This document discusses Java Just-In-Time (JIT) compilation. It describes JIT as compiling Java bytecode to native machine code during program execution rather than prior to execution. It outlines the main types of JIT compilers in HotSpot (client, server, tiered) and the key optimizations they perform like inlining, escape analysis, on-stack replacement, and tiered compilation. The document provides details on JIT tuning flags and how to get more profiling information from the JIT compiler logs. It emphasizes that letting the JIT do its work through warmup and avoiding microbenchmarks is important to achieving full performance.

1. JAVA JIT
Compilation and optimization

2. AGENDA
o What is JIT
o Types - Client, Server, Tiered
o Main optimizations approach
o JIT tuning
o Conclusions
2

3. WHAT IS JIT
o Just In Time compiler
o Compilation done during execution of a
program – at run time – rather than prior to
execution
o First presented at 1960 in LISP
o Java, .NET, JS…
o Oracle HotSpot, IBM J9, Azul…
3

4. WHAT IS JIT
o JIT separates optimization from SD (just update JVM
- not improve code, tune for your platform)
o JIT'ing requires Profiling
• Because you don't want to JIT everything
o Profiling allows better code-gen
• Inline what’s hot
• Loop unrolling, range-check elimination, etc
• Branch prediction, spill-code-gen, scheduling
4

5. HOTSPOT JIT CLIENT (C1) WORKFLOW
5
Java
Source Bytecode compiler
Bytecode
Optimized
code
JIT Compiler
Run time
1.5K invocations 

6. JIT CLIENT (C1)
o Produced Compilations quickly
o Generated code runs relatively slowly
6

7. HOTSPOT JIT SERVER (C2) WORKFLOW
7
Java
Source Bytecode compiler
Bytecode
Optimized
code (native)
HotSpot info
Profiler
JIT compiler
(optimization)
Run time
JIT compiler
(deoptimization)
10K invocations

8. HOTSPOT JIT SERVER (C2)
o Produce compilations slowly (long warm-up)
o Generated code runs fast
o Profiler guided
o Speculative
8

9. HOTSPOT JIT TIERED (C2)
o Available from Java 7
o Default in Java 8
o Best of C1 and C2 approaches
o Level0=Interpreter
o Level1-3=C1
o #1 – C1 w/o profiling
o #2 – C1 with basic profiling (invocations)
o #3 – C1 w full profiling (~35% overhead)
o Level4=C2
9

10. KEYS FOR JIT VERSION
10
o -client
o -server (-d64)
o -server (-d64) -XX:+TieredCompilation

11. DEFAULT JIT VERSION
11
Install bits -client -server -d64
Linux 32-bit 32-bit client compiler 32-bit server compiler Error
Linux 64-bit 64-bit server compiler 64-bit server compiler 64-bit server compiler
Mac OS X 64-bit server compiler 64-bit server compiler 64-bit server compiler
Windows 32-bit 32-bit client compiler 32-bit server compiler Error
Windows 64-bit 64-bit server compiler 64-bit server compiler 64-bit server compiler
OS Default compiler
Windows, 32-bit, any number of CPUs -client
Windows, 64-bit, any number of CPUs -server
MacOS, any number of CPUs -server
Linux/Solaris, 32-bit, 1 CPU -client
Linux/Solaris, 32-bit, 2 or more CPUs -server
Linux, 64-bit, any number of CPUs -server
*In Java 8 the server compiler is the default in any of these cases
Information about default compiler
% java -version
java version "1.7.0" Java(TM) SE Runtime Environment (build
1.7.0-b147)
Java HotSpot(TM) Server VM (build 21.0-b17, mixed mode)

12. OPTIMIZATIONS IN HOTSPOT JVM
12
• compiler tactics
• delayed compilation
• tiered compilation
• on-stack replacement
• delayed reoptimization
• program dependence graph rep.
• static single assignment rep.
• proof-based techniques
– exact type inference
– memory value inference
– memory value tracking
– constant folding
– reassociation
– operator strength reduction
– null check elimination
– type test strength reduction
– type test elimination
– algebraic simplification
– common subexpression elimination
– integer range typing
• flow-sensitive rewrites
– conditional constant propagation
– dominating test detection
– flow-carried type narrowing
– dead code elimination
• language-specific techniques
• class hierarchy analysis
• devirtualization
• symbolic constant propagation
• autobox elimination
• escape analysis
• lock elision
• lock fusion
• de-reflection
• speculative (profile-based) techniques
• optimistic nullness assertions
• optimistic type assertions
• optimistic type strengthening
• optimistic array length strengthening
• untaken branch pruning
• optimistic N-morphic inlining
• branch frequency prediction
• call frequency prediction
• memory and placement transformation
expression hoisting
expression sinking
redundant store elimination
adjacent store fusion
card-mark elimination
merge-point splitting
• loop transformations
• loop unrolling
• loop peeling
• safepoint elimination
• iteration range splitting
• range check elimination
• loop vectorization
• global code shaping
• inlining (graph integration)
• global code motion
• heat-based code layout
• switch balancing
• throw inlining
• control flow graph transformation
• local code scheduling
• local code bundling
• delay slot filling
• graph-coloring register allocation
• linear scan register allocation
• live range splitting
• copy coalescing
• constant splitting
• copy removal
• address mode matching
• instruction peepholing
• DFA-based code generator

13. INLINING – MOTHER OF OPTIMIZATION
13
Before After
*Using JVM Devirtualization if needed
Frequency and size matter
int addAll(int max){
int accum=0;
for (int i=0;i<max;i++) {
accum = add(accum, i);
}
return accum;
}
}
int add(int a, int b) {return a+b;}
int addAll(int max){
int accum=0;
for (int i=0;i<max;i++) {
accum = accum+i;
}
return accum;
}
}
int add(int a, int b) {return a+b;}

14. OSR – ON-STACK REPLACEMENT
14
oRunning method never exits?
oBut it’s getting really hot?
oGenerally means loops, back-branching
oCompile and replace while running
oNot typically useful in large systems
oLooks great on benchmarks!

15. ESCAPE ANALYSIS
15
oObject is referenced only inside some loop; no
other code can ever access that object?
oIt needn’t get a synchronization lock when
calling the methods working with object
oIt needn’t store the fields in memory; it can
keep that value in a register
oSimilarly it can store the objects references in a
register

16. ESCAPE ANALYSIS
16
public class Factorial {
private BigInteger factorial;
private int n;
public Factorial(int n) {
this.n = n;
}
public synchronized BigInteger getFactorial() {
if (factorial == null) factorial =...;
return factorial;
}
}
ArrayList< BigInteger > list = new ArrayList < BigInteger >();
for ( int i = 0 ; i < 100 ; i ++) {
Factorial factorial = new Factorial ( i );
list.add(factorial.getFactorial ());
}

17. ESCAPE ANALYSIS (SIMPLE CASE)
17
oIt needn’t get a synchronization lock when
calling the getFactorial() method.
oIt needn’t store the field n in memory; it can
keep that value in a register.
oIt can just keep track of the individual fields of
the object.
oSometime – it needn’t to execute it at all.

18. JIT TUNING
(THESE MIGHT SAVE YOU )
o -client , -server or -XX:+TieredCompilation
o -XX:ReservedCodeCacheSize=, -XX:InitialCodeCacheSize=
19

19. JIT TUNING
o -XX:CompileThreshold=invocation value for compiling
o -XX:CICompilerCount= number of threads
o -XX:MaxFreqInlineSize=for hot methods (default value 325
bytes)
o -XX:MaxInlineSize= method smaller this will be inlined anyway
(default value 35 bytes)
20

20. WANT TO GET MORE DETAILS?
(BE CAREFUL WITH USING THEM ON PRODUCTION)
o -XX:+UnlockDiagnosticVMOptions
o -XX:+TraceClassLoading
o -XX:+LogCompilation
o -XX:+PrintAssembly
o -XX:+PrintCompilation - info about compiled methods
o -XX:+PrintInlining – info about inlining decisions
o -XX:CompileCommand=… - to control compilation policy
21

21. WANT TO GET MORE DETAILS? – LOGS 
22

22. WANT TO GET MORE DETAILS – JITWATCH, JSTAT
23

23. CONCLUSIONS
o KISS, SOLID, DRY, YAGNI – all well-known principles are
perfect for JIT to make his job
o Your code will be optimized and compiled, de-compiled
o There is a lot of various algorithms to do it inside JVM
o You need to reserve memory for compiled code
(CodeCache inside Metaspace/Permgen)
o To get full performance throttle JVM needs to warm-up
o Micro benchmarks lie to you. All the time
24

24. WHAT WE DIDN’T TOUCH
o Deoptimazing
o Specific benchmark for compilers
o Specific compiled code examples
o …
25

25. Q&A
26
