This document is a product catalog from MicroE Systems that summarizes their range of high-performance encoder products. They offer various types of encoders including performance and value encoders, high-performance encoders, compact encoders, high vacuum encoders, and absolute encoders. Their encoders provide high resolution, accuracy, and value for applications ranging from motion control to metrology. MicroE Systems focuses on innovative optical and electronic designs to create encoders that achieve superior performance while being small, easy to install, and low power.
