Unit and integration tests are automated tests written by developers to test their code. Unit tests test individual functions or methods, while integration tests test how components work together. Tests are run automatically during continuous integration to check for failures and ensure code works as intended before deployment. Writing tests is important to catch bugs early and ensure code continues working properly over time as changes are made. Mocking is used in unit tests to simulate interactions between code components without executing their actual implementation.

1. Unit & Integration Testing
Infusion Bootcamp 2017
Paul Churchward, FRM
Team Lead

2. ABOUT ME
• Team Lead based in Toronto
• With Infusion 2 years
• Background in finance (FRM, CSC)
• Stack: Java, Ruby
• Companies worked for

3. Developers code UNIT and INTEGRATION tests which
run automatically to test their software.
compares expected behaviour with actual behaviour
Unit and integration tests are part of the project source
Written by developer, not QA
Tests are executed automatically as part of continuous integration or by local builds, not by QA
Failures are reported (web dashboard/email/slack) and cause the build to abort
Fix failures by changing the code (sometimes, the test needs to be changed)
Fixing test failure raised by continuous integration is developer’s top priority b/c this holds up the team.

4. Verify logic works as intended
Simulate how code behaves under different circumstances (e.g. negative testing)
Ensure logic continues to works as designed after you’ve written
Not alone! Unit and integration testing is the first line of defense against bugs, not QA.
In a continuous delivery setup, unit & integration tests are your only line of defense, there is
no QA. When code passes the automated tests, it is automatically deployed to prod.
ISN’T TESTING QA’S JOB?
WHY WRITE A TEST?

5. A unit test tests the smallest unit of a program
produces expected behaviour.
A unit test typically tests a single method / function
Tests the method produces expected behaviour under different circumstances
Typical unit test will invoke a single method and test it produces expected output / right behaviour

6. Method’s return value is compared against the expected output for the input fed to it
Method invokes a service the expected number of times with the expected arguments
Note, we wouldn’t test the service’s output here. It should have its own test.
This is a key unit testing concept. Each test tests the bare minimum.
Method does not invoke a service when passed certain arguments
Method saves to database only when its call to Service-A returns true
Note, we wouldn’t test database was updated, only that the database service
in our code was called. This is a key unit testing concept. Don’t talk to external
services.
Examples of testing expected behaviour in a unit test:

7. An integration test tests components work together to
produce expected behaviour.
Scope goes beyond the innerworkings of a single method / function
Tests collaboration between components, taking it further than a unit test
For it to be an integration test, a “boundary” must be crossed
-> More than one component must be tested.
e.g. calling another class or calling an external service
Purpose is to test behaviour of external services like databases and other APIs
Number of unit tests outweigh integration tests -> Integration tests are much slower because
they talk to file systems / external APIs / databases.

8. UNIT TEST EXAMPLE:
(Let’s do this in pseudo code first)
When checkUserExists() on the UserDAO is invoked, force it to return false
When the addUser() method on UserService is invoked with the argument "FOO“ then:
Assert checkUserExists() on the UserDAO is invoked only once with the parameter "FOO"
Assert saveUser() on the UserDAO is invoked only once with the parameter "FOO"
Notice, we’re not testing the state of the database, only that we attempted to update the database. By
only testing the behaviour of the method, without testing anything outside the method we have
created a unit test. If we went further and tested the state of the database, we would have an
integration test.
This does not invoke the methods on the UserDAO or call out to the DB, it simply checks it should be
called. That would be out of scope for a unit test. This is achieved by using a mocking library (we’ll talk
about that later) which blocks actually invoking designated parts of the code we don’t want to be run
during the test.

9. INTEGRATION TEST EXAMPLE:
(Let’s do this in pseudo code first)
When the addUser() method on UserService is invoked with the argument "FOO“ then:
Assert getUser("FOO") on UserDAO returns a valid user with the username "FOO"
Notice, we’re testing the state of the database here. The test adds a user and then tests we get the
expected user back from the database when we query for it through our DAO. We’re not preventing the
code invoking any service (mocking). This is an integration test.
Build expected report
When the generateAndSave() method on ReportService is invoked, capture it’s report ID.
Assert retrieveReport("S3") on ReportService returns a report matching the expected report.
This test invokes the ReportService to generate a report and save it to Amazon S3. We test the code by retrieving the
report from S3 and comparing against one we already have. It should match. We’re not just testing the report itself
here, but that ReportService can read and write to Amazon S3 as expected. This makes it an integration test.
ANOTHER EXAMPLE:

10. Consider this example …
You write a report for another system to consume and the columns must be in
alphabetical order.
public void generateReport() {
List<String> columns = columnFactory.getColumns();
FooBarReport report = reportService.generateReport(ReportType.FooBar);
publishReportToS3(report);
}
Output:
FooBar Report
2015-03-18 13:00
================
A|B|C|D|E|F
2|6|2|4|2|6
1|3|5|9|11|
==
2 rows
I WISH I WROTE A (UNIT) TEST!

11. … 5 months later an accidental change is made to ColumnFactory causing it to spit out
columns in reverse alphabetical order and is pushed to production.
Your report now looks like this:
Output:
FooBar Report
2015-08-18 13:00
================
F|E|D|C|B|A
6|2|4|2|6|2
|11|9|5|3|1
==
2 rows
... The system consuming this report fails to read it and blows up in production
A unit test would have caught this right away.

12. WHAT TO UNIT TEST:
Method return value matches expected value (or null)
Method invokes a method of another classes the expected number of times.
Example: if your method calls UserDAO.save(), test that save() is only called once
Method doesn’t invoke method of another class.
Example: if you method should only call UserDAO.save() if the user doesn’t already exist, test for an existing
user and make sure UserDAO.save() is not called.
Method throws a specific exception
Example: if your method throws an CannotProcessException when a null userId , test that passes a null
and expects CannotProcessException to be thrown. If it were to throw IOException instead (or no
exception at all), that would be considered a failure.

13. MOCKING
In a unit test, we do not care about testing things outside of our method: e.g:
state of database changed by our method, state of file on file system, state of
another class invoked by our method.
We go a step further and prevent our method from changing the state or
databases, file systems and other classes. We use mocking to do this.
Mocking allows us to create fake (mock) instances of classes that we can
manipulate to make our test easier.
Mocking can render a class inert (calling its methods do nothing), or we can
specify the behaviour we want to happen when we call a specific method
Mocking is not used in an Integration test. That would defeat the purpose.

14. EXAMPLE:
Let’s write a unit test for this method in UserService
public void addUser(UserDAO dao,
Configuration config,
Connection conn,
String userName) throws BadArgException {
if(conn == null || config == null) {
throw new ConfigurationException();
}
dao.init(config, conn);
if(dao.userExists(userName)) {
throw new BadArgException()
}
dao.saveUser(userName);
}

15. EXAMPLE:
Components of the test:
Provide non-null instances of Configuration, Connection, UserDAO and a username String
Force UserDAO.checkUserExists() to return false -> Without talking to the database
Verify UserDAO.saveUser() is invoked only once -> BUT don’t write to the database
We will use Mockito (Java Mocking library) to “mock” UserDAO. This will:
> Preventing its methods from actually executing their code
> Allow us to force UserDAO.checkUserExists() to return false
> Allow us to count the number of times UserService.addUser() will call
UserDAO.saveUser() when we execute it in the test.
We will use Mockito to mock Configuration and Connection so that we get non null instances but
don’t have to create them (let’s assume it takes a fair bit of code to create these)

16. EXAMPLE:
public class UserService {
@Test
public void addUser_withRegualrUser_callsSaveUserOnce(){
UserDao dao = mock(UserDao.class);
Configuration config = mock(Configuration.class);
Connection conn = mock(Connection.class);
String user ="FOO";
UserService service = new UserService();
addUser(dao, config, conn, user);
verify(dao.saveUser(user), 1);
}
}

17. Test Driven Development advocates writing tests
BEFORE writing the code.
This forces you to plan how the component will work before you start coding it.

18. BEWARE of tests that don’t test anything
Not uncommon for people to write “tests” to invoke parts of the code outside
the normal flow. These so called tests don’t do any testing! A “test” that
simple invokes code but does not test it against expected behaviours is not a
test!
If a test does not compare expected behaviour with actual behaviour, it is not
a test. These are surprisingly common in the real world.

19. Multiple testing frameworks to chose from in each language. Here are a few
Java:
Junit, TestNg
C#:
Nunit
Ruby:
Rspec, FactoryGirl
Multi Language:
Cucumber (behaviour driven testing)
Tools
