Performance & Scalability Improvements in Perforce
- 1. # 1 Michael Shields Server Performance Engineer
- 2. # 2 Developed and supported software since 1977, specializing in server optimization for software products including Perforce, Sybase and Ingres. Hobbies include on the human psyche.
- 3. # 3 • Lockless Reads • Edge/Commit Servers • Clustering
- 4. # 4
- 5. # 5 • Goal: Efficiently utilize machine resources • Particularly CPU cores • Reduce likelihood blocked on metadata locks • Lockless Reads != Dirty Reads • Returned data is consistent • btree and layers above ensure consistency • e.g. maxCommitChange, client entity locks
- 6. # 6 • Example: p4 sync //<depot-path>/...@<change> --- db.counters --- locks read/write 0/0 rows get+pos+scan put+del 1+0+0 0+0 --- db.have --- locks read/write 0/3 rows get+pos+scan put+del 0+1+1 201+0 --- db.rev --- locks read/write 0/0 rows get+pos+scan put+del 0+1+202 0+0 --- db.working --- locks read/write 0/0 rows get+pos+scan put+del 0+1+1 0+0
- 7. # 7 • Example: p4 sync //<depot-path>/...@<change> --- /write /0 rows +pos+scan put+del +0+0 0+0 --- db.have --- locks read/write 0/3 rows get+pos+scan put+del 0+1+1 201+0 --- /write /0 rows get+ + put+del 0+ + 0+0 --- db.working --- locks read/write 0/0 rows get+pos+scan put+del 0+1+1 0+0 • Lockless scan of db.rev (uses maxCommitChange)
- 8. # 8 • Example: p4 sync //<depot-path>/...@<change> --- db.counters --- locks read/write 0/0 rows get+pos+scan put+del 1+0+0 0+0 --- /write /3 rows get+ + put+del 0+ + 201+0 --- db.rev --- locks read/write 0/0 rows get+pos+scan put+del 0+1+202 0+0 --- /write /0 rows get+ + put+del 0+ + 0+0 • Lockless scan of db.rev (uses maxCommitChange) • Lockless scan of db.have (uses client entity lock)
- 9. # 9 • Example: p4 sync //<depot-path>/...@<change> --- db.counters --- locks read/write 0/0 rows get+pos+scan put+del 1+0+0 0+0 --- read/ 0/ rows get+pos+scan +del 0+1+1 +0 --- db.rev --- locks read/write 0/0 rows get+pos+scan put+del 0+1+202 0+0 --- db.working --- locks read/write 0/0 rows get+pos+scan put+del 0+1+1 0+0 • Lockless scan of db.rev (uses maxCommitChange) • Lockless scan of db.have (uses client entity lock) • db.have update exclusive lock easier to acquire
- 10. # 10 • db.peeking=2 • Significant concurrency improvements • Shared locks not taken for some large reads, e.g. integrate • db.peeking=3 • Lockless db.rev scan • Instead of db.revhx and db.revdx scans with shared locks • Can require more resources • Not all commands and arguments can be lockless
- 11. # 11 • btree layer implementation (Patent Pending) • Structural changes requiring checkpoint replay • Maximum table size is now 64 zettabytes • Additional potential invalidation of process-level caches • Data scans can tolerate writes • Additional complexities
- 12. # 12 • Executes commands “typical” of a “developer” • sync, fstat, edit, change, submit, integrate, resolve, etc. • Concurrent execution of many “developer” roles • Random paths, files per task, and delays • Shorter average delay simulates many more users • 256@15sec might approximate 10,000@10min • 512@15sec ~20,000@10min, YMMV
- 13. # 13
- 14. # 14
- 15. # 15
- 16. # 16
- 17. # 17
- 18. # 18
- 19. # 19
- 20. # 20
- 21. # 21
- 22. # 22
- 23. # 23 • EA • VMware • Not track=1 • track=1 required for best analysis
- 24. # 24
- 25. # 25
- 26. # 26
- 27. # 27
- 28. # 28
- 29. # 29 • Goal: Improve remote user experience • Client commands handled by local edge • Helps enable larger remote presence • Network load to Commit Server likely reduced • Network latency to Commit Server less of an impact • acb simulation • 128 “developer” roles, average delay of 15 seconds • 128@15sec might approximate 5,000@10min
- 30. # 30
- 31. # 31
- 32. # 32
- 33. # 33
- 34. # 34
- 35. # 35
- 36. # 36 • Goals • Improve scalability • Automated failover • Leverages Edge/Commit infrastructure • Workspace server/depot master (and depot standby!) • Shared archive an integral component • Users connect to broker acting as a router • Forwards to selected workspace server
- 37. # 37 Shared Archive High-bandwidth Network Clients Clients Clients Clients Corporate Network
- 38. # 38 Shared Archive High-bandwidth Network Clients Clients Clients Clients Corporate Network Depot Master Workspace Server Workspace Server Depot Standby Workspace Server
- 39. # 39 Shared Archive High-bandwidth Network Clients Clients Clients Clients Server Clustering Corporate Network Depot Master Workspace Workspace Server Depot Standby Workspace Server Router Clustering Router
- 40. # 40 Shared Archive High-bandwidth Network Clients Clients Clients Clients Server Clustering Corporate Network Depot Master Depot Standby Workspace Workspace Server Workspace Server Low-Latency Network Router Clustering Router
- 41. # 41 Shared Archive High-bandwidth Network Clients Clients Clients Clients Server Clustering Corporate Network Depot Master Depot Standby Workspace Workspace Server Workspace Server Low-Latency Network Router Clustering Router High-bandwidth Network
- 42. # 42 • acb simulation • Average delay reduced to five seconds (from 15) • 512@5sec might approximate 60,000@10min • Simulation stressed • 2x workspace servers: 2x more “developers” • Only 14% longer run time when stressed
- 43. # 43
- 44. # 44
- 45. # 45
- 46. # 46 • Doubling workspace servers again • Cheated by deploying two on each machine • For large deployments, one per machine is best practice • Average delay further reduced to three seconds • 512@3sec might approximate 100,000@10min • 100,000 simulated “developer” roles!
- 47. # 47
- 48. # 48
- 49. # 49
- 50. # 50
- 51. # 51 • Lockless Reads • Get there now if you’re not already • Edge/Commit Servers • Deploy edge servers across latency • Clustering • Scale to even larger number of users
- 52. # 52
- 53. # 53 Michael Shields mshields@perforce.com @p4mshields
Editor's Notes
- Writers in part of the btree don’t affect readers of other parts.
- All data is from the active portion of the simulation: all roles have warmed up and are running their tasks (and none have finished).
- All data is from the active portion of the simulation: all roles have warmed up and are running their tasks (and none have finished).
