Spark SQL is a very effective distributed SQL engine for OLAP and widely adopted in Baidu production for many internal BI projects. However, Baidu has also been facing many challenges for large scale including tuning the shuffle parallelism for thousands of jobs, inefficient execution plan, and handling data skew. In this talk, we will explore Intel and Baidu’s joint efforts to address challenges in large scale and offer an overview of an adaptive execution mode we implemented for Baidu’s Big SQL platform which is based on Spark SQL. At runtime, adaptive execution can change the execution plan to use a better join strategy and handle skewed join automatically. It can also change the number of reducer to better fit the data scale. In general, adaptive execution decreases the effort involved in tuning SQL query parameters and improves the execution performance by choosing a better execution plan and parallelism at runtime. We’ll also share our experience of using adaptive execution in Baidu’s production cluster with thousands of server, where adaptive execution helps to improve the performance of some complex queries by 200%. After further analysis we found that several special scenarios in Baidu data analysis can benefit from the optimization of choosing better join type. We got 2x performance improvement in the scenario where the user wanted to analysis 1000+ advertisers’ cost from both web and mobile side and each side has a full information table with 10 TB parquet file per-day. Now we are writing probe jobs to detect more scenarios from current daily jobs of our users. We are also considering to expose the strategy interface based on the detailed metrics collected form adaptive execution mode for the upper users.

1. #SAISEco12
Carson Wang(Intel) Chenzhao Guo(Intel)
carson.wang@intel.com chenzhao.guo@intel.com
Spark SQL Adaptive Execution
Unleashes the Power of Cluster
in Large Scale
#SAISEco12

2. #SAISEco12
About me
• Chenzhao Guo
• Big Data Engineer at Intel
• Contributor of Spark*, OAP and HiBench
• Github:gczsjdy
2
*Other names and brands may be claimed as the property of others.

3. #SAISEco12
Agenda
• Challenges
• Adaptive Execution
• Performance
3

4. #SAISEco12
Agenda
• Challenges
• Adaptive Execution
• Performance
4

5. #SAISEco12
Parallelism on reduce side
• Influence performance but hard to tune
• Manual efforts
• Too small -> Spill, OOM
• Too big -> Scheduling overhead, I/O requests
• Single spark.sql.shuffle.partitions doesn’t fit all
stages within an application
5

6. #SAISEco12
Join Strategy Selection
• Spark* chooses Join implementation(influences performance)
based on data size estimation
• BroadcastHashJoin(when 1 side < broadcastThreshold)
• SortMergeJoin
• ShuffledHashJoin
• Problem: output data size of an intermediate operator can’t be
accurately anticipated while planning
• The most efficient Join operator may not be employed
6
*Other names and brands may be claimed as the property of others.

7. #SAISEco12
Data Skew in Join
• Some partitions data >> the others’
• Poor load balancing slows down the whole
• Common ways to resolve it, but with limitation:
• Increase spark.sql.shuffle.partitions
• Increase BroadcastJoin threshold
• Add prefix to the skewed keys
7
execution time
task 0
task 1
task 2

8. #SAISEco12
Spark SQL* Execution Diagram
8
*Other names and brands may be claimed as the property of others.

9. #SAISEco12
Agenda
• Challenges
• Adaptive Execution
• Performance
9

10. #SAISEco12
Core Idea
• Transfer control (dicisions of physical plan &
parallelism) from users and static to framework
& runtime
10

11. #SAISEco12
Adaptive Execution during Planning
11
SortMerge
Join
Sort Sort
Exchange Exchange
… …
SortMerge
Join
Sort Sort
Exchange Exchange
… …
QueryStage
QueryStageInput QueryStageInput
QueryStage QueryStage
Non-AE physical plan AE physical plan
QueryStage:
To take over control and make
runtime decision, like altering
SortMergeJoin ->
BroadcastHashJoin
QueryStageInput:
After modifying the physical plans,
need to embed new RDDs in
some operators

12. #SAISEco12
Adaptive Execution during Execution
12
SortMerge
Join
Sort Sort
Exchange Exchange
… …
QueryStage
QueryStageInput QueryStageInput
QueryStage QueryStage
1.Execute child stages &
collect runtime information
2.Alter physical plan choice
3.Handle skewed Join
4.Determine reducer number
execute

13. #SAISEco12
Adaptively Determine Number of Reducers
• Enable the feature
• spark.sql.adaptive.enabled -> true
• Configurations
• Target input size for a reducer
• Min/Max reducer number
13

14. #SAISEco12 14
Adaptively Determine Number of Reducers
• Target input size for reducer -> 64MB
• Min-max reducer number -> 1-5
map side reduce side
partition merging
better load balancing
reduced I/O…

15. #SAISEco12
Alter Join Implementation at Runtime
15
SortMerge
Join
Sort Sort
QueryStage
QueryStageInput QueryStageInput
… …
only 5M !
Reduced shuffle
Broadcast
HashJoin
Broadcast
Exchange
QueryStage
QueryStageInput QueryStageInput
… …
only 5M !
runtime altering

16. #SAISEco12
• Enable the feature
• spark.sql.adaptive.skewedJoin.enabled -> true
• Configuration
• skewed factor F, skewed size S, skewed rowcount R
• A partition is considered skewed iff
• its size is larger than median partition size * F and also
larger than S or
• its rowcount is larger than median partition rowcount * F
and also larger than R
16
Handle Skewed Join at Runtime

17. #SAISEco12
Handle Skewed Join at Runtime
17
better load balancing
Partition 0
Partition 0
left table right table
Join
runtime translation
Partition 0
left table
Join
partition 0 from
mapper 1
partition 0 from
mapper 2
partition 0 from
mapper 0
right table
Union
Partition 1
Partition 2

18. #SAISEco12
Agenda
• Challenges
• Adaptive Execution
• Performance
18

19. #SAISEco12
Performance in Baidu*
• Performance boost: 50% ~ 200%
• Certain BI scenario hitting SMJ ->BHJ rule
• Long running application & use Spark as a
service
• GraphFrame
19
*Other names and brands may be claimed as the property of others.

20. #SAISEco12
Performance in Alibaba* Cloud
• TPC-DS* 1TB
• 1 master (32 Cores, 64GB RAM) + 6 slave(d1,
32 Cores, 64GB RAM)
• Overall performance boost: 1.38x, and max
performance boost: 3x
• Already incorporated Adaptive Execution in their
cloud service product
20
*Other names and brands may be claimed as the property of others.

21. #SAISEco12
Summary
• Adaptively determine reducer number
• Alter Join strategy selection at runtime
• Handle skewed Join at runtime
• More potential opportunies since Adaptive Execution
provides a runtime optimization framework
• https://github.com/Intel-bigdata/spark-adaptive
21
