This document describes an Ethernet MAC IP core called MTIP_MAC1G that is compliant with DO-254 DAL A guidelines. It is a tri-mode 10/100/1000 Ethernet MAC core that supports IEEE 802.3 standards with a simple FIFO interface. The core has been developed, verified and licensed by DMAP according to their assurance processes and deliverables include RTL, verification IP, and documentation for certification.
