1. Load Balancing in
Distributed Database
Md. Shamsur Rahim 14-98181-3 Student, MScCS, AIUB
AZM Ehtesham Chowdhury 15-98451-1 Student, MScCS, AIUB
Saiful Akhter 15-98502-1 Student, MScCS, AIUB

2. Load Balancing:
 Means distributing transaction and queries among different nodes.
 The goal is to maximize the throughput.
 Parallel Execution Problems
 1. Initialization
 2. Interference
 3. Skew

3. Parallel Execution Problems : Initialization
 Initialization is necessary before execution.
 This sequential steps includes
 Process/ Thread Creation and initialization
 Communication Initialization etc.
 The duration is proportional to the degree of parallelism
 The degree of parallelism should be fixed according to query complexity.
 Formula for finding response time for an Operator:
𝑅𝑒𝑠𝑝𝑜𝑛𝑠𝑒𝑇𝑖𝑚𝑒 = 𝑎 ∗ 𝑛 +
𝑐∗𝑁
𝑛
 The equation can be further derived to obtain:
𝑁 = 𝑡𝑜𝑢𝑝𝑙𝑒𝑠, 𝑐 = 𝑎𝑣𝑔 𝑝𝑟𝑜𝑐𝑒𝑠𝑠𝑖𝑛𝑔 𝑡𝑖𝑚𝑒
n = No. Of Processors
optimal number of processors to allocate (n) maximal achievable speedup (S)
𝑛 = √
𝑐 ∗ 𝑁
𝑎
𝑆 =
𝑛
2

4. Parallel Execution Problems : Interferences
 Parallel execution can be slowed down by interference.
 Interference occurs when several processors simultaneously access the same
resource,
 Hardware
 Solution: Duplicate Shared resource
 Software.
 Solution: Partition the shared resource into several independent resources

5. Parallel Execution Problems : Skew
 Problem appears with intra- operator parallelism (variation in partition size) is known as data
skew.
 Classification of Skew:
 Attribute Value Skew : inherent in the dataset
 e.g., there are more citizens in Paris than in Waterloo
 Tuple Placement Skew: introduced when the data are initially partitioned
 e.g., with range partitioning
 Selectivity Skew
 introduced when there is variation in the selectivity of select predicates on each node
 Redistribution Skew
 occurs in the redistribution step between two operators.
 Join Product Skew
 occurs because the join selectivity may vary between nodes

6. Inter-Query Parallelism
 Form of parallelism where many different Queries or Transactions are
executed in parallel with one another on many processors.
 Advantages:
 Increases Transaction Throughput.
 Scales up the Transaction processing system
 Easy to implement in Shared Memory Parallel System.
 Example: Oracle 8 & Oracle Rdb.

7. Intra-Query Parallelism
 Form of parallelism where Single Query is executed in parallel on many
processors.
 2 Types.
 Intra-operation parallelism
 Inter-operation parallelism
 Advantages:
 speed up a single complex long running queries.
 Best suited for complex scientific calculations (queries).
 Example: Informix, Terradata.

8. Intra-operation parallelism
 The process of speeding up a query through parallelizing the execution of
individual operations.
 The operations which can be parallelized are Sort, Join, Projection, Selection
and so on.

9. Inter-operation parallelism
 The process of speeding up a query through parallelizing various operations
which are part of the query.
 Example Step:
 A query which involves join of 4 tables executed in two processors
 Each processor shall join two relations locally and the result1 and result2 can be
joined further to produce the final result.

10. Intra-Operator Load Balancing
 Depends on
 The degree of parallelism.
 Allocation of processors for the operator.
 The home of the operator (the set of processors where it is executed) must be
carefully decided.
 The skew problem makes it hard for a parallel query optimizer to make this
decision statically.
 Require a very accurate and detailed cost model.

11.  Two Solutions incorporated in a hybrid query optimizer.
 Adaptive
 Specialized

12. Adaptive Technique
 The main idea is to statically decide on an initial allocation of the
processors to the operator (using a cost model).
 Adapt to skew using load reallocation.
 Load reallocation is to detect the oversized partitions.
 Partition them again onto several processors.

13. Adaptive Technique(Continued)
 Advantage:
 More dynamic adjustment of the degree of parallelism.
 useful to improve intra-operator load balancing in all kinds of parallel
architectures.
 By reducing processor interference
 Excellent load balancing for intra-operator parallelism

14. Adaptive Technique(Continued)
 specific control operators.
 Detect whether the static estimates for intermediate result sizes differ from
the run-time values.
 Relation redistribution in order to prevent join product skew and
redistribution skew.
 Depends on difference between the estimate and the real value is sufficiently
high.

15. Specialized techniques
 Two main techniques.
 Range partitioning
 Sampling
 Avoid redistribution skew of the building relation.
 Processors can get partitions of equal numbers of tuples, corresponding to
different ranges of join attribute values.

16. Specialized techniques(Continued)
 To deal with skew as follows:
 Sample the building relation to determine the partitioning
ranges.
 Redistribute the building relation to the processors using the
ranges. Each processor builds a hash table containing the
incoming tuples.
 Redistribute the probing relation using the same ranges to
the processors. For each tuple received, each processor
probes the hash table to perform the join.

17. Inter-Operator Load Balancing
 Important to Choose for each operator
 How many and which processors to assign for its execution.
 Taking into account pipeline parallelism, which requires inter-operator
communication.
 Harder to achieve in shared-nothing for this Reasons:
 Choice of the degree of parallelism cause to errors
 Reason: Both processors and operators are discrete entities.

18. Inter-Operator Load
Balancing(Continued)
 Processors associated with the latest operators in a pipeline
chain may remain idle a significant time.
 Shared-memory allows the parallel execution of independent
pipeline chains
 It is known as Tasks.
 Dynamically adjusting the degree of intra-operator parallelism
of the tasks in order to reach maximum resource utilization.

19. Activations
 Represents a sequential unit of work
 Can be executed by any thread
 Self-contained
 Can only be executed in the same SM(shared memory)-node

20. Activation Queues
Moving data activation along pipeline chains
Also called table queues
Threads have unrestricted access to the same SM-node queues
Small number of queue results interference
A thread a queue

21. Thread
 Simple strategy for good load balancing if number of threads are higher than
the processors
 One thread per processor per query reduce the overhead of interference
 Thread will consume activation as much as possible to limit thread
interference

22. THANK YOU

23. Reference:
 M. Tamer Özsu • Patrick Valduriez, Principles of Distributed Database Systems,
Third Edition
