Tweaking with the
Java Compiler J--
Trung M Dang
TCSS 421 Compiler Construction
Scanning
Exercise 2.10: Multi-line comment:
- Added 1 branch to check for star after slash. If there is, ignore characters
until a star is encountered. If slash after this star, comment ends.
Scanning
Exercise 2.10: Multi-line comment:
Scanning
Exercise 2.11 and 2.12: Operators/Reserved words:
- Added new operators to TokenInfo.java
- Division was hard since it is used for comment.
- Added reserved words to TokenInfo and Hashtable.
Exercise 2.13: Double_literal
- Check if there is a dot. 2 if statements: start with 0 and not start
with 0.
Exercise 2.14: Float_literal, long_literal
- Switch statement with empty cases is brilliant: handles
number beginning with 0 to 9 in simple way
Exercise 2.15: Hexadecimal, otal…
- Added to TokenInfo.
- Check if literal begins with 0, and if there is any x character, b
character, or digit after that 0.
Parsing
Parser is structured from
less precedence
(assignmentExpression) to
high precedence
(postfixExpression)
- Higher precedence
methods are called last
Parsing
Exercise 3.21, 3.22, 3.23, 3.27, 3.28, 3.29, 3.34:
double, float, long, operators, , try-catch-finally,
throw(s), do-until
- Added more branches to method literal() in Parser in
the case of literals.
- Created more classes for AST, added tokens to
TokenInfo.
Exercise 3.24 ternary
- Difficult to do. New methods added:
• Parsing the expression until the question mark “?”
• Parsing the rest of the ternary expression.
Parsing
Exercise 3.25 For statement
- Both starts with initializer (example: int i = 0)
-> Solution: Overload the
localVariableDeclarationStatement() method in Parser
to indicate whether to consume the next character
after initializer. If not, then the character is used to
identify type of “for” statement.
Exercise 3.26: Switch
- Difficulty: BREAK is sometimes followed by a semi-
colon or a semi-colon and a right curly brace. Check to
see if there is a left curly brace first before checking the
switch block.
Type Checking
Exercise 4.1: One public type declaration
- Added counter to count public types. Only 1 is allowed.
Exercise 4.2: Jvariable
- Added an entry of the missing variable to the symbol table
as Type.ANY.
Code Generation
Modified Main.java to output JVM instructions, not the
default SPIM codes.
Code Generation
Exercise 5.7 Classic For
- rewriting the for-
statement into while-
statement.
- Added getters for out-of-
scope objects.
Code Generation
Exercise 5.11: ternary
- Each part of ternary is
extracted individually.
- Textbook:
• condition == false, branch
to the alternative.
• Generate code for the
consequent
• unconditional jump to the
end
• generating code for the
alternative
• generate code for the
assignment.
Code Generation
Exercise 5.12: OR
- Short circuited: branch
to true label if lhs == true.
If lhs == false, branch to
target label if rhs == false.
Code Generation
Exercise 5.15: Throw
- Added new class JThrowStatement
- Used addNoArgInstruction(ATHROW)
Code Generation
Exercise 5.21: Long primitive
- Generated codes for pushing
long variable to the stack
(ldc2_w) , but not storing it
(lstore_<n>)
 Solution: Added long type to
JVariable in codegenstore method.
The End
Thank you for listening!
Feel free to ask questions!
