GPUs should complement, not replace, the Hadoop ecosystem for big data workloads. Replacing the entire big data stack would be too costly. The presenter believes GPUs are best suited for accelerated computation and a few other use cases to gain an initial foothold in the market. Existing Python interfaces to machine learning frameworks rely too heavily on network communication and serialization, introducing significant overhead. Nd4j and Jumpy provide alternatives that use direct C++ interfaces and pointers for lower latency between Python and deep learning operations on CPU and GPU.

2. Who are we?
This slide shows that GPUs should complement the big data stack on the Hadoop ecosystem, rather than trying to
replace Hadoop etc. outright. Wholesale replacement of the big data stack will be cost-prohibitive to many clients. We
believe the right approach is to sell GPUs for accelerated computation and a few other use cases. That’s our beach
head. (Obviously, the widening functionality of the Volta will change the GPU ecosystem.)
Founded 2014
Distributed worldwide
Lots of activity in China

3. Skymind in China

4. Most JVM python interfaces
● Network based. Requires gateway and py4j
● Tons of overhead. Often a bottleneck with real Spark
jobs
● Places a focus on “pushing logic down to scala”
● Doesn’t interop well with existing python ecosystem
● Often api compatibility issues
● “Good enough” for basic use cases despite overhead

5. Basic facts about overhead
● In depth paper: https://arxiv.org/pdf/1612.01437.pdf
● Python vs scala: 15x slower
● Much of this is due to network traffic
● Serialization is another big problem
● Imagine saving objects every time you run compute.

6. Distributed Deep Learning bottlenecks
● Network overhead from param servers
● Data movement between cpu and gpu
● Buffer allocation for compute
● Data Loading and input creation (creating tensors
from data)

7. Linear Algebra in python
● C based internally
● Python is just an interface
● Tend to interop with numpy pointers directly
● Supports cpu and gpu
● For DL often varied engines (MPI,GRPC,..)
● Often extended in C

8. Linear Algebra in spark
● Based on breeze and net lib java (not maintained
anymore, limited to cpu)
● Most routines are Scala based
● On heap memory (bad for latency)
● Cuda support is sparse at best
● Doesn’t conform with industry standards (python)
● Not meant for heavy compute (hardware accel)
● Relies on spark for most ops (you can’t do this with
deep learning)

9. Minor conclusions
● 1 of these is not like the other
● Hard to interop with python ecosystem
● Spark tries to be something it’s not re: linear algebra
● Spark should do data loading. Not linear algebra
better handled by c++ (simd,gpus,..)
● Alternatives are needed (more specialization) (a focus
on c++ with pythonic conventions)

10. Nd4j
● Java based api, c++ core
● Own off heap memory management (even for gpu)
● Soon: Autodiff and graph execution (graph of
operations) and sparse
● Similar architecture to numpy (easy interop)
(http://nd4j.org/userguide)
● Works with blas/lapack
● Generally faster than numpy even from python (as
we’ll see soon)
● It’s not python though!

11. Nd4j Parameter Server
Aeron: More stable latency than GRPC and way faster
(25x!) than TF

12. Jumpy: A better python interface
● Low latency using c internally
● Interface with nd4j <-> numpy via direct pointers
● Syntax sugar similar to numpy
● Uses jnius underneath(https://github.com/kivy/pyjnius)
● JNIUS starts and manages a JVM for you. Interops
via JNI and Cython
● Easy to extend

13. Jumpy examples

14. Thanks! Join our QQ group:

15. Conclusions and future work
● No networks! An actual path to improvement
● Reflection can be a bottleneck
● Like most useful things in python, most of it is c!
● Plans to optimize pyjnius itself
● Can enable us to interop with other parts of python
