7. AIM & INTRODUCTION TO
THE PROJECT
AIM : To design the circuit of NOR gate using
diodes, switches, transistors, LED, battery, etc.
Introduction (procedure) :
This project entitled “Two-Input NOR gate” is
designed using basic equipments which are
connected accordingly. The gate takes two input
through different switches and gives a single output.
The different carbon resistors are used to control the
resistance in the circuit.
The circuit is made by connecting a 9V battery and
then the input switches that allow the input in the
circuit. Then the transistor used amplifies the
electronic signals. The components of the circuit are
connected as required and then only the circuit gives

8. MATERIAL REQUIRED
Wires
LED
Switches Battery

9. Diode Transistor
Carbon Resistor

10. DESCRIPTION OF MATERIALS USED
1. Electric Wires : It’s a single, flexible
stand of metal that is used in the circuit
for forming a working circuit as
mentioned in this project.
2. Carbon Resistors : It’s a passive-two
terminal electrical component that
implements electrical resistance as a
circuit element. In electronic circuits,
resistors are used to reduce current
flow, adjust signal levels, to divide
voltages, among other uses.
3. Switches : It’s an electrical component
that can “make” or “break” an electrical
circuit, interrupting the current or
diverting it from one conductor to
other. It is basically used to start and
stop the flow of current in a circuit on
our own wish.

11. 1. Transistors : It’s a semiconductor
device used to amplify or switch
electronic signals and electrical power.
It’s composed of semiconductor
material. The Transistors are the
fundamental building block of same
modern electronic devices, and is
obiquitous in modern electronic
system.
2. LED : It is a Light-Emitting Diode that
has to be lighten up when the circuit is
in working mode. So, efficient current
should be supplied for lightening up of
LED.
3. Battery : It converts chemical energy
directly to electrical energy. It’s a
source of energy which provides a push
- a voltage - of energy to get the
current flowing in a circuit. It’s an
essential component of any circuit.
4. Diodes : Semiconductor device with 2
terminals typically allowing the flow of

12. CIRCUIT DIAGRAM

13. NOR - GATE
 The Nor-Gate is a digital logic gate that
implements logic NOR- it behaves
according to the truth table given below.
It may have 2 or more input but only one
output.
Truth – Table
 A high output [1] results if both the
inputs to the gate are low [0].
 If one or both input is high [1], a low
output [0] results.
INPUT A INPUT B
OUTPUT
(A)NOR(B)
0 0 1
0 1 0
1 0 0
1 1 0

14. About NOR Gate :-
It’s the negative of the or operator.
It’s a functionally complete
operator. The NOR gate can be
combined to generate other logic
gates.
Symbols:-
or
Expression:-
Y =

15. Alternative for NOR gate :-
If no specific NOR gates are
available, one can be made from
NAND gates, because NAND and
NOR gates are considered as
universal gates i.e., they can be
used to make all other gates.
NAND gate construction:-

16. BASIC GATES FROM NOR GATE
1. NOR gate by NOR gate:-
By using one NOR gate we can obtain the
function of NOR gate by combining both
inputs as a single input.
Truth Table:-
2. OR gate by NOR gate:-
By using a 2 NOR gates we can obtain the
function of OR gate.
A X
0 1
1 0

17. Truth Table of OR gate:-
3. AND gate from gate:-
By using 3 NOR gates we can obtain the function
of AND gate.
Truth Table:-
A B R X
0 0 1 0
0 1 0 1
1 0 0 1
1 1 0 1
A B !A !B Q
0 0 1 1 0
0 1 1 0 0
1 0 0 1 0
1 1 0 0 1
