4. Event processing with
Apache Storm
Nuno Caneco - Tuga IT - 20/May/2017

5. Nuno Caneco
Senior Software Engineer @ Talkdesk
/nunocaneco
nuno.caneco@gmail.com
/@nuno.caneco
Who am I

6. Stream Processing - Why?
WHY
● Data is crucial for business
● New data is always being generated
● Companies want to extract value from
data in “real-time”
USE CASES
● Fraud detection
● Sensor data aggregation
● Live monitoring

7. What is Storm?
Apache Storm is a free and open source distributed realtime computation system.
Storm makes it easy to reliably process unbounded streams of data, doing for realtime
processing what Hadoop did for batch processing. Storm is simple, can be used with
any programming language, and is a lot of fun to use!
Storm has many use cases: real time analytics, online machine learning, continuous
computation, distributed RPC, ETL, and more. Storm is fast: a benchmark clocked it at
over a million tuples processed per second per node. It is scalable, fault-tolerant,
guarantees your data will be processed, and is easy to set up and operate.
http://storm.apache.org/

8. Under the hood
(A bit of)

9. Architecture
Nimbus
Master node
Zookeeper
Zookeeper
Cluster
coordination
Supervisor
Supervisor
Supervisor
Supervisor
Cluster
Worker
process
Worker
process
Worker
process
Worker
process
Worker
process
Worker
process
JVM
instances

10. Concepts

11. Topology
Topologies combine individual work units to be applied to input data
Spout
Bolt A
Bolt C
Bolt B
data
[Tuple]
[Tuple]
[Tuple]
[Tuple]
[Data out]
Bolt D
[Tuple]
Topology

12. Spout
● First node of every topology
○ Collects data from the outside world
○ Injects the data on the topology in order to be processed
● Must implement ISpout interface
○ BaseRichSpout is a more convenient abstract class
Spouts

13. Bolt
● Middle or terminating nodes of a topology
● Implements a Unit of Data Processing
● Each Bolt has an output stream
● Can emit one or more Tuples to other Bolts subscribing the output
stream
● Must implement IBolt
○ BaseRichBolt is a more convenient abstract class
Bolt

14. Tuple
Hash-alike data structure containing the data that flows between Spouts and Bolts
Data can be accessed by:
● Field index: [{0, “foo”}, {1, “bar”}]
● Key name: [{“foo_key”, “foo”}, {“bar_key”, “bar”}]
Values can be:
● Java primitive types
● String
● byte[]
● Any Serializable object

15. Example: Alert on monitored words
Monitored
Words Bolt
Collector
Spout
{Message} Split
Sentence
Bolt
{Word, MessageId}
Message
queue
[Message]
Notify User
Bolt
Store event
on DB Bolt
{MonitoredWord,
MessageId}
{MonitoredWord,
MessageId}

16. Demo

17. Message Processing Guarantees
Message
is lost
Error

18. Acknowledging Tuples
● ack(): Tuple was processed successfully
● fail(): Tuple failed to process
Tuples with no ack() nor fail() are automatically replayed
Tuples with fail() will fail up the dependency tree

19. Acknowledge done right

20. Ack: Anchoring
public class SplitSentence extends BaseRichBolt {
public void execute(Tuple tuple) {
String sentence = tuple.getString(0);
for(String word: sentence.split(" ")) {
_collector.emit(tuple, new Values(word));
}
_collector.ack(tuple);
}
}
}
Anchors the
output tuple to
the input tupleAcknowledges
the input tuple

21. Dealing with fail()
Spout
Bolt Bolt
BoltBolt Bolt✅ ✅
✅
✅
✅
✅ Spout
Bolt Bolt
BoltBolt Bolt✅ ✅
✅
❌
❌
❌

22. Beware!
Storm is designed to scale to process millions of messages per second.
It's design deliberately assumes that some Tuples might be lost.
If your application needs Exactly Once semantics, you should consider using
Trident (will talk about that in a while)
Storm does not ensure
exactly once processing

23. Demo

24. Parallelism
Cluster node
Worker Process Worker Process
Cluster Node → 1+ JVM instances
JVM Instance → 1+ Threads
Thread → 1+ Task
Each instance of a Bolt or Spout is a
Task
Thread Thread
Thread Thread
Task Task
Task
Task Task
Task Task Task

25. Parallelism Example
Config conf = new Config();
conf.setNumWorkers(2); // use two worker processes
topologyBuilder.setSpout("blue-spout", new BlueSpout(), 2);
topologyBuilder.setBolt("green-bolt", new GreenBolt(), 2)
.setNumTasks(4)
.shuffleGrouping("blue-spout");
topologyBuilder.setBolt("yellow-bolt", new YellowBolt(), 6)
.shuffleGrouping("green-bolt");

26. Stream grouping
● Shuffle grouping: randomly distributed across all downstream Bolts
● Fields grouping: GROUP BY values - Same values of the grouped fields will be
delivered to the same Bolt
● All grouping: The stream is replicated across all the bolt's tasks. Use this grouping
with care
● Direct grouping: The producer of the Tuple must indicate which consumer will
receive the Tuple
● Custom Grouping: When you go NIH

27. Storm UI - Cluster

28. Storm UI - Cluster

29. Storm UI - Topology

30. Storm UI - Topology

31. Other features: Trident
Trident is an abstraction layer to manage state across the topology
The state can be kept:
● Internally in the topology - in memory or backed by HDFS
● Externally on a Database - such as Memcached or Cassandra

32. Other features: Storm SQL
The Storm SQL integration allows users to run SQL queries over streaming data
in Storm.
Cool feature, but still experimental

33. Q&A
Questions ?

34. Thank you
/nunocaneco
nuno.caneco@gmail.com
/@nuno.caneco

35. PLEASE FILL IN EVALUATION FORMS
FRIDAY, MAY 19th SATURDAY, MAY 20th
https://survs.com/survey/cprwce7pi8 https://survs.com/survey/l9kksmlzd8
YOUR OPINION IS IMPORTANT!

36. THANK YOU TO OUR SPONSORS
PLATINUM
GOLD SILVER

38. Trident: How it works
1. Tuples are processed as small batches
2. Each batch of tuples is given a unique id called the "transaction id" (txid).
a. If the batch is replayed, it is given the exact same txid.
3. State updates are ordered among batches. That is, the state updates for
batch 3 won't be applied until the state updates for batch 2 have succeeded.

39. Trident: Transactional Spout
Trident
Store
java => [count=5, txid=1]
kotlin => [count=8, txid=2]
csharp => [count=10, txid=3]
["kotlin"]
["kotlin"]
["csharp"]
Batch txid=3
Trident
Store
java => [count=5, txid=1]
kotlin => [count=10, txid=3]
csharp => [count=10, txid=3]
"kotlin" += 2
"csharp" += 0
