Pini Dibask presented on Oracle ASM concepts, architecture, and best practices. Some key points: - ASM is Oracle's recommended storage management solution and provides high performance storage for single-instance and RAC databases. - ASM uses disk groups and stripes and mirrors data across disks for redundancy and load balancing. It also rebalances data automatically during storage changes. - Administering ASM involves tasks like starting and stopping the ASM instance, managing disk groups and disks, and monitoring storage usage and I/O balance. - Best practices for ASM include using separate disk groups for data and recovery files, ensuring consistent disk performance, monitoring I/O balance, and in

1. ASM Concepts, Architecture & Best PracticesProduct Manager for Database Tools
April 24th , 2018
Pini Dibask
IOUG
Collaborate
2018

2. Confidential2
• Pini Dibask, Product Manager for Database Tools, Quest Software
• Oracle ACE
• Oracle Certified Professional DBA (OCP)
• Public Speaker: Oracle OpenWorld, IOUG Collaborate, DOAG, OUGN, AOUG
• Blogger: OracleDBPro.BlogSpot.com
Pini.Dibask@Quest.com
http://Linkedin.com/in/pinidibask
@pini_dibask
About the Speaker

3. Confidential3
Who is Quest Software?
9 0 % o f
F o r t u n e 1 0 0
using our
software
1 , 5 0 0
engineers building
quality products
4 M
c o m m u n i t y
m e m b e r s
sharing best practices
3 , 5 0 0
employees focused
on customers
Quest is a global software provider trusted by
100,000 customers and 6,000 partners in 100
countries.
We help IT organizations spend less time on
administration and more time on innovation.
6 , 0 0 0
partners selling
our software

4. Confidential4
• Toad database development &
management tools
• Foglight & Spotlight database
performance monitoring
solutions
• SharePlex for heterogeneous
database replication
Quest Database Management Solutions

5. Confidential5
Agenda
 Concepts & Architecture
 Administration
 Best Practices
 Monitoring

6. Concepts & Architecture01

7. Confidential7
Oracle Deployment Options – Single Instance vs. RAC
D1
D2
I1 I2 I3
D
Clustered System
(= Real Application Clusters
Nonclustered System
(= Single Instance)
Local
Storage
Shared Storage
In today’s
presentation we
will focus on this
area

8. Confidential8
Storage Options for RAC
 ASM - Oracle’s recommended storage for Oracle Database
 DNFS (Direct Network File System)
 Unformatted partitions (aka “raw devices”) are no longer supported
 No longer supported since 12c
 Local storage is obviously not supported
 RAC requires “shared storage”

9. Confidential9
What is ASM?
 Stands for Automatics Storage Management
 Introduced in 2003 (Oracle 10gR1)
 Volume manager and file system for Oracle database files
 Supports single-instance and Real Application Clusters (RAC)
 Oracle’s recommended storage management solution

10. Confidential10
Why ASM?
ASM
File
System
Volume
Manager
Operating System
Application
Database
 Solves many storage management challenges
 High performance cluster file system
 Administer disk groups instead of individual disks
 Data is spread across disks to balance load
 Integrated mirroring across disks

11. Confidential11
About Oracle ASM Instance
 Oracle ASM is built on the same technology as an Oracle Database instance
 Has SGA and background processes
 Installed in the Grid Infrastructure home
 ASM instance mounts disk groups to make ASM files available
 Does not have data files, uses control file

12. Confidential12
About Oracle ASM Instance
 Processes
 RBAL – coordinates rebalance activity
 ARBn – One or more processes that do the rebalance activity
 DMON – Managing disk-level activities (e.g. drop)
 Memory components
 Shared Pool - metadata information
 Large Pool – parallel operations
 ASM Cache – read/write blocks during rebalance

13. Confidential13
ASM Instance Initialization Parameters
 ASM uses a small subset of the parameters that Oracle DB instance uses

14. Confidential14
ASM Storage Components

15. Confidential15
ASM Disk Groups and Disks

16. Confidential16
ASM Disk Groups and Disks

17. Confidential17
ASM Disk Groups and Disks

18. Confidential18
ASM for single-instance Oracle Databases

19. Confidential19
ASM with RAC (Real Application Clusters)

20. Confidential20
Oracle ASM Cluster with Single-Instance Oracle Database

21. Striping & Mirroring02

22. Confidential22
RAID
 Redundant Array for Independent/Inexpensive disks
 Employs techniques of disk mirroring or disk striping (or both)
 Let’s see the most common RAID options…

23. Confidential23
RAID 0
Source: TechTarget

24. Confidential24
RAID 1
Source: TechTarget

25. Confidential25
RAID 10
Source: TechTarget

26. Confidential26
RAID 5
Source: TechTarget

27. Confidential27
ASM Striping
 The goal of striping is to maximize storage subsystem throughput
 Balances I/O load across disks
 Reduces I/O latency by removing bottleneck from one specific disk
 Fine-grained striping - small chunks (128KB) for small I/O operations
 Coarse-grained striping – bigger chunks (equal to the AU size) for data files

28. Confidential28
ASM Mirroring
 Protects data by storing copies of data on multiple disks
 ASM mirrors data based on file extents
 ASM supports 3 redundancy-levels
 Normal redundancy - each file extent has a single copy (2-way mirroring)
 High redundancy - each file extent has two copies (3-way mirroring)
 External redundancy - No mirroring

29. Confidential29
Failure Groups
Disk Group “DATA”

30. Confidential30
Mirroring Cont’d
 ASM Mirrors copies of file extents in separate failure groups
 External redundancy used in environments that use smart storage solutions
 ASM can be more flexible than traditional RAID storage mirroring
 2 Files in the same ASM Disk Group
 One file being mirrored, while the other one is not (ASM templates)

31. Confidential31
Striping & Mirroring – External Redundancy Diagram

32. Confidential32
Striping & Mirroring – Normal Redundancy Diagram

33. Confidential33
Striping & Mirroring – High Redundancy Diagram

34. Confidential34
ASM Extents
 Extents are stored in individual disks in ASM
 Consists of one or more allocation units
 Extent size = AU size for the first 20,000 extents
 Extent size = AU size * 4 for the next 20,000 extents
 Extent size = AU size * 16 for the next 20,000 extents (and higher)

35. Confidential35
ASM Extents Cont’d

36. Confidential36
From where does Oracle read the data?
 Example: File with 5 extents striped across eight disks in the disk group
 Reads are made against the primary extents (red blocks)

37. Confidential37
Failure Example
 Disk H fails, therefore the extents are re-created on surviving disks

38. Confidential38
Disk Group Rebalancing
 Automatic online rebalance during storage changes
 Only moves data proportional to storage added
 No need for manual I/O tuning
 Online migration to new storage

39. Administration03

40. Confidential40
Accessing an ASM Instance
 SYSASM was introduced in 11gR1
 11gR1
 SYSDBA still had full administrative permissions
 Every administrative command was reported in alert log
 11gR2
 Administrative tasks can only be performed by SYSASM
 ASMSNMP should be used for read-only operations

41. Confidential41
Example - Trying to execute administrative command in 11gR2
Not allowed via
“SYSDBA“
Allowed via
“SYSASM“

42. Confidential42
Starting and Stopping using SQL*Plus

43. Confidential43
Starting and Stopping using srvctl
 Server Control Utility (srvctl) can be used to start/stop ASM instances
 Server Control Utility (srvctl) can be used to check the status of ASM instances

44. Confidential44
Starting and Stopping using ASMCMD

45. Confidential45
Managing Disk Groups

46. Confidential46
Adding Disks to Disk Groups

47. Confidential47
Altering Disk Groups

48. Confidential48
Administering via Tools - Toad for Oracle ASM Manager

49. Best Practices04

50. Confidential50
Example of monitoring I/O activity balance
 The query below returns a value in the range of 0% - 100% to indicate the I/O balance
 DATA - Balanced
 RECO - Imbalanced
Balanced (over 80%)
Imbalanced

51. Confidential51
Storage Preparation
 Configure at least 2 disk groups, one for Data and the other for the FRA
 Ensure all ASM disks in disk group have same performance characteristics
 Make sure all the disks in the same Oracle ASM disk group are the same size
 Minimize I/O contention ASM disks and other applications (dedicated ASM disks)
 Monitor the I/O activity balance across disks
 See: https://community.oracle.com/docs/DOC-995178
 External redundancy when using high-end storage

52. Monitoring05

53. Confidential53
Mirroring via Dynamic Performance Views
 ASM instance hosts memory-based metadata tables (dynamic performance views)
 Below you can find the most common and useful dynamic performance views

54. Confidential54
Monitoring via Tools

55. Confidential55
Monitoring via Tools

56. Confidential56
Monitoring via Tools Cont’d

57. Confidential57
References and additional information
 Oracle Documentation
https://docs.oracle.com/database/121/OSTMG/toc.htm
 My article on Oracle Developer community - “Verifying I/O activity across disks in ASM”
https://community.oracle.com/docs/DOC-995178
 My favorite blog - Tim Hall’s Blog (ORACLE-BASE.com)
https://oracle-base.com/

58. Confidential58
Quest provides your team with the tools to cover all of your
database platforms…
* Platform support varies from tool to tool
