This document discusses patterns in object-oriented programming versus abstractions in functional programming. It provides code examples of using functional abstractions like the IO monad and type classes in Scala. The examples demonstrate how to construct programs by composing functions, handle errors, and test programs using the IO monad. Known applications of functional abstractions include using monoids for accumulating values, functors for mapping over data types, and monads for modeling effects. The document advocates thinking algebraically by focusing on properties, extending closed data types, and building applications from small, composable abstractions.

1. Patterns vs Abstractions
Code
Motivating Examples
Applications
SCALAZ BY EXAMPLE
Figure:
Credit http://www.flickr.com/photos/slambo_42
Susan Potter @SusanPotter
ScalaPDX January 2014
https://github.com/mbbx6spp/funalgebra
1

2. PATTERNS VS ABSTRACTIONS

3. Patterns vs Abstractions
Code
Motivating Examples
Applications
OO PATTERNS VS FP ABSTRACTIONS
→
More (Subjective -> Objective)
→ More (Ambiguous -> Precise)
→ "Fluffy" Interfaces -> Generic Functions
3

4. Patterns vs Abstractions
Code
Motivating Examples
Applications
LAYING BRICKS
4

5. Patterns vs Abstractions
Code
Motivating Examples
Applications
WARNING
→
Abstract Algebra -> (Continuous, Infinite)
→ Real World -> usually (Discrete, Finite)
5

6. CODE

7. Patterns vs Abstractions
Code
Motivating Examples
Applications
EXAMPLE UNIX PIPE
1
2
3
find . -name "*. rb"
| xargs egrep "#.*? TODO:"
| wc -l
Character-based, through file descriptors
7

8. Patterns vs Abstractions
Code
Motivating Examples
Applications
EXAMPLE FUNCTION COMPOSITION
1
( length . mapToUpper . sanitize ) input
Value based, through functions
8

9. Patterns vs Abstractions
Code
Motivating Examples
Applications
VALUING VALUES IN REAL WORLD
1
2
final case class Somefink [A](a: A) extends
PossiblyMaybe [A]
final case object Nowt extends PossiblyMaybe [
Nothing ]
3
4
5
6
7
8
9
10
sealed trait PossiblyMaybe [+A]
object PossiblyMaybeOps {
def noneDefault [A]( pm: PossiblyMaybe [A])(a:
A): A = pm match {
case Somefink (x) => x
case _ => a
}
}
Note _ in second match, caters for nulls with Java interop
9

10. Patterns vs Abstractions
Code
Motivating Examples
Applications
START WITH "CLOSED" MODEL
1
2
3
4
5
6
7
8
9
final case object Production extends Env
final case object Staging extends Env
final case class QA(n: Int) extends Env
final case class Dev(u: String ) extends Env
final case object Integration extends Env
sealed trait Env
object Env {
/* companion object code ... " instances " */
}
10

11. Patterns vs Abstractions
Code
Motivating Examples
Applications
EXTEND VIA ADHOC POLYMORPHISM
1
2
3
4
5
6
// companion object for Env
object Env {
// default " instances " over type Env
// for typeclasses below
implicit val EnvRead : Read[Env] = ???
implicit val EnvShow : Show[Env] = ???
7
// maybe you want ability to use
// one of two implementations of Order [Env]
// as well as Equal [Env ]. Anyone ?
implicit val EnvOrder : Order [Env] = ???
implicit val EnvEqual : Equal [Env] = ???
8
9
10
11
12
13
}
11

12. MOTIVATING EXAMPLES

13. Patterns vs Abstractions
Code
Motivating Examples
Applications
WHY USE IO MONAD?
→
Construct I/O "programs" from parts
→ Control error handling at runtime
→ Much easier to test various scenarios
→ And more …
13

14. Patterns vs Abstractions
Code
Motivating Examples
Applications
IO: "CONSTRUCTION" (1/2)
1
import scalaz ._, Scalaz ._, effect ._
2
3
4
5
trait MyApp {
def start (env: Env): IO[Unit]
}
6
7
8
def readConfig (env: Env):
IO[ BufferedSource ] = ???
9
10
11
def parseConfig (bs: BufferedSource ):
IO[Map[String , String ]] = ???
12
13
14
def setupMyApp (pool: ConnectionPool ):
IO[MyApp ] = ???
14

15. Patterns vs Abstractions
Code
Motivating Examples
Applications
IO: "CONSTRUCTION" (2/2)
1
2
3
4
5
def initialize (env: Env): IO[ MyApp] = for {
bs
<- readConfig (env)
map
<- parseConfig (bs)
app
<- setupMyApp (pool)
} yield app
6
7
8
def withCookieSessions (app: MyApp ):
IO[MyApp] = ???
9
10
11
def withServerSessions (app: MyApp ):
IO[MyApp] = ???
12
13
14
15
16
def run(env: Env): IO[Unit] = for {
app
<- initialize (env)
app2 <- withCookieSessions (app)
} yield app2. start (env)
15

16. Patterns vs Abstractions
Code
Motivating Examples
Applications
IO: ERROR HANDLING (1/2)
1
import scalaz ._, Scalaz ._, effect ._
2
3
4
def process (rq: Request ):
IO[ Response ] = ???
5
6
7
def showErrorTrace :
Throwable => IO[ Response ] = ???
8
9
10
def logErrorTrace :
Throwable => IO[ Response ] = ???
11
12
13
def reportErrorTrace :
Throwable => IO[ Response ] = ???
16

17. Patterns vs Abstractions
Code
Motivating Examples
Applications
IO: ERROR HANDLING (2/2)
1
2
3
4
def handleReq (rq: Request )( implicit e: Env) =
env match {
case Production =>
process (rq). except ( logErrorTrace )
5
case Staging =>
process (rq). except ( reportErrorTrace )
6
7
8
case _ =>
process (rq). except ( showErrorTrace )
9
10
11
}
17

18. Patterns vs Abstractions
Code
Motivating Examples
Applications
IO: TESTING EXAMPLE
1
2
3
import scala .io .{ BufferedSource , Codec }
import scalaz ._, Scalaz ._, effect ._
import java.io.{ ByteArrayInputStream => JBAIS
}
4
5
6
7
8
9
10
11
12
implicit val codec = Codec ("UTF -8")
IO(new BufferedSource (new JBAIS ("""{
"host": " localhost ",
"port": "5432",
" driver ": "my. awesome . PostgresDriver ",
" protocol ": " postgres ",
"name": " contactsdb "
}""". getBytes (codec . charSet ))))
18

19. Patterns vs Abstractions
Code
Motivating Examples
Applications
IO: TESTING EXAMPLE
1
2
// At the end of the universe we then do ...
run(env). unsafePerformIO
3
4
5
// or whatever your starting point is , e.g.
main(args). unsafePerformIO
6
7
// only ONCE ... most of the time ;)
19

20. Patterns vs Abstractions
Code
Motivating Examples
Applications
SAME TYPE, MANY "INTERFACES"
A type defined as a Monad (think: (>>=)) can also be used
as:
→
A Functor (think: fmap)
→ An Applicative (think: <*>, pure)
→ And possibly others
though not necessarily
20

21. APPLICATIONS

22. Patterns vs Abstractions
Code
Motivating Examples
Applications
KNOWN USES
→
Monoids:
Accumulators are everywhere, almost
→
Functors:
Lots of uses with common and user defined types
→
Monads:
→
Applicatives:
→
More:
Effects, "linear happy path", and more
"validations", safer Java interop, and more
e.g. Arrows, Zippers, Lenses, Tagged Types, …
22

23. Patterns vs Abstractions
Code
Motivating Examples
Applications
THINKING ALGEBRAICALLY
→
Properties:
→
Data Types:
→
Abstractions:
property based testing: quickcheck, scalacheck
start closed, extend using "type classes",
dependent types, etc when relevant
build small building blocks, use motar to
build solid walls
→
Dist Systems:
using algebraic abstractions, properties to
build more useful distributed systems
23

24. Patterns vs Abstractions
Code
Motivating Examples
Applications
QUESTIONS?
24
