1. JAREL EXPORT
ELECTRICAL PRODUCT
DESIGN AND SUPPLY
1
TEL +447432191824
E MAIL: sales.richardson5@virgin.net

2. HAZZARDOUS EQUIPMENT
• Jarel export was formed in 2001 after many
years in the electrical business I identified a
market which not only required expertise and
commitment but also keeps me exited and
interested in what I do. We specialise in
Hazardous area electrical products in all
ranges lighting, control, containment
,distribution,maintenance,cables, bespoke
made to order products.
2

3. 3

4. 4

5. 5

6. 3300v 500a bolted socket
3300v 500a
6

7. 7
▼ Provision of 3 power and 1 pilot and 2
auxiliary contacts with scraping earth facility.
Current rating - 500 Amps.
Voltage - 3,300 Volts.
Weight - 11 Kgs.
▼ Minimal spares stockholding.
▼ Compact size and weight.
▼ Simple serviceable design.
▼ Fully waterproof.
▼ Socket flange mounting design to BS5620
CERTIFICATION & APPROVALS
EN 60079-0: 2006 and EN 60079-1: 2007.
ATEX Component Certificate
Baseefa09ATEX0121U.
IM2 Exd I
IECEx Certificate of Conformity
IECExBAS09.0048U
Exd I
China MA Approved
&
Russian GOST Approved
Variants also available

8. 8

9. 9
▼ Supplied with Long Life LED Lamp
▼ LED Lamp offers greater than 50,000 hours
continuous lamp life
▼ Quick re-lamp. Lamp glass secured with single bolt
and if necessary can be removed completely by
withdrawing two split pins. ▼ Simple installation using
Victor range of LP plugs designed to NCB Spec. 691/1984
▼ Protected against dust and water ingress.
▼ Guard option available.
▼ Casting made from zinc alloy to reduce weight and
avoid rusting.
▼ No control gear required
SIRA02ATEX1407X I M2 EExd I
I M2 EExd I

10. 10

11. 11

12. 12
Intrinsically Safe (Exia), Weather-proof Call Point

13. 13
BG3 Range - MANUAL CALL POINT
Features
Zone 0, Zone 1 and Zone 2 use.
Exia IIC T4.
ATEX Approved Ex II 1 G.
BASEEFA certified.
Chinese (CQST) certified.
Designed in accordance with EN54-11.
IP66 and IP67.
Certified temperature: –55ºC to +55ºC.
Corrosion free GRP.
Optional in line/end of line resistors/diodes.
Optional LED indicator.
Optional lift flap.
Key operated test facility.
Various body colours available

14. 14
Type PXSS2K/MF
Type PXSS2K/MF

15. 15
SPECIFICATION
Ex d for Group 1 Mining applications.
Group II options also available.
Flange mounted cable gland
For use with un-armoured cable
CMP Type PXSS2K/MF Cable gland
Designed to BS 6121: Part 1:1989,
EN50262:1999 & IEC 62444:2010
CERTIFICATION & APPROVAL
Provides a flameproof seal with a compound
barrier seal around conductors and an
environmental seal on the cable outer sheath
Provide mechanical cable retention
Operating temperature range from – 60 oC
to + 100 oC
OPTIONS
EN 60079-0:2006, EN 60079-1:2007,
EN 60079-7:2007, IEC 61241-0:2004,
EN 61241-1:2004 and IEC 60079-0:2007
ATEX Certified I M2 Ex d I
Component certificate No.
Sira09ATEX1034U + Sira06ATEX1097X
Ingress Protection
IP66
Contact sales for further information

16. 16
DB7 Range - SOUNDERS - Up to 110 dB(A)
Intrinsically Safe (Ex ia), Weather-proof

17. 17
Features
4 Zones 0, 1, 2 and safe area use.
4 Ex ia IIB/IIC T4.
4 ATEX approved Ex II 1G.
4 Weather-proof uncertified version.
4 BASEEFA certified.
4 CUTR certified.
4 IP66 & IP67.
4 Certified temperature: –55ºC to +70ºC.
4 Corrosion resistant red painted GRP.
4 Up to 110 dB(A) output.
4 27 tones, user selectable.
4 Tones comply with UKOOA/PFEER guidelines.
4 Any two tones may be switched by the
external

18. Control Systems And
Components Overview
18
Control Systems
Power Distribution
Motor Starters
Load Break Switches
Terminal Enclosures IIB
Terminal Enclosures IIC
Grounding Systems
System Components

19. 19
Jarel provides an extensive range of explosion
proof control systems suitable for both
onshore and offshore operation.
Many different types of complete control
systems are available which include, but are
not limited to:
Signalling units
Power devices
Distribution equipment
Monitoring systems
Circuit breaker panel boards
Switch racks
Motor starting
Control systems are assembled using Oxalis
control system components. These include
EJB, EJBX, GUB & GUBW enclosures with EF
control functions.
Bespoke assemblies are produced specific to
customer requirements following an initial
design consultation with Oxalis technical
specialists

20. 20
Control Systems
Features
 Multiple Enclosure Options
 Cast Alloy, Cast Stainless
 Frame Mounting, Wall Mounting, Foot Mounting
 Large Switch Loading Capacity
 Internal Components Per Customer Requirements
 Variable Voltages Available AC / DC
 See EJB Series, GUB Series & EF Series

21. 21
Power Distribution
Features
 Options Include MCB, MCCB, Main Isolation & RCBOs
 Three Phase & Single Phase Available
 With or Without Control Terminals
 Heavy Duty Load Break Options
 Pad lockable Door Mount Handles
 See XPD Series

22. 22
Motor Starters
 Available as DOL, Star Delta & Reversing
 Multiple Control Features
 Internal Control Gear Per Customer Requirements
 Separate Ex e Terminal Chamber Available
 Auxiliary Equipment Includes Transformers, Fuses, MCBs etc.
 See XDS Series

23. 23
Load Break Switches
 Switch Ratings from 16 A to 630 A
 Separate Control Terminals Available
 Triple Pole, 4 P or 6 P Options
 Pad lockable External Handles
 Early Make & Late Break Auxiliary Contacts Available
 See XPS Series

24. 24
Terminal Enclosures IIB
 Standard Terminals with Multiple Options
 Hinged Lid, Multi-bolt Fixing
 Vertical or Horizontal Internal Mounting
 Separate Internal Mounting Plate
 Suitable for Gas Groups IIA & IIB
 See DTB Series

25. 25
Terminal Enclosures IIC
 Standard Terminals with Multiple Options
 Hinged Lid, Multi-bolt Fixing
 Vertical or Horizontal Internal Mounting
 Separate Internal Mounting Plate
 Suitable for Gas Groups IIA & IIB
 See DTB Series

26. 26
Grounding Systems
 Includes 8m Cable
 Signal Indication Lights
 Electronic Circuit System
 Control Pushbutton
 Complete with Earthling Clamp
 See XGR Series

27. 27
(N)SHÖU O/J Cable
APPLICATION
Flexible cable, rubber sheathed, suitable for
mining
applications alongside conveyor belts, for
energy supply to
equipment in movement, industrial apparatus
and submersed
pumps. It’s resistant to abrasion, oils and flame
retardant.
Suitable for indoor and outdoor applications
CABLE STANDARDS
Generally to VDE 0250 Part 812, VDE 0295,
BS EN/IEC 60332-1-2, BS EN/IEC 60811-2-1

28. 28
CONSTRUCTION
Phase Conductor
Class 5 flexible copper conductor according to
VDE 0295
(IEC 60228)
Insulation
Rubber compound Type 3GI3 according to VDE
0207
Part 20
Inner Sheath
Rubber compound Type GM1b
Outer Sheath
Heavy duty rubber compound Type 5GM5
according to VDE
0207 Part 21
CHARACTERISTICS
Voltage Rating (Uo/U)
600/1000V
Test Voltage
3kV
Maximum Short Circuit Temperature
+250°C
Ambient Temperature
Fixed: -40°C to +80°C
Flexed: -25°C to +80°C
Minimum Bending Radius
Fixed: 4 x overall diameter
Flexed: 5 x overall diameter

29. 29
CHARACTERISTICS
The cables available within the range offer high
performance characteristics such as:
• Voltage Ratings: 0.6/1kV, 3.6/6kV, 6/10kV, 8.7/15kV &
12/20kV
• Maximum short circuit temperature of +250°C
• Maximum permissible water temperature of +40°C
• Maximum tensile loads from 15 to 20 N/mm²
• Maximum torsional stress of ±25°/m
TECHNICAL SUPPORT
All of our cables are in accordance with
international certifications and standards such
as HAR,
VDE, IEC, BS, UL, BASEC and TUV. We also test
our cables in-house using state-of-the-art
technology and equipment to ensure they
meet the strictest industry standards

30. 30
Type ML102 Ex d LED Face Lighting Luminaire

31. 31
CERTIFICATION & APPROVAL
IECEx Certification No. IECEx SIR09.0134
I M2 Exd I Mb
ATEX Certification No. Sira 09ATEX1328
I M2 Exd I Mb
DGMS Applied For
Ambient Temperature range:
-20°C To +45°C
Ingress Protection:
IP65
▼ Low Maintenance
▼ Long LED Lamp Life
▼ High Resistance to Vibration & Shock
▼ Low Power Consumption.
▼ The higher voltage luminaire will operate
from 80V to 240V AC / DC without
modification.
▼ Other voltage options are available for 12V
AC / DC or 24V AC / DC
▼ Low Profile ideal for applications with
restricted head room.
▼ Hinged lamp-glass assembly.

32. 32
EEx nA
Construction: Aluminium or Cast Iron
Frame sizes: 63 to 355
Output: 0.07kW to 400kW
The W EEx nA non-sparking range of motors
covers products with outputs from 0.18kW to
400kW in cast iron frame sizes W-DF80M to W-DF355L,
in either 2,4,6 or 8 pole speeds (also
available in aluminum from 71 to 180 frames).
All relevant products fully comply with the
requirements of ATEX.

33. 33
Our standard ISTB enclosure range gives you
the most modern, robust and cost effective
solution for hazardous and heavy industrial use

34. 34
Key Features
✓✓Any size up to 600x600x300mm for
hazardous area
✓✓Any size for industrial use
✓✓316L, 304 Stainless and painted Mild Steel
✓✓ATEX
✓✓Silicon gaskets as standard
✓✓Brushed finish as standard, other options
available
✓✓316L is Corrosion resistant for min 25 years
✓✓Impact resistant 7 NM
✓✓All fixtures and fittings in 316L Stainless
Steel
✓✓Innovative mounting assembly options
✓✓Din rail supports fitted
✓✓Various material thicknesses available
on request
Questions, enquiries?
Call us on 01233 638311 Email
sales@indexenclosures.com Visit
www.indexenclosures.com
No
No Inconvenience
✓✓Rapid design to your
specification
No Compromise
✓✓Any size
✓✓Custom as standard
No Delay
✓✓Delivered to your
schedule
