The document discusses ways to make applications more resilient to crashes. It suggests using caches instead of master copies to avoid data loss on crashes. Database transactions can maintain consistency even if the database crashes. Atomic operations like file renames can be used to update counts reliably. Recovery is also important - inconsistent states after crashes should be detected and resolved. The document advocates designing systems with crashes in mind through techniques like logging, versioning, and watchdog processes.

1. Make Sure Your Applications Crash
Moshe Zadka

2. True story

3. Python doesn't crash
Memory managed, no direct pointer arithmetic

4. ...except it does
C bugs, untrapped exception, infinite loops,
blocking calls, thread dead-lock, inconsistent
resident state

5. Recovery is important
"[S]ystem failure can usually be considered to
be the result of two program errors[...] the
second, in the recovery routine[...]"

6. Crashes and inconsistent data
A crash results in data from an arbitrary
program state.

7. Avoid storage
Caches are better than master copies.

8. Databases
Transactions maintain consistency
Databases can crash too!

9. Atomic operations
File rename

10. Example: Counting
def update_counter():
fp = file("counter.txt")
s = fp.read()
counter = int(s.strip())
counter += 1
# If there is a crash before this point,
# no changes have been done.
fp = file("counter.txt.tmp", 'w')
print >>fp, counter
fp.close()
# If there is a crash before this point,
# only a temp file has been modified
# The following is an atomic operation
os.rename("counter.txt.tmp", "counter.txt")

11. Efficient caches, reliable masters
Mark inconsistency of cache

12. No shutdown
Crash in testing

13. Availability
If data is consistent, just restart!

14. Improving availability
Limit impact
Fast detection
Fast start-up

15. Vertical splitting
Different execution paths, different processes

16. Horizontal splitting
Different code bases, different processes

17. Watchdog
Monitor -> Flag -> Remediate

18. Watchdog principles
Keep it simple, keep it safe!

19. Watchdog: Heartbeats
## In a Twisted process
def beat():
file('beats/my-name', 'a').close()
task.LoopingCall(beat).start(30)

20. Watchdog: Get time-outs
def getTimeout()
timeout = dict()
now = time.time()
for heart in glob.glob('hearts/*'):
beat = int(file(heart).read().strip())
timeout[heart] = now-beat
return timeout

21. Watchdog: Mark problems
def markProblems():
timeout = getTimeout()
for heart in glob.glob('beats/*'):
mtime = os.path.getmtime(heart)
problem = 'problems/'+heart
if (mtime<timeout[heart] and
not os.path.isfile(problem)):
fp = file('problems/'+heart, 'w')
fp.write('watchdog')
fp.close()

22. Watchdog: check solutions
def checkSolutions():
now = time.time()
problemTimeout = now-30
for problem in glob.glob('problems/*'):
mtime = os.path.getmtime(problem)
if mtime<problemTimeout:
subprocess.call(['restart-system'])

23. Watchdog: Loop
## Watchdog
while True:
markProblems()
checkSolutions()
time.sleep(1)

24. Watchdog: accuracy of
Custom checkers can manufacture problems

25. Watchdog: reliability of
Use cron for main loop

26. Watchdog: reliability of
Use software/hardware watchdogs

27. Conclusions
Everything crashes -- plan for it

28. Questions?

29. Welcome to the back-up slides
Extra! Extra!

30. Example: Counting on Windows
def update_counter():
fp = file("counter.txt")
s = fp.read()
counter = int(s.strip())
counter += 1
# If there is a crash before this point,
# no changes have been done.
fp = file("counter.txt.tmp", 'w')
print >>fp, counter
fp.close()
# If there is a crash before this point,
# only a temp file has been modified
os.remove("counter.txt")
# At this point, the state is inconsistent*
# The following is an atomic operation

31. os.rename("counter.txt.tmp", "counter.txt")

32. Example: Counting on Windows
(Recovery)
def recover():
if not os.path.exists("counter.txt"):
# The permanent file has been removed
# Therefore, the temp file is valid
os.rename("counter.txt.tmp",
"counter.txt")

33. Example: Counting with versions
def update_counter():
files = [int(name.split('.')[-1])
for name in os.listdir('.')
if name.startswith('counter.')]
last = max(files)
counter = int(file('counter.%s' % last
).read().strip())
counter += 1
# If there is a crash before this point,
# no changes have been done.
fp = file("tmp.counter", 'w')
print >>fp, counter
fp.close()
# If there is a crash before this point,
# only a temp file has been modified

34. os.rename('tmp.counter',
'counter.%s' % (last+1))
os.remove('counter.%s' % last)

35. Example: Counting with versions
(cleanup)
# This is not a recovery routine, but a cleanup
# routine.
# Even in its absence, the state is consistent
def cleanup():
files = [int(name.split('.')[-1])
for name in os.listdir('.')
if name.startswith('counter.')]
files.sort()
files.pop()
for n in files:
os.remove('counter.%d' % n)
if os.path.exists('tmp.counter'):
os.remove('tmp.counter')

36. Correct ordering
def activate_due():
scheduled = rs.smembers('scheduled')
now = time.time()
for el in scheduled:
due = int(rs.get(el+':due'))
if now<due:
continue
rs.sadd('activated', el)
rs.delete(el+':due')
rs.sremove('scheduled', el)

37. Correct ordering (recovery)
def recover():
inconsistent = rs.sinter('activated',
'scheduled')
for el in inconsistent:
rs.delete(el+':due') #*
rs.sremove('scheduled', el)

38. Example: Key/value stores
0.log:
['add', 'key-0', 'value-0']
['add', 'key-1', 'value-1']
['add', 'key-0', 'value-2']
['remove', 'key-1']
.
.
.
1.log:
.
.
.
2.log:

39. .
.
.

40. Example: Key/value stores (utility
functions)
## Get the level of a file
def getLevel(s)
return int(s.split('.')[0])
## Get all files of a given type
def getType(tp):
return [(getLevel(s), s)
for s in files if s.endswith(tp)]

41. Example: Key/value stores
(classifying files)
## Get all relevant files
def relevant(d):
files = os.listdir(d):
mlevel, master = max(getType('.master'))
logs = getType('.log')
logs.sort()
return master+[log for llevel, log in logs
if llevel>mlevel]

42. Example: Key/value stores (reading)
## Read in a single file
def update(result, fp):
for line in fp:
val = json.loads(line)
if val[0] == 'add':
result[val[1]] = val[2]
else:
del result[val[1]]
## Read in several files
def read(files):
result = dict()
for fname in files:
try:
update(result, file(fname))

43. except ValueError:
pass
return result

44. Example: Key/value stores (writer
class)
class Writer(object):
def __init__(self, level):
self.level = level
self.fp = None
self._next()
def _next(self):
self.level += 1
if self.fp:
self.fp.close()
name ='%3d.log' % self.currentLevel
self.fp = file(name, 'w')
self.rows = 0
def write(self, value):

45. print >>self.fp, json.dumps(value)
self.fp.flush()
self.rows += 1
if self.rows>200:
self._next()

46. Example: Key/value stores (storage
class)
## The actual data store abstraction.
class Store(object):
def __init__(self):
files = relevant(d)
self.result = read(files)
level = getLevel(files[-1])
self.writer = Writer(level)
def get(self, key):
return self.result[key]
def add(self, key, value):
self.writer.write(['add', key, value])
def remove(self, key):
self.writer.write(['remove', key])

47. Example: Key/value stores
(compression code)
## This should be run periodically
# from a different thread
def compress(d):
files = relevant(d)[:-1]
if len(files)<2:
return
result = read(files)
master = getLevel(files[-1])+1
fp = file('%3d.master.tmp' % master, 'w')
for key, value in result.iteritems():
towrite = ['add', key, value])
print >>fp, json.dumps(towrite)
fp.close()

48. Vertical splitting: Example
def forking_server():
s = socket.socket()
s.bind(('', 8080))
s.listen(5)
while True:
client = s.accept()
newpid = os.fork()
if newpid:
f = client.makefile()
f.write("Sunday, May 22, 1983 "
"18:45:59-PST")
f.close()
os._exit()

49. Horizontal splitting: front-end
## Process one
class SchedulerResource(resource.Resource):
isLeaf = True
def __init__(self, filepath):
resource.Resource.__init__(self)
self.filepath = filepath
def render_PUT(self, request):
uuid, = request.postpath
content = request.content.read()
child = self.filepath.child(uuid)
child.setContent(content)
fp = filepath.FilePath("things")
r = SchedulerResource(fp)
s = server.Site(r)
reactor.listenTCP(8080, s)

50. Horizontal splitting: scheduler
## Process two
rs = redis.Redis(host='localhost',
port=6379, db=9)
while True:
for fname in os.listdir("things"):
when = int(file(fname).read().strip())
rs.set(uuid+':due', when)
rs.sadd('scheduled', uuid)
os.remove(fname)
time.sleep(1)

51. Horizontal splitting: runner
## Process three
rs = redis.Redis(host='localhost',
port=6379, db=9)
recover()
while True:
activate_due()
time.sleep(1)

52. Horizontal splitting: message
queues
No direct dependencies

53. Horizontal splitting: message
queues: sender
## Process four
rs = redis.Redis(host='localhost',
port=6379, db=9)
params = pika.ConnectionParameters('localhost')
conn = pika.BlockingConnection(params)
channel = conn.channel()
channel.queue_declare(queue='active')
while True:
activated = rs.smembers('activated')
finished = set(rs.smembers('finished'))
for el in activated:
if el in finished:
continue

54. channel.basic_publish(
exchange='', routing_key='active',
body=el)
rs.add('finished', el)

55. Horizontal splitting: message
queues: receiver
## Process five
# It is possible to get "dups" of bodies.
# Application logic should deal with that
params = pika.ConnectionParameters('localhost')
conn = pika.BlockingConnection(params)
channel = conn.channel()
channel.queue_declare(queue='active')
def callback(ch, method, properties, el):
syslog.syslog('Activated %s' % el)
channel.basic_consume(callback, queue='hello', no_ack=True)
channel.start_consuming()

56. Horizontal splitting: point-to-point
Use HTTP (preferably, REST)
