2. CPU, Central Processing Unit
• CPU = Central Processing Unit
• Processing chip
• microprocessor
kotak (casing) komputer berisi:
•motherboard,
•processor,
•ram,
•harddisk,
•floppy drive, …
3. Representasi Data
• Biner:
– data disimpan sebagai state
• ON = 1
• OFF = 0
• Standard representasi:
– ASCII
– EBCDIC
– UNICODE
5. Standard
• Jumlah kode
– ASCII = American Standard Code for
Information Interchange; ASCII-8 : 8 bit =
256 chars (0-255)
– EBCDIC = Extended Binary Coded Decimal
Interchange Code; 256 chars
– UNICODE; 65536
Jika
•1 huruf diwakili 1 char, dan
•1 char ASCII-8 memerlukan tempat penyimpanan 8 bit (=1
byte),
maka berapakah tempat untuk menyimpan “ILKOM UB” ?
Berapa memory untuk menyimpan “ILKOM UB” dalam
UNICODE?
7. Bagian CPU
• Aritmetic and Logic Unit (ALU) : melakukan
perhitungan, proses pengolahan
• Control Unit (CU) : mengatur pekerjaan,
koordinasi
• Register : tempat penyimpanan sementara.
Proses lebih cepat (efisien, dan terjamin)
daripada akses langsung ke primary storage.
8. Siklus Mesin
• Machine cycle:
– Instruction time
1. CU mengambil (fetch) instruksi
2. CU mengartikan (interpret) instruksi
– Execution time
1. ALU melakukan proses
2. ALU menyimpan hasil
9. Kecepatan komputer
• Waktu
– milisecond = 10-3 second
– microsecond = 10-6 second
– nanosecond = 10-9 second
– picosecond = 10-12 second
• Megahertz (MHz) : jumlah clock per detik
• MIPS : Million Instructions Per Second
• Megaflop : million floating point operations
per second
Floating point: angka dengan ketelitian tinggi
10. Coprocessor
• Coprocessor : processor lain yang
digunakan untuk membantu kerja CPU
– math coprocessor: sudah ada di dalam
processor Intel Pentium atau yang setara
– graphics coprocessor: untuk grafik
Dulu mathco tidak disertakan dalam processor karena pemakaian
terbatas dan harga (teknologi) mahal.
11. Instruction Set
• The RISC machine executes instructions faster because
it doesn't have to go through a microcode conversion
layer. The RISC compiler generates more instructions
than the CISC compiler for the same processing.
12. Parallel Processing
• Parallel Processing : melakukan proses
atau perhitungan secara paralel
(bersamaan).
– Multiprocessor
– symmetric multiprocessing (SMP)
–…
13. Bus Width
• Bus Width:
– Jumlah varian instruksi
– Ukuran data (yang diproses pada satu saat)
– Besar alamat (ukuran memory)
• Kecepatan transfer dari/ke processor
• Processor PC/Intel
– 8080 : 8 bit
– 8086 : 16 bit
– 80486 : 32 bit
– Pentium : 32 bit
– Pentium III : 64 bit
14. Primary Storage
• RAM: Random Access Memory
volatile; mudah hilang (berubah)
• ROM: Read Only Memory
non-volatile; tidak mudah hilang
15. RAM
• DRAM: Dynamic RAM
– harus di-refresh setiap beberapa
milisecond agar isinya tidak hilang.
• SRAM: Static RAM
– tidak perlu refresh daya
– Access time lebih cepat
– Lebih mahal
16. DRAM (1)
• Fast Page Mode DRAM (FPM DRAM)
• Extended Data Output DRAM (EDO DRAM)
• Synchronous DRAM (SDRAM) : dapat berjalan
dengan clock yang tinggi hingga 100 MHz (3x FPM
RAM, 2x EDO RAM), menyesuaikan dengan
kecepatan bus CPU.
• Rambus DRAM (RDRAM)
• Double Data Rate SDRAM (DDR SDRAM)
• Untuk video :
– Video RAM (VRAM)
– Windows RAM (WRAM)
– Synchronous Graphic RAM (SGRAM)
20. ROM: Read Only Memory
• ROM: Read Only Memory
• PROM: Programmable ROM
– ROM burner
• EPROM (Erasable PROM)
– dihapus dengan ultraviolet
• EEPROM (Electrically EPROM)
• Flash Memory
21. PROM
PROM awalnya terhubung (status=on,
1). Programmer adalah alat untuk
memutuskan hubungan tersebut
(status=off, 0) dengan mengirimkan
voltase tinggi pada baris dan kolom
yang tepat. Proses ini disebut
"burning".
Jadi: PROM hanya dapat
"ditulisi" satu kali saja.
22. Flash memory
• PC Card untuk laptop
• Lainnya untuk digital camera dan devices
handhelds
23. Form Factor
• Form factor: bentuk/susunan motherboard
• Saat ini ada 6 form factor:
– AT
– ATX
– Micro ATX
– Flex ATX
– NLX
– Custom ATX
27. Expansion slots
Slot untuk menerima kartu perluasan (expansion)
• ISA : Industry Standard Achitecture, a relatively low
speed interface primarily used for sound cards and
modems; runs at approx. 8MHz.
• EISA : Extended ISA
• PCI: Peripheral Component Interconnect, a high
speed interface for video cards, sound cards, network
interface cards, and modems; runs at 33MHz.
• AGP: Accelerated Graphics Port, - a high speed
interface for video cards; runs at 1X (66MHz), 2X
(133MHz), or 4X (266MHz).
28. PC Card
• PCMCIA: Personal Computer Memory Card
International Association, San Jose, CA, www.pc-
card.com. Sebuah lembaga standarisasi atau
asosiasi dagang yang mengeluarkan standard untuk
menghubungkan peripherals ke portable computer.
• Jenis:
– Type I : memory
– Type II : network adapter
– Type III : storage
• Peralatan PC dapat menggunakan card ini dengan
PC Card.
30. Ports
• Ports: standard penghubung antara komputer
(mainboard) dengan peralatan tambahan (peripheral)
pada masa tahun 1980 - 2000. Tahun berikutnya,
alat-alat tersebut menggunakan USB dan jarang
menggunakan port lagi.
– Serial port: pertukaran data (communication)
secara serial.
• contoh: COM1, COM2
• digunakan untuk: modem, mouse
– Parallel port : pertukaran cara paralel.
• LPT1, LPT2 (Line Printer Terminal)
• digunakan untuk: printer
Ada arti lain untuk istilah PORT yang tidak ada hubungannya,
misalnya:
1. port (lobang) untuk konektor kabel, dan
2. software/aplikasi yang cocok untuk platform tertentu.
31. Specialized ports
• Universal Serial Bus (USB port)
• FireWire (IEEE 1394 )
• SCSI : Small Computer System Interface
• MIDI : Musical instrument Digital Interface
• Game port
33. FireWire
• A high-speed serial bus that allows for the connection of
up to 63 devices.
• It is widely used for downloading video from digital
camcorders to the computer.
• Also known as the IEEE 1394 standard,
• 400 Mbits/sec transfer rates
• distance of 4.5 meters between devices.
34. Catu daya
• Power supply:
– Mengubah AC ke DC
– bersama dengan casing
• Voltage Stabilizer
– menjaga stabilitas tegangan listrik
• Uninterruptable Power Supply (UPS):
– Dumb
– Smart: berinteraksi dengan komputer
36. Keyboard
Merakit Komputer Kbdport (con)
Processor Casing Price
Clock speed Form
Proc. form Kbd port Mouse
Bus speed Mouse Port Mouse port
L2 cache Price M. type
price Price
Motherboard
Mboard form Video Card Monitor
Proc. form VRAM Size
Memory Bus speed Standard Price
Mem type Mem support Price
Bus speed HD support
Capacity Exp. slots
Price Price Sound card Speaker
Exp slot Price
Price
Harddisk FDD
Capacity Price Modem card
Hd standard Exp slot
price CDROM Price
Speed
Price
