Visual Dictionary




By: Sarah-Ashley McCall
Air Barrier Paper

  A sheet material used as both a vapor
retarder and an air barrier. It controls the
     infiltration ...
Attic Ventilation:
Allows water to escape and cools the house in the
summer by preventing the buildup of solar heat.

    ...
Attic Ventilation: Ridge Vent
    A long, open assembly that allows air to
circulate in and out of a gable roof at the rid...
Attic Ventilation: Gable Vent
Attic Ventilation: Roof Turbine
Backhoe & Front End Loader

                                       Backhoe
                             A backhoe is a pie...
Batter boards
A temporary frame built just outside the corner of an excavation to carry marks that lie on
the surface plan...
Jack Arch


Semi-Circular Arch
Keystone Arch




          Centering
   Temporary formwork for an arch.
Flemish Bond
                             Pattern: Alternating stretchers and headers




Running Bond
   Pattern: All str...
Common Bond
Pattern: Alternating rows of stretchers and
full-length headers
Stretcher

            Soldier
Sailor Brick




Rowlock Brick
Header
 Brick
Shiners
Utility
3 ½”x11 ½”x3 ½”
Modular
3 ½”x7 ½”x2 ¼”
Bulldozer
This is a piece of heavy equipment used to push soil, gravel, etc. around construction sights.
Stone Cladding
Brick Cladding
                 Pattern: Random Ashlar
EFIS
Exterior Insulation and
    Finish System




                          A cladding system that
                      ...
Wood Shakes
                          A shingle split from a block of wood.
              This is an overlapping cladding ...
My window is 18.6 sf
Code Requirements: My Room            4’1” x 4’6 ½”
                                      This is up ...
Interior Stairs
        11 ½” + 2 (7 ¼”)=26
The tread is to code, the riser is not.




                       7 ¼” ¼”
   ...
Sawed Control Joint
Control Joint: A joint in the concrete
that allows for swelling and shrinking
   so that it does not d...
Isolation Joint
This joint is isolating a column from slab and slab from wall.
Isolation joints are used to relieve flexur...
Brick Coursing

3 brick courses = 1 CMU course
Concrete Masonry Unit (CMU)
A block of hardened concrete, with or without
hollow cores, designed to be laid in the same
ma...
Ribbed CMU
             split block
Left Hand Door                               Right Hand Door
The hallway is on the outside of the door.   The hallway is o...
Exterior Flush Door
Transom
   Sidelight
                                                       Top Rail
                              A small...
Utility Pole   Transformer: It provides the
                                           final voltage transformation in the...
Service Head: This steps the electricity down from
 the wires to the consumption level of the home.




                  ...
2. Sill Plate




1. Anchor Bolt
3. Floor Joists (2nd Floor)
9. Ceiling Joists (1st Floor)
                                4. Stringer
5. Subflooring
                The loadbearing surface beneath a finish floor.
6. Sole Plate
7. Stud
8. Top Plate
10. Rafters
A framing member that runs up and down the
           slope of a steep roof.
11. Roof Decking
12. Sheathing
Front End Loader: Heavy equipment piece used on construction sites.
 Primarily used to load material such as recycled mate...
High Impact Gypsum Board
An interior facing panel consisting of a gypsum core sandwiched between paper faces.
Air Handling Unit: Takes in air, cools and
dehumidifies the air, and distributes it in the interior space.
Advantage: Rapi...
Insulation: Insulating material in the cavities of walls to retard the passage of heat and cold to
   and from the buildin...
Loose-Fill Insulation




                        Rigid Board Insulation
Brick Lintel
              Lintel: Carries the weight of the
              structure above it across openings.
Metal Angle
Type S Mortar
                                     Tooled Joint   3/8” Joint
                                             ...
Oriented Strand Board




A building panel
composed of long sheets
of long shreds of wood
fiber (not veneer)
oriented in s...
Water Closet
3” Pipe Below




                Lavatory
                1 ½” Pipe Diameter
                A fixed bowl or...
Shower
Interior VTR
This plumbing vent keeps the pressure equal
in the pipes so that a vacuum does not suck
the water out of P-tr...
Exterior VTR
The plumbing vent goes out through the roof to let the gas
               out into the atmosphere.
Kitchen Sink
Undermount
Plywood
A wood panel composed of an odd number of layers of
wood veneer bonded together under pressure.

Veneer: A thin la...
Rebar
#8 Rebar
The purpose of the deformations on the rebar are to help bind the concrete and rebar together.
Downspout
Gutter: A channel that collects rainwater and         a vertical pipe used to drain
                            ...
Underlayment: A layer of waterproof material such as
building felt between roof sheathing and roofing.
This protects the b...
Clay Tile Roof
Metal Shingle Roof
Shingle: A small unit of water-
resistant material nailed in
overlapping fashion to render a
sloping ro...
Preformed Metal Roof
A roof made of metal panels that requires no special
equipment for installation on-site. Made of long...
Gable Roof
Hip Roof
Mansard Roof
Gambrel
Rake: The inclined portion of a cornice.
           These are typically found on gable roofs.



                         ...
Eave: The part of a roof which projects out
from the side wall, projecting the edge of the roof.




                     ...
Building Without A Fascia
Coursed Ashlar
Random Ashlar
Random Rubble
Vapor Retarder
Put on the warm in winter side
of the insulation. This retards
the passage of water vapor.
Waterproofing: Liquid or sheet material applied to the exterior of a basement wall or floor to
resist the intrusion of wat...
Control Joint
A joint in the brick coursing
that allows for swelling of
the brick so that it does not
damage the cladding....
Welded Wire Fabric
12” x 12” grid
Gliding Window

                 Gliding windows
                 are named this
                 way because they
       ...
Casement Window
These windows open outward by a crank
located on the sill.
Double-Hung
  Window
This window is called double-
hung because the top pane or
the bottom pane can be open
without the ot...
