java card technology for smart cards

1. Presented by:
SAMIKSHA SHRUTI
CS 3rd year ‘a’
1241610086

2. CONTENTS
 Introduction
 History of Java Card
 What is Java Card
 Architecture of Java Card
 Working of Java Card
 Applications of Java Card
 Challenges in Java Card
 Conclusion

3. INTRODUCTION
 Java Card refers to a technology that allows java-based
applications(applets)to be run securely on smart cards and similar
small memory footprint devices.
 Java Card gives the user ability to program the device and make them
application specific.
 The Java Card is an extremely secure Java-powered electronic token.
 Java Card could have a number of real-world applications.

4. YEAR VERSION FUNCTIONALITY
1996 Introduction of Java Card technology
1997 Java Card 2.0 Technology Foundations
1999 Java Card 2.1 Interoperable File Format
2000 Java Card
2.1.1
Additional Crypto APIs
2002 Java Card 2.2 Next gen crypto ,memory management
2003 Java Card
2.2.1
Enhancements for USIM
2006 Java Card
2.2.2
Contactless
2008 Java Card 3.0 “Classic ” and “Connected”
HISTORY OF JAVA CARD

5. JAVA CARD
What is a Java Card?
Simple Answer:
A programmable smart card
A multi-application smart card
A smart card for secure application loading
Java+Card=Java card
Adoption of Java platform for usage on Smart cards.

6. Java Cards are Smart!
How??
 They store and process Information
 Smart Cards can be used to add
authentication and secure access to
information systems that require a high
level of security

7. ARCHITECTURE

8. 8
Elements of Java Card Application:
A complete Java Card application consists of :
a back-end application
a host (off-card) application
an interface device (card reader )
the on-card applet
user credentials
and supporting software

9. WORKING

10. 10
The Back-End Application and Systems
Provide connectivity to security systems
Example:
In an electronic payment system, the back-end
application could provide access to credit card
and other payment information

11. 11
The Reader-Side
Consists of two parts:
Host Application
Card Acceptance Device
Think of a bank machine:
Host Application as the Computer that provides
interaction with the system
Card Acceptance Device being where you put your debit
card in

12. 12
The Card-Side
Elements:
One or more Java Applets
Card’s operating System
Java Card Runtime
Environment(JCRE)
◦ Java Card Virtual Machine
◦ Java Card Framework and APIs

13. DEVELOPING A JAVA CARD APPLET
1.Write the Java source
2.Compile your source
3.Convert the class files into a
Converted Applet (CAP)
file(Binary representation of
Classes & interfaces)
4.Verify that the CAP is valid
5.Install the CAP file

14. APPLICATION AREAS
Financial
• Smart Credit / Debit
• E-Purses
• Loyalty Programs
Mobile Communication
• Infotainment
• Business Support
• Network Optimizers

15. Advantages
•Interoperable
•Secure
•Multi-Application capable
•Dynamic
•Compatible with existing standards
•Hardware Independence

16. CHALLENGES
Java cards have very restricted resources
1.Limited Memory
2.Limited Computing Power
Java Card doesn’t support some of java features
1.Large primitive data types : long, double, float
2.char,string
3.Multidimensional array
4.Dynamic class loading
5.Garbage collection
6.Multithreading
7.Object Cloning

17. CONCLUSION
•Java Card and other flavors of Java will open new markets
•Java Card Technology defines a run time environment that
supports the smart card memory, communication, security and
application execution model.
•Java Card Technology fits java system software in a smart card
while conserving enough space for applications.
•Java Card mitigates some risks associated with Java such as
dynamic class loading

18. THANK YOU
