1. © Copyright 2018 Pivotal Software, Inc. All rights Reserved. Version 1.0
How to Overcome Data Challenges When
Refactoring Monoliths to Microservices
Kenny Bastani, Developer Advocate, Pivotal
Twitter: @kennybastani
Jason Mimick, Technical Director, MongoDB
Twitter: @jmimick

2. Today’s Speakers
Kenny Bastani
Spring Developer Advocate
Jason Mimick
Technical Director, Partners

3. Pivotal Partner Ecosystem

4. Agenda
Overcoming Data Challenges
When Refactoring Monoliths to
Microservices
● From Monolith to Microservices
● Migration Strategies
○ Splitting the Monolith
○ Strangling the Monolith
● From RDBMS to NoSQL
● Pivotal Cloud Foundry + MongoDB
● Reference Architecture & Open Source Example
● Q/A

5. Safe Harbor Statement
This presentation contains “forward-looking statements” within the meaning of Section 27A of the
Securities Act of 1933, as amended, and Section 21E of the Securities Exchange Act of 1934, as
amended. Such forward-looking statements are subject to a number of risks, uncertainties, assumptions
and other factors that could cause actual results and the timing of certain events to differ materially from
future results expressed or implied by the forward-looking statements. Factors that could cause or
contribute to such differences include, but are not limited to, those identified our filings with the Securities
and Exchange Commission. You should not rely upon forward-looking statements as predictions of future
events. Furthermore, such forward-looking statements speak only as of the date of this presentation.
In particular, the development, release, and timing of any features or functionality described for MongoDB
products remains at MongoDB’s sole discretion. This information is merely intended to outline our general
product direction and it should not be relied on in making a purchasing decision nor is this a commitment,
promise or legal obligation to deliver any material, code, or functionality. Except as required by law, we
undertake no obligation to update any forward-looking statements to reflect events or circumstances after
the date of such statements.

6. Abandoning the Status Quo
From Monolith to Microservices

7. The Monolith

8. Make JAR not WAR. – Josh Long
Monolith – One Release Cycle to Rule Them All
● Slows down velocity of deploying new features
● Takes too long to ramp up new developers
● The code base becomes too large to fully comprehend
● Centralized change management slows progress (DBA, Ops)
● Deployments batch together changes from different teams
● Ops team manages infrastructure
● Ops team drives execution environment and upgrades
● Deploy everything at once or nothing at all

9. The SOA
Independent Release
Cycles

10. Single Responsibility Principle
A class should have only one
reason to change. – Uncle Bob
Distributed Monolith
If your [services] must be deployed
as a complete set in a specific
order, please put them back in a
monolith and save yourself some
pain. – Matt Stine
SOA – The Curious Case of Shared Ownership
● Services typically share one database
● Services typically share ownership of tables
● Services share libraries containing domain objects
● Boundaries of ownership become blurred over time

11. Single Responsibility Principle
A class should have only one
reason to change. – Uncle Bob
Distributed Monolith
If your [services] must be deployed
as a complete set in a specific
order, please put them back in a
monolith and save yourself some
pain. – Matt Stine
SOA – Coordinated Releases
● Account service makes a change to customer record
○ Can be deployed independently
● Account service makes a change to address record
○ Must deploy all three services together

12. Microservices
● Independent Release Cycles
● No table sharing
● No library sharing
● Teams do not share ownership

13. Conway’s Law
Organizations which design
systems ... are constrained to
produce designs which are copies
of the communication structures of
these organizations.
– Melvin Conway
Microservices – Share-nothing Architecture
● Small teams focusing on business capabilities
● Share-nothing architecture
● Independent release cycles
● Increases number of pathways to production

14. Microservices - Encapsulation of Data
Data Encapsulation
For us service orientation means
encapsulating the data with the
business logic that operates on the
data, with the only access through
a published service interface. No
direct database access is allowed
from outside the service, and
there’s no data sharing among the
services.
– Werner Vogels, CTO, Amazon

15. Microservices - Encapsulation of Data
Logical Separation
Horizontal Scalability

16. Replacing the Airplane’s Engine While In-flight
Migration Strategies

17. Splitting the Monolith
Monolith
Shared Tables

18. Splitting the Monolith Monolith
New
Microservice

19. The monolith grows over time. It
acquires new functionality and
lines of code at an alarming rate.
Before long it becomes a big, scary
giant presence in our organization
that people are scared to touch or
change. But all is not lost! With the
right tools at our disposal, we can
slay this beast.
– Sam Newman
Splitting the Monolith – Fracture & Refactor
● Fracture and refactor modules into encapsulated services
● Impractical for most large enterprises
● Foreign-key relationships are not easy to break
● High risk of breaking data warehouse integrations and ETLs

20. Strangling the Monolith
Gradually create a new system
around the edges of the old, letting it
grow slowly over several years until
the old system is strangled.
– Martin Fowler
The strangler vine seeds itself in the upper branches of a fig tree and works its way
down to the roots, slowly starving the tree of resources.

21. Strangling the Monolith
Monolith
Create an edge around the legacy system and slowly migrate data away

22. Strangling the Monolith
Monolith
API Gateway
New Microservices
Move new feature development to microservices

23. “Gradually create a new system
around the edges of the old, letting
it grow slowly over several years
until the old system is strangled.”
– Martin Fowler
Strangling the Monolith – Abstract Away & Deprecate
● Minimizes wasted development cycles
● Focuses on new feature development with microservices
● Integrates with legacy system using an API gateway
● Slowly moves data away from large shared database

24. Strangling the Monolith
API Gateway
● API gateway automatically adapts
between old and new formats
● Uses cache pattern to migrate system
of record to microservices
● Needs to replicate writes back to large
shared database
● Legacy system also routes requests
through API gateway
● Router can identify system of record
for domain data by primary key

25. The Struggle of Systems of Record
From RDBMS to NoSQL

26. Scalability
& Performance
Always On,
Global Deployments
FlexibilityExpressive Query Language
& Secondary Indexes
Strong Consistency
Enterprise Management
& Integrations
Non relational (NoSQL) and relational/tabular

27. Scalability
& Performance
Always On,
Global Deployments
FlexibilityExpressive Query Language
& Secondary Indexes
Strong Consistency
Enterprise Management
& Integrations
Modern database requirements

28. 28
Freedom to run anywhere
Database that runs
the same
everywhere
Coverage in any
geography
Leverage the
benefits of a
multi-cloud strategy
Avoid lock-in
Mainframe
Database as a service
ServerLaptop Self-managed in the cloud
Modern database requirements

29. Database as a service
Self-service, elastic,
and automated
Secure by defaultGlobal and highly
available
Continuous
backups
Real-time monitoring and
optimization
Cloud agnostic

30. A Cloud-native Platform for Microservices
Pivotal Cloud Foundry
+ MongoDB

31. MongoDB as a service on Pivotal Cloud Foundry,
build faster and deliver faster with reliability
BUILD FASTER DELIVER
FASTER,
RELIABILY
DEV
• On demand production ready
MongoDB
• Integrate and bind easily with app and
other services
OPS
• Provisioning and scaling
• Management
• Continuous backup and recovery
• Monitoring
• Automate and simplify:
• Security and control

32. How does the integration work

33. Value
Deliver value from day 1.
MongoDB Enterprise on Pivotal Cloud Foundry aligns with existing DevOps (CI/CD)
workflows and provides on demand production ready MongoDB and application cluster in
minutes, enabling you to rapidly build apps and micro-services
De‐risk your deployments.
Our solution offers enterprise grade with high availability, blue-green deployments,
continuous backups and point-in-time recovery to keep your mission critical deployments
always-on
Drive operational excellence.
MongoDB Ops Manager with BOSH automate and simplify managing, patching, configuring,
scaling, tuning, and monitoring MongoDB deployments to reduce IT capital and operational
expenses

34. Supporting modern applications
New and coming features:
• Change Streams
• Change Data Capture/Event Sourcing
• Schema Validation
• Data governance
• Transactions - COMING MONGODB 4.0
• Coordinating multi-system & complex data relationships

35. Change Streams
Enabling developers to build
reactive, real-time services
ChangeStreamsAPI
Business
Apps
User Data
Sensors
Clickstream
Real-Time
Event Notifications
Message Queue

36. Schema Validation
Enforces strict schema structure over a complete collection
for data governance & quality
• Builds on document validation introduced by restricting new content that
can be added to a document
• Enforces presence, type, and values for document content, including
nested array
• Simplifies application logic
Tunable: enforce document structure, log warnings, or allow
complete schema flexibility
Queryable: identify all existing documents that do not comply

37. MongoDB Multi-Document Transactions
Just like relational transactions
● Multi-statement, familiar relational syntax
● Easy to add to any application
● Multiple documents in 1 or many collections
ACID guarantees
● Snapshot isolation, all or nothing execution
● No performance impact for non-transactional
operations
Schedule
● MongoDB 4.0, Summer ‘18: replica set
● MongoDB 4.2: extended to sharded clusters

38. Cloud Native Java + PCF + MongoDB
Reference Architecture

43. $ cf dev start
Open Source Example

44. https://github.com/kbastani/cloud-native-microservice-strangler-example
http://www.kennybastani.com/2016/08/strangling-legacy-microservices-spring-cloud.html
Open Source Example on GitHub

45. © Copyright 2018 Pivotal Software, Inc. All rights Reserved. Version 1.0
How to Overcome Data Challenges When
Refactoring Monoliths to Microservices
Kenny Bastani, Developer Advocate, Pivotal
Twitter: @kennybastani
Jason Mimick, Technical Director, MongoDB
Twitter: @jmimick

46. The First Law of Microservices – “It Depends”
Q/A
