Presented by Elise Schieck, Caroline Fossum and Bernt Hjertner at Swedish University of Agricultural Sciences, 6 December 2019

1. Diagnostics to reduce antimicrobial (mis)-use
Elise Schieck, Caroline Fossum, Bernt Hjertner
SLU, Uppsala, 6 December 2019
Viktor Ahlberg

2. The idea
Development of a test that discriminates
between bacterial and viral infections

3. The idea – Why?
to treat not to treatOR

4. The idea – Why?
to treat not to treatOR
Hypothesis:
Proper diagnosis will
reduce antimicrobial
(mis)-use.

5. The idea – How?
Development of a test that discriminates
between bacterial and viral infections
How ?
Identify host responses typical
for bacterial versus viral infections

6. Background
Sligthly modified from: Mittal, R et al. 2014. Int J. Infectious Diseases 29: 259-267
Overlap between bacterial and viral pathways

7. Background
Discovery group: 240 children
52 definite bacterial infection,
92 definite viral infection,
96 indeterminate infection.
Validation group: 130 children
23 definite bacterial,
28 definite viral,
79 indeterminate infections
Identification of bacterial infections:
90-100% sensitivity
94-96% specificity

8. Selection of candidate genes
Gene Name Definition
Definite Bacterial vs.
Definite Viral
log2 FC q-value
Upregulated in viral infections
IFI27 interferon alpha inducible protein 27 -4.32 4.78E-21
IFI44L Homo sapiens interferon-induced protein 44-like, mRNA. -3.79 1.36E-22
IFIT1 interferon induced protein with tetratricopeptide repeats 1 -3.49 2.90E-20
RSAD2 radical S-adenosyl methionine domain containing 2 -3.28 5.14E-19
IFIT3 interferon induced protein with tetratricopeptide repeats 3 -2.66 2.47E-16
OTOF otoferlin -2.53 1.73E-14
MxA MX dynamin like GTPase 1
Upregulated in bacterial infections
FAM89A family with sequence similarity 89 member A 1.21 2.97E-14
UPB1 beta-ureidopropionase 1 1.23 5.27E-13
PTPN20 protein tyrosine phosphatase non-receptor type 20 1.35 1.88E-11
TMEM119 transmembrane protein 119 1.35 1.76E-08
SLPI secretory leukocyte peptidase inhibitor 1.84 2.44E-12
S100P S100 calcium binding protein P 2.35 1.39E-16
PI3 peptidase inhibitor 3; elafin precursor 2.58 4.52E-10
CRP C-reactive protein

9. Primer design
• Orthologues for selected genes were identified in S.
scrofa by sequence homology.
• 6 reference genes were identified from Uddin et al.
(2011) and new primer pairs designed for them.
• Primers were designed using NCBI’s Primer-BLAST
tool and their specificity confirmed using BLASTN.

10. Primer design

11. Testing Primers – conventional PCR
Reference genes
“Viral” genes “Bacterial” genes
# Primer ID BP
1 FAM89A 1 97
2 FAM89A 5 142
3 UBP1 1 102
4 UBP1 2 101
5 PTPN20 2 149
6 PTPN20 10 83
7 TMEM119 1 108
8 TMEM119 4 80
9 SLP1 1 113
10 SLP1 7 94
11 S100PBP 4 136
12 CRP 4 75
13 PI3 1 81
# Primer ID BP
1 MxA 1 99
2 MxA 4 109
3 IFI27 2 140
4 IFI27 3 102
5 IFI44L 1 104
6 IFI44L 8 177
7 IFIT1 N 141
8 RSAD2 4 102
9 RSAD2 8 123
10 IFIT3 6 136
11 OTOF 1 97
12 OTOF 7 104
# Primer ID BP
1 RPL4 udding 185
2 RPFL 107
3 TBP udding 118
4 TBP 135
5 B2M udding 180
6 B2M 88
7 PPIA udding 171
8 PPIA 109
9 SDHA udding 149
10 SDHA 113
11 YWHAZ udding 146
12 YWHAZ 114

12. Testing shortlisted primers - qPCR
Shortlisted genes:
Ref genes:
SDHA
YWHAZ
”Viral” genes:
MxA
IFI44L
RSAD2
“Bacterial” genes
FAM89A
SLP1
S100PBP
YWHAZ
FAM89A

13. Testing shortlisted primers - qPCR
Shortlisted genes:
Ref genes:
SDHA
YWHAZ
”Viral” genes:
MxA
IFI44L
RSAD2
“Bacterial” genes
FAM89A
SLP1
S100PBP
YWHAZ
FAM89A
PPIA

14. Testing on reference and clinical samples
Refgenes
Viral
Bacterial
2216/polyIC PMA/ionomycin

15. Testing on reference and clinical samples
Refgenes
Viral
Bacterial
Haemophilus day 0 Haemophilus day 4
Actinobacillus acute

16. Testing on reference and clinical samples
0.00
0.50
1.00
1.50
2.00
2.50
3.00
3.50
4.00
LF524 SH86 pig No 14 day 4 Actbac pig 25
Average viral vs bacterial
viral bacterial

17. Conclusion
Development of a test that discriminates
between bacterial and viral infections
- Is it possible?

18. Conclusion
Development of a test that discriminates
between bacterial and viral infections
- Is it possible?
- Yes it is!

19. Conclusion
Development of a test that discriminates
between bacterial and viral infections
- Is it possible?
- Yes it is!

20. Next steps
• Improve/ test further bacterial biomarkers
• Optimization of assays
• Test on more clinical/trial samples (viral and bacterial
infections
• Develop similar assays for other livestock (cattle and goats)
• Identify suitable technology for the final test

21. Thank you!
Ulf Magnusson and Vish Nene
Benjamin Nzau
