The gel-filled cable repair joint is a new system with excellent advantages.
It’s quick and easy to install and reduces the risk of installation errors. The
impact-resistant housing is connected with a hinge for easy installation.
Ideal for permanent repairs however its still possible to open the cable joint
and reuse after.
The gel-filled repair joint is a new system with special advantages.
It is quick and easy to install and reduces the chance of install
errors.
The QUICKI cable sheath repair joint is suitable for repairing
damaged cable sheaths. After closing the cable joint the special
gel flows together and ensures a good sealing and insulation
around the cable.
• No special tools required.
• Good adhesion to metals and plastics.
• Approved in accordance with EN 50393.
Features
• No specialist tooling required
• Shells manufactured from high grade polymeric materials
• Double seals for moisture protection
• High temperature resistance gel -40˚C to +140˚C
Set content:
• Gel filled cable joint
• Cable ties
• Mounting instruction
QUICKI cable jacket repair joint
Material halogen-free PP
Material GEL Type GQ Silicon
Temperature range GEL -40°C / +140°C
IP rating IP 68 in accordance with EN 60529: 1989 + A1: 1999
GEL JOINTS
Item number Description Cable diameter (mm) Dimensions (mm)
88000955UK QUICKI GTQR 16 Ø 7 - 16 121x46x35
88000956UK QUICKI GTQR 25 Ø 19 - 25 198x66x57
