This document summarizes an presentation about building performant APIs with GraphQL and PHP. The presentation introduces GraphQL concepts like queries, fields, arguments, variables, types and schemas. It discusses how GraphQL can help address challenges with traditional REST APIs like over-fetching or under-fetching data. The document also provides an overview of building a GraphQL server in PHP using the webonyx/graphql-php library and implementing resolvers to fetch data and return object types.

1. Performant APIs with GraphQL and PHP
@AndrewRota | Dutch PHP Conference 2019

2. APIs are important
Native Mobile Apps
Web browsers
(http requests from JavaScript)
External API
API

3. Native Mobile Apps
Web browsers
External API
API
article
comment
comment
author
author
author

4. Native Mobile Apps
Web browsers
External API
API
article
comment
comment author

5. Native Mobile Apps
Web browsers
External API
APIgetBlog

6. Challenges with Traditional APIs
‣ Over-fetching data
‣ Under-fetching data, requiring multiple round-trips
‣ Time spent iterating on endpoints and expected data shape

7. GraphQL offers an alternative
architecture for developing efficient,
easy to understand APIs.

8. Andrew Rota
@AndrewRota
Associate Director, Software Engineering

9. What is GraphQL?
“GraphQL is a query
language for APIs and a
runtime for fulfilling those
queries with your existing
data.”

10. {
conferences {
name
dates
}
}
"conferences": [
{
"name": "Dutch PHP 2019",
"dates": "June 6-8, 2019"
}
]

11. {
conferences {
name
speakers {
name
twitter
}
}
}
{
"conferences": [
{
"name": "Dutch PHP 2019",
"speakers": [
{
"name": "Andrew Rota",
"twitter": "https://twitter.com/andrewrota"
}
]
}
]
}

12. Topics
‣ Introduction
‣ GraphQL Concepts
‣ Client-Side GraphQL
‣ Server-side GraphQL with PHP
‣ Beyond the Basics
‣ GraphQL Tooling

13. GraphQL
‣ Developed internally at Facebook in 2012
‣ Open sourced in 2015
‣ Spec: facebook.github.io/graphql/draft

14. GraphQL Implementations
‣ GraphQL is technology agnostic on both client and server
‣ Client implementations:
‣ Server implementations:

15. GraphQL Advantages
‣ Client requests exactly the shape of the data it needs
‣ Multiple resources can be queried in a single request
‣ API is defined with a strongly-typed schema
‣ Enables strong tooling for developers

16. GraphQL in a web stack
QueryClient
(e.g., browser, mobile
app)
/graphql on
PHP Server
response
Database

17. GraphQL in a web stack
QueryClient
(e.g., browser, mobile
app)
/graphql on
PHP Server
response
Cache
Service
Database

18. GraphQL in a web stack
QueryClient
(e.g., browser, mobile
app)
/graphql
server
response
Cache
REST Service
Database
PHP

19. GraphQL Concepts

20. Queries + Fields
‣ In GraphQL you make queries
for fields on objects
‣ The response will have the
same shape as the query
query {
conferences {
name
dates
}
}
query
field

21. Fields
‣ Fields might be scalar values,
or they might be other Objects.
‣ Fields can refer to Objects, and
you can make a sub-selection
for fields of these Objects.
‣ This lets you avoid making
multiple requests for related
resources
query {
conferences {
name
speakers {
name
}
}
}
sub-selection

22. Arguments
‣ You can pass named
arguments to each field
and nested object.
{
conference(name: "LonghornPHP") {
speakers {
name
}
}
}
argument

23. Variables
‣ Dynamic values can be
passed into queries via
variables
query SearchConfs($name: String){
conferences(nameFilter:$name) {
name
}
}
{"name": "LonghornPHP"}

24. Types + Schemas
‣ Every GraphQL service
defines the a set of types
that describe what data can
be requested

25. Types + Schemas
‣ GraphQL servers can be
written in any language, so
we describe types with a
language-agnostic “GraphQL
schema language”
type Conference {
name: String!
url: String!
description: String
location: String
dates: String!
# List of speakers at this conference
speakers: [Speaker]
}

26. Types + Schemas
‣ GraphQL servers can be
written in any language, so
we describe types with a
language-agnostic “GraphQL
schema language”
‣ Types include: object, scalar,
list, enumeration, union,
interface, and non-nullable.
type Conference {
name: String!
url: String!
description: String
location: String
dates: String!
# List of speakers at this conference
speakers: [Speaker]
}
non-nullable
scalar type
list of
object
types

27. Query + Mutation Types
‣ There are two special types
in every GraphQL schema:
Query and Mutation
‣ Root fields you define on
Query and Mutation are the
entry points of requests
type Query {
# Returns conferences
conferences: [Conference]
# Returns speakers
speakers: [Speaker]
}
root
fields
root type

28. Queries
‣ Queries ask for for data;
analogous to GET requests.
‣ GraphQL clients (e.g.,
browsers, mobile apps),
make queries against a single
GraphQL endpoint
‣ Operation name and type
can be optional
query ConferenceNamesAndDates{
conferences {
name
dates
}
}
operation nameoperation type
fields

29. Mutations
‣ Mutations are for modifying
data; analogous to
POST/PUT/DELETE requests.
‣ They start with the mutation
root type, and will often
leverage arguments, but are
otherwise the same as
queries
mutation {
addSpeaker(
name: "Andrew Rota",
twitter: "https://twitter.com/andrewrota")
{
id
}
}

30. GraphQL on the Client

31. Client-side GraphQL is about writing queries to request data from
a GraphQL server with a defined schema.

32. Queries from JavaScript
‣ Queries are made via HTTP
requests to a single endpoint
‣ There are several libraries
available to manage
GraphQL on the client
query ConferenceNamesAndDates{
conferences {
name
dates
}
}

33. Lokka
a simple graphql client library
‣ Lokka is a simple JavaScript
library for sending GraphQL
queries in JavaScript, just like
standard fetch or ajax
requests
const t = new HttpTransport('/graphql');
t.send(`query ConferenceNamesAndDates{
conferences {
name
dates
}
}`).then(response => {
console.log(response);
});

34. Apollo
complete data management solution
‣ Declarative API for queries and
mutations
‣ Normalized client-side caching
‣ Combine local and remote data
‣ Pagination, error handling,
refetching, and optimistic UI
‣ Client libraries for popular frontend
frameworks (React.js, Angular, Vue),
as well as native Android and iOS
applications
<Query client={client} query={CONFERENCES_QUERY}>
{({ loading, error, data }) => {
if (loading) return 'Loading...';
if (error) return `Error!`;
return (
<ul>
{data.conferences.map(conference => (
<li>{conference.name}</li>
))}
</ul>
);
}}
</Query>

35. GraphQL on the Server

36. Client-side GraphQL is about writing queries to request data from
a GraphQL server with a defined schema.
Server-side GraphQL is about implementing that schema to
return data.

37. Let’s build a GraphQL server in PHP!

38. webonyx/graphql-php
Provides:
‣ Type primitives for your Type system
‣ Query parsing, validation, and
execution against a Type system
‣ Type introspection
‣ Tools for deferred field resolution
Feature-complete implementation of the
GraphQL spec in PHP, inspired by
Facebook’s original node-js reference library.

39. Create a /graphql endpoint to handle requests, and execute queries

40. Handle queries
‣ Queries are made via HTTP
requests to a single endpoint
‣ GraphQL::executeQuery
parses, validates, and
executes the query
$schema = new Schema([
'query' => Types::query()
]);
$result = GraphQL::executeQuery(
$schema,
$requestData['query'],
null,
$appContext,
(array)$requestData['variables']
);
$output = $result->toArray();

41. Then start with the special root type, Query.

42. Root fields
‣ This root type (Query) has a
list of root fields, which are
the entry points to the API
‣ Each field has a type, and a
resolve method for getting
the data
use GraphQLTypeDefinitionObjectType;
use GraphQLTypeDefinitionType;
$queryType = new ObjectType([
'name' => 'Query',
'fields' => [
'message' => [
'type' => Type::string(),
'resolve' => function () {
return 'hello world';
}
],
]
]);

43. Fields can return objects
‣ A field can also return a
custom ObjectType, which is
a type with its own collection
of fields.
‣ It can also return lists of other
types
$queryType = new ObjectType([
'name' => 'Query',
'fields' => [
'conferences' => [
'type' => Types::listOf(Types::conference()),
'description' => 'Returns conferences',
'resolve' => function() {
return DataSource::getConferences();
}
],
'message' => [
'type' => Type::string(),
'resolve' => function () {
return 'hello world';
}
],
]
]);

44. Resolvers
‣ Resolve functions tell the server
how to get the data for the field
‣ Resolve function can be
implemented however you’d like to
get the data: SQL queries, cache, or
another API
‣ For scalars, the return value will be
the value of the field
‣ For object types, the return value
will be passed on to nested fields
$queryType = new ObjectType([
'name' => 'Query',
'fields' => [
'conferences' => [
'type' => Types::listOf(Types::conference()),
'description' => 'Returns conferences',
'resolve' => function() {
return DataSource::getConferences();
}
],
'message' => [
'type' => Type::string(),
'resolve' => function () {
return 'hello world';
}
],
]
]);

45. ...let’s take a closer look at a resolve function
function($root, $args, $context, ResolveInfo $info) {
return DataSource::getData($root->id);
}
root / parent
result
arguments app context
query AST and
other meta info

46. Creating a custom ObjectType

47. 1. Define your object type
2. Add it to a new field
3. Write the field resolver function

48. Custom object type
‣ Just like the root query type,
a custom type is a collection
of fields, each with their own
types
$config = [
'name' => 'Conference',
'fields' => [
'name' => Type::nonNull(Types::string()),
'url' => Type::nonNull(Types::string()),
'location' => Types::string(),
]
];

49. Custom object type
‣ Just like the root query type,
a custom type is a collection
of fields, each with their own
types
‣ Fields on a type can also
have custom ObjectTypes
$config = [
'name' => 'Conference',
'fields' => [
'name' => Type::nonNull(Types::string()),
'url' => Type::nonNull(Types::string()),
'location' => Types::string(),
'speakers' => [
'type' => Types::listOf(Types::speaker()),
'resolve' => function($root) {
return DataSource::getSpeakersAtConf($root->id);
}
]
]
];

50. And now we have a GraphQL server!

51. GraphQL Tooling

52. Introspection
‣ A key feature of GraphQL is
its introspection system
‣ You can ask any GraphQL
schema about what queries
it supports
‣ This unlocks opportunities
for powerful tooling
{
"data": {
"__schema": {
"queryType": {
"name": "Query"
},
"types": [
{
"kind": "OBJECT",
"name": "Query",
"description": null,
"fields": [
{
"name": "conferences",
"description": "Returns a list of PHP conferences",
"args": [],
"type": {
"kind": "LIST",
"name": null,
"ofType": {
"kind": "OBJECT",
"name": "Conference",
"ofType": null
}
},
"isDeprecated": false,
"deprecationReason": null
}
]
}
]
}
}
}

53. GraphiQL - in browser IDE for exploring GraphQL

54. Graphql Playground - like GraphiQL, but more features

55. Voyager - Any GraphQL API as an interactive graph

56. PHPStorm JS GraphQL Plugin - IDE Integration

57. Types can be used in client-side code
‣ If you’re using a client-side language that supports types, you can
generate types for graphql queries automatically from the GraphQL
schema using tools such as Apollo Codegen
‣ Examples: TypeScript, FlowType, or Swift (iOS)

58. Beyond the Basics

59. n+1 problem
‣ Data-fetching problem that
occurs when you need to
fetch related items in a
one-to-many relationship
{
conferences {
name
speakers{
name
}
}
}

60. Solution: deferred resolvers
‣ graphql-php provides Deferred
objects to delay field resolution
until we can make a single batch
request for the data
‣ Once all non-deferred fields are
resolved, graphql-php will call the
wrapped closures
‣ If you have an environment that
supports async operations (e.g.,
HHVM, ReactPHP, PHP threads),
some fields can also resolve async.
'resolve' => function($root) {
SpeakerCollection::add($root->id);
return new Deferred(function() use ($root) {
return SpeakerCollection::get($root->id);
});
}

61. Limiting Query Complexity and Depth
‣ graphql-php provides a method to calculate and limit the complexity
of any query, based on the sum of complexity scores set per field
‣ You can also limit the nested fields requested in queries

62. Persisted Queries
queryClient Server
query {
conferences {
name
dates
}
}
idClient Server{ id: 001 }
‣ In production, queries can be
extracted at build-time as
“persisted queries”
‣ Clients send the server the
reference to the query
‣ Reduce data sent to server
‣ Restrict queries that can be
run to a pre-built whitelist
With persisted queries:

63. Subscriptions
Client Server
Subscribe to an event
‣ GraphQL subscriptions push
data to the client when
events happen, usually over
a long-lived WebSocket
connection.
‣ graphql-php does not
implement support for
subscriptions
subscription SubscribeToVotes {
newVote {
time,
voter,
value
}
}

64. Challenges

65. GraphQL is a new paradigm that offers a lot of new opportunities
for developing performant APIs, but with that comes new
challenges as well.

66. Challenges when using GraphQL
‣ It’s more complex than RESTful APIs
‣ ORMs are not ready to work performantly with GraphQL (yet)
‣ Caching is a lot more challenging
‣ Application metrics are more complicated
Robert Zhu’s “The Case Against GraphQL” (bit.ly/against-graphql)

67. GraphQL might not always be the best choice for your API:
consider your use case and the problems you’re trying to solve,
weigh the tradeoffs, and make an informed decision.

68. GraphQL makes it easier to make
more efficient queries between your
client and your server.

69. GraphQL provides new ways to think
about your APIs and the structure of
your application’s data.

70. Give it a try!

71. Thanks!

72. Andrew Rota
@AndrewRota
Resources
‣ graphql.org
‣ github.com/webonyx/graphql-php
‣ github.com/chentsulin/awesome-graphql
‣ Howtographql.com
Tutorial:
slideshare.net/andrewrota/tutorial-building-a-graphql-api-in-php/
