JavaScript and NodeJS overview - Capabilities in testing, NodeJS platform overview. JavaScript testing tools and frameworks - WebdriverJS, Protractor, Jasmine, Cucumber. Test Framework solutions - Page Object, Page Element, REST Api testing, Database interaction.

1. Viacheslau Bushyla
JavaScript in test automation

2. Viacheslau Bushyla
Senior Software Test Automation Engineer

3. 3
Node js platform to execute JS
Node.JS = V8 + I/O + libraries
V8
- fast
- modern (all standards)
- efficiently uses resources
I/O
- files
- network
- input/output
NPM
- installs libraries
JavaScript and Node js

4. 4
var employee = {
active: true,
age: 20,
name: "Ivan",
skills: ['Java', 'AT', 'JavaScript'],
employer: {company: "Epam"},
workStation: null,
summary: undefined,
toString: function () {
console.log("Name: ", this.name, "Age: ", this.age);
}
}
typeof(employee.active)
"boolean"
typeof(employee.age)
"number"
typeof(employee.name)
"string"
typeof(employee.skills)
"object"
typeof(employee.employer)
"object"
typeof(employee.workStation)
"object"
typeof(employee.summary)
"undefined"
typeof(employee.toString)
"function"
JavaScript types

5. 5
JSON - JavaScript Object Notation
var objectToString = JSON.stringify(employee);
"{
"active":true,
"age":20,
"name":"Ivan",
"skills":["Java","AT","JavaScript"],
"employer":{"company":"Epam"},
"workStation":null
}"
var stringToObject = JSON.parse(objectToString)
Object
Object {active: true, age: 20, name: "Ivan", skills: Array[3], employer: Object…}
HTTP
DB
File
Browser
JavaScript and JSON

6. 6
Stack
Input/Output
console.log("start");
var file = fs.readFile('/etc/passwd')
console.log("done");
main()
readFileconsole.log("end")console.log("done")console.log("start")fs.readFile(cb)
start
done
task queue
console
Synchronous JavaScript

7. 7
Stack
webapis/IO
event loop
cb
console.log("start");
fs.readFile('/etc/passwd', (err, data) => {
if (err) throw err;
console.log("done");
});
console.log("end");
main()
cb
console.log("end")console.log("done")console.log("start")fs.readFile(cb)
start
end
done
task queue
console
Asynchronous JavaScript

8. 8
Stack
driver
console.log("start");
driver.findElement(locator).then(function (q) {
console.log("done");
}).then(function () {
console.log("end");
});
main()
driver.findElementconsole.log("done")console.log("end")console.log("start")driver.findElement()
start
done
end
console
Synchronization with Promises

9. 9
Promise - represents the eventual result of an asynchronous operation.
Then method, which registers callbacks to receive either a promise’s eventual
value or the reason why the promise cannot be fulfilled.
<pending>
fulfilled
rejected
Promises

10. 10
Web Browser Web Server
request url
HTML page
AJAX request
response
constant long polling
requests....
Synchronization

11. 11
● Run test framework with CLI and configuration file
● Integration with popular JavaScript test framework - Jasmine, Cucumber
● Maintains a queue of pending promises to keep execution organized
● Provides Api to locate and perform actions on DOM elements
● Provides synchronization with Angular application
Protractor test framework

12. 12
Page
http pending requests
Browser
Driver
WD request
Sync
Angular
WD response
Synchronization with Angular

13. 13
Runner
Protractor
Selenium
WDApi
Adapter
Jasmine
Cucumber
Mocha
Protractor decomposition

14. 14
// C#
public class LoginPage
{
[FindsBy(How = How.Id, Using = "bbcid_unique")]
private IWebElement userName;
[FindsBy(How = How.Id, Using = "bbcid_password")]
private IWebElement password;
[FindsBy(How = How.Id, Using = "bbcid_submit_button")]
private IWebElement signInButton;
[FindsBy(...)]
private IList<IWebElement> someElements;
public LoginPage()
{
PageFactory.InitElements(DriverManager.getDriver(), this);
}
public void login(string login, string password)
{
userName.SendKeys(login);
password.SendKeys(password);
signInButton.Click();
}
}
// JS
var LoginPage = function() {
this.userName = element(by.id('bbcid_unique'));
this.password = element(by.id('bbcid_password'));
this.signInButton = element(by.id('bbcid_submit_button'));
this.someElements = element.all(by.tagName('img'));
this.login = function (login, password) {
userName.sendKeys;
password.sendKeys(password);
signInButton.click();
};
};
module.exports = LoginPage;
Page Object

15. 15
Page Element
- verifyValidationError
- checkElement
Clickable Element
- click
Custom
Element
- setElement
Dropdown
- setElementByValue
- setElementBydate
- setElementByIndex
Radiogroup
- setElementByIdFragment
- setElementByIndex
Textfield
- fillElement
BooleanRadioGroup
- setElementByIdFragment
Page Elements

16. 16
carRegNumber: {set: {value: 'MF15MYC'}},
findCarButton: 'click',
licenceIssued: {check: {idFragment: 1}},
carRegNumber: {set: {value: false}},
howLongHeldLicenceYear: "verifyValidationError",
Interaction with JSON profile

17. 17
1. Support by Angular community
2. High Level abstraction (built-in factories,
builders, workers etc, configuration through
config file)
3. Supports JS test frameworks (mocha, jasmine,
cucumber)
4. Improved Control Flow (Promises chaining)
5. Integration with CI (Bamboo Atlassian, Jenkins,
Teamcity etc.)
1. Tests quite slow
2. Build in Solutions make you dependent
3. Easy make simple solution build-in for
integration tests
4. You have to create complex solution if create
tests as user do
Protractor pros and cons

18. 18
1. Native support JSON
2. NPM - build in solutions(REST, BD, reports, IO
libraries)
3. Integration with modern web UI solution
4. Integration with services, support and
documentation
5. Popular Node JS ecosystem
6. Easy to start
7. Small community
1. Slower than others platform
2. Doesn’t support strong typisation
3. Slow down development
4. Platform depended
5. Dinamic
6. Async
7. Non-standard approaches and code design
patterns
Conclusions

19. 19
https://developer.mozilla.org/ru/docs/Web/JavaScript - mozila development network
https://nodejs.org - Node JS official
https://www.npmjs.com/ - NPM official
https://www.npmjs.com/package/selenium-webdriver - WebDriver JS official documentation
http://protractortest.org - Protractor official
http://jasmine.github.io/ - Jasmine official
https://cucumber.io/ - Cucumber official
Info sources
