1. When one solid penetrates another, their surfaces intersect along a curve. This curve of intersection is common to both solids and results from their interpenetration.
2. Curves of intersection show the exact maximum surface contact between two solids, which is important for making strong, leak-proof joints when objects are joined together.
3. The document provides examples of curves of intersection for different combinations of solids penetrating each other, such as cylinders, cones, and prisms, along with step-by-step instructions for constructing their projections.
This document discusses the intersection of surfaces between different solids. It provides examples of 8 cases of solids intersecting, including cylinders, prisms, cones, and presents the common steps to solve such problems by drawing the projections and curves of intersection. Sample problems are provided for each case with descriptions of the solids and their orientations for analysis.
1. The document discusses the intersection of surfaces between different solids, providing examples of cylinders intersecting cylinders, prisms intersecting cylinders, cones intersecting cylinders, and other combinations.
2. It presents the common construction method for drawing the intersections, which involves drawing the three views of one solid standing on the horizontal plane and the other penetrating horizontally. Points of intersection are marked and projections drawn to show the curve of intersection.
3. Eight example problems are given showing the specific solids and their dimensions, and asking the reader to draw the projections and curve of intersection. Diagrams illustrate the example problems.
The document discusses the intersection of solids and curves of intersection. It provides examples of different solids intersecting, like cylinders, cones, and prisms. It explains that curves of intersection show the maximum surface contact between intersecting solids. Steps are provided to draw the projections and curves of intersection for different examples, like a cylinder penetrated by another cylinder, or a square prism penetrated by a cylinder. Real-world examples are shown like machine components or industrial equipment.
Intersection OF SOLIDES
THIS SLIDE CONTAINS WHOLE SYLLABUS OF ENGINEERING DRAWING/GRAPHICS. IT IS THE MOST SIMPLE AND INTERACTIVE WAY TO LEARN ENGINEERING DRAWING.SYLLABUS IS RELATED TO rajiv gandhi proudyogiki vishwavidyalaya / rajiv gandhi TECHNICAL UNIVERSITY ,BHOPAL.
1. When two solids intersect, their surfaces meet along a common curve called the curve of intersection. This curve shows the maximum surface contact between the solids and is important for making strong, leak-proof joints.
2. The document provides examples of curves of intersection for different geometric solids intersecting in various configurations, such as cylinders, prisms, cones, and other industrial parts.
3. Step-by-step procedures are described for drawing the projections of the solids and determining the curves of intersection in different cases, including cylinders penetrating cylinders, prisms penetrating cylinders, cones penetrating cylinders, and other configurations.
This document provides examples and step-by-step instructions for drawing the curves of intersection that result when one solid penetrates another. It begins with definitions and examples of curves of intersection and their importance for joining objects. It then presents 8 example problems showing solids like cylinders and prisms in different penetrating configurations. For each problem, it provides the views and guides the reader in constructing the curves of intersection between the solids using common construction steps.
When one solid penetrates another, their surfaces intersect along a curve. This curve of intersection is common to both solids and results from their interpenetration. Drawing curves of intersection is important when joining two objects, as it shows their exact maximum surface contact for a strong, leak-proof joint. The document then provides examples of solids intersecting and instructions for drawing the curves of intersection in their projections.
1. When one solid penetrates another, their surfaces intersect along a curve. This curve of intersection is common to both solids and results from their interpenetration.
2. Curves of intersection show the exact maximum surface contact between two solids, which is important for making strong, leak-proof joints when objects are joined together.
3. The document provides examples of curves of intersection for different combinations of solids penetrating each other, such as cylinders, cones, and prisms, along with step-by-step instructions for constructing their projections.
