2. Self-introduction
Copyright (C) 2013 Japan CloudStack User Group All Rights Reserved.
@MayumiK0 オーじゃなくてゼロです
日本CloudStackユーザー会 会長
一般社団法人クラウド利用促進機構 技術アドバイザー
クリエーションライン株式会社 シニアエンジニア
主にCloudStackをさわってますが、何でも屋
どちらかというと実はネットワークのが好き
家に19inchのフルラックがあるけど、殆どただの棚と化している
とにかくビール重要
3. Santa Clara
Copyright (C) 2013 Japan CloudStack User Group All Rights Reserved.
やって参りました
Santa Clara
このへん
5. Copyright (C) 2013 Japan CloudStack User Group All Rights Reserved.
それではセッションのお話
6. Conference Schedule
Copyright (C) 2013 Japan CloudStack User Group All Rights Reserved.
聞きたいな〜と思うセッションの
時間が結構かぶってる
http://www.cloudstackcollab.org/
7. Keynote - Chip Childers
Copyright (C) 2013 Japan CloudStack User Group All Rights Reserved.
8. Keynote - Chip Childers
「State of the Project: Apache CloudStack in 2013」
• 1年未満のinclubator期間でTopレベルプロジェクトになった
• 4.1.0 released
• 20 features 24 improvements 155 bug fixs
• 2.X userが4.XにUpdateするためのHelp
• Email Trafficeが相当増えている
• JCSUGおよびCloudStack徹底入門の紹介
• Apache CloudStackは 272+ Operators in Production
• Flexible Deployment option and infra choice
• Next apache cloudstack collaboration 11/20-22 2013 Amsterdam
Copyright (C) 2013 Japan CloudStack User Group All Rights Reserved.
11. Tales from the cloudstack real-
time support team
初心者向け
普段CloudStackユーザー会で話している技術
的入門編のような内容でした
Copyright (C) 2013 Japan CloudStack User Group All Rights Reserved.
12. Linux Native VXLAN Integration
NTT-comのhatanoさんの
VLANの壁をこえるためのVXLANの実装の話
http://www.slideshare.net/haeenajp/
asfccc2013-toshiaki-release
Copyright (C) 2013 Japan CloudStack User Group All Rights Reserved.
14. How to Run from a Zombie:
CloudStack Distributed Process
Management
CloudStackのプロセスの分散管理要件の探索
https://speakerdeck.com/jburwell/how-to-
run-from-a-zombie-cloudstack-distributed-
process-management
Copyright (C) 2013 Japan CloudStack User Group All Rights Reserved.
16. SDN in CloudStack
CloudstackとSDN
GRE isolation
Nicira VPN
BigSwitch VNS
Midokura Midnet
Stratosphere SSP
http://www.slideshare.net/buildacloud/sdn-
in-cloudstack
Copyright (C) 2013 Japan CloudStack User Group All Rights Reserved.
17. Lessons Learned in the
CloudStack 4.1.0 Release
アーキテクチャの変更
• Custum Injection FrameworkをSpring Frameworkに変換
• パッケージの変更
cloud-という名前がcloudstack-に
• リファクタリング
Storage plugin model
Network plugin model
API implementation(互換あり)
Copyright (C) 2013 Japan CloudStack User Group All Rights Reserved.
18. Lessons Learned in the
CloudStack 4.1.0 Release
Copyright (C) 2013 Japan CloudStack User Group All Rights Reserved.
http://www.slideshare.net/chipchilders/
cloudstack-release-41
19. High Availability and Disaster
Recovery for Cloud Workloads
高可用性とDRについて。4.2以降で実装される
内容+NetScalerのGSLBで実現できること。
Copyright (C) 2013 Japan CloudStack User Group All Rights Reserved.
21. Hands-on-Lab: Running
CloudStack & Nicira NVP
NetworkOfferingで、Nicira NVPを使うオファリ
ングを作成し、そのオファリングを使うネット
ワークを作成し、インスタンスを作成するという
流れ。
Copyright (C) 2013 Japan CloudStack User Group All Rights Reserved.
22. Next
Next apache cloudstack collaboration
11/20-22 2013 Amsterdam
Copyright (C) 2013 Japan CloudStack User Group All Rights Reserved.
