RFID Antenna Types.pptx
•Download as PPTX, PDF•
0 likes•19 views
RFID antenna is responsible for transmitting and receiving radio signals in RFID system. It helps in the identification and tracking of items equipped with RFID tags. The antenna is designed to operate at specific frequencies, such as low frequency(LF), high frequency(HF), ultra high frequency (UHF).It Can be integrated into various devices and applications. It's Size and shape of the antenna can vary depending on the requirements of RFID system. Benefits of RFID Antenna • Automated Data Collection • Streamlined Inventory Management • Enhanced Security • Improved Supply Chain Visibility • Reduced Labor Costs • Anti-counterfeiting and Authentication Types of RFID Antenna • Linearly Polarized Antennas • Circularly Polarized Antennas • Far-Field Antennas • Near-Field Antennas • Ground Antennas
