OAuth based reference architecture for API Management
- 1. OAuth 2.0 Reference Model for API Management Sumedha Rubasinghe Senior Architect, WSO2 API Manager Team
- 2. About WSO2 ๏ ๏ Global enterprise, founded in 2005 by acknowledged leaders in XML, web services technologies, standards and open source Provides only open source pla:orm-‐as-‐a-‐service for private, public and hybrid cloud deployments ๏ ๏ * All WSO2 products are 100% open source and released under the Apache License Version 2.0. Is an AcIve Member of OASIS, Cloud Security Alliance, OSGi Alliance, AMQP Working Group, OpenID FoundaIon and W3C. ๏ Driven by InnovaIon ๏ Launched first open source API Management soluIon in 2012 ๏ Launched App Factory in 2Q 2013 ๏ Launched Enterprise Store and first open source Mobile soluIon in 4Q 2013
- 3. What we Deliver *
- 4. What we will cover... ● Main concepts in OAuth 2.0 model ● How WSO2 supports OAuth 2.0 based API Management? ● OAuth 2.0 based extensions in WSO2 API Management soluIon *
- 5. Web (based) APIs ● hXps://www.facebook.com/sam.jason/photos ● hXp://api-‐public.ne:lix.com/catalog/Itles/movies/60021896 ● many more.. *
- 6. Pre OAuth Era .. How do I know for sure? *
- 7. Pre OAuth Era .. *
- 8. Pre OAuth Era .. No Control over password storage. Complete access to user account. * ApplicaIons can be compromised. Changing password can break many apps. Requires password reset to revoke.
- 9. OAuth 2.0 -‐ in a nutshell.. “The OAuth 2.0 authorizaIon framework enables a third-‐party applica2on to obtain limited access to an HTTP service…” -‐OAuth 2.0 SpecificaKon, hLp://tools.ieO.org/html/rfc6749 *
- 10. WSO2 API Manager ● Complete API Management Pla:orm ○ ○ ○ ○ ○ ○ ○ ○ API Publishing API Store SubscripIon Mgt Token Management ThroXling StaIsIcs Scalable Deployment OAuth 2.0 based ● Apache v2 Licensed ● Build on top of proven WSO2 components * ○ Enterprise Service Bus ○ IdenIty Server ○ Governance Registry ● hXp://docs.wso2.org/display/AM160/WSO2+API+Manager
- 11. OAuth 2.0 -‐ DefiniKons * ● Resource Owner ○ EnIty(end user) capable of granIng access to a resource ○ FB user (enIty) -‐> hXps://www.facebook.com/search/me/friends (resource) ● Resource Server (hXps://www.facebook.com) ○ Server hosIng protected resources ○ Capable of accepIng and responding to resource requests ● Client (FB applicaIon) ○ ApplicaIon making requests to access protected resources ● Authoriza2on Server (can be same as Resource Server) ○ Server issuing access tokens to the client
- 12. OAuth 2.0 Protocol Flow hLp://tools.ieO.org/html/rfc6749 *
- 14. AuthorizaKon Code ● End user visits auth page ○ response_type=code Web Server Apps ● End user is redirected to your site with auth code ○ http://yoursite.com/?code=xxxxxx ● Web Server exchanges Auth Code for an Access Token ○ POST /token code=xxxxxx&grant_type=authorization_code *
- 17. Access Token from Auth Code hLp://docs.wso2.org/display/AM160/Token+API *
- 18. Access Token Response *
- 19. Implicit Grant ● Browser based apps ■ no server side code ■ browser makes API requests directly ● User visits a page ○ response_type=token Browser based Apps ● User is redirected to your site with access token ○ http://yoursite.com/#token=xxxxxx ● Token is only available to browser (only in fragment) *
- 20. Implicit Grant -‐ Syntax Browser based Apps hLp://docs.wso2.org/display/AM160/Token+API *
- 21. Password Grant Trusted ApplicaKons ● Only by trusted clients ○ Apps & APIs -‐ by same enterprise /First party Apps hLp://docs.wso2.org/display/AM160/Token+API *
- 22. Client CredenKals ApplicaKons ● ApplicaIon level access ● ApplicaIon has ○ client_id (consumer key) ○ client_secret (consumer secret) ● Server uses client_id & client_secret to obtain access token ○ POST /token grant_type=client_credenIals&client_id=XXXX&client_secret= YYYY *
- 24. Mobile ApplicaKons ● Use ‘implicit’ grant type ○ (similar to browser based apps) ● Mobile App directly does API calls ● No client (mobile app) secret ● NaIve App -‐> Browser based call * Mobile Apps
- 26. Grant Type Summary ● authorizaKon_code ○ Web Server based applicaIons ● implicit ○ Browser based applicaIons, Mobile Apps ● password ○ username/password based access ● client _credenKals ○ ApplicaIons (with no need of user level authorizaIon) *
- 27. Extensions to Grant Types ● SAML2 Bearer Tokens -‐> OAuth2 *
- 28. Accessing APIs Query Parameter Access token in HTTP Header *
- 29. Access Token Lifecycle ● AcIve ● Revoked ● Expired ● In-‐AcIve *
- 30. Refreshing an expired token hLp://docs.wso2.org/display/AM160/Token+API *
- 31. Bearer Tokens ● Security ConsideraIons ○ Replies on transport level security (HTTPS) ○ No cryptographic verificaIon ● Security RecommendaIons ○ Use HTTPs (always) & verify SSL CerIficates ○ Protect Bearer tokens ○ Choose token lifeIme wisely ○ Do not persist tokens unnecessarily *
- 32. MAC Tokens ● Provides cryptographic verificaIon of request *
- 33. LimiKng Access through ‘scope' ● ‘scope’ -‐> specifies what needs be done with the access token ● Specified @ the point of obtaining access token ● space delimited, comma delimited string ● eg: Facebook Extended Permissions ○ hXps://developers.facebook.com/docs/reference/login/ extended-‐permissions/ *
- 34. “scope” -‐ Facebook Example hXps://developers.facebook.com/docs/reference/login/extended-‐permissions/ *
- 35. “scope” -‐ Facebook Example *
- 36. “scope” -‐ Facebook Example *
- 37. “scope” -‐ Token Request Syntax hXps://www.facebook.com/dialog/oauth? client_id=APP_ID&redirect_uri=APP_URL&scope=read_friendlists ,read_mailbox *
- 38. Extensions based on OAuth Model ● API InvocaIon StaIsIcs CollecIon ● Access ThroXling *
- 39. WSO2 API Manager *
- 43. Tier based ThroLling *
- 44. StaKsKcs *
- 45. Business Model *
- 46. Contact us !
