This document discusses various techniques for scaling web applications, including horizontal scaling by adding more servers behind a load balancer, using a session store like Redis for shared sessions, centralized logging, and continuous integration to deploy updates. It also covers load balancing with HAProxy, monitoring with Zabbix, caching with Varnish, database scaling with master-slave replication or sharding in MongoDB, and using queues like RabbitMQ. The key is to think of the application as independent workers that can run on multiple servers rather than a single instance.

1. Scalable web apps
execution time
vs
development time
Piotr Pelczar
me@athlan.pl

2. Types of scaling
Vertical scaling
Horizontal scaling
scale up
scale out

3. Think about your app as a worker
not single instance
OS
Load balancer
App
Server #1
App #1
App #2
Server #2
App #3
App #4
Server #3
App #5

4. Think about your app as a worker
not single instance
Load balancer
Server #1
App #1
Server #3
Load balancer
App #2
Server #2
App #3
App #4
App #5
Server #n

5. Sessions
We need:
• Common
• Fast
• Persistent
Storage for sessions.

6. Sessions
OS
Load balancer
App
Server #1
App #1
App #2
Server #2
App #3
Session storage
App #4
Server #3
App #5

7. Sessions - Redis
•
•
•
•
•
Key-value in memory database (hash-tabled)
Scalable up to 1k nodes
Partitioning with Query routing
Non blocking M-S replication on nodes
Clustered (currently not production ready)
http://athlan.pl/symfony2-redis-session-handler/

8. Redis - Partitioning with Query routing
Query
random
node
Miss
Node #1
Hit, abort
Node #2
Node #3
Also supported:
• Client-side partitioning (app calls appropriate
node)
• Proxy assisted partitioning (proxy selects
appropriate node)

9. Centralized Logging
• Logs should be centrailzed to avoid taking
notice to each node separately
• Approaches:
– File replication (rsync + cron)
– syslog (easy to integrate with log4j)
• syslogd over UDP p:514
• rsyslog over TCP, stores data in db

10. Common storage, no local changes!
• Keep storage avaliable to all nodes
– Symfony2 Gaufrette Bundle
•
•
•
•
•
FTP
Amazon S3
OpenCloud
AzureBlobStorage
Rackspace

11. Architecture
OS
Load balancer
App
Server #1
App #1
App #2
OS
Session storage
Server #2
App #3
App #4
Server #3
App #5
Files storage abstraction
Centralized logging

12. Continuous Integration
• To keep all nodes up-to-date, you need CI
• Automatize disabling nodes, building,
deploying
– Jenkins CI

13. Contineous Integration
1. Disable service on node
2. Deploy/build app
1. Copy files
2. Update db schema (liquibase, ORM schema
update)
3. Execute scripts
3. Re-run service

14. Balance the payload - HAProxy
Yeah guys, this is logo :)
But no schema is needed
just imagine how it works.
• Very, very fast proxy!
• Software TCP/HTTP load balancer
• Different node selecting algorithms:
– roudrobin (limit 4128)
– static-rr
– leastconn (lowest number of connections)

15. Balance the payload - HAProxy
• You can check node’s status by pinging
• Dead node is excluded from balancing strategy
vi /etc/haproxy/haproxy.cfg
option httpchk HEAD /check.txt HTTP/1.0
server webA 192.168.0.102:80 check
server webB 192.168.0.103:80 check

16. Balance the payload - HAProxy
• Monitor node’s status by read stats from
socket via socat.
echo "show stat" | socat
/tmp/haproxy.sock stdio

17. Balance the payload - HAProxy
• Monitor node’s status by native stats webapp
console

18. Nodes Monitoring - Zabbix
• Zabbix, centralized server monitoring

19. Zabbix + HAProxy
• UserParameter=haproxy.qcur[*],
echo "show stat" | socat
/tmp/haproxy.sock stdio | grep -i
'$1' | sed 's/,/ /g' | awk
'{print $$3}'

20. Reverse Proxy and Varnish cache
• Global virtual user = global cache
http://tomayko.com/writings/things-caches-do

21. Reverse Proxy – Expiration model
http://tomayko.com/writings/things-caches-do

22. Reverse Proxy – Expiration model
http://tomayko.com/writings/things-caches-do

23. Reverse Proxy – Validation model
http://tomayko.com/writings/things-caches-do

24. Reverse Proxy – Validation model
http://tomayko.com/writings/things-caches-do

25. Reverse Proxy and Varnish cache
Apache
:81
Varnish
:80
App

26. Reverse Proxy and Varnish cache
Apache
:8081
Varnish
:8080
App
HAProxy
:80
Apache
:8083
Varnish
:8082
App

27. Reverse Proxy and Varnish cache
Apache
:8081
App
Varnish
:80
HAProxy
:81
Apache
:8082
App

28. Varnish and ESI
<!DOCTYPE html>
<html>
<body>
<!-- ... some content -->
<!-- Embed the content of another page here -->
<esi:include src="http://..." />
<!-- ... more content -->
</body>
</html>

29. Scaling databases - Master slave
Write
Master
Slave
Read
• All data redundancy
Slave
Slave

30. MongoDB scaling
• Common models to spread data over nodes:
– range keys
– hash keys
• Many nodes on cheap machines
• No all data redundancy in each node

31. MongoDB – range-based keys
http://docs.mongodb.org
• Awesome for range queries (grab data from min nodes –
Query isolation)
• Not good enough to distribute data over nodes in case of
monotinic incemental

32. MongoDB – hash-based keys
http://docs.mongodb.org
• Take notice: not good for range queries while
merge-sorting, no Query isolation in this case
• Write scaling – Write to many nodes simultaneously (take
notice to readers-writer lock, where write is exclusive)

33. Mongodb sharding and clustering
http://docs.mongodb.org

34. CQRS
• Command Query Responsibility Segregation
– separate application service layers for writing and
readng from DB (possibility to use different data
sources like RAM or DB)

35. CQRS
• Examples
– post-insert population cache
• all SELECTs are from cache (even invalid)
• consider LFU instead of LRU to invaidate cache
– pre-insert into memory
• dump results periodicaly
In both approaches there is convenient to use
Queues or data bus !

36. Queues, RabbitMQ
• RabbitMQ is based on AMQP (Advanced
Message Queuing Protocol)
– point-to-point
– publish-and-subscribe
– queueing, routing
• AMQP is not JMS (Java Message Service is an
API, not protocol)
• Happy Rabit is empty Rabbit
– do not try to store any data (messages) in queue
system in persistent mode to keep HA

37. Queues, RabbitMQ
• Simple queue
• Work queues
(one consumer)
• Publish/Subscribe
(many consumers)

38. Box vs spread architecture.
• Box architecture
– no scaling
– easy to maintenance
Server
Webapp
Redis
RabbitMQ
Varnish
DB

39. Box vs spread architecture.
• Spread architecture
– High availability
– more integrations, more administrative
Server #1
RabbitMQ
Redis
HAProxy
Server #2
Server #3
Webapp
Webapp
DB shard
Varnish
DB shard
Varnish

40. Scalable web apps
execution time
vs
development time
Piotr Pelczar
me@athlan.pl
