The document describes a 12,000 pound capacity mobile column lift from MAHA-USA. It can lift vehicles up to 69 inches high, has a base width of 45-58 inches depending on the model, and weighs 1,042 pounds. The lift increases maintenance capabilities by being mobile and accessible from all sides, boosts productivity over four-post lifts by providing unobstructed underbody access, and increases shop floor utilization by storing compactly when not in use despite having a 48,000 pound total lifting capacity.

1. www.maha-usa.com/12000PoundMobileColumnLifts.htm
866-624-2872
Technical Data MCL 12
Capacity 12,000 lbs. per column
Height 97.64”
Maximum Lifting Height 69”
Length of Standard Fork 16”
Base Length 46.02” / 47.99” *
Total Base Width 45” / 58” *
Tire Diameter
(Extra Wide Universal Carriage)
up to 79”
Motor Power 2.4 HP, 208/230V or
440/480V,
3-Phased, 60 Hz
Weight 1042 lbs.
Carriage Options Standard MCL 12
Standard 32.28” (16” Fork Length)
Wide Body 35.43” (16” Fork Length)
*Extra Wide Universal 48.23” (20” Fork Length)
Made in the USA
12,000 lbs Mobile Column Lifting System
Lift up to
48,000
Pounds!
- INCREASE MAINTENANCE CAPABILITIES -
Unlike fixed lifts, MAHA USA’s mobile column lifts can be used anywhere a suitable
concrete surface is present, even outdoors, taking your garage to the next level.
- BOOST PRODUCTIVITY -
Unlike four-post lifts, which limit the technician’s access to the underbody, MAHA
USA’s unique design offers full, unobstructed access to the vehicle.
- INCREASE SHOP FLOOR UTILIZATION -
Our lifts cost the same or less than a 30,000 lbs. capacity four-post lift but come
with 48,000 lbs. capacity without tying up a bay! When not in use, the MCLs can be
conveniently stored against a wall or in a corner, occupying minimal storage space.
MAXIMIZE SERVICE
OPERATIONS
Increase your Dealership’s bottom line with MAHA USA’s
Mobile Column Lifts for the Dodge heavy duty RAM series.
