This document proposes a system management framework leveraging OpenStack. It discusses problems with current vendor-specific management solutions and scattered interfaces. The proposed solution would use OpenStack components like Glance, Heat, and Ironic for deployment and management of physical machines. A converged user interface and REST API would provide software/hardware monitoring, visibility, alerts, and diagnostics. Vendors could implement plugins to integrate their specific capabilities. The goals are to build prototypes and initiate an open source project incubated within OpenStack.

1. © Copyright 2013 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. HP Restricted
System management
framework leveraging
OpenStack
Gary Duan

2. © Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.2
Agenda
Problem Statement
Our Solution
Competitive Approaches
Next Steps

3. © Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.3
Problem Statements
 For physical machines in data center
Deployment:
Install/upgrade/re-install using PXE/chef/puppet
System management: Vendor-specific solutions, Not compatible with other vendors’ hard wares
HP’s OneView, Cisco’s UCS Mgmt System
Enterprise Customized scripts/tools to monitor/control via SNMP, IPMI, etc
Hardware diagnostics
Vendor-specific solutions with their specific UI
Scattered, vendor-specific, no unified interface
 In OpenStack, hosts want being managed in a convennient way

4. © Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.4
Our Solution
 Converged Management Framework
 Deployment
 Monitor/Management
 Diagnostics
 Is it possible to manage physical machines leveraging OpenStack?
 OpenStack existing utilities
Glance(Image Management) +Heat(Collaboration):
Automation of Install/upgrade/re-install
Ironic:
Manage bare-metal: IPMI, SSH, PXE
Ceilometer:
Obtain info and status of target and notify upon events

5. © Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.5
Our Solution(Cont’d)
 To be Done
Framework
Monitoring, Visibility, Alert, Failure Remediation, Management, Report, Deployment, Diagnostics
Converged user interface and REST API
display software/hardware info/status;
manage physical machines, etc
Plugin mechanism allow vendor to implement their specific features
Obtain info/status to feed ceilometer-agent
Allow vendors to implement their drivers for storage/switches, and even servers, besides WBEM;
Customer can also define their monitor target/policies
Management: power management, plan for down
Online diagnostics: Define plugin interface; leverage WBEM/Heat
Offline diagnostics: Define plugin interface; leverage EFI, leverage Heat
(nice to have) Preventive hardware failure with big-data thinking:
Failure probability curve of specific hardwares based on their use pattern, vendors’ data and datacenter’s data
Failure probability of servers/hardwares based on datacenter’s data(public database or enterprise own database)
Other popular preventive features

6. © Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.6
Competitive Approaches
 Current Manage Softwares
o Nagios(GPLv2): http://www.nagios.com/products/nagioscore
o GoundWork: http://www.gwos.com/
o Zabbix: http://www.zabbix.com/
o Cacti: http://www.cacti.net/
o OpenNMS (GPL): http://www.opennms.org/wiki/Main_Page
 Compare with Our solution
o Brand, owned by small company V.S. OpenStack: vendors support, enterprise use
o Just management, no deploy/diag V.S. Includes mgmt, deployment, diagnostics
o Not easy to customize V.S. REST API, Plugin for monitor target and policy
o Not include vendors’ specific hardware V.S. Plugin mechanism, allows vendor implement
diagnostics

7. © Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.7
Next Steps
 Tasks
 Investigate enterprise’s system management solution more deeply
 Make proto and PoC
1) First, targeted for hosts management in OpenStack
2) Then, extend to manage all machines in datacenters
 Initiate an Open Source project for this
 incubated/formal project of OpenStack

8. © Copyright 2013 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. HP Restricted.
Thank you

9. © Copyright 2013 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.
Backup Slides

10. © Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.10
Puppet

11. © Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.11
Ceilometer
