describes the most upcoming technology of the world hyperloop. which was proposed by elon musk a renowned scientist. it is a 5g mode of transportation to the new world. it is one of the up coming technology.it is a best project on technology. A Hyperloop is a proposed mode of passenger and/or freight transportation, first used to describe an open-source vactrain design released by a joint team from Tesla and SpaceX.[1] Drawing heavily from Robert Goddard's vactrain, a hyperloop is a sealed tube or system of tubes through which a pod may travel free of air resistance or friction conveying people or objects at high speed while being very efficien

2. ABOUT HYPERLOOP
WHAT IS HYPERLOOP?
COMPONENTS
DESIGN
OPERATION
ADVANTAGES
DIS ADVANTAGES
CONCLUSION

3. INTRODUCTION
TODAY’S CONVENTIONAL M0DES OF TRANSPORTATION ARE
MAINLY RAIL,ROAD,WATER AND AIR WAYS.
THESE MODES OF TRANSPORT EITHER BE RELATIVELY SLOW
(I.E.,ROAD,RAIL,WATER WAYS) OR MOSTLY EXPENSIVE(I.E.,AIR
WAYS).
HERE COMES OUR NEW MODE OF TRANSPORTATION
HYPERLOOP THAT SEEKS CHANGE THE PATTERN BOTH FAST
AND INEXPENSIVE FOR PEOPLE AND GOODS.

4. WHAT IS HYPERLOOP?
HYPERLOOP IS A 5G MODE OF TRANSPORTATION.IT WAS PROPOSED AND WORKED OUT BY ELON
MUSK.
IT IS A SYSTEM WHERE MAGNETICALLY LEVIATING CAPSULES ARE SENT AT HIGH SPEEDS THROUGH
LOW PRESSURE TUBES WHICH PASS THROUGH A LOOP FILLED WITH VACCUM

5. HYPERLOOP VISUALS

7. HYPERLOOP TRAIN MODEL

8. COMPONENTS IN HYPERLOOP
• AIR COMPRESSOR
• ELECTRO MAGNET LAUNCH SYSTEM
• CAPSULE
• BATTERY SUSPENSION

9. PARTS OF HYPERLOOP

10. DESIGN AND OPERATION OF HYPERLOOP
FIRSTLY LOOP IS MAINTAINED AT LOW PRESSURES OF 1 MILLIBAR(100PA).THEN IT IS
FILLED VACCUM.
THE HYPERLOOP CONCEPT OPERATES BY SENDING SPECIALLY DESIGNED ‘CAPSULES’ OR
‘PODS’.DUE TO VACCUM EACH CAPSULE FLOATS IN AIR UPTO HEIGHT OF(0.5-1MM).
LINEAR INDUCTION MOTORS ARE USED TO ACCELERATE AND DECELERATE THE CAPSULE.
ELECTRICALLY DRIVEN INLET AND AIR COMPRESSOR ARE PLACED AT NOSE OF CAPSULE TO
TRANSFER HIGH PRESSURE FROM FRONT TO REAR OF VESSEL WHICH RESOLVES PROBLEM
OF AIR PRESSURE.

11. BLOCK DIAGRAM OF CAPSULE

12. ADVANTAGES OF HYPERLOOP
FASTER
POLLUTION FREE
SAFER THAN OTHER TRANSPORT
RESISTANT TO EARTHQUAKES

13. BENEFITS OF HYPERLOOP
oA SOLAR ARRAY IS COVERING THE ENTIRE LOOP WHICH PRODUCES A BIG AMOUNT OF SOLAR
ENERGY.
oA NUMBER OF ROUTES WERE PROPOSED FOR HYPERLOOP SYSTEMS.
oAMONG THEM HYPERLOOP TRANSPORTATION TECHNOLOGIES START WORK BETWEEN LOS
ANGELES AND LOS VEGAS CONNECTING ACROSS IMPORTANT CITIES’
oIT IS ALSO IMPLEMENTING IN ABU DHABI BETWEEN UAE AND AL ALN
oOUR INDIAN GOVERNMENT ALSO SHOW INTEREST TO LINK ALL METROPOLITAN CITIES.
oIN SEPT 2017 HTT ANNOUNCED AND SIGNED WITH AP GOVT TO BUILD A TRACK BETWEEN
AMARAVATI AND VIJAYAWADA WHICH WILL BE A 6 MINUTE RIDE.

14. DIS ADVANTAGES OF HYPERLOOP
• TUBE PRESSURIZATION.
• TURNING WILL BE CRTICAL(WITH LARGE RADIUS).
• IN SUFFICIENT MOVABLE SPACE FOR PASSENGER.
• INITIAL ACCELERATION IS HIGH.(NEARLY 0.5G) WHICH IS NEARLY 2 TO 3 TIMES
MORE THAN ACCELERATION IN AEROPLANES WHILE TAKE OFF.

16. CONCLUSION
• AS IT HAS NUMBER OF ADVANTAGES IT WILL VERY HELPFUL FOR TRANSPORT PUBLIC AS WELL AS GOODS IN VERY
SHORT PERIOD OF TIME(AT A TOP SPEED OF 1220KMPH) AND ALSO IN LOWER COST.
• IT IS A NEW CONCEPT SO THERE IS SOME FUTURE WORK WILL BE REQUIRED FOR DEVELOPMENT OF THIS PROJECT.
