1. Product Presentation
Trailing Shields
Titanium
Welding

2. 2
ARGWELD®
Trailing Shields
ARGWELD® Trailing Shields

3. 3
Main Features
ARGWELD® Trailing Shields
■ Designed for effective gas coverage when welding
titanium alloys
■ Ensures welds are left bright and shiny and eliminates both
discolouration & oxidation
■ For use on flat sheet or plate & internal or external welds on tubes,
pipes, tanks, vessels, heat exchangers etc.
■ Fit any make of GTAW/Tig ,PAW/Plasma, or GMAW/Mig
welding torch for manual or automatic welding
■ Reduces gas consumption, saves re-work &
eliminates wasted material costs, due to oxidation

4. 4
Main features continued
ARGWELD® Trailing Shields
■ Reduces gas consumption, saves re-work & eliminates wasted
material costs, due to oxidation
■ Flexible silicone side walls to create closed inert gas chamber
■ Replaceable silicone rubber side walls
■ Auxiliary hoses for greater shield gas coverage where required
■ Triple mesh gas distribution system non
turbulent gas flow

5. 5ARGWELD® Trailing Shields
Potential Customers
■ Aero engine manufacturing and maintenance companies
■ Boiler, Heat Exchanger, Vacuum Tank, Cryotank manufacturers
■ Semi conductor, petrochemical, food, dairy piping fabricators
■ Racing and sports car manufactures
■ Every titanium alloy fabricator wishing
to save money by dramatically
reducing cleaning costs

6. 6
Example
ARGWELD® Trailing Shields
A typical costing of a weld with trailing shield vs one without:
36'' Ø Tank, vessel or pipe
UK List price:
Trailing Shield for a 36'' Ø tank… £196

7. 6
Example
ARGWELD® Trailing Shields
36'' Ø Pipe/Tank
welded with no TRAILING
SHIELD used
36'' Ø Pipe/Tank
welded with an ARGWELD®
TRAILING SHIELD
Grinding time1 hr (est.) £30.00 £0.00
Cleaning material costs £10.00 £0.00
Disposal costs £10.00 £0.00
Grinding consumables £10.00 £0.00
Administration costs* £100.00 £10.00 (1 product only)
Cleaning time 1 hr (est.)
subject to size of weld.
£30.00 £0.00
Cost of ARGWELD®
Trailing Shield
£0.00 £196.00
Once only purchase
Total costs £190.00 (every weld) £206 (first weld only)
Approximately £10 for all
Subsequent welds

8. 7ARGWELD® Trailing Shields
Fast Payback
■ 2 Welds achieves payback
■ The use of a trailing shield of some kind for titanium welding
is almost mandatory, for the applications where the product
cannot be placed inside a Welding Enclosure
■ When welding smaller titanium components, that could be
placed in a Welding Chamber of some kind, Trailing Shields
might be dramatically more cost effective than
the use of a Welding Chamber

9. 8
Automatic inline seam welder
ARGWELD® Trailing Shields
Front: Trailing shield, homemade.
Rear: Argweld®
Trailing Shield.
Argweld Trailing Shield
Homemade Trailing Shield

10. 9
Trailing Shields – Internal Welding
ARGWELD® Trailing Shields
Trailing shield for internal welding of large diameter
pipes and tubes, tanks and vessels

11. ARGWELD® Trailing Shields 10
Trailing Shields – Family shot
Family of shields for Automatic Welding Machines.
All have secondary gas shield delivery.

12. Trailing Shields – External Welding
ARGWELD® Trailing Shields 11
Trailing shield for the external welding of pipes and tubes

13. ARGWELD® Trailing Shields 12
Trailing Shield – Fitted to Mig torch
ARGWELD®
Trailing Shields

14. ARGWELD®
Trailing Shields
ARGWELD® Trailing Shields 13
How a Trailing Shield can be used to shield the outside of a
circumferential weld while being welded from the inside.
(Inset bottom right : finished weld with no discoloration)

15. Trailing shield – Automatic Welding
ARGWELD® Trailing Shields
Trailing Shield for automatic welding machine used for flat plate
(Note dual shield gas supply)
A) 250 mm/10” approx Body length
B) 320 mm/12.6” approx Length including gasket
C) 50 mm/2” approx Body width
D) 75 mm/3” approx Width including gasket
14

16. Inside view Trailing Shields
ARGWELD® Trailing Shields 16
Inside view of a Trailing Shield, showing gauze mesh for uniform gas
distribution and high temperature resistant silicone rubber
replaceable skirts.

17. ARGWELD®
Thank You
2013
All photos courtesy of Huntingdon Fusion Techniques Limited, UK.
