Parallel SQL for SolrCloud
- 1. O C T O B E R 1 3 - 1 6 , 2 0 1 6 • A U S T I N , T X
- 2. Parallel SQL Joel Bernstein Search Engineer, Alfresco jbernste@apache.org
- 3. 3 03 Introduction • Joel Bernstein • Lucene/Solr Committer • Search Engineer at Alfresco • Live and work in NYC
- 4. 4 03 Alfresco • Open source ECM (Enterprise Content Management) • Alfresco is a system of record for documents • Uses Solr for search • 1800+ customers • 11 million active user accounts • Alfresco Solr: Document level access control, eventually consistent, transactional, multi-master, distributed search and faceting (coming in Alfresco 5.1)
- 5. 5 01 Agenda 1. SQL Unleashed (What can it do?) 2. SQL Under the Hood (How does it work?)
- 6. 6 01 SQL Unleashed (In Solr 6.0)
- 7. 7 01 Why SQL? • Solr has many awesome features. • But all of these feature create complexity. • Which faceting API to use? When to Stream? Which parameters to use for optimal performance? • The complexity level increases dramatically when distributed joins come into play • With SQL we can provide an optimizer to choose the best query plan.
- 8. 8 01 The SQL Interface at Glance • SQL over Map/Reduce: supports high cardinality aggregations and distributed joins. • SQL over Facets: high performance on moderate cardinality aggregations. • SQL with Solr Search Predicates • SQL is fully integrated with SolrCloud
- 9. 9 01 SQL Syntax: Limited and Unlimited SELECT • select colA, colB from tableB • select colA, colB from tableB limit 100 • Unlimited selects return the entire result set. Return fields must be DocValues. • Limited selects can sort by score and retrieve any stored field.
- 10. 10 01 SQL Syntax: ORDER BY • select a, b from tableB order by a desc, b desc • Unlimited selects sort the entire result set
- 11. 11 01 The Predicate: Phrase Searching • select a, b from tableB where c = ‘hello world’ • Searches for the phrase ‘hello world’ in field c.
- 12. 12 01 The Predicate: Boolean searching • select a, b from tableB where c = ‘(hello world)’ • Adding parens searches for (hello OR world). • Supports Solr query syntax inside the parens.
- 13. 13 01 The Predicate: Range query • select a, b from tableB where c = ‘[0 TO 100]’
- 14. 14 01 The Predicate: Arbitrary Boolean clauses • select a, b from tableB where (c = ‘hello world’ AND d = ‘[0 TO 100]’)
- 15. 15 01 SQL Syntax: Select Distinct • select distinct a, b from tableB • Map/Reduce Implementation: Tuples are shuffled to worker nodes where the distinct operation is performed. • JSON Facet Implementation: distinct operation is pushed down into the search engine • Map/Reduce for high cardinality • Facet for high QPS
- 16. 16 01 Shuffle vs Push Down • Shuffling: high cardinality and parallel relational algebra (Distributed Joins) • Pushdown (Facet): blazing fast, high QPS, moderate cardinality • aggregationMode flag is available with the JDBC driver and http interface [map_reduce or facet]
- 17. 17 01 Aggregations: Stats • select count(*), sum(a) from tableA • Uses the StatsComponent under the covers • Initial release supports count, sum, avg, min, max • Aggregation logic is always pushed down into the search engine.
- 18. 18 01 Aggregations: GROUP BY • select a, b count(*), sum(c) from tableB group by a , b having count(*) > 50 order by sum(c) desc • Supports complex having clause: having (count(*) > 50 AND sum(b) < 1000) • Has Map/Reduce implementation (shuffle) • And JSON Facet implementation (push down) • Map/Reduce can handle high cardinality multi- dimension aggregations.
- 19. 19 01 JDBC Driver • Ships with Solrj • Poolable Connection and Statement • SolrCloud Aware Load Balancing • Connection has aggregationMode switch [map_reduce or facet]
- 20. 20 01 SQL Under the Hood
- 21. 21 01 SQL Parsing • Presto SQL Parser handles the parsing • SQL Statements are compiled to TupleStream objects • The TupleStream is the base interface of the Streaming API • The Streaming API is a general purpose parallel computing API for SolrCloud
- 22. 22 01 Parallel Computing Framework • Shuffling • Worker Collections • Streaming API • Streaming Expressions • Parallel SQL
- 23. 23 01 Shuffling (sorting & partitioning) • Shuffling is pushed down into the search engine • Sorting: /export handler “stream sorts” entire result sets. • Partitioning: HashQParserPlugin, hash partitioning filter. Partitions results on arbitrary fields. • Tuples (search results) begin streaming instantly to worker nodes. Shuffling never requires a spill to disk. • All replicas shuffle in parallel for the same query. Allows for massive throughput.
- 24. 24 01 Shuffling (sorting & partitioning) Worker 2Worker 1 Shard 1 Replica 1 Shard 2 Replica 1 Shard 1 Replica 2 Shard 2 Replica 2 Client Each worker is shuffled ½ the result set Tuples are sorted and partitioned on keys
- 25. 25 01 Worker Collections • Are Generic SolrCloud Collections • Can hold data, or just perform work • Search results are shuffled to the workers • Configured with the /stream handler
- 26. 26 01 Streaming API • Java Programming API for the parallel computing framework • Real-time Map/Reduce and Parallel Relational Algebra • Abstracts search results as Streams of tuples (TupleStream) • Streams are transformed in parallel by pluggable Decorator streams. • Parallel transformations include: group by, rollup, union, intersect, complement and join
- 27. 27 01 Streaming Expressions • Contributed by Dennis Gove (Bloomberg) • String Query Language and Serialization format for the Streaming API • Streaming Expressions compile to TupleStreams • TupleStreams serialize to Streaming Expressions
- 28. 28 01 Parallel SQL • Compiles SQL to a TupleStream • The TupleStream is serialized to a Streaming Expression and sent to worker nodes. • Worker nodes translate the Streaming Expression back into TupleStream • Worker nodes open() and read() the TupleStream in parallel. Tuples are returned from each worker
- 29. 29 01 From SQL to Streaming Expression select str_s, count(*), sum(field_i), min(field_i), max(field_i), avg(field_i) from collection1 where text='XXXX' group by str_s rollup( search(collection1, q="(text:XXXX)", qt="/export", fl="str_s, field_i", partitionKeys=str_s, sort="str_s asc", zkHost="127.0.0.1:64149/solr"), over=str_s, count(*), sum(field_i), min(field_i), max(field_i), avg(field_i))
- 30. 30 01 Parallel SQL Shuffle (5 workers, 5 shards, aggregationMode=map_reduce) Client Worker 2 Shard 3 Replica 2 Worker 3Worker 1 Worker 4 Worker 5 Shard 1 Replica 2 Shard 1 Replica 3 Shard 2 Replica 3 Shard 2 Replica 2 Shard 2 Replica 1 Shard 1 Replica 1 Shard 3 Replica 1 Shard 3 Replica 3 Shard 4 Replica 3 Shard 4 Replica 2 Shard 4 Replica 1 Shard 5 Replica 3 Shard 5 Replica 2 Shard 5 Replica 1 /SQL handler
- 31. 31 01 Jira Tickets • SOLR-7560: Parallel SQL Support • SOLR-7377: Solr Streaming Expressions • SOLR-7082: Streaming Aggregation for SolrCloud • SOLR-7441: Improve overall robustness of the Streaming stack: Streaming API, Streaming Expressions, Parallel SQL
- 32. 32 01 Getting Involved • SQL is in Trunk • Releasing with Solr 6 • Streaming API and Streaming Expressions are located in the Solrj libraries (solrj.io) • Patches welcome • Testers and feedback needed
Editor's Notes
- This slide shows a network diagram of a parallel SQL shuffle. Below are the steps: A client sends a SQL query to the SQL handler running on a Solr node. The SQL handler compiles the SQL query to a Streaming Expression (See slide 27). The Streaming Expression is sent across the wire to worker nodes Each worker node compiles the Streaming Expression to a Streaming API TupleStream. The workers open the TupleStream and iterate the Tuples. The requests from the worker nodes to the shards occur when then TupleStream is opened and iterated. Each worker node contacts each shard and is shuffled 1/5 of the search results. Requests to the shards are spread evenly across all replicas. All replicas shuffle in parallel to satisfy the query.
