A PROBE-FED PATCH ANTENNA WITH
Figure 1 (a) Geometry of the proposed probe-fed patch antenna with a
A STEP-SHAPED GROUND PLANE FOR step-shaped ground plane for 2.4-GHz WLAN operation. (b) Side view of
2.4 GHz ACCESS POINT the proposed antenna. [Color figure can be viewed in the online issue,
which is available at www.interscience.wiley.com]
Fa-Shian Chang,1 Yung-Tao Liu,2 Saou-Wen Su,3 and
Jui-Hung Chou3
1
Department of Electronics, Cheng Shiu University, Kaohsiung
County, 83347, Taiwan which makes it very difficult to well match the antenna to imped-
2
Department of Electrical Engineering, R.O.C. Military Academy, ance bandwidth within VSWR of 2. In addition to the use of a short
Fengshan 83059, Taiwan probe pin, the matching mechanism in these studies also demon-
3
Network Access Strategic Business Unit, Lite-On Technology strates some modification to the structure of the antenna feed.
Corporation, Taipei County 23585, Taiwan; Corresponding author:
susw@ms96.url.com.tw
These designs include the use of a bevel-feed transition [1], a
cylinder-feed transition [2], a T-shaped probe feed [3], an L-
shaped probe feed [4], an edge-fed patch with an L-shaped ground
Received 26 May 2008
[5], a ridge-shaped ground [6], and so forth. In this letter, we
introduce a new design of a probe-fed patch antenna capable of
ABSTRACT: This letter demonstrates a new design of a probe-fed
broadband operation. The antenna is backed by a step-shaped
patch antenna with a modified antenna ground, and a constructed proto-
type ideal for applications in a 2.4-GHz WLAN access point is pre-
ground plane and can be fed by a long probe pin at one of the patch
sented. The antenna has a thick air substrate for broadband operation radiating edges. Simply by tuning the probe-pin length, good
and is fed by an inclined probe pin at the edge of the patch bent por-
tion. The antenna ground comprises different portions and is in the
shape of a step. With the proposed probe feed and ground configuration,
good impedance bandwidth with VSWR below 1.5 over the 2.4 GHz
WLAN band can be obtained. In addition, good broadside radiation
characteristics have also been observed. © 2008 Wiley Periodicals, Inc.
Microwave Opt Technol Lett 51: 139 –141, 2009; Published online in
Wiley InterScience (www.interscience.wiley.com). DOI 10.1002/mop.
24019
Key words: probe-fed patch antennas; WLAN antennas; access-point
antennas
1. INTRODUCTION
Many patch antennas utilizing thick air substrates have been de-
veloped and studied to achieve impedance bandwidth exceeding
10% defined by 2:1 VSWR or 5% by 1.5:1 VSWR for broadband
operation [1– 6]. Among these researches, a short probe pin of the
probe feed is mostly employed in conjunction with various match- Figure 2 Measured return loss for the design prototype of various
ing mechanism. That is because for patch antenna with such thick probe-pin lengths. [Color figure can be viewed in the online issue, which
air substrate, using a long probe pin can cause large inductance, is available at www.interscience.wiley.com]
DOI 10.1002/mop MICROWAVE AND OPTICAL TECHNOLOGY LETTERS / Vol. 51, No. 1, January 2009 139

2. For matching the input impedance of the patch antenna, the
length of the probe pin was carefully tuned. When a thick air
substrate is utilized for the radiating patch, large inductance intro-
duced by the probe pin may occur, which can be compensated for
additional capacitive reactance arising between the vertical plate
(of the ground) and the patch bent portion and between the inclined
plate and the bent portion. Thus, the probe pin of the probe feed
can be relatively long in this study, compared with the short probe
pin used in broadband patch designs reported in [1– 6]. The related
results will be elaborated more in the next section.
3. EXPERIMENTAL RESULTS AND DISCUSSION
On the basis of the antenna configuration shown in Figure 1, a few
prototypes have been constructed and experimentally studied. Fig-
ure 2 shows the measured return loss for the design prototype of
Figure 3 Measured input impedance for the design prototype of various
various probe-pin lengths (d). It is first seen that with d equal to 8
probe-pin lengths. [Color figure can be viewed in the online issue, which
is available at www.interscience.wiley.com]
mm, good impedance bandwidth defined by 1.5:1 VSWR (14 dB
return loss) can be obtained and reaches 140 MHz (2370 –2510
MHz), easily covering the 2.4 GHz band. The sum of d and L
impedance matching over frequency band with 1.5:1-VSWR band- (patch length) also corresponds to a half wavelength of the center
width of about 6% can be obtained. Several design prototypes have operating frequency at 2442 MHz targeted in this study. In addi-
been built, and a design example aimed for operation in the 2.4 tion, compared with a short probe pin, usually 2% wavelength of
GHz (2400 –2484 MHz) WLAN band has been implemented too. the center operating frequency, used for broadband patch antenna
The proposed antenna is designed for access-point applications in designs [1– 6], the probe pin of 8 mm here is relatively long and
the WLAN environment. Details of the antenna design are de- about 6.5% wavelength at 2442 MHz. Notice that when the probe-
scribed, and experiment results are discussed. pin length d changes from 5 to 9 mm, the thickness of the air
substrate slightly increases from 8 to 11 mm. In general, with an
2. ANTENNA DESIGN increase in d, the antenna operating frequency moves to lower
Figure 1(a) shows the geometry, in detail, of the proposed antenna frequencies, where the behavior is the same as that a thicker
for operation in the 2.4 GHz band. The radiating patch is in the substrate can result in a lower frequency band as reported in [5].
shape of a rectangle with the dimensions 54 mm (L) 60 mm (W) The measured input impedance, including real (resistance) and
and has a small bent portion (4 mm in length) at one of the patch imaginary (reactance) parts, for the antenna of various probe-pin
radiating edges. The antenna ground plane is bent three times into lengths (d) is shown in Figure 3. It can be seen that for operating
a step-shaped structure and consists of four portions: two horizon- frequencies of interest at about 2442 MHz, the curve of imaginary
tal plates, one vertical plate, and one inclined plate, all with the part is closest to 0 with the real-part curve approaching 50 when
same width of 80 mm. The angle between the inclined (5 mm in a near optimal value d of 8 mm is chosen.
length) and horizontal (60 mm in length) plates is 135°. In the Figure 4 gives the measured radiation patterns of the E-plane
center of the inclined plate , below a via hole is located a 50- (x-z cut) and H-plane (y-z cut) at 2442 MHz for the constructed
SMA connector of the probe feed. In this case, the probe pin prototype studied in Figure 2 with probe-pin length d 8 mm.
(length d) of the probe feed is inclined at an angle of 45° [see Fig. Measurements at other frequencies in the 2.4 GHz band were also
1(b)]. The radiating patch is edge-fed by this inclined probe feed, taken, and the results were similar radiation patterns as those
and the probe pin is coplanar with the patch bent portion. The plotted here. In the x-z cut was seen cross-polarization radiation
thickness of the air substrate is set to be 10 mm in this study, which below about 20 dB in the E-plane patterns for the frequencies
is about 0.08 times the free-space wavelength at 2442 MHz, the over the 2.4 GHz band; as for H-plane patterns in the y-z cut, the
center frequency of the 2.4-GHz WLAN band. cross-polarization radiation is below about 15 dB. The measured
Figure 4 Measured radiation patterns at 2442 MHz for the patch antenna studied in Figure 2 with the length of the probe pin equal to 8 mm. [Color figure
can be viewed in the online issue, which is available at www.interscience.wiley.com]
140 MICROWAVE AND OPTICAL TECHNOLOGY LETTERS / Vol. 51, No. 1, January 2009 DOI 10.1002/mop
