The document discusses BERR's services for transformers and switchgear equipment, including installation, testing, commissioning, maintenance, engineering, spare parts, and consulting. BERR provides these services for the entire life cycle of equipment, from selection and installation to maintenance and decommissioning. They have experience installing and servicing all types and brands of transformers and switchgear equipment.

4.  INSTALLATION
 TEST & COMMISSIONING
 MAINTENANCE
 SPARE PARTS

5. Transformers are the most important components of electrical energy supply networks. They
raise or lower voltage levels at substations.
It is critical to perform transformer maintenance periodically, although the transformers has
long life cycle and low failure rate.
BERR provides installation, testing, commissioning, maintenance, engineering and consulting
services throughout the transformer life cycle, from selection commissioning to recycling, for all
brands and kinds of transformers.

6. Whether you are installing a new, repaired or refurbished transformer or if it is a reallocation of
an existing transformer, BERR offers a secure and efficient solution to meet your needs.
This can also be tailored to your needs by BEER qualified personnel at your site(s).
BEER has extensive experience in installation and commissioning all types of transformers to all
parts in Turkey. The combination of highly qualified technicians, expertise, experience and high
quality equipment enhances the speed and efficiency of this vital operation.
You can find below the transformers at all voltage level that we can install at your sites.
• Power transformers
• Oil-type distribution transformers
• Dry-type distribution transformers
• Instrument transformers
With our mobile service equipment, including high-voltage test equipment, we can install
transformers on time according to global installation standards.

7. BERR expert staff perform transformer field tests with high-quality and calibrated test
equipments for installed power and distribution transformers. After test process, all
transformers can be commissioned safely.
You can find below the transformer tests that we can.
• DC Insulation Resistance ( MEGGER )
• Conversion Rate Measurement (TTR)
• DC Resistance Measurement
• Power factor(dissipation factor) (DOBLE)
• Excitation Current Measurement
• Polarity
Visually inspection of current transformer,.Screwing the primary connections in line with the
tork key after tests are completed and control of connection tightness of secondary
connections. Control of grounding connections.

8. Maintenance can either be time-based or condition-based, depending on the service strategy
selected. The time-based maintenance is carried out at predetermined intervals of time or on
the base of prescribed criteria and aimed at reducing the probability of failure or the working
deterioration of the element.
Power transformers are the most important components of electrical energy supply networks.
Although these components have high reliability, failures can occur due to external factors such
as short circuits in the grid. Failures can also occur due to ageing effects of the active part,
especially the insulation system, or ageing of important accessories such as bushings or on load
tap changers.
BERR proposes the following maintenance solutions:
• Power and distribution transformer maintenance
• On-Load Tap Changer (OLTC) maintenance
• Transformer oil and dissolved gas analysis
• Corrosive Sulfur and Furan Analysis
• Oil Exchange and Treatment Process

9. BERR provides all brand and type spare parts and consumables for maintenance of an existing
transformer. BERR provides genuine high quality spare parts and consumables for transformers
with fast turn-around time, using BERR’s extensive experience and knowledge, thus reducing
downtime.
BERR proposes the following spare parts solutions:
• Transformer oil
• On-load tap changer(OLTC)
• AVR Relay
• HV-MV-LV Bushings
• Termometer
• Bucholz relay
• Moisture holder
• Pressure switches
• Oil level indicator
• Other accessories

10.  INSTALLATION
 TEST & COMMISSIONING
 MAINTENANCE
 SPARE PARTS

11. BERR support the entire portfolio of all brand switchgear products that include indoor and
outdoor circuit breakers, indoor switchgear cubicles, gas insulated switchgear, generator circuit
breakers, disconnectors, instrument transformers and surge arrestors.
Use BERR's know-how to identify opportunities for improving system and equipment
performance, optimizing your processes economically and technically, with regulatory
compliance.

12. Installation and commissioning of new equipment at site as per our recommended procedures
which ensures perfect performance of your switchgear. Our technicians are fully trained and
certified to carry out the installation and commissioning work. The service includes required
tests as per our standard checks. We also offer services for decommissioning of old switchgear.
For any switchgear products we always recommend to use our supervision to ensure proper
installation of the equipment if the installation is done by other service providers for the
complete plant.
Installation for medium voltage and high voltage products are performed
experienced BEER experts for high reliability and optimum life-cycle performance from first
operation. Contact BEER for Installation services for MV and HV switchgear products. Full
installation services include:
• Decommissioning and removal of old switchgear.
• Site supervision.
• Installation and erection of new equipment.
• Functional testing and site handover.

13. Experienced BERR technicians perform commissioning of MV and HV switchgear, protection
and control systems as brand-independent, which includes:
• Cold commissioning to verify protection and control operation.
• Hot commissioning and energisation of the equipment.
• Supervision during plant start up.
BERR expert staff perform commissioning tests with high quality and calibrated test
equipments for installed and erected MV and HV switchgear products.
Full commissioning tests include:
• DC Insulation Test (MEGGER)
• CB Open-Close Time Measurement
• Contact Resistance Measurement
• Contact Travel Test (optional)
• Power factor(dissipation factor)
• SF6 Dew-Point Measurement
• Gas leakage test

14. The portfolio of preventive maintenance services includes routine planned maintenance,
breaker diagnostics and condition assessment of switchgear. BERR provides complete solutions
for inspection, maintenance, retrofit for all brand and all type Switchgear products.
Also, BERR provides service contracts for annual maintenance as well as emergency 24/7
support.
Reduce operation costs by relying on BERR solutions and
experienced experts to support your maintenance strategy,
according to expected asset lifetime.
By inspecting and analyzing your equipment we are able to program
maintenance in a targeted and economically advantageous way.
Interventions can be brought forward or delayed according to your
priorities.

15. We offer a comprehensive range of overhead line systems to suit client requirements. With our
own skilled overhead lines team, we undertake the development, design, construction,
installation and maintenance for every type of overhead system including OHL Distribution up to
and including 132kV as well as 400kV Transmission.
• Substation build, repair and maintenance
• Asset replacement and refurbishment
• Line design, surveys and asset data management
• Condition assessments and feasibility studies
• Material procurement
• Construction of new overhead lines
• Reactive fault repairs and network recovery
• Wood pole replacements
• Underground lines – LV, MV, HV
• Optical Fibre cabling

16. BERR has extensive spare part portfolio of MV and HV Switchgear Products. Our expertise and
experience ensure you always receive the right part no matter for your Switchgear Systems.
Whether in scheduled maintenance or in emergency situations, the use of original and suitable
spare parts is ultimately the most economical choice and effectively protects the operational
reliability of your facility.
BERR maintains an extensive portfolio of all brand spare parts. Spare parts may be individual
equipment items or complete and full-range package deals for your inventory. Based on the
specific equipment spectrum in your plant, we will make suggestions for an optimal
combination of spare part packages.
BERR proposes the following spare parts solutions:
• MV or HV Circuit Breaker (Complete)
• Mechanism (complete)
• Close-trip coils
• Charger motor
• Heater
• Switches
• Other accessories

17.  ENGINEERING & CONSULTING
 INSTALLATION
 TEST & COMMISSIONING
 MAINTENANCE
 SPARE PARTS

18. BERR‘s Power Systems Solutions provide support for the turnkey projects for various industries
and utilities that include greenfield MV/HV substations, substation expansion, protection,
SCADA and network controls.
BERR experts have a profound knowledge of best practices in a wide range of substation and
substation protection systems. We develop and implement service solutions based on industry-
specific technologies and competences to support customers in improving overall equipment
effectiveness and return on investment.

19. Contact the BERR representative to request services or engineering solutions and studies on:
• Short-circuit calculations
• Protection coordination and selectivity studies
• Load flow analysis
• Voltage drop calculations
• Reactive power compansation
• Earthing calculations
• Instrument transformer selection
• Primary & secondary projects for substations
• Preparing technical specification
• Product selection
• Technical evaluation for offers and projects

20. We undertake projects of installation, testing and commissioning of medium voltage and high
voltage substations up to 380 kV. The project covers the entire substation or plant including
power and distribution transformers, high and medium voltage switchgear, gas insulated
switchgear. We provide the services and solutions for both outdoor switchyard and indoor
installations.
Installation of the entire power transmission and distribution plant or MV-HV power products
like transformer, switchgear, protection systems performed by BERR expert engineer and
technicians.

21. BERR offers complete testing of switchyard equipment including CT, VT, isolator, earth switch,
and breakers for MV and HV. In additionally, we offer complete testing of protection and
measurement systems, including configuration and parameterisation of all numerical relays and
latest IEDs.
Full commissioning tests that are performed according to global
standards include:
• Complete testing of MV-HV Switchyard
• Power and distribution transformers
• Breakers and disconnecting switches
• Surge Arresters, Capacitors
• Instrument transformers
• Protection relays
• Meter tests
• Redresor & Accumulator Test

22. BERR possesses complete power plant maintenance service capabilities with or without service
agreements. We can take care of routine maintenance needs of all brand your power products
and power systems right from transformers to low voltage distribution. We also take care of
maintenance contract agreements for 24/7 emergency support.
Effective time-based, condition-based or reliability centred maintenance maximises the
reliability of the substations and their equipments. BERR expert staff utilise the most advanced
diagnostic and maintenance practices.

23. The reliable, cost-effective, long term solution to pollution induced flashovers of high voltage
insulators.
Insulator contamination has been a problem since the birth of electrical power distribution. Salt
spray, industrial pollutants, and even desert sand can lead to costly power interruptions due to
arcing and flashover. While numerous attempts with other protective methods have had their
limitations, there is a solution that utility maintenance engineers can rely on: SYLGARD High
Voltage Insulator Coating (HVIC).

24. BERR supplies all brand spare parts for MV-HV substation plant to
minimise unexpected costs and maximise systems utilisation. Taking
care of your equipment’s components is essential to keep your
assets safe and reliable.
BERR proposes the following spare parts for your substation plants:
• Power and distribution transformers
• Breakers and disconnecting switches
• Instrument transformers
• Insulation Materials
• Protection and control panels
• Protection relays
• Meters
• Other accessories

25. High Voltage Polymer Surge Arrester High Voltage Polymer Insulator

26. High Voltage Circuit Fuse Brakers High Voltage SF6 Circuit Braker

27. Medium & High Voltage Test Truck

28. Professional Thermal Camera Remote Inspector Helicopter
High Efficiency Inspection and Diagnostic Equipment and Devices

29. Paratoner and Grounding Systems and Spare Parts

30. HV Insulation Sheets & Blankets Insulator Coating Chemical

31. High Voltage Safety Equipment

32.  TEST AND MEASUREMENT

33. For Generator and Rotary Equipment Inspection
 Winding/Earth And Winding/Winding Power Factor & Tip-up Tests Of Stator Windings.
 Winding/Earth And Winding/Winding Capacity Measurement Of Stator Windings.
 Measurement Of İnsulation Resistance And Pı Tests Of Rotor And Stator Windings.
 Measurement Of Rotor İmpedance,
 Measurement Of Dc Resistance Of Rotor And Stator Windings.
 Dc High Voltage Tests.
 Screwing The Stator Winding Connections İn Line With The Torque Key After The Test Are Completed.
 Control Of Grounding.

35. Our Skilled ManPower Providing Services consist of high experienced electrical engineers
and technicians for High – Medium – Low Voltage Electrical Works
 LV Works Electricians
 HV & MV Works Technicians
 Substation & Relay Electricians
 Swicthgear Facility Electricians
 Transformator Electricians
 Synchronization System Electricians
 Automation Technicians
 Sensoring & Monitoring Technicians
 SCADA & PLC Programmers
 Instrumentation and Control Technicians
 Test and Calibration Technicians

36. Adress:
TR - Postane, Levent Sitesi, I6 No:7 34940 Tuzla, Istanbul, Turkey
UK - Kingston Upon Hull (England) United Kingdom
Telephones:
Headquarters Pbx : +90 216 395 20 34
Support Center : +90 532 163 62 90 ( TR ) & +44 743 246 14 62 ( UK )
URL:
http://www.berrindustry.com
E-Mail:
General Information
UK Contact
India Contact
Business Development
Skype:
Berr.Industry
SlideShare Link for all brochures and referances Go >>>
36
: info@berrindustry.com
: r.moore@berrindustry.com
: m.kumar@berrindustry.com
: k.edes@berrindustry.com
