The document provides information on ignition system components, operation, and diagnostics for Chrysler vehicles. It includes descriptions of components like the ignition coil, distributor, oxygen sensor, and powertrain control module. The diagnostics section provides testing procedures for components such as the camshaft position sensor, crankshaft position sensor, and oxygen sensors. It also discusses using the DRB scan tool and onboard diagnostics to test the ignition system.
The document provides information about a vehicle speed control system, including:
- Major components of the system are a speed control servo, powertrain control module, vacuum reservoir, vehicle speed sensor, and speed control switch.
- The powertrain control module monitors the system and can store diagnostic trouble codes.
- Diagnosis procedures are provided for common problems like the vehicle speed sensor, speed control switch, and speed control servo.
- Removal and installation procedures are given for the speed control servo on different engine models.
The document provides general information about power locks on a Grand Cherokee vehicle. It describes the major components, including power lock switches, relays, motors, and the keyless entry transmitter and module. It provides diagnosis procedures to test the different systems and components. It also lists the steps to remove and install various parts like the power lock switch, motors, and to program a new keyless entry transmitter.
This document provides information about diagnosing and servicing power window systems. It describes the major components, including the power window switch, motor, and circuit breaker. Diagnosis steps are outlined to troubleshoot issues like no windows operating or a single inoperative window. Service procedures are also included for removing and installing components like the window switch, motor, and regulator.
This document provides an index and contents for the Electrical Group 8A manual, focusing on diagnosing battery, starting, and charging systems. It begins with an overview that these systems are interconnected and should be tested as a complete unit. The document then covers batteries, describing battery components, ratings, diagnosing state-of-charge using built-in indicators or testing electrolyte levels. It also covers starting and charging systems. Testing procedures range from basic to using onboard diagnostics.
The document provides information on turn signal and hazard warning systems. It describes the main components, which include a combination flasher, multi-function switch, turn signal indicator lamps, and turn signal lamps. It outlines procedures for diagnosing issues and testing components like the flasher and switch. Removal and installation instructions are provided for the multi-function switch and combination flasher.
This document provides information on wiring diagrams, including:
- How to identify circuits, connectors, terminals and wires
- Troubleshooting tips for wiring problems like intermittent connections
- Safety precautions and warnings for working on vehicle electrical systems
- Procedures for repairing or replacing connectors, terminals and wires
The goal is to organize wiring information by system and make troubleshooting easier by showing all electrical components in a circuit together.
This document provides information about a vehicle theft alarm system, including:
- General descriptions of how the system arms, disarms, and responds to unauthorized access attempts.
- Instructions for performing self-diagnosis tests to check the operation of sensors and circuits.
- Procedures for technicians to remove and install the VTA module, which involves removing various dash panel components.
- Steps for technicians to diagnose the system using the self-diagnosis mode and by checking for proper horn responses from sensors.
This document provides general information about audio systems for Jeep Grand Cherokee models. It describes components such as radios, speakers, antennas, and amplifiers. It also provides diagnostic procedures and service instructions for removing and installing these components.
The document provides information about a vehicle speed control system, including:
- Major components of the system are a speed control servo, powertrain control module, vacuum reservoir, vehicle speed sensor, and speed control switch.
- The powertrain control module monitors the system and can store diagnostic trouble codes.
- Diagnosis procedures are provided for common problems like the vehicle speed sensor, speed control switch, and speed control servo.
- Removal and installation procedures are given for the speed control servo on different engine models.
The document provides general information about power locks on a Grand Cherokee vehicle. It describes the major components, including power lock switches, relays, motors, and the keyless entry transmitter and module. It provides diagnosis procedures to test the different systems and components. It also lists the steps to remove and install various parts like the power lock switch, motors, and to program a new keyless entry transmitter.
This document provides information about diagnosing and servicing power window systems. It describes the major components, including the power window switch, motor, and circuit breaker. Diagnosis steps are outlined to troubleshoot issues like no windows operating or a single inoperative window. Service procedures are also included for removing and installing components like the window switch, motor, and regulator.
This document provides an index and contents for the Electrical Group 8A manual, focusing on diagnosing battery, starting, and charging systems. It begins with an overview that these systems are interconnected and should be tested as a complete unit. The document then covers batteries, describing battery components, ratings, diagnosing state-of-charge using built-in indicators or testing electrolyte levels. It also covers starting and charging systems. Testing procedures range from basic to using onboard diagnostics.
The document provides information on turn signal and hazard warning systems. It describes the main components, which include a combination flasher, multi-function switch, turn signal indicator lamps, and turn signal lamps. It outlines procedures for diagnosing issues and testing components like the flasher and switch. Removal and installation instructions are provided for the multi-function switch and combination flasher.
This document provides information on wiring diagrams, including:
- How to identify circuits, connectors, terminals and wires
- Troubleshooting tips for wiring problems like intermittent connections
- Safety precautions and warnings for working on vehicle electrical systems
- Procedures for repairing or replacing connectors, terminals and wires
The goal is to organize wiring information by system and make troubleshooting easier by showing all electrical components in a circuit together.
This document provides information about a vehicle theft alarm system, including:
- General descriptions of how the system arms, disarms, and responds to unauthorized access attempts.
- Instructions for performing self-diagnosis tests to check the operation of sensors and circuits.
- Procedures for technicians to remove and install the VTA module, which involves removing various dash panel components.
- Steps for technicians to diagnose the system using the self-diagnosis mode and by checking for proper horn responses from sensors.
This document provides general information about audio systems for Jeep Grand Cherokee models. It describes components such as radios, speakers, antennas, and amplifiers. It also provides diagnostic procedures and service instructions for removing and installing these components.
This document provides information about lighting systems on a vehicle, including:
- General information on lighting systems and bulb applications.
- Diagnostic procedures for headlamp, fog lamp, and multi-function switch systems.
- Details on exterior lamp systems.
- Service procedures for replacing bulbs and lenses in various interior and exterior lamps.
This document provides information on servicing batteries, starters, and generators. It discusses general information on these components and their related systems. The document then provides specific procedures for removing and installing batteries, cleaning battery terminals, and removing and installing starters. It also identifies locations of related components like the starter relay.
The document provides information about the overhead console in Jeep Grand Cherokee models. It describes the different types of overhead consoles that are used depending on whether the vehicle has a power sunroof option. It also describes the major components in the overhead console including the trip computer, compass, thermometer, reading lamps, remote garage door opener storage, and sunglasses storage. The document provides details on diagnosing issues with these components through self-diagnostic tests and flow charts.
The document provides general information on the wiper and washer systems for a Grand Cherokee vehicle. It describes the components of the windshield wiper system, liftgate wiper/washer system, wiper arms and blades, linkages and motors. It also outlines the diagnosis procedures for testing the windshield wiper system, windshield washer system, wiper/washer switches and intermittent wipe module. The diagnosis sections provide steps to test the electrical components and circuits of each system.
The document provides information on airbag systems, including:
- Warnings about the sensitive nature of airbag components and need to disconnect the battery before working on the system.
- Descriptions of major airbag system components like the airbag module, impact sensors, and airbag control module.
- Procedures for diagnosing airbag systems using a scan tool and checking for diagnostic trouble codes.
- Guidelines for handling undeployed and deployed airbag modules and cleaning up after a deployment.
- Steps for removing and installing airbag modules and impact sensors.
(1) The document provides general information about the horn system components in a Grand Cherokee, including the horn switch, horn relay, and horns.
(2) Diagnosis instructions check the fuse, horn relay connections, horn switch wiring, and horn ground before replacing components.
(3) Service procedures are provided for removing and installing the horn switch, horns, and horn relay. The horn switch is accessed through the steering wheel and airbag module. Horns are mounted under the right front fender. The horn relay is located in the relay center in the glove box.
This document provides information about power mirrors and an automatic day/night rear view mirror on Jeep Grand Cherokee models. It describes the major components of these systems and their functions. The document also provides diagnostic procedures to test the power mirror switch and motors, as well as the automatic rear view mirror. Finally, it lists the service procedures for removing and installing the power mirror switch and removing the power mirrors and automatic rear view mirror.
The document provides information about diagnosing issues with a vehicle's rear window defogger system. It describes the major components of the system, including the rear window glass grid, defogger switch, and defogger relay/timer. It then lists steps to test overall system operation and to isolate problems, such as using a voltmeter to check for breaks in the glass grid lines or testing power supply to the relay.
This document provides information about power seats in Jeep Grand Cherokee models. It describes the major components of the power seat system, including the power seat switch and three reversible motors that operate the seat adjustments. The document provides guidance on diagnosing issues with the power seat motors or switch, including continuity tests of the switch connections. It also outlines procedures for removing and installing the power seat switch and motor/adjuster assembly.
This document provides information about power window systems, including:
1) It describes the major components of power window systems, including door modules, power window motors, and power window switches.
2) It explains how the door modules house the front door power window and lock switches, and how the individual window switches control the corresponding motors.
3) It provides instructions for diagnosing issues like an inoperative window, including checking for continuity to ground and voltage supply to the door module.
This document provides information about cooling system diagnosis and service procedures for a vehicle. It includes:
- An overview of cooling system components and coolant routing
- Diagnosis charts to help identify potential causes of overheating
- Procedures for testing the water pump, draining and refilling the cooling system, and replacing components like the radiator, hoses, thermostat, and water pump.
- Cautions for working on the high-pressure cooling system and ensuring the correct rotating water pump is installed.
The document provides information about chime/buzzer warning systems on Grand Cherokee models. It describes the components of the system including the chime module, driver's door jamb switch, ignition key-in switch, headlamp switch, and driver's seat belt switch. Diagnosis and service procedures are outlined to test each component if the warning system is not functioning properly.
This document provides an overview and descriptions of the key components in a vehicle starting system, including the starter relay, starter, and starter solenoid. It describes how the starting system forms a high-amperage feed circuit to power the starter and a low-amperage control circuit. It explains how the starter relay connects these circuits to engage the starter motor when the ignition switch and transmission position allow starting. Troubleshooting and service procedures for the starter relay and starter are also covered.
The document provides instructions and information for operating and customizing the features of a transmitter. It includes sections on adjusting driving position, steering wheel and throttle trigger tension, trim position, battery safety, transmitter controls and buttons, function pages for programming, settings for dual rate steering, end point adjustment, and other settings. The document contains detailed steps, diagrams, and explanations to help users understand and configure the different transmitter options.
This document provides a summary of key information from a service manual supplement for JCB AMS machines:
- It is a supplement to other service manuals and only covers areas different from standard versions.
- Sections include general information, electrics, hydraulics, transmission, brakes, and engine.
- Diagrams and descriptions show the layout of controls and components in the cab for tracked and wheeled machines.
- Information on starting the engine, auxiliary circuits, priority switches, and other machine functions is provided.
Safety precautions from the main manuals should also be followed. The supplement provides additional technical details for servicing JCB machines with the AMS electronic control system.
This document provides information about heating and air conditioning systems. It discusses the components and operation of both manual and automatic temperature control systems. It covers the heater core, evaporator, condenser, compressor, refrigerant lines, and sensors. It provides warnings and cautions for safely servicing the A/C system. Refrigerant R-134a is used, which requires special equipment, hoses, and oil compared to R-12.
This document provides information on horn systems, including descriptions and removal/installation procedures for the horn relay, horn switch, and horns. It describes the horn relay as an electromechanical device located in the junction block that switches battery current to the horns. The center-blow horn switch is integral to the driver's airbag module cover. Dual electromagnetic diaphragm horns are mounted behind the front bumper and connected in parallel. Diagnosis and testing procedures are provided for the horn relay, horn switch and horns.
This document provides information about a vehicle speed control system, including:
1) It describes the major components of the speed control system including the powertrain control module, speed control servo, switches, stop lamp switch, vacuum reservoir, and vehicle speed sensor.
2) It explains how the system operates and the functions of the components like using vacuum to control throttle position via the servo and switches to control settings.
3) It provides information on diagnosing and testing the system including onboard diagnostic tests, electrical tests of components, and checking for issues like loose connections or faulty switches.
This document provides information about a vehicle's chime warning system, including:
- The system warns the driver if the seat belt is not fastened, temperatures are high, lights are on with the ignition off and door open, or the key is in the ignition with the door open.
- It describes the major components of the system: the driver door jamb switch, driver seat belt switch, headlamp switch, instrument cluster, and key-in ignition switch.
- Diagnosis and testing procedures are provided for each component to determine if it is functioning properly.
The document describes the overhead console systems on a vehicle model. It includes descriptions of the compass, trip computer, thermometer, garage door opener storage bin, sunglasses storage bin, and reading lamps. It provides details on the operation and functions of these components, as well as procedures for diagnosis, testing, removal, and installation of parts.
1993 Mitsubishi 3000GT Service Repair Manual.pdfujfjkskmmdm
This service manual provides information to aid technicians in properly servicing and maintaining vehicles. It is divided into groups and sections covering various vehicle systems. Diagnosis, repair, and installation procedures are included along with specifications and tightening references. Following the procedures in this manual will help ensure high performance and reliability.
This document provides information about lighting systems on a vehicle, including:
- General information on lighting systems and bulb applications.
- Diagnostic procedures for headlamp, fog lamp, and multi-function switch systems.
- Details on exterior lamp systems.
- Service procedures for replacing bulbs and lenses in various interior and exterior lamps.
This document provides information on servicing batteries, starters, and generators. It discusses general information on these components and their related systems. The document then provides specific procedures for removing and installing batteries, cleaning battery terminals, and removing and installing starters. It also identifies locations of related components like the starter relay.
The document provides information about the overhead console in Jeep Grand Cherokee models. It describes the different types of overhead consoles that are used depending on whether the vehicle has a power sunroof option. It also describes the major components in the overhead console including the trip computer, compass, thermometer, reading lamps, remote garage door opener storage, and sunglasses storage. The document provides details on diagnosing issues with these components through self-diagnostic tests and flow charts.
The document provides general information on the wiper and washer systems for a Grand Cherokee vehicle. It describes the components of the windshield wiper system, liftgate wiper/washer system, wiper arms and blades, linkages and motors. It also outlines the diagnosis procedures for testing the windshield wiper system, windshield washer system, wiper/washer switches and intermittent wipe module. The diagnosis sections provide steps to test the electrical components and circuits of each system.
The document provides information on airbag systems, including:
- Warnings about the sensitive nature of airbag components and need to disconnect the battery before working on the system.
- Descriptions of major airbag system components like the airbag module, impact sensors, and airbag control module.
- Procedures for diagnosing airbag systems using a scan tool and checking for diagnostic trouble codes.
- Guidelines for handling undeployed and deployed airbag modules and cleaning up after a deployment.
- Steps for removing and installing airbag modules and impact sensors.
(1) The document provides general information about the horn system components in a Grand Cherokee, including the horn switch, horn relay, and horns.
(2) Diagnosis instructions check the fuse, horn relay connections, horn switch wiring, and horn ground before replacing components.
(3) Service procedures are provided for removing and installing the horn switch, horns, and horn relay. The horn switch is accessed through the steering wheel and airbag module. Horns are mounted under the right front fender. The horn relay is located in the relay center in the glove box.
This document provides information about power mirrors and an automatic day/night rear view mirror on Jeep Grand Cherokee models. It describes the major components of these systems and their functions. The document also provides diagnostic procedures to test the power mirror switch and motors, as well as the automatic rear view mirror. Finally, it lists the service procedures for removing and installing the power mirror switch and removing the power mirrors and automatic rear view mirror.
The document provides information about diagnosing issues with a vehicle's rear window defogger system. It describes the major components of the system, including the rear window glass grid, defogger switch, and defogger relay/timer. It then lists steps to test overall system operation and to isolate problems, such as using a voltmeter to check for breaks in the glass grid lines or testing power supply to the relay.
This document provides information about power seats in Jeep Grand Cherokee models. It describes the major components of the power seat system, including the power seat switch and three reversible motors that operate the seat adjustments. The document provides guidance on diagnosing issues with the power seat motors or switch, including continuity tests of the switch connections. It also outlines procedures for removing and installing the power seat switch and motor/adjuster assembly.
This document provides information about power window systems, including:
1) It describes the major components of power window systems, including door modules, power window motors, and power window switches.
2) It explains how the door modules house the front door power window and lock switches, and how the individual window switches control the corresponding motors.
3) It provides instructions for diagnosing issues like an inoperative window, including checking for continuity to ground and voltage supply to the door module.
This document provides information about cooling system diagnosis and service procedures for a vehicle. It includes:
- An overview of cooling system components and coolant routing
- Diagnosis charts to help identify potential causes of overheating
- Procedures for testing the water pump, draining and refilling the cooling system, and replacing components like the radiator, hoses, thermostat, and water pump.
- Cautions for working on the high-pressure cooling system and ensuring the correct rotating water pump is installed.
The document provides information about chime/buzzer warning systems on Grand Cherokee models. It describes the components of the system including the chime module, driver's door jamb switch, ignition key-in switch, headlamp switch, and driver's seat belt switch. Diagnosis and service procedures are outlined to test each component if the warning system is not functioning properly.
This document provides an overview and descriptions of the key components in a vehicle starting system, including the starter relay, starter, and starter solenoid. It describes how the starting system forms a high-amperage feed circuit to power the starter and a low-amperage control circuit. It explains how the starter relay connects these circuits to engage the starter motor when the ignition switch and transmission position allow starting. Troubleshooting and service procedures for the starter relay and starter are also covered.
The document provides instructions and information for operating and customizing the features of a transmitter. It includes sections on adjusting driving position, steering wheel and throttle trigger tension, trim position, battery safety, transmitter controls and buttons, function pages for programming, settings for dual rate steering, end point adjustment, and other settings. The document contains detailed steps, diagrams, and explanations to help users understand and configure the different transmitter options.
This document provides a summary of key information from a service manual supplement for JCB AMS machines:
- It is a supplement to other service manuals and only covers areas different from standard versions.
- Sections include general information, electrics, hydraulics, transmission, brakes, and engine.
- Diagrams and descriptions show the layout of controls and components in the cab for tracked and wheeled machines.
- Information on starting the engine, auxiliary circuits, priority switches, and other machine functions is provided.
Safety precautions from the main manuals should also be followed. The supplement provides additional technical details for servicing JCB machines with the AMS electronic control system.
This document provides information about heating and air conditioning systems. It discusses the components and operation of both manual and automatic temperature control systems. It covers the heater core, evaporator, condenser, compressor, refrigerant lines, and sensors. It provides warnings and cautions for safely servicing the A/C system. Refrigerant R-134a is used, which requires special equipment, hoses, and oil compared to R-12.
This document provides information on horn systems, including descriptions and removal/installation procedures for the horn relay, horn switch, and horns. It describes the horn relay as an electromechanical device located in the junction block that switches battery current to the horns. The center-blow horn switch is integral to the driver's airbag module cover. Dual electromagnetic diaphragm horns are mounted behind the front bumper and connected in parallel. Diagnosis and testing procedures are provided for the horn relay, horn switch and horns.
This document provides information about a vehicle speed control system, including:
1) It describes the major components of the speed control system including the powertrain control module, speed control servo, switches, stop lamp switch, vacuum reservoir, and vehicle speed sensor.
2) It explains how the system operates and the functions of the components like using vacuum to control throttle position via the servo and switches to control settings.
3) It provides information on diagnosing and testing the system including onboard diagnostic tests, electrical tests of components, and checking for issues like loose connections or faulty switches.
This document provides information about a vehicle's chime warning system, including:
- The system warns the driver if the seat belt is not fastened, temperatures are high, lights are on with the ignition off and door open, or the key is in the ignition with the door open.
- It describes the major components of the system: the driver door jamb switch, driver seat belt switch, headlamp switch, instrument cluster, and key-in ignition switch.
- Diagnosis and testing procedures are provided for each component to determine if it is functioning properly.
The document describes the overhead console systems on a vehicle model. It includes descriptions of the compass, trip computer, thermometer, garage door opener storage bin, sunglasses storage bin, and reading lamps. It provides details on the operation and functions of these components, as well as procedures for diagnosis, testing, removal, and installation of parts.
1993 Mitsubishi 3000GT Service Repair Manual.pdfujfjkskmmdm
This service manual provides information to aid technicians in properly servicing and maintaining vehicles. It is divided into groups and sections covering various vehicle systems. Diagnosis, repair, and installation procedures are included along with specifications and tightening references. Following the procedures in this manual will help ensure high performance and reliability.
1995 Mitsubishi 3000GT Service Repair Manual.pdfujfjkskmmdm
This document is the foreword to a service manual for Mitsubishi vehicles from 1992-1996. It provides an overview of the contents and organization of the manual. The manual contains service information to aid technicians in properly maintaining and repairing vehicles. It is divided into categories and sections covering diagnosis, repair procedures, specifications, and tightening references. The manual's use will help ensure high performance and reliability of the vehicles.
1992 Mitsubishi 3000GT Service Repair Manual.pdfujfjkskmmdm
This document is the foreword to a service manual for Mitsubishi vehicles from 1992-1996. It provides an overview of the contents and organization of the manual. The manual contains service information to aid technicians in properly maintaining and repairing vehicles. It is divided into categories and sections covering diagnosis, repair procedures, specifications, and tightening references. The manual's use will help ensure high performance and reliability of the vehicles.
1996 Mitsubishi 3000GT Service Repair Manual.pdfujfjkskmmdm
This service manual provides information to aid technicians in properly servicing and maintaining vehicles. It is divided into groups and sections covering various vehicle systems. Diagnosis, repair, and installation procedures are included along with specifications and tightening references. Following the procedures in this manual will help ensure high performance and reliability.
1994 Mitsubishi 3000GT Service Repair Manual.pdfujfjkskmmdm
This service manual provides information to aid technicians in properly servicing and maintaining vehicles. It is divided into groups and sections covering various vehicle systems. Diagnosis, repair, and installation procedures are included along with specifications and tightening references. Following the procedures in this manual will help ensure high performance and reliability.
The document describes the components and operation of a vehicle's passive restraint system. It includes airbag modules in the steering wheel and instrument panel, an airbag control module, impact sensors, and a clockspring. The airbag modules contain inflators that deploy the airbags in a collision. Proper handling and repair of the system is critical due to safety risks from accidental deployment.
The document provides information on ignition systems for 2.5L 4-cylinder and 4.0L 6-cylinder engines, including:
- The ignition system is controlled by the powertrain control module (PCM) and consists of spark plugs, ignition coil, distributor with camshaft position sensor, and various sensors.
- The distributor houses the camshaft position sensor which provides fuel injection synchronization. It does not have adjustable timing.
- The crankshaft position sensor mounted on the transmission bellhousing provides engine speed and position to the PCM.
The document discusses the onboard diagnostic system of a vehicle. It describes how the system monitors components and circuits for faults, and stores diagnostic trouble codes (DTCs) when issues are detected. It outlines the various ways that technicians can retrieve and interpret DTCs to diagnose emission control problems. The system also continuously monitors for engine misfires and illuminates the malfunction indicator lamp if emissions thresholds are exceeded.
The document provides information about the emission control system for a 2.5L diesel engine, including:
1) It describes the main components of the exhaust gas recirculation (EGR) system which works to reduce oxides of nitrogen emissions, including the EGR valve, electric vacuum modulator, and EGR tube.
2) It provides a vacuum hose routing schematic and explains how the internal vacuum pump supplies vacuum for the EGR system and power brake booster.
3) It describes procedures for testing exhaust gas flow through the EGR valve and testing the electric vacuum modulator to diagnose EGR system issues.
4) It provides removal and installation instructions for the EGR tube
2002 Mitsubishi Space Star Service Repair Manual.pdff7usedjkddm
This document is a workshop manual for chassis components. It provides service and repair procedures for technicians. The manual covers various vehicle systems including the engine, fuel system, brakes, suspension, steering, and electrical components. It includes safety warnings and provides an overview of how to use the manual, vehicle identification numbers, specifications, lifting and jacking points, and a standard torque table. Technicians should thoroughly review the manual before working on any vehicle components.
2003 Mitsubishi Space Star Service Repair Manual.pdff7usedjkddm
This document is a workshop manual for chassis components. It provides repair and maintenance procedures for technicians. The manual covers various vehicle systems including the engine, fuel system, brakes, suspension, electrical components, and more. Safety warnings are provided for working on supplemental restraint systems and airbags. The manual also outlines how to identify vehicle models and locate lifting and jacking points when working underneath the vehicle.
2001 Mitsubishi Space Star Service Repair Manual.pdff7usedjkddm
This document is a workshop manual for chassis components. It provides repair and maintenance procedures for technicians. The manual covers various vehicle systems including the engine, fuel system, brakes, suspension, electrical components, and more. Safety warnings are provided for working on supplemental restraint systems and airbags. The manual also outlines how to identify vehicle models and locate lifting and jacking points when working underneath the vehicle.
2000 Mitsubishi Space Star Service Repair Manual.pdff7usedjkddm
This document is a workshop manual for chassis components. It provides repair and maintenance procedures for technicians. The manual covers topics like the engine, fuel system, brakes, suspension, electrical components, and more. Technicians are warned to only perform supplemental restraint system and airbag work at authorized dealers due to safety risks. The manual instructs technicians on how to identify vehicle models and locate lifting and jacking points. It provides general information on specifications, precautions, and torque specifications to aid technicians in repair work.
1999 Mitsubishi Space Star Service Repair Manual.pdff7usedjkddm
This document is a workshop manual for chassis components. It provides repair and maintenance procedures for technicians. The manual covers various vehicle systems including the engine, fuel system, brakes, suspension, electrical components, and more. Safety warnings are provided for working on supplemental restraint systems and airbags. The manual also outlines how to identify vehicle models and locate lifting and jacking points when servicing vehicles.
The document provides general information about emission control systems, including:
1) It describes the different emission control components and systems used on 4.0L and 5.2L engines.
2) It explains how the on-board diagnostic system checks for faults in emission components like the EGR and EVAP systems.
3) It provides an overview of the evaporative emission control system and its components like the EVAP canister.
This quick start guide provides instructions for installation, start-up, programming, operation and troubleshooting of Yaskawa's AC Drive-V1000 compact vector control drive. The guide includes information on receiving and inspecting the drive, mechanical and electrical installation, basic programming for start-up and operation, specifications, parameter listings and standards compliance. Proper use and maintenance of the drive requires reading this manual in its entirety.
This document provides information about steering systems for ZJ vehicles. It describes the major components of the power steering system including the recirculating ball steering gear, steering linkage, power steering pump, and steering column. It provides details on identifying codes for the steering gear and pump as well as diagnosing common noise complaints.
The document provides information about rear suspension and axles for a Grand Cherokee vehicle. It describes the main components of the rear suspension system, including coil springs, upper and lower suspension arms, shock absorbers, stabilizer bar, track bar, and jounce bumpers. It also explains how the standard differential allows the axle shafts to rotate at different speeds when turning corners to compensate for the longer path of the outside wheel. The Model 35 axle used in the Grand Cherokee can be equipped with an optional Trac-Lok limited slip differential.
This document provides an overview of fuel delivery systems for vehicles with 4.0L and 5.2L engines. It describes the components of the fuel pump module, which is mounted in the fuel tank and contains the electric fuel pump, fuel pressure regulator, and in-tank fuel filter. The fuel pressure regulator is no longer mounted on the fuel rail. Procedures are provided for releasing fuel system pressure before servicing, and for testing fuel system pressure.
This document appears to be an electronic service manual for the 1995 Jeep Grand Cherokee. The logo on the page links to instructions when clicked. The page requests the user click the link for further information.
The document provides information on standard service procedures for engines, including form-in-place gaskets, honing cylinder bores, measuring crankshaft and connecting rod bearing clearances using Plastigage, repairing damaged or worn threads using a Heli-Coil tap, and servicing a 4.0L engine assembly (short block). It includes diagrams and step-by-step instructions for compression testing, measuring bearing clearance, and honing cylinder bores. Tables of contents and indexes provide page references for additional information on specific engines and procedures.
The document discusses various exterior body components of a vehicle. It provides removal and installation instructions for components like the grille, headlamps, hood, hood latches and related parts. The document is organized in sections covering the grille/reinforcement, radiator support, hood, hood hinges/latches/striker and other exterior parts. Diagrams and step-by-step instructions are provided for servicing these exterior body parts.
This document contains information about brakes for a vehicle model. It includes sections on general brake information, ABS brakes, changes for the 1995 model year, brake components, fluids and cleaning products, safety precautions, and an index of topics. The key points are:
- The vehicle uses power assisted four-wheel disc brakes with ABS standard on all models.
- Changes for 1995 include different master cylinder, power brake booster, and hydraulic control unit components for the ABS system.
- Safety precautions for working on brakes include wearing protective equipment and properly disposing of any potential asbestos dust.
This document provides information about exhaust systems and intake manifolds. It discusses the basic components of exhaust systems, including exhaust manifolds, pipes, catalytic converters, heat shields, mufflers and tailpipes. It describes symptoms of exhaust system problems and provides procedures for removing and installing exhaust pipes and manifolds. Intake manifolds and catalytic converters are also discussed.
This document provides contact information for obtaining special service tools in the United States, Canada, and internationally. The same tools or their equivalent are required for certain vehicle service operations and can be obtained from local sources or through the listed contacts, which include addresses and phone/fax numbers for Miller Special Tools in Michigan and C&D Riley Enterprises in Ontario.
The document provides information about manual transmissions and transfer cases used in Jeep vehicles, including:
- An index listing transmission and transfer case models covered
- Service information for the AX15 5-speed manual transmission, including identification, gear ratios, lubrication, diagnosis and repair procedures
- Procedures for transmission removal, disassembly, component inspection and installation
This document provides information on propeller shafts. It discusses:
1) There are three types of propeller shafts used on 4WD vehicles, differing by their joint configurations and whether they include a slip yoke.
2) Universal joints are used to allow the propeller shaft to operate at different angles and are not repairable if damaged.
3) Vibration can be caused by an unbalanced propeller shaft, worn or misaligned universal joints, or other vehicle component issues like loose engine mounts. Diagnosis procedures include measuring runout and clamping sections to isolate the source.
The document provides information on servicing a clutch system. It includes:
- Descriptions of clutch components and their functions.
- Procedures for diagnosing clutch problems through road testing, inspection of components for contamination, misalignment or excessive wear.
- Guidelines for checking flywheel and clutch disc runout and how to address issues found.
- Causes of clutch housing misalignment and how it can lead to premature wear.
- Charts outlining common clutch faults, their causes and recommended corrective actions.
- Steps for removal and installation of clutch cover/disc, housing, hydraulic linkage, pedal, pilot/release bearings and flywheel service.
The
This document provides instructions and cautions for automotive service professionals. It advises that all repair procedures should follow the manufacturer's recommendations. Special tools may be required for some procedures, and safety goggles should always be worn. Cautions are included to minimize risks of injury from components like clips and springs. The manufacturer cannot test all procedures, so service professionals must ensure personal and vehicle safety. Contact information is provided to order service manuals.
This document is the 1995 Jeep Grand Cherokee service manual published by Chrysler Corporation. It provides service and repair instructions for technicians working on 1995 Jeep Grand Cherokee vehicles. The manual is divided into groups covering different vehicle systems. It notes that specific tools are required for some procedures and instructions on where to order them. The manual also reserves the right for Chrysler to make changes to vehicles or manuals without obligation.
This document provides information about wheels, tires, and their maintenance. It discusses tire identification, inflation pressures, wear patterns, and replacement. The document also covers wheel installation, balance, and replacement. Proper maintenance of wheels and tires, such as regular inflation and rotation, can improve vehicle performance and safety.
The document provides information on servicing the front suspension and axle of a Grand Cherokee vehicle. It discusses components like the track bar, stabilizer bar, upper and lower suspension arms, coil springs, shock absorbers and bushings. The summary also covers procedures for front wheel alignment, diagnosis of noise/vibration issues, specifications and torque values.
The document provides instructions for viewing and navigating service manuals on CD-ROM using the Acrobat Reader. It describes how to access manuals in Windows 98/95/NT and Windows 3.1, and explains the welcome page, tab page, viewing contents within groups, and using bookmarks to navigate. It also summarizes the basic features of the Acrobat Reader toolbar for navigating manuals.
Este documento proporciona una lista de descripciones de grupos y páginas para varios componentes y sistemas de vehículos. La lista incluye descripciones breves de varios componentes del motor, la transmisión, la suspensión, el sistema de aire acondicionado y otros sistemas.
Implementing ELDs or Electronic Logging Devices is slowly but surely becoming the norm in fleet management. Why? Well, integrating ELDs and associated connected vehicle solutions like fleet tracking devices lets businesses and their in-house fleet managers reap several benefits. Check out the post below to learn more.
Fleet management these days is next to impossible without connected vehicle solutions. Why? Well, fleet trackers and accompanying connected vehicle management solutions tend to offer quite a few hard-to-ignore benefits to fleet managers and businesses alike. Let’s check them out!
Welcome to ASP Cranes, your trusted partner for crane solutions in Raipur, Chhattisgarh! With years of experience and a commitment to excellence, we offer a comprehensive range of crane services tailored to meet your lifting and material handling needs.
At ASP Cranes, we understand the importance of reliable and efficient crane operations in various industries, from construction and manufacturing to logistics and infrastructure development. That's why we strive to deliver top-notch solutions that enhance productivity, safety, and cost-effectiveness for our clients.
Our services include:
Crane Rental: Whether you need a crawler crane for heavy lifting or a hydraulic crane for versatile operations, we have a diverse fleet of well-maintained cranes available for rent. Our rental options are flexible and can be customized to suit your project requirements.
Crane Sales: Looking to invest in a crane for your business? We offer a wide selection of new and used cranes from leading manufacturers, ensuring you find the perfect equipment to match your needs and budget.
Crane Maintenance and Repair: To ensure optimal performance and safety, regular maintenance and timely repairs are essential for cranes. Our team of skilled technicians provides comprehensive maintenance and repair services to keep your equipment running smoothly and minimize downtime.
Crane Operator Training: Proper training is crucial for safe and efficient crane operation. We offer specialized training programs conducted by certified instructors to equip operators with the skills and knowledge they need to handle cranes effectively.
Custom Solutions: We understand that every project is unique, which is why we offer custom crane solutions tailored to your specific requirements. Whether you need modifications, attachments, or specialized equipment, we can design and implement solutions that meet your needs.
At ASP Cranes, customer satisfaction is our top priority. We are dedicated to delivering reliable, cost-effective, and innovative crane solutions that exceed expectations. Contact us today to learn more about our services and how we can support your project in Raipur, Chhattisgarh, and beyond. Let ASP Cranes be your trusted partner for all your crane needs!
How To Fix The Key Not Detected Issue In Mercedes CarsIntegrity Motorcar
Experiencing a "Key Not Detected" problem in your Mercedes? Don’t take it for granted. Go through this presentation to find out the exact nature of the issue you are dealing with. Have your vehicle checked by a certified professional if necessary.
Ever been troubled by the blinking sign and didn’t know what to do?
Here’s a handy guide to dashboard symbols so that you’ll never be confused again!
Save them for later and save the trouble!
Learn why monitoring your Mercedes' Exhaust Back Pressure (EBP) sensor is crucial. Understand its role in engine performance and emission reduction. Discover five warning signs of EBP sensor failure, from loss of power to increased emissions. Take action promptly to avoid costly repairs and maintain your Mercedes' reliability and efficiency.
Your VW's camshaft position sensor is crucial for engine performance. Signs of failure include engine misfires, difficulty starting, stalling at low speeds, reduced fuel efficiency, and the check engine light. Prompt inspection and replacement can prevent further damage and keep your VW running smoothly.
Comprehensive program for Agricultural Finance, the Automotive Sector, and Empowerment . We will define the full scope and provide a detailed two-week plan for identifying strategic partners in each area within Limpopo, including target areas.:
1. Agricultural : Supporting Primary and Secondary Agriculture
• Scope: Provide support solutions to enhance agricultural productivity and sustainability.
• Target Areas: Polokwane, Tzaneen, Thohoyandou, Makhado, and Giyani.
2. Automotive Sector: Partnerships with Mechanics and Panel Beater Shops
• Scope: Develop collaborations with automotive service providers to improve service quality and business operations.
• Target Areas: Polokwane, Lephalale, Mokopane, Phalaborwa, and Bela-Bela.
3. Empowerment : Focusing on Women Empowerment
• Scope: Provide business support support and training to women-owned businesses, promoting economic inclusion.
• Target Areas: Polokwane, Thohoyandou, Musina, Burgersfort, and Louis Trichardt.
We will also prioritize Industrial Economic Zone areas and their priorities.
Sign up on https://profilesmes.online/welcome/
To be eligible:
1. You must have a registered business and operate in Limpopo
2. Generate revenue
3. Sectors : Agriculture ( primary and secondary) and Automative
Women and Youth are encouraged to apply even if you don't fall in those sectors.
What Are The Immediate Steps To Take When The VW Temperature Light Starts Fla...Import Motorworks
Learn how to respond when the red temperature light flashes in your VW with this presentation. From checking coolant levels to seeking professional help, follow these steps promptly to prevent engine damage and ensure safety on the road.
What Could Cause The Headlights On Your Porsche 911 To Stop WorkingLancer Service
Discover why your Porsche 911 headlights might flicker out unexpectedly. From aging bulbs to electrical gremlins and moisture mishaps, we're delving into the reasons behind the blackout. Stay tuned to illuminate the road ahead and ensure your lights shine bright for safer journeys.
The Octavia range embodies the design trend of the Škoda brand: a fusion of
aesthetics, safety and practicality. Whether you see the car as a whole or step
closer and explore its unique features, the Octavia range radiates with the
harmony of functionality and emotion
1. ZJ IGNITION SYSTEMS 8D - 1
IGNITION SYSTEMS
CONTENTS
page page
COMPONENT IDENTIFICATION/SYSTEM DIAGNOSTICS/SERVICE PROCEDURES . . . . . . . 6
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 IGNITION SWITCH . . . . . . . . . . . . . . . . . . . . . . . 29
COMPONENT REMOVAL/INSTALLATION . . . . . . 17 SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . 32
COMPONENT IDENTIFICATION/SYSTEM OPERATION
INDEX
page page
Automatic Shutdown (ASD) Relay . . . . . . . . . . . . . . 1 Ignition Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Camshaft Position Sensor . . . . . . . . . . . . . . . . . . . . 2 Intake Manifold Air Temperature Sensor . . . . . . . . . . 5
Crankshaft Position Sensor . . . . . . . . . . . . . . . . . . . 2 Manifold Absolute Pressure (MAP) Sensor . . . . . . . . 5
Distributors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Oxygen (O2S) Sensor . . . . . . . . . . . . . . . . . . . . . . . 5
Engine Coolant Temperature Sensor . . . . . . . . . . . . 4 Powertrain Control Module (PCM) . . . . . . . . . . . . . . 5
General Information . . . . . . . . . . . . . . . . . . . . . . . . 1 Throttle Position Sensor . . . . . . . . . . . . . . . . . . . . . 5
GENERAL INFORMATION IGNITION SYSTEMS
Throughout this group, references are made to par- The distributors used on 4.0L 6-cylinder and 5.2L
ticular vehicle models by alphabetical designation or V-8 engines are basically the same for the 1995
by the particular vehicle nameplate. A chart showing model year. Similarities and differences between the
a breakdown of alphabetical designations is included two distributors will be discussed.
in the Introduction group at the beginning of this A multi-port, fuel injected engine is used on all
manual. models. The ignition system is controlled by the pow-
This section of the group, Component Identifica- ertrain control module (PCM) on all engines. The
tion/System Operation, will discuss ignition system PCM was formerly referred to as the SBEC or engine
operation and will identify ignition system compo- controller.
nents. The ignition system consists of:
For diagnostic procedures and adjustments, refer to • Spark plugs
the Diagnostics/Service Procedures section of this • Ignition coil
group. • Secondary ignition cables
For removal and installation of ignition system • Distributor (contains rotor and camshaft position
components, refer to the Component Removal/Instal- sensor)
lation section of this group. • Powertrain control module (PCM)
For other useful information, refer to On-Board Di- • Crankshaft position sensor
agnostics in the General Diagnosis sections of Group
14, Fuel System in this manual. AUTOMATIC SHUTDOWN (ASD) RELAY
For operation of the DRB scan tool, refer to the ap- The automatic shutdown (ASD) relay is located in
propriate Powertrain Diagnostic Procedures service the power distribution center (PDC) near the battery
manual. (Fig. 1). As one of its functions, it will supply battery
An Ignition specifications section is included at the voltage to the ignition coil. The ground circuit for the
end of this group. A general Maintenance Schedule ASD relay is controlled by the powertrain control
(mileage intervals) for ignition related items can be module (PCM). The PCM regulates ASD relay opera-
found in Group 0, Lubrication and Maintenance. This tion by switching the ground circuit on-and-off.
schedule can also be found in the Owners Manual.
2. 8D - 2 IGNITION SYSTEMS ZJ
When the leading edge of the pulse ring (shutter)
enters the sync signal generator, the following occurs:
The interruption of magnetic field causes the voltage
to switch high resulting in a sync signal of approxi-
mately 5 volts.
When the trailing edge of the pulse ring (shutter)
leaves the sync signal generator, the following occurs:
The change of the magnetic field causes the sync sig-
nal voltage to switch low to 0 volts.
For component testing, refer to the Diagnostics/Ser-
vice Procedures section of this group.
For removal and installation of this component, re-
fer to the Component Removal/Installation section of
this group.
CRANKSHAFT POSITION SENSOR
4.0L 6-CYLINDER ENGINES WITH MANUAL
TRANSMISSION:
The crankshaft position sensor is mounted to the
transmission bellhousing with two bolts at the left/
Fig. 1 Power Distribution Center rear side of the engine block (Fig. 3).
CAMSHAFT POSITION SENSOR
The camshaft position sensor is located in the dis-
tributor (Fig. 2) on all engines. This sensor is similar
on both the 4.0L and 5.2L engines for the 1995 model
year.
Fig. 3 Crankshaft Position Sensor—4.0L Engine
With Manual Transmission
4.0L 6-CYLINDER ENGINES WITH AUTOMATIC
TRANSMISSION
The crankshaft position sensor is mounted to the
Fig. 2 Camshaft Position Sensor—Typical transmission bellhousing with one bolt at the left/
rear side of the engine block (Fig. 4).
The camshaft position sensor contains a hall effect
device called a sync signal generator to generate a 5.2L V-8 ENGINE
fuel sync signal. This sync signal generator (Fig. 2) On 5.2L engines, the sensor is bolted to the top of
detects a rotating pulse ring (shutter) on the distrib- cylinder block near the rear of the right cylinder
utor shaft. The pulse ring rotates 180 degrees head (Fig. 5).
through the sync signal generator. Its signal is used Engine speed and crankshaft position are provided
in conjunction with the crankshaft position sensor to through the crankshaft position sensor. The sensor
differentiate between fuel injection and spark events. generates pulses that are the input sent to the pow-
It is also used to synchronize the fuel injectors with ertrain control module (PCM). The PCM interprets
their respective cylinders. the sensor input to determine the crankshaft posi-
3. ZJ IGNITION SYSTEMS 8D - 3
SENSOR OPERATION—4.0L ENGINE
The flywheel/drive plate has groups of four notches
at its outer edge. On 4.0L engines there are three
sets of notches (Fig. 6).
The notches cause a pulse to be generated when
they pass under the sensor. The pulses are the input
to the PCM. For each engine revolution there are
there are 3 groups of four pulses generated on 4.0L
6-cylinder engines.
The trailing edge of the fourth notch, which causes
the pulse, is four degrees before top dead center
(TDC) of the corresponding piston.
The engine will not operate if the PCM does not re-
ceive a crankshaft position sensor input.
For component testing, refer to the Diagnostics/Ser-
vice Procedures section of this group.
For removal and installation of this sensor, refer to
the Component Removal/Installation section of this
group.
Fig. 4 Crankshaft Position Sensor—4.0L Engine
With Automatic Transmission
Fig. 6 Sensor Operation—4.0L Engine—Typical
SENSOR OPERATION—5.2L V-8 ENGINE
On 5.2L engines, the flywheel/drive plate has 8 sin-
gle notches, spaced every 45 degrees, at its outer
edge (Fig. 7).
Fig. 5 Crankshaft Position Sensor—5.2L Engine—
The notches cause a pulse to be generated when
Typical
they pass under the sensor. The pulses are the input
tion. The PCM then uses this position, along with to the PCM. For each engine revolution, there are 8
other inputs, to determine injector sequence and ig- pulses generated on 5.2L V-8 engines.
nition timing. The engine will not operate if the PCM does not re-
The sensor is a hall effect device combined with an ceive a crankshaft position sensor input.
internal magnet. It is also sensitive to steel within a For component testing, refer to the Diagnostics/Ser-
certain distance from it. vice Procedures section of this group.
For removal and installation of this component, re-
fer to the Component Removal/Installation section of
this group.
4. 8D - 4 IGNITION SYSTEMS ZJ
For removal and installation of this component, re-
fer to the Component Removal/Installation section of
this group.
IGNITION COIL
Battery voltage is supplied to the ignition coil pos-
itive terminal from the ASD relay.
The powertrain control module (PCM) opens and
closes the ignition coil ground circuit for ignition coil
operation.
Base ignition timing is not adjustable. By con-
trolling the coil ground circuit, the PCM is able to set
the base timing and adjust the ignition timing ad-
vance. This is done to meet changing engine operat-
ing conditions.
The ignition coil is not oil filled. The windings are
embedded in an epoxy compound. This provides heat
and vibration resistance that allows the ignition coil
to be mounted on the engine.
On 4.0L 6-cylinder engines, the ignition coil is
mounted to a bracket on the side of the engine (Fig.
8).
Fig. 7 Sensor Operation—5.2L V-8 Engine On 5.2L V-8 engines, the ignition coil is mounted to
DISTRIBUTORS a bracket at the front of the right cylinder head (Fig.
All engines are equipped with a camshaft driven 9). This bracket is also used to mount the automatic
mechanical distributor, containing a shaft driven dis- belt tensioner.
tributor rotor. All distributors are equipped with an
internal camshaft position (fuel sync) sensor (Fig. 2).
This sensor provides fuel injection synchronization
and cylinder identification.
The distributors on 4.0L or 5.2L engines do not
have built in centrifugal or vacuum assisted advance.
Base ignition timing and all timing advance is con-
trolled by the powertrain control module (PCM). Be-
cause ignition timing is controlled by the PCM, base
ignition timing is not adjustable on any of these
engines.
On the 4.0L 6-cylinder engine, the distributor is
locked in place by a notch on the distributor housing.
The distributor holddown clamp bolt passes through
this notch when installed. Because the distributor po-
sition is locked when installed, its rotational position
can not be changed. Do not attempt to modify the Fig. 8 Ignition Coil—4.0L Engine—Typical
distributor housing to get distributor rotation.
For component testing, refer to the Diagnostics/Ser-
Distributor position will have no effect on igni-
vice Procedures section of this group.
tion timing.
For removal and installation of this component, re-
On the 5.2L V-8 engine, the distributor is held to
fer to the Component Removal/Installation section of
the engine in the conventional method using a hold-
down clamp and bolt. Although the distributor on this group.
the 5.2L engine can be rotated, it will have no
effect on ignition timing. ENGINE COOLANT TEMPERATURE SENSOR
All distributors contain an internal oil seal that For an operational description, diagnosis and re-
prevents oil from entering the distributor housing. moval/installation procedures, refer to Group 14,
The seal is not serviceable. Fuel System.
For component testing, refer to the Diagnostics/Ser-
vice Procedures section of this group.
5. ZJ IGNITION SYSTEMS 8D - 5
Fig. 9 Ignition Coil—5.2L Engine—Typical
INTAKE MANIFOLD AIR TEMPERATURE SENSOR
For an operational description, diagnosis and re-
moval/installation procedures, refer to the Diagnosis
sections of Group 14, Fuel System.
Fig. 10 PCM Location—Typical
MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR
For removal and installation of this component, re-
For an operational description, diagnosis and re-
moval/installation procedures, refer to Group 14, fer to the Component Removal/Installation section of
Fuel System. this group.
For diagnostics, refer to the appropriate Powertrain
POWERTRAIN CONTROL MODULE (PCM) Diagnostic Procedures service manual for operation
The PCM (formerly called the SBEC or engine con- of the DRB scan tool.
troller) is located in the right/rear side of the engine
compartment (Fig. 10). THROTTLE POSITION SENSOR
The ignition system is controlled by the PCM. For an operational description, diagnosis and re-
Base ignition timing by rotation of distributor moval/installation procedures, refer to Group 14,
is not adjustable. The PCM opens and closes the ig- Fuel System.
nition coil ground circuit to operate the ignition coil.
This is done to adjust ignition timing, both initial OXYGEN (O2S) SENSOR
(base) and advance, for changing engine operating For an operational description, diagnosis and re-
conditions. moval/installation procedures, refer to Group 14,
The amount of electronic spark advance provided Fuel System.
by the PCM is determined by five input factors: En-
gine coolant temperature, engine rpm, intake mani-
fold air temperature, manifold absolute pressure and
throttle position.
6. 8D - 6 IGNITION SYSTEMS ZJ
DIAGNOSTICS/SERVICE PROCEDURES
INDEX
page page
Automatic Shutdown (ASD) Relay . . . . . . . . . . . . . . 6 Ignition Timing . . . . . . . . . . . . . . . . . . . . . . . ... . 12
Camshaft Position Sensor Test . . . . . . . . . . . . . . . . 6 Intake Manifold Air Temperature Sensor Test . ... . 12
Crankshaft Position Sensor Test . . . . . . . . . . . . . . . 7 Manifold Absolute Pressure (MAP) Sensor Test .. . 12
Distributor Cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 On-Board Diagnostics . . . . . . . . . . . . . . . . . . ... . 16
Distributor Rotor . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Oxygen Sensor Tests . . . . . . . . . . . . . . . . . . ... . 16
DRB Scan Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Powertrain Control Module (PCM) . . . . . . . . . ... . 12
Engine Coolant Temperature Sensor Test . . . . . . . 10 Spark Plug Secondary Cables . . . . . . . . . . . . ... . 14
General Information . . . . . . . . . . . . . . . . . . . . . . . . 6 Spark Plugs . . . . . . . . . . . . . . . . . . . . . . . . . ... . 12
Ignition Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Throttle Position Sensor Test . . . . . . . . . . . . . ... . 16
Ignition Secondary Circuit Diagnosis . . . . . . . . . . . 10
GENERAL INFORMATION
This section of the group, Diagnostics/Service Pro-
cedures, will discuss basic ignition system diagnostics
and service adjustments.
For system operation and component identification,
refer to the Component Identification/System Opera-
tion section of this group.
For removal or installation of ignition system com-
ponents, refer to the Component Removal/Installa-
tion section of this group.
For other useful information, refer to On-Board Di-
agnostics in the General Diagnosis sections of Group
14, Fuel System in this manual.
For operation of the DRB Scan Tool, refer to the
appropriate Powertrain Diagnostic Procedures ser-
vice manual.
Fig. 1 Camshaft Position Sensor—Typical
AUTOMATIC SHUTDOWN (ASD) RELAY
To perform a complete test of the ASD relay and its (1) Connect the positive (+) voltmeter lead into the
circuitry, refer to the DRB scan tool and appropriate sensor output wire. This is at done the distributor
Powertrain Diagnostics Procedures manual. To test wire harness connector. For wire identification, refer
the sensor only, refer to Relays—Operation/Testing in to Group 8W, Wiring Diagrams.
the Group 14, Fuel System section of this service (2) Connect the negative (-) voltmeter lead into the
manual. ground wire. For wire identification, refer to Group
8W, Wiring Diagrams.
CAMSHAFT POSITION SENSOR TEST (3) Set the voltmeter to the 15 Volt DC scale.
The camshaft position sensor is located in the dis- 4.0L Engines: Remove distributor cap. Rotate
tributor on all engines (Fig. 1). (crank) engine with starter until rotor is pointed in
To perform a complete test of this sensor and its the 10 o’clock position. The movable pulse ring (Fig.
circuitry, refer to the DRB scan tool. Also refer to the 1) will now be within the magnetic pickup on the
appropriate Powertrain Diagnostics Procedures man- camshaft position sensor.
ual. To test the sensor only, refer to the following: 5.2L Engines: Remove coil high-tension cable and
all spark plug cables at distributor cap. Note and
4.0L OR 5.2L ENGINE mark position of cables before removal (Fig. 2). Re-
For this test, an analog voltmeter is needed. move distributor cap from distributor (two screws).
Do not remove the distributor connector from the dis- Rotate (crank) the engine until the rotor is pointed
tributor. Using small paper clips, insert them into towards the rear of vehicle. The movable pulse ring
the backside of the distributor wire harness connec- (Fig. 1) will now be within the magnetic pickup on
tor to make contact with the terminals. Be sure that the camshaft position sensor.
the connector is not damaged when inserting the pa- (4) Turn ignition key to ON position. Voltmeter
per clips. Attach voltmeter leads to these paper clips. should read approximately 5.0 volts.
7. ZJ IGNITION SYSTEMS 8D - 7
CRANKSHAFT POSITION SENSOR TEST
To perform a complete test of this sensor and its
circuitry, refer to the DRB scan tool. Also refer to the
appropriate Powertrain Diagnostics Procedures man-
ual. To test the sensor only, refer to the following:
On the 4.0L engine, the sensor is located on the
transmission bellhousing at the left/rear side of the
engine block (Figs. 3 or 4).
Fig. 2 Engine Firing Order—5.2L Engine
(5) If voltage is not present, check the voltmeter
leads for a good connection.
(6) If voltage is still not present, check for voltage
at the supply wire. For wire identification, refer to
Group 8W, Wiring Diagrams.
(7) If voltage is not present at supply wire, check
for voltage at pin-7 of powertrain control module
(PCM) 60-way connector. Leave the PCM connector
connected for this test.
Fig. 3 Crankshaft Position Sensor—4.0L Engine
With Manual Transmission
(8) If voltage is still not present, perform vehicle
test using the DRB scan tool.
(9) If voltage is present at pin-7, but not at the
supply wire:
(a) Check continuity between the supply wire.
This is checked between the distributor connector
and pin-7 at the PCM. If continuity is not present,
repair the harness as necessary.
(b) Check for continuity between the camshaft
position sensor output wire and pin-44 at the PCM.
If continuity is not present, repair the harness as
necessary.
(c) Check for continuity between the ground cir-
cuit wire at the distributor connector and ground.
If continuity is not present, repair the harness as
necessary.
(10) While observing the voltmeter, crank the en-
gine with ignition switch. The voltmeter needle
should fluctuate between 0 and 5 volts while the en-
gine is cranking. This verifies that the camshaft po-
sition sensor is operating properly and a sync pulse
signal is being generated.
If a sync pulse signal is not present, replacement of Fig. 4 Crankshaft Position Sensor—4.0L Engine
the camshaft position sensor is necessary. With Automatic Transmission
For removal or installation of ignition system com-
ponents, refer to the Component Removal/Installa-
tion section of this group.
For system operation and component identification,
refer to the Component Identification/System Opera-
tion section of this group.
8. 8D - 8 IGNITION SYSTEMS ZJ
On the 5.2L engine, the sensor is located on the top DISTRIBUTOR CAP
of cylinder block near the rear of right cylinder head
(Fig. 5). INSPECTION
(1) Near the rear of intake manifold, disconnect Remove the distributor cap and wipe it clean with
sensor pigtail harness connector from main wiring a dry lint free cloth. Visually inspect the cap for
harness. cracks, carbon paths, broken towers, or damaged ro-
tor button (Figs. 7 and 8). Also check for white depos-
its on the inside (caused by condensation entering
the cap through cracks). Replace any cap that dis-
plays charred or eroded terminals. The inside flat
surface of a terminal end (faces toward rotor) will in-
dicate some evidence of erosion from normal opera-
tion. Examine the terminal ends for evidence of
mechanical interference with the rotor tip.
Fig. 5 Crankshaft Position Sensor—5.2L Engine—
Typical
(2) Place an ohmmeter across terminals B and C Fig. 7 Cap Inspection—External—Typical
(Fig. 6). Ohmmeter should be set to 1K-to-10K scale
for this test. The meter reading should be open (no
resistance). Replace sensor if a low resistance is indi-
cated.
Fig. 8 Cap Inspection—Internal—Typical
If replacement of the distributor cap is necessary,
transfer spark plug cables from the original cap to
Fig. 6 Crankshaft Position Sensor Connector the new cap. This should be done one cable at a time.
Each cable is installed onto the tower of the new cap
that corresponds to its tower position on the original
cap. Fully seat the cables onto the towers. If neces-
sary, refer to the Engine Firing Order diagrams
(Figs. 9 or 10).
9. ZJ IGNITION SYSTEMS 8D - 9
Fig. 9 Engine Firing Order—4.0L 6-Cylinder Engine
Fig. 11 Rotor Inspection—Typical
the appropriate Powertrain Diagnostics Procedures
manual. To test the coil only, refer to the following:
The ignition coil (Figs. 12 or 13) is designed to op-
erate without an external ballast resistor.
Fig. 10 Engine Firing Order—5.2L V-8 Engine
DISTRIBUTOR ROTOR
Visually inspect the rotor (Fig. 11) for cracks, evi-
dence of corrosion, or the effects of arcing on the
metal tip. Also check for evidence of mechanical in-
terference with the cap. Some charring is normal on
the end of the metal tip. The silicone-dielectric-var-
nish-compound applied to the rotor tip for radio in-
terference noise suppression, will appear charred.
This is normal. Do not remove the charred com-
pound. Test the spring for insufficient tension. Re- Fig. 12 Ignition Coil—4.0L Engine—Typical
place a rotor that displays any of these adverse Inspect the ignition coil for arcing. Test the coil ac-
conditions. cording to coil tester manufacturer’s instructions.
Test the coil primary and secondary resistance. Re-
DRB SCAN TOOL place any coil that does not meet specifications. Refer
For operation of the DRB scan tool, refer to the ap- to the Ignition Coil Resistance chart.
propriate Powertrain Diagnostic Procedures service If the ignition coil is being replaced, the secondary
manual. spark plug cable must also be checked. Replace cable
if it has been burned or damaged.
IGNITION COIL Arcing at the tower will carbonize the cable nipple,
To perform a complete test of the ignition coil and which if it is connected to a new ignition coil, will
its circuitry, refer to the DRB scan tool. Also refer to cause the coil to fail.
10. 8D - 10 IGNITION SYSTEMS ZJ
Fig. 13 Ignition Coil—5.2L Engine Fig. 14 Cable Removal
If the secondary coil cable shows any signs of dam-
age, it should be replaced with a new cable and new
terminal. Carbon tracking on the old cable can cause
arcing and the failure of a new ignition coil.
ENGINE COOLANT TEMPERATURE SENSOR TEST
For an operational description, diagnosis and re-
moval/installation procedures, refer to Group 14,
Fuel System.
IGNITION SECONDARY CIRCUIT DIAGNOSIS
CHECKING FOR SPARK
CAUTION: When disconnecting a high voltage cable
from a spark plug or from the distributor cap, twist
Fig. 15 Checking for Spark—Typical
the rubber boot slightly (1/2 turn) to break it loose
(Fig. 14). Grasp the boot (not the cable) and pull it THE PULLEYS, BELTS OR THE FAN. DO NOT WEAR
off with a steady, even force. LOOSE FITTING CLOTHING.
(1) Disconnect the ignition coil secondary cable (2) Rotate (crank) the engine with the starter mo-
from center tower of the distributor cap. Hold the ca- tor and observe the cable terminal for a steady arc. If
ble terminal approximately 12 mm (1/2 in.) from a steady arcing does not occur, inspect the secondary
good engine ground (Fig. 15). coil cable. Refer to Spark Plug Cables in this group.
Also inspect the distributor cap and rotor for cracks
WARNING: BE VERY CAREFUL WHEN THE ENGINE
IS CRANKING. DO NOT PUT YOUR HANDS NEAR
IGNITION COIL RESISTANCE
11. ZJ IGNITION SYSTEMS 8D - 11
or burn marks. Repair as necessary. If steady arcing
occurs, connect ignition coil cable to the distributor
cap.
(3) Remove a cable from one spark plug.
(4) Using insulated pliers, hold the cable terminal
approximately 12 mm (1/2 in.) from the engine cylin-
der head or block while rotating the engine with the
starter motor. Observe the spark plug cable terminal
for an arc. If steady arcing occurs, it can be expected
that the ignition secondary system is operating cor-
rectly. (note that if the ignition coil cable is re-
moved for this test, instead of a spark plug
cable, the spark intensity will be much higher.)
If steady arcing occurs at the spark plug cables, but
the engine will not start, connect the DRB scan tool.
Refer to the Powertrain Diagnostic Procedures ser-
vice manual. Fig. 17 Coil Harness Connector—5.2L Engine—
Typical
FAILURE TO START TEST
To prevent unnecessary diagnostic time and wrong • If the voltage remains near zero during the entire
test results, the previous Checking For Spark test period of cranking, refer to On-Board Diagnostics in
should be performed prior to this test. Group 14, Fuel Systems. Check the powertrain con-
trol module and auto shutdown relay.
WARNING: SET PARKING BRAKE OR BLOCK THE • If voltage is at or near battery voltage and drops
DRIVE WHEELS BEFORE PROCEEDING WITH THIS to zero after 1-2 seconds of cranking, check the cam-
TEST. shaft position sensor-to-powertrain control module
circuit. Refer to On-Board Diagnostics in group 14,
(1) Unplug the ignition coil harness connector at Fuel Systems.
the coil (Figs. 16 or 17). • If voltage remains at or near battery voltage dur-
ing the entire 5 seconds, turn the key off. Remove
the 60-way connector (Fig. 18) from the powertrain
control module (PCM). Check 60-way connector for
any spread terminals.
Fig. 18 PCM 60-Way Connector
(5) Remove test lead from the coil positive termi-
Fig. 16 Coil Harness Connector—4.0L Engine— nal. Connect an 18 gauge jumper wire between the
Typical battery positive terminal and coil positive terminal.
(2) Connect a set of small jumper wires (18 gauge (6) Make the special jumper shown in figure 19.
or smaller) between the disconnected harness termi- Using the jumper, momentarily ground terminal-19
nals and the ignition coil terminals. To determine po- of the 60-way connector. A spark should be generated
larity at connector and coil, refer to the Wiring at the coil cable when the ground is removed.
Diagrams section. (7) If spark is generated, replace the powertrain
(3) Determine that sufficient battery voltage (12.4 control module (PCM).
volts) is present for the starting and ignition sys- (8) If spark is not seen, use the special jumper to
tems. ground the coil negative terminal directly.
(4) Crank the engine for 5 seconds while monitor- (9) If spark is produced, repair wiring harness for
ing the voltage at the coil positive terminal: an open condition.
12. 8D - 12 IGNITION SYSTEMS ZJ
Fig. 19 Special Jumper Ground-to-Coil Negative
Terminal
(10) If spark is not produced, replace the ignition
coil.
IGNITION TIMING
Base (initial) ignition timing is NOT adjust-
able on any of the 4.0L 6-cylinder or 5.2L V-8 en-
gines. Do not attempt to adjust ignition timing
by rotating the distributor.
All ignition timing functions are controlled by the
powertrain control module (PCM). Refer to On-Board Fig. 20 PCM Location—Typical
Diagnostics in the Multi-Port Fuel Injection—Gen-
eral Diagnosis section of Group 14, Fuel Systems for are pressed into the cylinder head to surround each
more information. Also refer to the appropriate Pow- spark plug cable boot and spark plug (Fig. 21). These
ertrain Diagnostics Procedures service manual for op- shields protect the spark plug boots from damage
eration of the DRB Scan Tool. (due to intense engine heat generated by the exhaust
manifolds) and should not be removed. After the
INTAKE MANIFOLD AIR TEMPERATURE SENSOR spark plug cable has been installed, the lip of the ca-
TEST ble boot should have a small air gap to the top of the
For an operational description, diagnosis and re- heat shield (Fig. 21).
moval/installation procedures, refer to the Diagnosis
sections of Group 14, Fuel System.
MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR
TEST
For an operational description, diagnosis and re-
moval/installation procedures, refer to Group 14,
Fuel System.
POWERTRAIN CONTROL MODULE (PCM)
The PCM (formerly called the SBEC or engine con-
troller) is located in the right/rear side of the engine
compartment (Fig. 20).
The ignition system is controlled by the PCM.
For diagnostics, refer to the appropriate Powertrain
Diagnostic Procedures service manual for operation
of the DRB scan tool. Fig. 21 Heat Shields—5.2L V-8 Engine
For removal and installation of this component, re-
Faulty carbon and/or gas fouled plugs generally
fer to the Component Removal/Installation section of
cause hard starting, but they will clean up at higher
this group.
engine speeds. Faulty plugs can be identified in a
SPARK PLUGS number of ways: poor fuel economy, power loss, de-
For spark plug removal, cleaning, gap adjustment crease in engine speed, hard starting and, in general,
and installation, refer to the Component Removal/In- poor engine performance.
stallation section of this group. Remove the spark plugs and examine them for
5.2L V-8 Engine Only: Spark plug heat shields burned electrodes and fouled, cracked or broken por-
13. ZJ IGNITION SYSTEMS 8D - 13
celain insulators. Keep plugs arranged in the order of the entire set of spark plugs may be caused by a
in which they were removed from the engine. An iso- clogged air cleaner element or repeated short operat-
lated plug displaying an abnormal condition indicates ing times (short trips).
that a problem exists in the corresponding cylinder.
Replace spark plugs at the intervals recommended in WET FOULING OR GAS FOULING
the maintenance chart in Group 0, Lubrication and A spark plug coated with excessive wet fuel or oil is
Maintenance. wet fouled. In older engines, worn piston rings, leak-
Spark plugs that have low mileage may be cleaned ing valve guide seals or excessive cylinder wear can
and reused if not otherwise defective. Refer to the cause wet fouling. In new or recently overhauled en-
following Spark Plug Condition section of this group. gines, wet fouling may occur before break-in (normal
oil control) is achieved. This condition can usually be
CONDITION resolved by cleaning and reinstalling the fouled
plugs.
NORMAL OPERATING
OIL OR ASH ENCRUSTED
The few deposits present on the spark plug will
probably be light tan or slightly gray in color. This is If one or more spark plugs are oil or oil ash en-
evident with most grades of commercial gasoline crusted (Fig. 23), evaluate engine condition for the
cause of oil entry into that particular combustion
(Fig. 22). There will not be evidence of electrode
chamber.
burning. Gap growth will not average more than ap-
proximately 0.025 mm (.001 in) per 1600 km (1000
miles) of operation. Spark plugs that have normal
wear can usually be cleaned, have the electrodes
filed, have the gap set and then be installed.
Fig. 22 Normal Operation and Cold (Carbon) Fouling
Some fuel refiners in several areas of the United Fig. 23 Oil or Ash Encrusted
States have introduced a manganese additive (MMT) ELECTRODE GAP BRIDGING
for unleaded fuel. During combustion, fuel with MMT Electrode gap bridging may be traced to loose de-
causes the entire tip of the spark plug to be coated posits in the combustion chamber. These deposits ac-
with a rust colored deposit. This rust color can be cumulate on the spark plugs during continuous stop-
misdiagnosed as being caused by coolant in the com- and-go driving. When the engine is suddenly
bustion chamber. Spark plug performance is not af- subjected to a high torque load, deposits partially liq-
fected by MMT deposits. uefy and bridge the gap between electrodes (Fig. 24).
This short circuits the electrodes. Spark plugs with
COLD FOULING/CARBON FOULING electrode gap bridging can be cleaned using standard
Cold fouling is sometimes referred to as carbon procedures.
fouling. The deposits that cause cold fouling are ba-
sically carbon (Fig. 22). A dry, black deposit on one or SCAVENGER DEPOSITS
two plugs in a set may be caused by sticking valves Fuel scavenger deposits may be either white or yel-
or defective spark plug cables. Cold (carbon) fouling low (Fig. 25). They may appear to be harmful, but
this is a normal condition caused by chemical addi-
14. 8D - 14 IGNITION SYSTEMS ZJ
Fig. 24 Electrode Gap Bridging Fig. 26 Chipped Electrode Insulator
tives in certain fuels. These additives are designed to has the correct heat range rating for the engine. De-
change the chemical nature of deposits and decrease termine if ignition timing is over advanced, or if
spark plug misfire tendencies. Notice that accumula- other operating conditions are causing engine over-
tion on the ground electrode and shell area may be heating. (The heat range rating refers to the operat-
heavy, but the deposits are easily removed. Spark ing temperature of a particular type spark plug.
plugs with scavenger deposits can be considered nor- Spark plugs are designed to operate within specific
mal in condition and can be cleaned using standard temperature ranges. This depends upon the thick-
procedures. ness and length of the center electrodes porcelain in-
sulator.)
Fig. 25 Scavenger Deposits
Fig. 27 Preignition Damage
CHIPPED ELECTRODE INSULATOR
A chipped electrode insulator usually results from SPARK PLUG OVERHEATING
bending the center electrode while adjusting the Overheating is indicated by a white or gray center
spark plug electrode gap. Under certain conditions, electrode insulator that also appears blistered (Fig.
severe detonation can also separate the insulator 28). The increase in electrode gap will be consider-
from the center electrode (Fig. 26). Spark plugs with ably in excess of 0.001 inch per 1000 miles of opera-
this condition must be replaced. tion. This suggests that a plug with a cooler heat
range rating should be used. Over advanced ignition
PREIGNITION DAMAGE timing, detonation and cooling system malfunctions
Preignition damage is usually caused by excessive can also cause spark plug overheating.
combustion chamber temperature. The center elec-
trode dissolves first and the ground electrode dis- SPARK PLUG SECONDARY CABLES
solves somewhat latter (Fig. 27). Insulators appear 5.2L V-8 Engine Only: Spark plug heat shields
relatively deposit free. Determine if the spark plug are pressed into the cylinder head to surround each
15. ZJ IGNITION SYSTEMS 8D - 15
around the spark plug insulator. Loose cable connec-
tions can cause corrosion and increase resistance, re-
sulting in shorter cable service life.
Clean the high tension cables with a cloth moist-
ened with a nonflammable solvent and wipe dry.
Check for brittle or cracked insulation.
When testing secondary cables for damage with an
oscilloscope, follow the instructions of the equipment
manufacturer.
If an oscilloscope is not available, spark plug cables
may be tested as follows:
CAUTION: Do not leave any one spark plug cable
disconnected for longer than necessary during test-
ing. This may cause possible heat damage to the
catalytic converter. Total test time must not exceed
Fig. 28 Spark Plug Overheating ten minutes.
spark plug cable boot and spark plug (Fig. 29). These
shields protect the spark plug boots from damage With the engine not running, connect one end of a
(due to intense engine heat generated by the exhaust test probe to a good ground. Start the engine and run
manifolds) and should not be removed. After the the other end of the test probe along the entire
spark plug cable has been installed, the lip of the ca- length of all spark plug cables. If cables are cracked
ble boot should have a small air gap to the top of the or punctured, there will be a noticeable spark jump
from the damaged area to the test probe. The cable
heat shield (Fig. 29).
running from the ignition coil to the distributor cap
can be checked in the same manner. Cracked, dam-
aged or faulty cables should be replaced with resis-
tance type cable. This can be identified by the words
ELECTRONIC SUPPRESSION printed on the cable
jacket.
Use an ohmmeter to test for open circuits, exces-
sive resistance or loose terminals. Remove the dis-
tributor cap from the distributor. Do not remove
cables from cap. Remove cable from spark plug.
Connect ohmmeter to spark plug terminal end of ca-
ble and to corresponding electrode in distributor cap.
Resistance should be 250 to 1000 Ohms per inch of
cable. If not, remove cable from distributor cap tower
and connect ohmmeter to the terminal ends of cable.
If resistance is not within specifications as found in
the Spark Plug Cable Resistance chart, replace the
Fig. 29 Heat Shields—5.2L V-8 Engine cable. Test all spark plug cables in this manner.
TESTING SPARK PLUG CABLE RESISTANCE
Spark plug cables are sometimes referred to as sec-
ondary ignition cables or secondary wires. The cables
transfer electrical current from the distributor to in-
dividual spark plugs at each cylinder. The spark plug
cables are of nonmetallic construction and have a
built in resistance. The cables provide suppression of
radio frequency emissions from the ignition system.
Check the high-tension cable connections for good To test ignition coil-to-distributor cap cable, do not
contact at the ignition coil, distributor cap towers remove the cable from the cap. Connect ohmmeter to
and spark plugs. Terminals should be fully seated. rotor button (center contact) of distributor cap and
The terminals and spark plug covers should be in terminal at ignition coil end of cable. If resistance is
good condition. Terminals should fit tightly to the ig- not within specifications as found in the Spark Plug
nition coil, distributor cap and spark plugs. The Cable Resistance chart, remove the cable from the
spark plug cover (boot) of the cable should fit tight distributor cap. Connect the ohmmeter to the termi-
16. 8D - 16 IGNITION SYSTEMS ZJ
nal ends of the cable. If resistance is not within spec- be found in the General Diagnosis sections of
ifications as found in the Spark Plug Cable Group 14, Fuel System. For numeric flash lamp
Resistance chart, replace the cable. Inspect the igni- code charts, refer to Diagnostic Trouble Code
tion coil tower for cracks, burns or corrosion. (DTC). This can also be found in the General
For removal and installation of spark plug cables, Diagnosis sections of Group 14, Fuel System.
refer to Spark Plug Secondary Cables in the Compo-
nent Removal/Installation section.
THROTTLE POSITION SENSOR TEST
For an operational description, diagnosis and re-
moval/installation procedures, refer to Group 14,
Fuel System.
OXYGEN SENSOR TESTS
For an operational description, diagnostics and re-
moval/installation procedures, refer to Group 14,
Fuel Systems, in this manual.
ON-BOARD DIAGNOSTICS
FOR CERTAIN IGNITION SYSTEM
COMPONENTS
The powertrain control module (PCM) performs an
On-Board Diagnostic (OBD) check for certain ignition
system components on all vehicles. This is done by
setting a diagnostic trouble code (DTC).
A DTC can be obtained in two different ways. One
of the ways is by connecting the DRB scan tool to the
data link connector. This connector is located in the Fig. 30 Data Link Connector—Typical
engine compartment (Fig. 30). Refer to the appropri-
ate Powertrain Diagnostic Procedures service manual
for operation of the DRB scan tool. The other way is
to cycle the ignition key and observe the malfunction
indicator lamp (MIL). The MIL lamp is displayed on
the instrument panel as the CHECK ENGINE lamp
(Fig. 31). This lamp will flash a numeric code. If a
numeric code number 11 (for the crankshaft position
sensor) or 42 (for the ASD relay) is observed, a prob-
lem has been found in the ignition system.
Note that the CHECK ENGINE lamp will illumi-
nate initially for approximately two seconds each
time the ignition key is turned to the ON position.
This is done for a bulb test.
For a complete operational description of all
DTC’s, for accessing a DTC and for erasing a
DTC, refer to On-Board Diagnostics. This can Fig. 31 Check Engine Lamp Location
17. ZJ IGNITION SYSTEMS 8D - 17
COMPONENT REMOVAL/INSTALLATION
INDEX
page page
Automatic Shutdown (ASD Relay . . .. . . . . . . . . . . 17 Intake Manifold Air Temperature Sensor . . . . . . . . . 25
Camshaft Position Sensor . . . . . . . .. . . . . . . . . . . 17 Manifold Absolute Pressure (MAP) Sensor . . . . . . . 25
Crankshaft Position Sensor . . . . . . .. . . . . . . . . . . 18 Oxygen (O2S) Sensor . . . . . . . . . . . . . . . . . . . . . . 26
Distributors . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . 20 Powertrain Control Module (PCM) . . . . . . . . . . . . . 26
Engine Coolant Temperature Sensor . . . . . . . . . . . 20 Spark Plug Secondary Cables . . . . . . . . . . . . . . . . 28
General Information . . . . . . . . . . . .. . . . . . . . . . . 17 Spark Plugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Ignition Coil . . . . . . . . . . . . . . . . . .. . . . . . . . . . . 25 Throttle Position Sensor (TPS) . . . . . . . . . . . . . . . 28
GENERAL INFORMATION INSTALLATION
This section of the group, Component Removal/In- (1) Inspect the relay terminals in the PDC and re-
stallation, will discuss the removal and installation pair as necessary.
of ignition system components. (2) Push the relay into the connector.
For basic ignition system diagnostics and service (3) Install the relay cover.
adjustments, refer to the Diagnostics/Service Proce- (4) Connect battery cable at battery.
dures section of this group.
For system operation and component identification, CAMSHAFT POSITION SENSOR
refer to the Component Identification/System Opera- The camshaft position sensor is located in the dis-
tion section of this group. tributor (Fig. 2).
AUTOMATIC SHUTDOWN (ASD) RELAY
The ASD relay is installed in the power distribu-
tion center (PDC) (Fig. 1). Relay location is printed
on the PDC cover.
Fig. 2 Camshaft Position Sensor—Typical
REMOVAL—4.0L 6-CYLINDER ENGINE
Distributor removal is not necessary to remove
camshaft position sensor.
(1) Disconnect negative battery cable at battery.
(2) Remove distributor cap from distributor (two
screws).
(3) Disconnect camshaft position sensor wiring
harness from main engine wiring harness.
(4) Remove distributor rotor from distributor shaft.
(5) Lift the camshaft position sensor assembly
Fig. 1 Power Distribution Center
from the distributor housing (Fig. 2).
REMOVAL
(1) Disconnect negative battery cable at battery. INSTALLATION
(2) Remove the PDC cover. (1) Install camshaft position sensor to distributor.
(3) Remove the relay by lifting straight up. Align sensor into notch on distributor housing.
18. 8D - 18 IGNITION SYSTEMS ZJ
(2) Connect wiring harness.
(3) Install rotor.
(4) Install distributor cap. Tighten mounting
screws.
(5) Connect negative battery cable at battery.
REMOVAL—5.2L V-8 ENGINE
Distributor removal is not necessary to remove
camshaft position sensor.
(1) Disconnect negative battery cable at battery.
(2) Remove coil high-tension cable and all spark
plug cables at distributor cap. Note and mark posi-
tion of cables (Fig. 3) before removal.
Fig. 4 Crankshaft Position Sensor—4.0L Engine
With Manual Transmission
(1) Near the rear of the intake manifold, discon-
nect the pigtail harness on the sensor from the main
electrical harness.
(2) Raise and support the vehicle.
(3) Remove the two sensor mounting bolts (Fig. 4).
(4) Remove the sensor.
(5) Remove clip from sensor wire harness.
INSTALLATION
(1) Install the sensor flush against the opening in
Fig. 3 Engine Firing Order—5.2L V-8 Engine the transmission housing.
(2) Install and tighten the two sensor mounting
(3) Remove distributor cap from distributor (two bolts to 19 N⅐m (14 ft. lbs.) torque.
screws).
(4) Disconnect camshaft position sensor wiring CAUTION: The two bolts used to secure the sensor
harness from main engine wiring harness. to the transmission are specially machined to cor-
(5) Remove distributor rotor from distributor shaft. rectly space the unit to the flywheel. Do not attempt
(6) Lift the camshaft position sensor assembly to install any other bolts.
from the distributor housing (Fig. 2).
(3) Lower the vehicle.
INSTALLATION (4) Connect the electrical connector to the sensor.
(1) Install camshaft position sensor to distributor. (5) Install clip on sensor wire harness.
Align sensor into notch on distributor housing.
(2) Connect wiring harness. REMOVAL—4.0L ENGINE WITH AUTOMATIC
(3) Install rotor. TRANSMISSION
(4) Install distributor cap. Tighten mounting The crankshaft position sensor is mounted to the
screws. transmission bellhousing with a single bolt. It is lo-
(5) Install spark plug cables in correct firing order cated at the left/rear side of the engine block (Fig. 5).
(Fig. 3) to distributor cap. Be sure all spark plug ca-
The slotted adjustment hole is not used for the 1995
bles are firmly connected into distributor cap towers.
model year.
(6) Connect negative battery cable at battery.
(1) Near the rear of the intake manifold, discon-
CRANKSHAFT POSITION SENSOR nect the pigtail harness (on the sensor) from the
main electrical harness.
REMOVAL—4.0L 6-CYLINDER ENGINE WITH (2) Remove the nut holding sensor wire clip to fuel
MANUAL TRANSMISSION rail mounting stud.
The crankshaft position sensor is mounted to the (3) Remove the one sensor mounting bolt.
transmission bellhousing with two bolts at the left/ (4) Remove the sensor.
rear side of the engine block (Fig. 4). (5) Remove clip from sensor wire harness.
19. ZJ IGNITION SYSTEMS 8D - 19
Fig. 6 Crankshaft Position Sensor—5.2L V-8 Engine
Fig. 5 Crankshaft Position Sensor—4.0L Engine
With Automatic Transmission
INSTALLATION
(1) Install the sensor into the access hole on the
transmission.
(2) Install sensor mounting bolt (Fig. 5).
(3) Tighten sensor mounting bolt to 6-to-8 N⅐m (50-
to-70 in. lbs.) torque.
(4) Connect the electrical connector to sensor.
(5) Install the clip to sensor wire harness.
(6) Install clip over fuel rail mounting stud. Install
clip mounting nut.
REMOVAL—5.2L V-8 ENGINE
The sensor is bolted to the top of the cylinder block
near the rear of right cylinder head (Fig. 6).
(1) Remove the spark plug cable loom and spark Fig. 7 Exhaust Manifold Heat Shield—5.2L Engine
plug cables from valve cover mounting stud at rear of
right valve cover (Fig. 6). Position spark plug cables (8) Loosen EGR tube mounting nut at intake man-
to top of valve cover. ifold (Fig. 6).
(2) Remove the right exhaust manifold heat shield (9) Remove 2 EGR tube mounting bolts at exhaust
nuts/bolts and remove heat shield (Fig. 7). manifold (Fig. 6) and remove EGR tube. Discard old
(3) Disconnect 2 hoses at exhaust gas recirculation gasket at exhaust manifold.
(EGR) valve. Note position of hoses at EGR valve be- (10) Disconnect crankshaft position sensor pigtail
fore removal. harness from main wiring harness.
(4) Disconnect electrical connector and hoses at (11) Remove 2 sensor (recessed hex head) mount-
EGR valve control. Note position of hoses at valve ing bolts (Fig. 6) and remove sensor.
control before removal.
(5) Remove 2 EGR valve mounting bolts (Fig. 6) INSTALLATION—5.2L ENGINE
and remove EGR valve. Discard old EGR gasket. (1) Position crankshaft position sensor to engine
(6) Disconnect electrical connector at engine oil and install mounting bolts. Tighten bolts to 8 N⅐m
pressure sending unit. (70 in. lbs.) torque.
(7) To prevent damage to oil pressure sending unit, (2) Connect main harness electrical connector to
a special tool, such as number C-4597 must be used sensor.
(Fig. 8). Remove sending unit from engine.
20. 8D - 20 IGNITION SYSTEMS ZJ
DISTRIBUTORS
All distributors contain an internal oil seal that
prevents oil from entering the distributor housing.
The seal is not serviceable. The camshaft position
sensor is located in the distributor on all engines.
4.0L 6-Cylinder Engine Only: Factory replace-
ment distributors are equipped with a plastic align-
ment pin already installed. The pin is located in an
access hole on the bottom of the distributor housing
(Fig. 9). It is used to temporarily lock the rotor to the
cylinder number 1 position during installation. The
pin must be removed after installing the distributor.
Fig. 8 Oil Pressure Sending Unit—Removal/
Installation
(3) Clean the EGR tube and exhaust manifold (at
EGR tube mounting point) of any old gasket mate-
rial.
(4) Install a new gasket to exhaust manifold end of
EGR tube and install EGR tube to both manifolds.
Tighten tube mounting nut at intake manifold.
Tighten 2 mounting bolts at exhaust manifold to 23
N⅐m (204 in. lbs.) torque.
(5) Coat the threads of the oil pressure sending
unit with thread sealant. Do not allow any of the
thread sealant to get into the sending unit opening, Fig. 9 Plastic Alignment Pin—4.0L Engine
or the opening at the engine. Install sending unit to
The camshaft position sensor is located in the dis-
engine and tighten to 14 N⅐m (130 in. lbs.) torque. In-
tributor on all engines (Fig. 10). For removal/instal-
stall electrical connector to sending unit.
lation procedures, refer to Camshaft Position Sensor
(6) Clean the intake manifold and EGR valve of
in this group. Distributor removal is not necessary
any old gasket material.
for sensor removal.
(7) Install a new EGR valve gasket at intake man-
Refer to figure 11 for an exploded view of the dis-
ifold.
tributor with the 4.0L engine.
(8) Install EGR valve to intake manifold. Tighten 2
4.0L 6-Cylinder Engine Only: A fork with a slot
EGR bolts to 23 N⅐m (200 in. lbs.) torque.
is supplied on the bottom of the distributor housing
(9) Position EGR valve control and install its elec-
where the housing base seats against the engine
trical connector. Connect hoses between EGR valve
block (Fig. 11). The centerline of the slot aligns with
and EGR valve control. Connect hose between main
the distributor holddown bolt hole in the engine
engine vacuum harness and valve control.
block. Because of the fork, the distributor cannot be
(10) Install spark plug cable loom and spark plug
rotated. Distributor rotation is not necessary as all
cables to valve cover mounting stud.
ignition timing requirements are handled by the
(11) Install heat shield at right exhaust manifold.
powertrain control module (PCM). Do not attempt
to modify this fork to attain ignition timing.
ENGINE COOLANT TEMPERATURE SENSOR
All Engines: The rotational position of the distrib-
For an operational description, diagnosis and re-
utor determines fuel synchronization only. It does not
moval/installation procedures, refer to Group 14,
determine ignition timing.
Fuel System.
21. ZJ IGNITION SYSTEMS 8D - 21
(5) Remove the cylinder number 1 spark plug.
(6) Hold a finger over the open spark plug hole.
Rotate the engine at the vibration dampener bolt un-
til compression (pressure) is felt.
Slowly continue to rotate the engine. Do this until
the timing index mark on the vibration damper pul-
ley aligns with the top dead center (TDC) mark (0
degree) on timing degree scale (Fig. 12). Always ro-
tate the engine in direction of normal rotation. Do
not rotate the engine backward to align the timing
marks.
Fig. 10 Camshaft Position Sensor—All Engines—
Typical
Fig. 12 Align Timing Marks
(7) Remove the distributor holddown bolt and
clamp (Fig. 11).
(8) Remove the distributor from engine by slowly
lifting straight up.
Note that the rotor will rotate slightly in a counter-
clockwise direction while lifting up the distributor.
The oil pump gear will also rotate slightly in a coun-
terclockwise direction while lifting up the distributor.
This is due to the helical cut gears on the distributor
and camshaft.
Note the removed position of the rotor during dis-
tributor removal. During installation, this will be re-
Fig. 11 Distributor—4.0L Engines—Typical ferred to as the Pre-position.
REMOVAL—4.0L 6-CYLINDER ENGINE Observe the slot in the oil pump gear through the
(1) Disconnect the negative battery cable at the hole on the side of the engine. It should be slightly
battery. before (counterclockwise of) the 11 o’clock position
(2) Disconnect coil secondary cable at coil. (Fig. 13).
(9) Remove and discard the old distributor-to-en-
(3) Remove distributor cap from distributor (2
gine block gasket (Fig. 11).
screws). Do not remove cables from cap. Do not re-
move rotor. INSTALLATION—4.0L 6-CYLINDER ENGINE
(4) Disconnect the distributor wiring harness from (1) If the engine crankshaft has been rotated after
the main engine harness. distributor removal, cylinder number 1 must be re-
22. 8D - 22 IGNITION SYSTEMS ZJ
Fig. 13 Slot At 11 O’clock Position—4.0L Engine
turned to its proper firing stroke. Refer to the previ-
ous REMOVAL steps number 5 and 6. These steps
must be done before installing distributor.
(2) Check the position of the slot on the oil pump
gear. It should be just slightly before (counterclock- Fig. 14 Pin Alignment Holes
wise of) the 11 o’clock position (Fig. 13). If not, place
a flat blade screwdriver into the oil pump gear and shaft. When the distributor is fully seated to the en-
rotate it into the proper position. gine block, the centerline of the base slot should be
(3) Factory replacement distributors are equipped aligned to the clamp bolt mounting hole on the en-
with a plastic alignment pin already installed (Fig. gine (Fig. 16). The rotor should also be pointed at the
9). This pin is used to temporarily hold the rotor to 5 o’clock position.
the cylinder number 1 firing position during distrib- It may be necessary to rotate the rotor and distrib-
utor installation. If this pin is in place, proceed to utor shaft (very slightly) to engage the distributor
step number 8. If not, proceed to step number 4. shaft with the slot in the oil pump gear. The same
(4) If the original distributor is to be reinstalled, may have to be done to engage the distributor gear
such as during engine overhaul, the plastic pin will with the camshaft gear.
not be available. A 3/16 inch drift pin punch tool may
be substituted for the plastic pin.
(5) Remove the camshaft position sensor from the
distributor housing. Lift straight up.
(6) Four different alignment holes are provided on
the plastic ring (Fig. 14). For this application, use
‘‘4.0L 6-CYLINDER ENGINE ALIGN. HOLE’’ as
shown in figure 14.
Rotate the distributor shaft and install the pin
punch tool through the proper alignment hole in the
plastic ring (Fig. 14) and into the mating access hole
in the distributor housing. This will prevent the dis-
tributor shaft and rotor from rotating.
(7) Clean the distributor mounting hole area of the
engine block.
(8) Install a new distributor-to-engine block gasket
(Fig. 11).
(9) Install the rotor to the distributor shaft.
(10) Pre-position the distributor into the engine
while holding the centerline of the base slot in the 1
o’clock position (Fig. 15). Continue to engage the dis-
tributor into the engine. The rotor and distributor
will rotate clockwise during installation. This is due Fig. 15 Distributor Pre-position—4.0L Engine
to the helical cut gears on the distributor and cam-
23. ZJ IGNITION SYSTEMS 8D - 23
(17) Connect the distributor wiring harness to the
main engine harness.
(18) Connect battery cable to battery.
REMOVAL—5.2L V-8 ENGINE
CAUTION: Base ignition timing is not adjustable on
the 5.2L V-8 engine. Distributors do not have built in
centrifugal or vacuum assisted advance. Base igni-
tion timing and timing advance are controlled by
the powertrain control module (PCM). Because a
conventional timing light can not be used to adjust
distributor position after installation, note position
of distributor before removal.
(1) Disconnect negative battery cable at battery.
(2) Remove coil high-tension cable and all spark
plug cables at distributor cap. Note and mark posi-
tion of cables (Fig. 17) before removal.
Fig. 16 Distributor Engaged Position—4.0L Engine
The distributor is correctly installed when:
• the rotor is pointed at the 5 o’clock position.
• the plastic alignment pin (or pin punch tool) is still
installed to distributor.
• the number 1 cylinder piston is set at top dead
center (TDC) (compression stroke).
• the centerline of the slot at the base of the distrib-
utor is aligned to the centerline of the distributor
holddown bolt hole on the engine. In this position,
the holddown bolt should easily pass through the slot
and into the engine.
No adjustments are necessary. Proceed to next
step. Fig. 17 Engine Firing Order—5.2L Engine
(11) Install the distributor holddown clamp and (3) Remove distributor cap from distributor (two
bolt. Tighten the bolt to 23 N⅐m (17 ft. lbs.) torque. screws).
(12) Remove the pin punch tool from the distribu- (4) Mark the position of distributor housing in re-
tor. Or, if the plastic alignment pin was used, remove lationship to engine or dash panel. This is done to
it straight down from the bottom of the distributor. aid in installation.
Discard plastic pin. Before distributor is removed, the number one cyl-
(13) If removed, install the camshaft position sen- inder must be brought to the top dead center (TDC)
sor to the distributor. Align the wiring harness grom- firing position.
met to the notch in the distributor housing. (5) Attach a socket to the crankshaft vibration
(14) Install the rotor. damper mounting bolt.
(6) Slowly rotate engine clockwise, as viewed from
CAUTION: If the distributor cap is incorrectly posi- front, until indicating mark on crankshaft vibration
tioned on distributor housing, the cap or rotor may damper is aligned to 0 degree (TDC) mark on timing
be damaged when engine is started. chain cover (Fig. 18).
(7) The distributor rotor should now be aligned to
(15) Install the distributor cap. Tighten distributor the CYL. NO. 1 alignment mark (stamped) into the
cap holddown screws to 3 N⅐m (26 in. lbs.) torque. camshaft position sensor (Fig. 19). If not, rotate the
(16) If removed, install the spark plug cables to crankshaft through another complete 360 degree
the distributor cap. For proper firing order, refer to turn. Note the position of the number one cylinder
the Specifications section at the end of this group. spark plug cable (on the cap) in relation to rotor. Ro-
See Engine Firing Order. tor should now be aligned to this position.
24. 8D - 24 IGNITION SYSTEMS ZJ
Fig. 18 Damper-To-Timing Chain Cover Alignment Fig. 20 Distributor Holddown Clamp—5.2L Engine
Marks—5.2L Engine (1) Clean top of cylinder block for a good seal be-
tween distributor base and block.
(2) Lightly oil the rubber o-ring seal on the distrib-
utor housing.
(3) Install rotor to distributor shaft.
(4) Position distributor into engine to its original
position. Engage tongue of distributor shaft with slot
in distributor oil pump drive gear. Position rotor to
the number one spark plug cable position.
(5) Install distributor holddown clamp and clamp
bolt. Do not tighten bolt at this time.
(6) Rotate the distributor housing until rotor is
aligned to CYL. NO. 1 alignment mark on the cam-
shaft position sensor (Fig. 19).
(7) Tighten clamp holddown bolt (Fig. 20) to 22.5
N⅐m (200 in. lbs.) torque.
Fig. 19 Rotor Alignment Mark—5.2L Engine (8) Connect camshaft position sensor wiring har-
ness to main engine harness.
(8) Disconnect camshaft position sensor wiring (9) Install distributor cap. Tighten mounting
harness from main engine wiring harness. screws.
(9) Remove distributor rotor from distributor shaft. (10) Install spark plug cables in correct firing or-
(10) Remove distributor holddown clamp bolt and der (Fig. 17) to distributor cap. Be sure all spark
clamp (Fig. 20). Remove distributor from vehicle. plug cables are firmly connected into distributor cap
towers.
CAUTION: Do not crank engine with distributor re-
(11) Refer to the following, Checking Distributor
moved. Distributor/crankshaft relationship will be
Position.
lost.
CHECKING DISTRIBUTOR POSITION—5.2L ENGINE ONLY
INSTALLATION—5.2L ENGINE To verify correct distributor rotational position,
If engine has been cranked while distributor is re- connect the DRB scan tool to the data link connector.
moved, establish the relationship between distributor The data link connector is located in the engine com-
shaft and number one piston position as follows: partment. Gain access to the SET SYNC screen on
Rotate crankshaft in a clockwise direction, as the DRB.
viewed from front, until number one cylinder piston
is at top of compression stroke (compression should WARNING: WHEN PERFORMING THE FOLLOWING
be felt on finger with number one spark removed). TEST, THE ENGINE WILL BE RUNNING. BE CARE-
Then continue to slowly rotate engine clockwise until FUL NOT TO STAND IN LINE WITH THE FAN
indicating mark (Fig. 18) is aligned to 0 degree BLADES OR FAN BELT. DO NOT WEAR LOOSE
(TDC) mark on timing chain cover. CLOTHING.
25. ZJ IGNITION SYSTEMS 8D - 25
Follow the directions on the DRB screen and start REMOVAL—5.2L V-8 ENGINE
the engine. With the engine running, the words IN The ignition coil is mounted to a bracket near the
RANGE should appear on the screen along with 0°. front of the right engine cylinder head on 5.2L en-
This indicates correct distributor position. gines (Fig. 22).
If a plus (+) or a minus (-) is displayed next to the
degree number, and/or the degree displayed is not
zero, loosen but do not remove the distributor hold-
down clamp bolt. Rotate the distributor until IN
RANGE appears on the screen. Continue to rotate
the distributor until achieving as close to 0° as pos-
sible. After adjustment, tighten clamp bolt to 22.5
N⅐m (200 in. lbs.) torque.
The degree scale on the SET SYNC screen of the
DRB is referring to fuel synchronization only. It is
not referring to ignition timing. Because of this,
do not attempt to adjust ignition timing using this
method. Rotating the distributor will have no effect
on ignition timing. All ignition timing values are con-
trolled by the powertrain control module (PCM).
IGNITION COIL Fig. 22 Ignition Coil—5.2L Engine—Typical
The ignition coil is an epoxy filled type. If the coil (1) Disconnect the wiring and secondary cable from
is replaced, it must be replaced with the same type. the ignition coil (Fig. 22).
REMOVAL—4.0L 6-CYLINDER ENGINE WARNING: DO NOT REMOVE THE COIL MOUNTING
The ignition coil is mounted to the right side of the BRACKET-TO-CYLINDER HEAD MOUNTING BOLTS.
4.0L engine block next to the distributor (Fig. 21). THE COIL MOUNTING BRACKET IS UNDER ACCES-
SORY DRIVE BELT TENSION. IF THIS BRACKET IS
TO BE REMOVED FOR ANY REASON, ALL BELT
TENSION MUST FIRST BE RELIEVED. REFER TO
THE BELT SECTION OF GROUP 7, COOLING SYS-
TEM.
(2) Remove ignition coil from coil mounting bracket
(two bolts).
INSTALLATION—5.2L ENGINE
(1) Install the ignition coil to coil bracket. If nuts
and bolts are used to secure coil to coil bracket,
tighten to 11 N⅐m (100 in. lbs.) torque. If the coil
mounting bracket has been tapped for coil mounting
bolts, tighten bolts to 5 N⅐m (50 in. lbs.) torque.
(2) Connect all wiring to ignition coil.
Fig. 21 Ignition Coil—4.0L Engine
INTAKE MANIFOLD AIR TEMPERATURE SENSOR
(1) Disconnect the ignition coil secondary cable
For an operational description, diagnosis and re-
from ignition coil (Fig. 21).
moval/installation procedures, refer to the Diagnosis
(2) Disconnect engine harness connector from igni-
sections of Group 14, Fuel System.
tion coil.
(3) Remove ignition coil mounting bolts. Remove
coil.
MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR
For an operational description, diagnosis and re-
INSTALLATION—4.0L ENGINE moval/installation procedures, refer to Group 14,
(1) Install ignition coil to bracket on cylinder block Fuel System.
with mounting bolts.
(2) Connect engine harness connector to coil.
(3) Connect ignition coil cable to ignition coil.
26. 8D - 26 IGNITION SYSTEMS ZJ
OXYGEN (O2S) SENSOR
For an operational description, diagnostics and re-
moval/installation procedures, refer to Group 14,
Fuel Systems, in this manual.
POWERTRAIN CONTROL MODULE (PCM)
The PCM is located on the cowl panel in the right/
rear side of the engine compartment (Fig. 23).
Fig. 24 Coolant Reserve/Overflow Tank Mounting
Fig. 23 PCM Location
REMOVAL
(1) Disconnect the negative battery cable at bat-
tery.
(2) Remove the coolant reserve/overflow tank (one
bolt and two nuts) (Fig. 24)
(3) Loosen the 60-Way connector mounting bolt
(Fig. 25).
(4) Remove the electrical connector by pulling
straight back.
(5) Remove the three PCM mounting bolts (Fig.
25).
(6) Remove PCM.
Fig. 25 PCM Mounting
INSTALLATION round each cable boot and spark plug (Fig. 26). These
(1) Check the pins in the PCM 60-way electrical shields protect the spark plug boots from damage
connector for damage. Repair as necessary. (due to intense engine heat generated by the exhaust
(2) Install PCM. Tighten three mounting bolts to 1 manifolds) and should not be removed. After the
N⅐m (9 in. lbs.) torque.
spark plug cable has been installed, the lip of the ca-
(3) Engage 60-way connector into PCM. Tighten
ble boot should have a small air gap to the top of the
connector mounting bolt to 4 N⅐m (35 in. lbs.) torque.
heat shield (Fig. 26).
(4) Install coolant reserve/overflow tank (Fig. 24).
If removal of the heat shield(s) is necessary, remove
(5) Connect negative cable to battery.
the spark plug cable and compress the sides of shield
SPARK PLUGS for removal. Each shield is slotted to allow for com-
5.2L V-8 ENGINE ONLY: Spark plug cable heat pression and removal. To install the shields, align
shields are pressed into the cylinder head to sur-
