 }
{ _id:1, a: 21 }
{ _id:1, a: 1 }

27. { _id: 1 }
{ _id: 1, a: 10 }
{ _id: 1, a: 100 }
---
{ _id: 1, a: "10" }
db.coll.update({_id:1},
[ {$set:{a:{$min:[ 100, {$cond:{
if: {$eq:[{$type:"$a"},"missing"]},
then: 21, else: {$sum:["$a", 1]} }}]},
prev_a: "$a"}}], {upsert:true})
{ _id:1, a: 21 }
{ _id: 1, a: 11 }
{ _id: 1, a: 100 }
{ _id:1, a: 21 }
{ _id:1, a: 1 }

28. { _id: 1 }
{ _id: 1, a: 10 }
{ _id: 1, a: 100 }
---
{ _id: 1, a: "10" }
db.coll.update({_id:1},
[ {$set:{a:{$min:[ 100, {$cond:{
if: {$eq:[{$type:"$a"},"missing"]},
then: 21, else: {$sum:["$a", 1]} }}]},
prev_a: "$a"}}], {upsert:true})
{ _id:1, a: 21 }
{ _id: 1, a: 11, prev_a: 10 }
{ _id: 1, a: 100, prev_a: 100 }
{ _id:1, a: 21 }
{ _id:1, a: 1, prev_a: "10" }

29. Set Defaults
{_id: 1, a: 5, b: 12}
{_id: 2, a: 15, c: "abc"}
{_id: 3, b: 99, c: "xyz"}
If a or b are missing, set to 0, if c is missing -> "unset"

30. Set Defaults
{_id: 1, a: 5, b: 12}
{_id: 2, a: 15, c: "abc"}
{_id: 3, b: 99, c: "xyz"}
If a or b are missing, set to 0, if c is missing -> "unset"
db.coll.update({}, [
{$replaceWith:{
}}
], {multi:true})

31. Set Defaults
{_id: 1, a: 5, b: 12}
{_id: 2, a: 15, c: "abc"}
{_id: 3, b: 99, c: "xyz"}
If a or b are missing, set to 0, if c is missing -> "unset"
db.coll.update({}, [
{$replaceWith:{$mergeObjects:[
]}}
], {multi:true})

32. Set Defaults
{_id: 1, a: 5, b: 12}
{_id: 2, a: 15, c: "abc"}
{_id: 3, b: 99, c: "xyz"}
If a or b are missing, set to 0, if c is missing -> "unset"
db.coll.update({}, [
{$replaceWith:{$mergeObjects:[
{ a:0, b:0, c:"unset" },
"$$ROOT"
]}}
], {multi:true})

33. Set Defaults
{_id: 1, a: 5, b: 12, c: "unset"}
{_id: 2, a: 15, b: 0, c: "abc"}
{_id: 3, a: 0, b: 99, c: "xyz"}
{_id: 1, a: 5, b: 12}
{_id: 2, a: 15, c: "abc"}
{_id: 3, b: 99, c: "xyz"}
If a or b are missing, set to 0, if c is missing -> "unset"
db.coll.update({}, [
{$replaceWith:{$mergeObjects:[
{ a:0, b:0, c:"unset" },
"$$ROOT"
]}}
], {multi:true})

34. Set array element upsert append update
{ id: 1,
d: ISODate("2019-06-04T00:00:00"),
h: [
{ hour:"11", value: 296 },
{ hour:"12", value: 300 }
]}
id: X, d:Y, hour:Z, value: VAL
db.coll.update({id:X, d:Y},
[ {$set:{h:{$cond:{
if:
then:
else:
}}}}],
{upsert:true})

35. Set array element upsert append update
{ id: 1,
d: ISODate("2019-06-04T00:00:00"),
h: [
{ hour:"11", value: 296 },
{ hour:"12", value: 300 }
]}
id: X, d:Y, hour:Z, value: VAL
db.coll.update({id:X, d:Y},
[ {$set:{h:{$cond:{
if: {$in:[Z,{$ifNull:["$h.hour",[]]}]},
then:{$map:{
input:"$h",
in: {$cond:{ if:{$ne:["$$this.hour",Z]}, then:"$$this",
else: {hour: Z, value: {$sum:[ "$$this.value", VAL]}}
}}
}},
else:{$concatArrays:[{$ifNull:["$h",[]]},[{hour:Z,value:VAL}]]}
}}}}],
{upsert:true})

36. Recap :
• Updates구문에서 집계 파이프라인을 사용 할 수 있습니다.
• 기존 문서의 모든 필드를 참조, 액세스 할 수 있습니다.

37. 새로운 $merge
스테이지

38. MongoDB 4.2 이전
$out
coll
new_coll
db.coll.aggregate( [ { pipeline }, …..
{ $out: “new_coll” } ]) ;
new_coll
○ must be unsharded
○ overwrites existing

39. MongoDB 4.2 이후
$merge
db.coll.aggregate( [
{pipeline}, ...,
{$merge: { ... }
]);
coll2
can exist
same or different 'db'
can be sharded
coll
coll2

40. $merge 구문
{
$merge: {
into: <target>
}
}

41. $merge 구문
{
$merge: {
into: <target>
}
}
{$merge: "collection2"}

42. $merge 구문
{
$merge: {
into: <target>
}
}
{$merge: {db: "db2", coll: "collection2"}

43. $merge 구문
{
$merge: {
into: <target>
}
}

44. $merge 구문
{
$merge: {
into: <target>,
on: <fields>
}
}
on: "_id"
on: [ "_id", "shardkey(s)" ]
must be unique

45. $merge 구문
{
$merge: {
into: <target>,
on: <fields>
}
}

46. 방안 ( Actions )
source target

47. 방안 ( Actions )
nothing matched:
source target

48. 방안 ( Actions )
nothing matched: usually insert
source target

49. 방안 ( Actions )
nothing matched: usually insert
document matched:
source target

50. 방안 ( Actions )
nothing matched: usually insert
document matched: overwrite? update? ???
source target

51. 방안 ( Actions )
nothing matched: usually insert
document matched: update
source target

52. 방안 ( Actions )
nothing matched: usually insert
document matched: update (merge)
source target

53. $merge 구문
{
$merge: {
into: <target>,
whenNotMatched:
whenMatched:
}
}

54. $merge 구문
{
$merge: {
into: <target>,
whenNotMatched:"insert",
whenMatched:
}
}

55. $merge 구문
{
$merge: {
into: <target>,
whenNotMatched:"insert",
whenMatched:"merge"
}
}

56. $merge 구문
{
$merge: {
into: <target>,
whenNotMatched:"insert"|"discard"|"fail",
whenMatched:"merge"
}
}

57. $merge 구문
{
$merge: {
into: <target>,
whenNotMatched:"insert"|"discard"|"fail",
whenMatched:"merge"|"replace"|"keepExisting"|"fail"|[...]
}
}

58. $merge 구문
{
$merge: {
into: <target>,
whenMatched:[...]
}
}

59. $merge 구문
{
$merge: {
into: <target>,
whenMatched:[<custom pipeline>]
}
}

60. $merge 예제
{
$merge: {
into: <target>,
whenMatched:[
{$addFields:{
}}
]
}
}

61. $merge 예제
{
$merge: {
into: <target>,
whenMatched:[
{$addFields:{
total:{$sum:["$total","$$new.total"]}
}}
]
}
}

62. $merge 예제
{
$merge: {
into: <target>,
whenMatched:[
{$set:{
total:{$sum:["$total","$$new.total"]}
}}
]
}
}

63. $merge 예제
{
$merge: {
into: <target>,
whenMatched:[
{$set:{
total:{$sum:["$total","$$new.total"]}
}}
]
}
}

64. $merge 예제
{
$merge: {
into: <target>,
whenMatched:[
{$set:{
total:{$sum:["$total","$$new.total"]}
}}
]
}
}
Incoming Target
{
_id: "37",
total: 64,
f1: "x"
}
{
_id: "37",
total: 245,
f1: "yyy"
}
Result:
{
}

65. $merge 예제
{
$merge: {
into: <target>,
whenMatched:[
{$set:{
total:{$sum:["$total","$$new.total"]}
}}
]
}
}
Incoming Target
{
_id: "37",
total: 64,
f1: "x"
}
{
_id: "37",
total: 245,
f1: "yyy"
}
Result:
{
_id: "37",
total: 309,
f1: "yyy"
}

66. $merge 예제 2
{
$merge: {
into: <target>,
whenMatched:[
{$replaceWith:{$mergeObjects:[
"$$new",
{total:{$sum:["$$new.total", "$total"]}}
]}}
]
}
}

67. $merge 예제 2
{
$merge: {
into: <target>,
whenMatched:[
{$replaceWith:{$mergeObjects:[
"$$new",
{total:{$sum:["$$new.total", "$total"]}}
]}}
]
}
}
Incoming Target
{
_id: "37",
total: 64,
f1: "x"
}
{
_id: "37",
total: 245,
f1: "yyy"
}
Result:
{
}

68. $merge 예제 2
{
$merge: {
into: <target>,
whenMatched:[
{$replaceWith:{$mergeObjects:[
"$$new",
{total:{$sum:["$$new.total", "$total"]}}
]}}
]
}
}
Incoming Target
{
_id: "37",
total: 64,
f1: "x"
}
{
_id: "37",
total: 245,
f1: "yyy"
}
Result:
{
_id: "37",
total: 309,
f1: "x"
}

69. $merge 구문
{
$merge: {
into: <target>,
whenMatched:[...]
}
}

70. $merge 구문
{
$merge: {
into: <target>,
let: { ... },
whenMatched:[ ...]
}
}

71. $merge 구문
{
$merge: {
into: <target>,
let: {new: "$$ROOT"},
whenMatched:[ ...]
}
}

72. $merge 구문
{
$merge: {
into: <target>,
whenMatched:[
{$set:{
total:{$sum:["$total","$$new.total"]}
}}
]
}
}

73. $merge 구문
{
$merge: {
into: <target>,
whenMatched:[
{$set:{
total:{$sum:["$total","$$new.total"]}
}}
]
}
}
{
$merge:{
into:<target>,
let:{itotal:"$total"},
whenMatched:[
{$set:{
total:{$sum:["$total","$$itotal"]}
}}
]
}
}

74. 활용 사례 1
APPEND from TEMP collection

75. temp
real
data
real
Using $merge to append loaded and
cleansed records loaded into db

76. aggregate 'temp' and append valid records to 'data'
db.temp.aggregate( [
{ ... } /* pipeline to massage and cleanse data in temp */,
{$merge:{
into: "data",
whenMatched: "fail"
}}
]);

77. aggregate 'temp' and append valid records to 'data'
db.temp.aggregate( [
{ ... } /* pipeline to massage and cleanse data in temp */,
{$merge:{
into: "data",
whenMatched: "fail"
}}
]);
Similar to SQL's INSERT INTO T1 SELECT * from T2

78. 활용 사례 2
Maintain Single View

79. mflix
users
users
mfriendbook
users
sv
Using $merge to populate/update
user fields from other services

80. mflix
users
users
mfriendbook
users
sv
Using $merge to populate/update
user fields from other services
sv.users
{
_id: "user253",
dob: ISODate(...),
f1: "yyy"
}

81. $merge updates fields from mflix.users collection into sv.users
collection. Our "_id" field is unique username
mflix_pipeline = [
{"$project" : {
"_id" : "$username",
"mflix" : "$$ROOT"
}},
{"$merge" : {
"into" : {
"db": "sv",
"collection" : "users"
},
"whenNotMatched" : "discard"
}}
]
(in mflix)
sv.users
{
_id: "user253",
dob: ISODate(...),
f1: "yyy"
}

82. $merge updates fields from mflix.users collection into sv.users
collection. Our "_id" field is unique username
mflix_pipeline = [
{"$project" : {
"_id" : "$username",
"mflix" : "$$ROOT"
}},
{"$merge" : {
"into" : {
"db": "sv",
"collection" : "users"
},
"whenNotMatched" : "discard"
}}
]
(in mflix) db.users.aggregate(mflix_pipeline)
sv.users
{
_id: "user253",
dob: ISODate(...),
f1: "yyy",
mflix: { ... }
}

83. $merge updates fields from mfriendbook.users collection into
sv.users collection. Our "_id" field is unique username
mfriendbook_pipeline = [
{"$project" : {
"_id" : "$username",
"mfriendbook" : "$$ROOT"
}},
{"$merge" : {
"into" : {
"db": "sv",
"collection" : "users"
},
"whenNotMatched" : "discard"
}}
]
(in mfriendbook)
sv.users
{
_id: "user253",
dob: ISODate(...),
f1: "yyy",
mflix: { ... }
}

84. $merge updates fields from mfriendbook.users collection into
sv.users collection. Our "_id" field is unique username
mfriendbook_pipeline = [
{"$project" : {
"_id" : "$username",
"mfriendbook" : "$$ROOT"
}},
{"$merge" : {
"into" : {
"db": "sv",
"collection" : "users"
},
"whenNotMatched" : "discard"
}}
]
(in mfriendbook) db.users.aggregate(mfriendbook_pipeline)
sv.users
{
_id: "user253",
dob: ISODate(...),
f1: "yyy",
mflix: { ... },
mfriendbook: { ... }
}

85. 활용 사례 3
Populate ROLLUPS into summary table

86. registrations
real
regsummary
real
Using $merge to incrementally
update periodic rollups in summary

87. $merge to create/update periodic
rollups in summary collection (for all days)
db.regsummary.createIndex({event:1, date:1}, {unique: true});

88. $merge to create/update periodic
rollups in summary collection (for all days)
db.regsummary.createIndex({event:1, date:1}, {unique: true});
db.registrations.aggregate([
{$match: {event_id: "MDBW19"}},
{$group:{
_id:{$dateToString:{date:"$date",format:"%Y-%m-%d"}},
count: {$sum:1}
}},
{$project: {_id:0,event:"MDBW19",date:"$_id",total:"$count"}},
{$merge: {
into: "regsummary",
on: ["event", "date"]
}}
])

89. $merge to create/update periodic
rollups in summary collection (for all days)
db.regsummary.createIndex({event:1, date:1}, {unique: true});
db.registrations.aggregate([
{$match: {event_id: "MDBW19"}},
{$group:{
_id:{$dateToString:{date:"$date",format:"%Y-%m-%d"}},
count: {$sum:1}
}},
{$project: {_id:0,event:"MDBW19",date:"$_id",total:"$count"}},
{$merge: {
into: "regsummary",
on: ["event", "date"]
}}
])
{ "event" : "MDBW19", "date" : "2019-05-19", "total" : 33 }
{ "event" : "MDBW19", "date" : "2019-05-20", "total" : 15 }
{ "event" : "MDBW19", "date" : "2019-05-21", "total" : 24 }

90. $merge to incrementally update periodic rollups in summary
collection (for single day)
db.registrations.aggregate([
{$match: {
event_id: "MDBW19",
date:{$gte:ISODate("2019-05-22"),$lt:ISODate("2019-05-23")}
}},
{$count: "total"},
{$addFields: {event:"MDBW19", "date":"2019-05-22"}},
{$merge: {
into: "regsummary",
on: ["event", "date"]
}}
])

91. $merge to incrementally update periodic rollups in summary
collection (for single day)
db.registrations.aggregate([
{$match: {
event_id: "MDBW19",
date:{$gte:ISODate("2019-05-22"),$lt:ISODate("2019-05-23")}
}},
{$count: "total"},
{$addFields: {event:"MDBW19", "date":"2019-05-22"}},
{$merge: {
into: "regsummary",
on: ["event", "date"]
}}
])
{ "event" : "MDBW19", "date" : "2019-05-19", "total" : 33 }
{ "event" : "MDBW19", "date" : "2019-05-20", "total" : 15 }
{ "event" : "MDBW19", "date" : "2019-05-21", "total" : 24 }
{ "event" : "MDBW19", "date" : "2019-05-22", "total" : 34 }

92. Thank You!

93. Aggregation Pipeline
Power [김준]
https://www.research.net/r/AggPipelineSeoul
