Java agents are pluggable self contained components that run embedded in a JVM and intercept the classloading process. They were introduced in Java 5 along with the powerful java.lang.instrument package. Java agents can be loaded statically at startup or dynamically (programmatically) at runtime to attach to a running process. Java agents were an awesome addition to the JVM as it opened a lot of opportunities for tool designers and changed Java tooling landscape quite drastically. In conjunction with Java bytecode manipulation libraries it is now possible to do amazing things to Java classes: we can experiment with programming models, redefine classes at runtime, record execution flow, etc. I’d like to give an overview of Java agents’ functionality along with the usage examples and real world experiences. You will learn, how to implement an agent and apply Instrumentation API in combination with bytecode manipulation libraries to solve interesting tasks.

1. Taming Java Agents
@antonarhipov

2. Me
Anton Arhipov
@antonarhipov
anton@zeroturnaround.com
ZeroTurnaround
JRebel, XRebel

4. Agenda
• Overview of Java agent technology
• Instrumentation API
• Attach API
• HacksApplications
http://xkcd.com/138/

5. BTrace

6. Pretty much every APM tool today uses
Java Agents to instrument the application

7. A lightweight profiler for Java web apps

8. A lightweight profiler for Java web apps

9. A lightweight profiler for Java web apps

10. A lightweight profiler for Java web apps

11. A lightweight profiler for Java web apps

12. A lightweight profiler for Java web apps

16. my.war
ClassLoader
getResource("hello.html"); read("src/main/.../hello.html");
rebel.xml
• Maps the running application to IDE workspace
• Reloads Java classes and framework configurations in
a running JVM process

17. This slide is intentionally left blank

19. public static void main(String[] args) {
for (String arg : args) {
new Thread(new Runnable() {
public void run() {
//....
}
}).start();
Java app

20. public static void main(String[] args) {
for (String arg : args) {
new Thread(new Runnable() {
public void run() {
//.....
}
}).start();
RULE trace thread start
CLASS java.lang.Thread
METHOD start()
IF true
DO traceln("*** start for thread: "+ $0.getName())
ENDRULE
Java app
Byteman
rule

21. public static void main(String[] args) {
for (String arg : args) {
new Thread(new Runnable() {
public void run() {
//.....
}
}).start();
RULE trace thread start
CLASS java.lang.Thread
METHOD start()
IF true
DO traceln("*** start for thread: "+ $0.getName())
ENDRULE
> java -javaagent:byteman.jar=script:thread.btm,boot:byteman.jar
-Dorg.jboss.byteman.transform.all org.my.AppMain2 foo bar baz
*** start for thread: foo
foo
*** start for thread: bar
bar
*** start for thread: baz
baz
Java app
Byteman
rule

22. public static void main(String[] args) {
for (String arg : args) {
new Thread(new Runnable() {
public void run() {
//.....
}
}).start();
RULE trace thread start
CLASS java.lang.Thread
METHOD start()
IF true
DO traceln("*** start for thread: "+ $0.getName())
ENDRULE
Java app
Byteman
rule

23. public static void main(String[] args) {
for (String arg : args) {
new Thread(new Runnable() {
public void run() {
//.....
}
}).start();
RULE trace thread start
CLASS java.lang.Thread
METHOD start()
IF true
DO traceln("*** start for thread: "+ $0.getName())
ENDRULE
> java -classpath byteman-install.jar
org.jboss.byteman.agent.install.Install 13101
Java app
Byteman
rule
Install agent:

24. public static void main(String[] args) {
for (String arg : args) {
new Thread(new Runnable() {
public void run() {
//.....
}
}).start();
RULE trace thread start
CLASS java.lang.Thread
METHOD start()
IF true
DO traceln("*** start for thread: "+ $0.getName())
ENDRULE
> java -classpath byteman-install.jar
org.jboss.byteman.agent.install.Install 13101
Java app
Byteman
rule
> java -classpath byteman-submit.jar
org.jboss.byteman.agent.submit.Submit -l thread.btm
Install agent:
Submit rules:

25. http://byteman.jboss.org

26. Java Agent Overview

27. import java.lang.instrument.ClassFileTransformer;
import java.lang.instrument.Instrumentation;
public class Agent {
public static void premain(String args, Instrumentation inst) {
inst.addTransformer(new ClassFileTransformer { … });
}
public static void agentmain(String args, Instrumentation inst) {
premain(args, inst);
}
}
META-­‐INF/MANIFEST.MF
Premain-­‐Class: Agent
$> java –javaagent:agent.jar application.Main

28. java.lang.instrument.ClassFileTransformer
public class MyTransformer implements ClassFileTransformer {
public void byte[] transform(ClassLoader loader,
String className,
Class<?> classBeingRedefined,
ProtectionDomain pd,
byte[] classfileBuffer){
ClassPool cp = ClassPool.getDefault();
CtClass ct = cp.makeClass(new ByteArrayInputStream(classfileBuffer));
// transform the bytes as required,
// for instance - with Javassist
return ct.toBytecode();
}
}

29. Class loading
Instrumentation

30. Class loading
ClassFileTransformer
ClassFileTransformer
ClassFileTransformer
Instrumentation

31. Class loading
ClassFileTransformer
ClassFileTransformer
ClassFileTransformer
Javassist
ASM
Instrumentation
Bytebuddy

32. https://github.com/zeroturnaround/callspy

33. Instrumentation API

34. java.lang.instrument.Instrumentation
void addTransformer(ClassFileTransformer transformer,
boolean canRetransform);
void appendToBootstrapClassLoaderSearch(JarFile jarfile);
void appendToSystemClassLoaderSearch(JarFile jarfile);
Class[] getAllLoadedClasses();
Class[] getInitiatedClasses(ClassLoader loader);
void redefineClasses(ClassDefinition... classes);
void retransformClasses(Class<?>... classes);

35. JVM JVM
Process 1 Process 2
Agent
-cp tools.jar
Attach API

36. • Executed when the agent attaches to the running JVM
• Instrumentation parameter is optional
• META-INF/MANIFEST.MF is required
• Requires support for loading agents in JVM
• Allows adding the code to JVM post-factum
public static void agentmain(String args,
Instrumentation inst)

37. import com.sun.tools.attach.VirtualMachine;
//attach to target VM
VirtualMachine vm = VirtualMachine.attach("2177");
//get system properties in the target VM
Properties props = vm.getSystemProperties();
//load agent into the VM
vm.loadAgent("agent.jar", "arg1=x,arg2=y");
//detach from VM
vm.detach();
http://docs.oracle.com/javase/7/docs/jdk/api/attach/spec/com/sun/tools/attach/VirtualMachine.html

38. https://gist.github.com/nickman/6494990
https://github.com/antonarhipov/attach-and-transform-with-mbeans

39. https://speakerdeck.com/antonarhipov
http://www.slideshare.net/arhan
@antonarhipov
anton@zeroturnaround.com

40. Resources
http://byteman.jboss.org
http://www.javassist.org
https://github.com/zeroturnaround/callspy
https://github.com/antonarhipov/attach-and-transform-with-mbeans
https://docs.oracle.com/javase/8/docs/api/java/lang/instrument/package-
summary.html
http://docs.oracle.com/javase/8/docs/jdk/api/attach/spec/com/sun/tools/
attach/VirtualMachine.html
http://asm.ow2.org/ http://bytebuddy.net/
