Vermitechnology means rearing of earthworms. earthworm is friend of farmer. earthworm is doing a great job and also produced a good organic manure is called vermicompost. vermicompost is a biofertilzer. which is enhancing soil qualities. This is explained earthworm biology, importance and preparation of vermicompost, vermiwash, panchgavya and their importance.
2. INTRODUCTION
• Rearing of earthworms
• Darwin – Friend of Farmer
• Aristotle – intestine of earth
• Earthworm – God’s most gracious creatures – miracle
• Earthworms convert
Waste into Wealth
Trash into Treasure
Garbage into Black gold
Black gold into Green gold
Waste lands into Wonder lands
3. Scope of Vermitechnology
• Provides Vermicompost – excellent manure
• Provides Vermiwash – foliar Spray
• Supplies Organic fertilizer
• Worm casts – manure for crops and gardens
• Vermiprotein – Poultry and fish feed
• Employment Opportunity
• Enhance the Green revolution
• Convert rural and urban biowastes
4. Earthworm Diversity
• Terrestrial Animal
• Cosmopolitan distribution
• 4600 species (world)
• 590 species (India)
• Few species are used for
vermicomposting
• Research Started in 1950
• 1978 – useful to society
• America, England, France and
Japan
5. CLASSIFICATION OF EARTHWORM
• Based on the habitat
• Based on the soil layers
• Based on the feeding habits and colour
• Based on the behavior
• Based on the habits
• Based on the food materials
• Based on the place of living
6. Based on the habits
• Epigeic forms - red worm – feed on decaying organic matter – no
burrows –Surface of the earth – loose soil – vermicomposting and
vermiculture systems -Eisenia fetida
• Endogeic forms - horizontal burrows – all layers – incorporate
mineral matter into the top soil layer -within the earth -Octochaetona
thurstoni
• Anecic forms - night crawlers - feed on decaying organic matter –
organic debris to humus –
4-6ft permanent vertical burrows – mucus
- Deep soil – Lampito mauritti
7. BIOLOGY OF EARTHWORM
• Segmentation – not in external but in
internal structures
• Head – Prostomium – infront of the
mouth – used to force into the soil
• Setae – each segments – locomotion
and made in burrows
• Glands – Skin – mucus – lubricating
and burrows
• No eyes but it has cells – detect light
– sensitive to chemicals and touch as
smell
• No lungs – breaths by skin
• Digestive tract – unique features
– burrowing and feeding – ingest
soil
• Digestive tract – fluids –
enzymes – help in releasing
sugars, amino acids and smaller
organic molecules
• Molecules – absorbed by the
intestine – energy and synthesis
of new cells
8. Digestive system
• Alimentary Canal and Digestive glands
• Alimentary canal – mouth, buccal cavity,
pharynx, oesophagus, intestine, rectum
and anus
• Oesophagus – gizzard – pharyngeal
gland
Feeding
• Detritus feeders
• Gizzard – break the food into fine
particles (Worm casts)
9. Life Cycle of earth worm
• Sexual reproduction – hermaphrodite –
copulation – rainy season – morning hours
– Protandrous (Male gametes than female)
• Cocoon formation – Cocoon (Ootheca) -
Protective covering for eggs, sperms, zygote
and young ones – Clitellum – yellow to
black in colour
• Development
• Egg + sperm Zygote Blastula
Gastrula Young worm
• Hatching – 10-12 worms
• Life span – 3 to 7 years
• Life cycle varies from sps to sps
10. IMPORTANCE OF EARTHWORM
• Enhancement of he soil – decomposition and two sources – Mineral and
organic
• Changes in soil pH -Neutral or alkaline – bacteria and fungi
• Humus formation – breakdown of cellulose
• Improvement of soil quality – nitrogenous matter
• So many Diseases affected by man and cattles
• Biological magnification
• Japan – minamata disease
• Organic farming – vermicompost
Economic importance
• Laboratory use
• Food for other animals
• Research and development
• Medicinal use – asthma, diabetes and hypertension
11. Vermiculture Techniques
• Artificial rearing
• Increase the number of worms
Steps involved in vermiculture
• Site selection
• Species selection
• Vermibed
• Feedstock
• Inoculation of earthworms
• Feeding
• Harvesting
12. Site selection
• Should be
• Slope area
• Drainage facility
• Transport facility
• Shady areas of trees
13. Species selection
• Short life cycle
• High rate of reproduction and growth
• Voracious feeder
• High output of worm casts
• Resistant to disease
• Adaptable to climatic changes
• Examples – Eudrillus eugeniae, Eisenia fetida,
Perionyx excavates and Lampito mauritii
14. Vermibed
• Substratum of the earthworms
• House of the earthworms
• Containers for vermibed
• Plastic bucket
• Plastic basin
• Wooden box
• Concrete tank
• Card board box
15. Feed Stock
• Detritivore and Omnivore
• The following materials are selected for feeding earthworm
• Agricultural waste - Straw, grass clippings, coconut husk, saw
dust, paddy husk
• Animal waste - cow dung, goat, sheep
• Municipality waste - degradable material
• Industrial waste - Food industry and Sugarcane industry
waste
• Biogas waste
• Kitchen waste
17. Inoculation of worms
• 100 worms are introduced pre-decomposed process
Types
• Monoculture
• Polyculture
Feeding
• Pre-decomposed feedstock
• Feed is loaded on the top of the bed
• Entire feed - Thrice in a week
• Watering is daily or alternate days
• Bed is covered by broad leaves
• Earthworms breed and multiply
18. Suitable conditions required for earthworms
• Feeding
• Moisture 75 – 90%
• Adequate aeration
• Optimum temperature 25 – 30oC
• Neutral pH
• Salinity of the soil is less than 0.5%
19. Harvesting
• Collection of earthworms from the culture bed
• Harvest in two months
• Spread a paper on the ground
• Pyramid like heap
• Heap remain in day light for about half to one
hour
• Earthworms to penetrate deep and reach the
bottom
• Organic manure removed
• Harvested from the bottom
20. Methods of vermicomposting:
1. Bin or Tray method:
• Conversion of organic waste into valuable compost in a tray.
• Worms in a bin with biodegradable bedding.
Bin or Tray- It may be wooden box, metal tub.
• Bin should not more than 18 inches deep.
• Keep bin upon bricks or wooden blocks or sheet.
• Bin kept at shady ranges 250-300 C.
• Bed made up of leaves, husk etc.
• Bed made wet by sprinkling water.
• If bin is 2x2 inch use one pound of worms (1000 worms).
21. Feeding the worms - feed includes dung, veg waste etc.
• Mark the bin into four sections, bury Scarps few inches in first
section, after 4 or 5 days the bury scarp on second like wise.
• This makes worms to move.
Harvesting - Vermicompost is ready in two months.
• The entire content piled as pyramid shape in a bright light, the worms
drive down.
• After 10-15 minutes gently collect the vermicompost.
22. 2. Wedge method:
• The arrangement of rows of vermibed in V-shaped.
• Organic waste and cow dung for vermibed.
• A layer of vermibed materials into row.
• The height of layer should 3-4 inches, breadth is 3 feet and
height is 1 feet.
• Water is sprinkled, worms released 1 kg per 10 feet length of
bed.
• Bed is covered by coconut or palm leaves.
• After one, second row is started, new row is at 450 angle to
first row.
• worms migrate one row to another row automatically.
• After one month first windrow can be harvested
Advantages:
• There is no need to separate worms only the compost
23. Vermicompost
• Manufactured from the buffalo / Cow dung & biomass used by
Vermiculture technology and Scientific Composting
Contains
• Macro nutrients
• Micro nutrients
• Vitamins
• Enzymes
• Hormones like Auxins and Cytokinins
• Beneficial Soil Microflora like Bacteria, Actinomycetes, Protozoans,
Fungi and others
24. Features of Vermicompost
• NPK level is high
• Contains Plant growth promoting rhizobacteria
• Humic acid – helpful for balancing the pH level in the
soil
• Protect ecosystem
• Reduce biological magnification
• Waste into wealth
• Micronutrients is high
• Auxin and Gibberlin – Plant growth hormones
• Physico chemical modulators
• Good secondary decomposer – Stability, Water
infiltration and water retention
25. Used For
• Gardening: Vegetable, Roof top,
herbal
• Organic Landscaping
• Agricultural Farms
• Fruit trees (Horticulture)
• Flowering Plants (Floriculture)
• Natural Lawn and Garden care
• Tissue culture Plants
• Sericulture
• Aquaculture
Benefits
• Enables efficient growth
• Increases moisture retention
• Promotes microbial activity
• Controls pest & diseases
27. Vermiwash
•Vermiwash is a Brown colored liquid fertilizer,
which is collected after water passes via a worm
culture column.
•As storehouse of nutrients and microorganisms,
Vermiwash is used as a foliar spray for crops.
•We prepare Vermiwash while maintaining high
concentrations of micro and macronutrients, plant
hormones to ensure healthy development of
plants.
28. Preparation of Vermiwash:
• Vermiwash is a liquid that is collected after
the passage of water through a column of
worm action and is very useful as a foliar
spray.
• It is a collection of excretory products and
mucus secretion of earthworms along with
micronutrients from the soil organic
molecules.
• It is a clear and transparent, pale yellow
coloured fluid.
• Worm worked soils have burrows formed
by the earthworms.
29. • Bacteria richly inhabit these burrows,
also called as the drilospheres
• Water passing through these passages
washes the nutrients from these
burrows to the roots to be absorbed
by the plants.
• Water is allowed to fall drop by drop
from a pot hung above the barrel into
the vermicomposting system.
30. How To Use
• Dilute with water (10%) before spraying
effectively on any plant
• Vermiwash should be diluted 5 to 10
times with water and then applied
• Can also be mixed with cow urine and
diluted for use as foliar spray and
pesticide as follows
• 1 litre of cow urine
• 1 litre of vermiwash
• 8 litres of water
31. Organic Farming
•Organic manure and natural methods of plant
protection
•Eco-friendly method – improves soil health and water
holding capacity – soil fertility
•Aims – production of quality and safe agricultural
products
•Popular in worldwide and global demand of products
•Components – Crop managements, waste recycling,
weed management, pest control, resistance, biological
chemicals, biological disease control, bioherbicides,
bioinsecticides and biofungicides
32. Advantages
• Supplies all nutrients
• Optimal conditions in the soil
• High yield and good quality
• Improvement of growth and physiological activities of the plant
• Carbon content-water holding capacity
• Restores pH – chemical fertilizers – acidic soil
• Healthy food
• Resistant plants
Disadvantages
• More labour
33. Panchagavya
• It is organic and made from the combination of five products
including cow’s dung, urine, milk, curd and ghee.
Benefits:
• Panchagavya acts as a growth-promoter and immunity
booster
• Safeguards plants and soil micro-organisms
• Increases Crops, vegetable and fruit production
• Various crops such as rice, a variety of vegetables, fruit crops
• Plants produce larger leaves
• Roots helps in better intake of nutrients and water.
34. Suitable For:
• Organic Farming
• All crops in Agriculture
• Herbal plants
• Flori culture
• Contract farming
Applications :
• Spray system
• Water Irrigation system
• Seed/Seedling treatment
