The document discusses the importance of software testing documentation, particularly focusing on test plans, which outline the scope, approach, objectives, and resources required for testing projects. It covers the types of test plans, the significance of a well-defined testing strategy, and the roles and responsibilities of the testing team. Additionally, it emphasizes the necessity of clear documentation to avoid misunderstandings and ensure effective testing processes.

2. SOFTWARE TESTING DOCUMENTATION
WHAT IS TEST PLAN?
BENEFITS OF USING TEST PLAN
TYPES OF TEST PLAN
TEST PLAN TEMPLATE
HOW TO WRITE A TEST PLAN?
www.edureka.co

3. www.edureka.co

4. YES! Documentation plays a critical role in
Software Testing. Let me share my
experience…
www.edureka.co
Documentation in Software Testing
A Project….unknown technical
issue…angry client....
requirement not documented..
Is documentation necessary in
Software Testing?

5. Test Case
TestScenario
Traceability
Matrix
Types of
Documented
Artifacts in
Software Testing
Test Plan
Test plan is a document prepared at the project level. In
general it defines work products to be tested, how they will
be tested and test type distribution among testers
www.edureka.co

6. Test Scenario
Traceability
Matrix
Types of
Documented
Artifacts in
Software Testing
Test case is a complexity of inputs, serious of steps, and
conditions that can be used during the process of testing.
Test Plan
www.edureka.co
Test Case

7. Test Case
Traceability
Matrix
Types of
Documented
Artifacts in
Software Testing
Test scenario can be considered as a single line statement
which notifies the area in which your application will
experiment. This artifact is needed for ensuring the overall
procedure tested from start to finish.
Test Plan
Test Scenario
www.edureka.co

8. Test Case
Test Scenario
Types of
Documented
Artefacts in
Software Testing
Traceability Matrix (also referred to as Requirement
Traceability Matrix - RTM) is a table that is used to trace
the requirements during the Software Development Life
Cycle
Test Plan
Traceability
Matrix
Traceability
Matrix
www.edureka.co

9. www.edureka.co

10. A test plan is a document describing the scope, approach, objectives, resources, and schedule of a software testing
effort. It is the document that outlines the what, when, how, who, and more of a testing project.
Why Where
When
HowWho
What
www.edureka.co

11. www.edureka.co
Acts as a quick guide for testing process
Helps avoid effort in ‘Out of Scope’ functionalities
Determines time, cost & efforts needed
Defines roles & responsibilities for tester
Provides schedule for testing activities
Outlines resource requirements & equipment
Acts as source of proof if need in future

12. www.edureka.co
01
Misunderstandings about roles &
responsibilities
02 Test team will have not so clear test
objectives
03
No surety about when the test
process ends
04
Undefined test scope misleads
testers & users

13. www.edureka.co

14. www.edureka.co
A single high-level
test plan for a
project/product that
unifies all other test
plans
Intermediate plans
specifically related to
a level of software
testing
Plans for major types
of testing like
Performance Test
Plan and Security Test
Plan
Master Test Plan Level Specific Test Plan Type Specific Test Plan
Test Plan Types

15. www.edureka.co

16. www.edureka.co
Q. Can you test a product without any
information about it?
As first step tester must learn about the
product thoroughly before testing it.
➢ Who will use the software
➢ What is it for?
➢ How will it work?
Interview client,
designer & developer
Review product &
project
Perform product
walkthrough
Analyse the
product
Develop Test
Strategy
Define Test
Objectives
Resource
Planning
Schedule &
Estimation
Determine Test
Deliverables
www.edureka.co

17. www.edureka.co
The tester should design a strategy which can
assist him/her in defining the scope of testing
Test Strategy defines
➢ The project’s testing objectives and the
means to achieve them
➢ Determines testing effort and costs
Define the scope of testing2.1
Step 2
2.2
2.3
2.4
Identify the testing type
Document risks & issues
Create the test logistics
Analyse the
product
Develop Test
Strategy
Define Test
Objectives
Resource
Planning
Schedule &
Estimation
Determine Test
Deliverables
www.edureka.co

18. www.edureka.co
A good test plan clearly defines the testing
scope and its boundaries. The basic goal of any
software project is to ensure that software is
bug free.
Tester can do the following to define scope:
➢ List features to be tested
➢ List features not to be tested
➢ Define the goal based on above features
Analyse the
product
Develop Test
Strategy
Define Test
Objectives
Resource
Planning
Schedule &
Estimation
Determine Test
Deliverables
www.edureka.co

19. www.edureka.co
Analyse the
product
Develop Test
Strategy
Define Test
Objectives
Resource
Planning
Schedule &
Estimation
Determine Test
Deliverables
Resource plan is a detailed summary of all types of
resources required to complete project task.
It includes:
➢ Different software & hardware requirements
(sever, computers, network, test tools etc)
➢ Employees requirement
(test manager, testers, developers, test admin etc)
www.edureka.co

20. www.edureka.co
Analyse the
product
Develop Test
Strategy
Define Test
Objectives
Resource
Planning
Schedule &
Estimation
Determine Test
Deliverables
A good test plan clearly lists down the ‘roles and
responsibilities’ of testing team along with
‘schedule’ and tells everyone what to do and when
to do.
A schedule usually has multiple components like:
➢ Tasks
➢ Members responsible for tasks
➢ Estimated effort
➢ Employee & project deadline’
➢ Project estimation
➢ Possible project risks
www.edureka.co

21. www.edureka.co
Analyse the
product
Develop Test
Strategy
Define Test
Objectives
Resource
Planning
Schedule &
Estimation
Determine Test
Deliverables
Test Deliverables is a list of all the documents, tools
and other components that has to be developed and
maintained in support of the testing effort.
➢ Test plan
documents
➢ Test cases
documents
➢ Test design
specifications
➢ Test scripts
➢ Simulators
➢ Test data
➢ Test matrix
➢ Error Logs
➢ Execution Logs
➢ Test Results
➢ Defects report
➢ Release notes
Before
Testing
During
Testing
After
Testing
www.edureka.co

22. www.edureka.co

23. www.edureka.co
Uniquely identifies the test plan & may include version number
Parameter Description
Test Plan Identifier
Standard for
Test Plan
Documentation
Introduction Sets objectives, scope, goals, resource & budget constraints
Lists the systems and subsystems which be tested
All the features & functionalities to be tested are listed here
Lists the characteristics of products that need not be tested
Has sources of test data, inputs and outputs, testing priorities
Describes a success criteria for evaluating the test results
Has criteria that may result in suspending testing activities
Test Items
Features to be
tested
Features not to be
tested
Approach
Item pass/fail
Suspension Criteria
www.edureka.co

24. www.edureka.co
Includes test cases, sample data, test report, issue log
Parameter Description
Test Deliverables
Standard for
Test Plan
Documentation
Testing Tasks Describes dependencies between tasks & resources needed
Lists software, hardware or other testing requirements
Lists roles and responsibilities assigned to the testing team
Describes the additional training needs for the staff
Details on when the testing activities will take place are listed
Lists overall risk of the project as it pertains to testing
Contains signature of approval from stakeholders
Environmental
Needs
Responsibilities
Staffing Needs
Schedule
Risks
Approvals
www.edureka.co
