The Unified Process (UP) is a software development process that provides guidance on team activities and work integration. It originated from issues with traditional processes being too diverse and outdated. Key aspects of UP include being use-case driven, architecture-centric, and iterative/incremental. UP follows a lifecycle of inception, elaboration, construction, and transition phases within iterative development cycles. While UP addressed issues with prior methods, its weaknesses include not covering the full software process and tools-focus not suiting complex systems.

1. Unified Process
DANIYAL YOUNIS

2. Reasons for Unified Process
1. Software becomes more complex and is updated fast
2. Software developer uses methods that are as told as 25 years ago
3. Development process is diverse

3. Precursor for Unified Process
Set of activities to transform a user’s requirements into a software.
Software Development
Process (Diversity)
Unified Process
User’s
Requirement
Software
System

4. What does Unified Process do?
1. Provides guidance to the order of team’s activities
2. Integrates team’s work and individual’s work
3. Specifies artifacts
4. Offers criteria for monitoring and measuring

5. History of Unified Process
• 1967: Ericsson software engineering process
- Component-based
- Divide and Conquer
- “traffic cases.”
• 1987: Ivar Jacobson, Objectory
- Workflaws: Requirements, analysis. Design, code and test
- Document driven: customized templates

6. History of Unified Process
• Rational
- Iterative development process
- Acquired Objectory in 1995 and formed
Rational Objectory Process (ROP)
Complementary approach:
Evolved into Rational Unified Process in 1998
- Process model
- Templates
-1999: Jacobson published Unified Software
Development Process

7. Key Aspects of Unified Process
1. Use-case driven
2. Architecture-centric
3. Iterative and incremental

8. Use-Case Driven
Use-Case Driven means:
Development process proceeds through a series of
workflows that derive from use cases.

9. Terminologies
Users: Someone or something that interact with systems
Use Case: interaction between users and system, what
the system supposed to do for each user?
Use Case Model: collection of users; decription of complete functionality

10. Initiate AND bind
1. Tool for specifying requirements
2. Driving design
3. Source for testing

11. Architecture-Centric
Architecture is the view of the whole design with key
Characteristics and without too many details
• Only 5-10% use cases
• Growth with use case in parallel (structure and function)

12. Simplified Process
1. Rough outline (use case independent )
2. Subset of identified use cases (5-10%)
3. More use cases specified, more architecure discovered

13. Use Case and Architecture
System architecture
Drive Influence
Use Case

14. Iterative and Incremental ??
Iteration: Steps in the workflow (mini-project)
• Create a design for relevant use cases
• Implement with components
• Required iteration in loigcal order for economy
Incremental: Growth in the product (might not be additive)

15. Relationship of 3 concepts
USE CASE
ARCHITECTURE
ITERATION
Define
Goals
Guide
Drive
Drive
influence

16. Lifecycle of Unified Process
• Each cycle concludes with a product release to customers
• Each cycle consist of four phases:
1. Inception
2. Elaboration
3. Construction
4. Transition

17. Phases within the cycle
Iteration

18. Phase-I Inception
• Development a good idea into a vision of the end product
• Business case for the product is presented
• Establish goals
• Build business case
• Identify essential system requiremnet

19. Phase-II Elaboration
Here architecture is expressed as a view of different models
• Develop architecture
• Capture functional requirements as use cases
• Identify non functional requirements
• Plan the construction
• Continue risk management

20. Phase-III Construction
Muscle built: software added to the architecture
• Build the system
• Maintain architectural integrity
(Architecture is stable but might has minor changes)
• Iterative, incremental
• However, is it sufficient to take early delivery

21. Phase-IV Transition
Prodcut move to beta release
Trail
Defects and deficiencies are reported.
Correctness and improvement
• Final testing (system, acceotance, beta)
• Training customer personal
• Documentation, installation and consultation
• Perform postmortem review

22. Weaknesses of RUP
Weaknesses of RUP:
1. Only developing process, not the entire software process
2. Not supporting multi-system infrastructure development
efforts
3. Iterative nature foreign to experiences developers
4. Tools-driven approach, not sufficient for complex system

23. RUP and UP
UP is more of a philosophy of how to run development
Project
RUP is Rational Commercial product

24. Rational Unified Process
Question & Queries
