From http://dc612.org/index.php/2013/11/02/november-14th-meeting-6pm-elsies/: Karl Fosaaen will be presenting on Attacking iOS Apps with Proxies at the November 14th DC612. This presentation will cover the basics of attacking iOS applications (and their back ends) using a web proxy to intercept, modify, and repeat HTTP/HTTPS requests. From setting up the proxy to pulling data from the backend systems, this talk will be a great primer for anyone interested in testing iOS applications at the HTTP protocol level. There will be a short primer on setting up the intercepting proxy, followed by three practical examples; showing how to intercept data headed to the phone, how to modify data heading to the application server, and how to pull extra data from application servers to further an attack. All of these examples will focus on native iOS apps (Game Center and Passbook) and/or functionality (Passbook Passes).

1. Hacking iOS GameCenter and Passbook with Proxies
DC612
November 14, 2013

2. Who am I?
• Karl Fosaaen
Senior Security Consultant
At NetSPI
Twitter: @kfosaaen

3. Presentation Overview
• Intercepting iOS Traffic
• Proxies
• Why and How
• Tools
• Certificates
• Attack Examples
• GameCenter Scores
• GameCenter Hashes
• Passbook files
• Conclusions

4. Intercepting traffic: Proxies
• What are they?
‒ A tool that allows you to intercept, modify,
and store HTTP and HTTPs requests
• Examples
‒ Burp
‒ ZAP
‒ Fiddler
‒ WebScarab

5. Intercepting traffic: Why
• iOS traffic can be interesting
‒ Most apps use web service calls
‒ Most apps are just pretty web browsers
• Traffic tampering
‒ Can you name your own price/score?
‒ Most back ends have the same vulnerabilities
as normal web apps (XSS, SQLi, etc.)
• Server responses can be interesting
‒ Modify what the server says to trick your app
‒ Intercepting files (ie: Passbook Passes)
• Same goes for Android

6. Intercepting traffic: How
• Use an intercepting proxy
‒ Be on the same Wi-Fi network as the iOS device
‒ Set it up to capture your traffic
‒ Store and forward allows for tampering
• SSL Interception
‒ Requires a trusted certificate
‒ Some apps don’t trust iOS cert stores
•
This is a good thing, just a pain for interception
• Traffic sniffing
‒ Some apps send requests in the clear
‒ Packet sniffing can be useful

7. Intercepting traffic: Tools
• Burp
• iOS simulator
• Other Proxies
‒ ZAP
‒ Fiddler
‒ WebScarab

8. Intercepting Traffic: Certs
• Exporting the Burp Root CA

9. Intercepting Traffic: Certs
• Exporting the Burp Root CA

10. Intercepting Traffic: Certs
• Exporting the Burp Root CA
• Save the root cert as
PortSwiggerCA.crt
• Send the cert to yourself via email
and add it to your iOS device
• Instructions from Portswigger:
http://portswigger.net/burp/help/proxy_options_installingCAcert.html#iphone

11. Intercepting Traffic: Certs
• Exporting the Burp Root CA
• Certificate installed on iPhone

12. Intercepting Traffic: Burp
• Burp Set Up

13. Intercepting Traffic: Burp
• iOS Proxy Set Up

14. Intercepting Traffic: Burp
• Intercepted iOS traffic
• HTTPS request to Google from iPhone

15. Intercepting Traffic: Burp
• A quick warning…
‒ Watch your credentials
•
•
Exchange ActiveSync sends encoded passwords
Your login creds for other apps and sites will get
stored in your proxy
‒ Mostly watch the data getting stored in your
proxy
•
You never know when you will need to send your
Burp session to someone else

16. Intercepting Traffic: Certs
• Identifying pinned apps
• Able to intercept normal browser SSL
traffic
• Can’t get app specific data
• Pinning might be in use
• The app may also be looking for specific
cert parameters
•
This is not pinning
• It’s cert checking

17. Intercepting Traffic: Certs
• Avoiding issues with cert pinned apps
•
•
•
•
Open the app without the proxy enabled
Get to a spot where you request an
external resource
Switch over to your preferences
• Turn on the Proxy
Request the resource
•
•
•
•
Passbook pass
Coupons
Etc.
Or just use the exclusions in Burp

18. Attack Examples
Example Time!

19. Attack Examples
• GameCenter High Scores
• GameCenter Email Hashes
• Passbook files

20. Attack Examples: GameCenter
GameCenter High Scores

21. Attack Examples: GameCenter

22. Attack Examples: GameCenter
• Attacking High Scores
‒ GameCenter scores update with
HTTPS POST requests
‒ No input validation on “score-value”
parameter
• Max score of
9,223,372,036,844,775,807

23. Attack Examples: GameCenter
• Attack Process
‒ Set up intercepting proxy
‒ Play a game
•
Beat the first level
or
•
Trigger a score update
‒ Intercept the score update
•
Look for “submitScores” page
‒ Replace score value with
9,223,372,036,844,775,807

24. Attack Examples: GameCenter

25. Attack Examples: GameCenter

26. Attack Examples: GameCenter

27. Attack Examples: GameCenter
‒ Bad News
•
•
This was fixed in iOS 7
There’s a token now
=

28. Attack Examples: GameCenter
Capturing GameCenter Email Hashes

29. Attack Examples: GameCenter
• Capturing Email Hashes
• Unsalted SHA1 email hashes can be
leaked by requesting player
information
• This can be done for current friends
and accounts of “friends of friends”
• Why would they allow this?

30. Attack Examples: GameCenter
• Capturing Email Hashes
• Step One: Add a bunch of friends
•
Current recommendations,
leaderboards, friends of your friends

31. Attack Examples: GameCenter
• Capturing Email Hashes
• Step Two: Get a list of all of their friends
•
•
So “friends of friends”
Use Burp for this

32. Attack Examples: GameCenter
• Capturing Email Hashes
• Step Three: Friend request all of them

33. Attack Examples: GameCenter
• Capturing Email Hashes
• RETURN to Step One multiple times
• Step Four: Query for the email hashes
for all of your friends and all of their
friends too
•
•
This will be done with intruder in Burp
Much like step three – Send the request on the
next slide to intruder
• *Step Five: Write a worm that tries to
friend everyone (*Very Optional)

34. Attack Examples: GameCenter

35. Attack Examples: GameCenter
• Next Steps
‒ So you have some hashes, so what…
•
You have their handle, first and last names too
‒ What’s your email address?
•
Common email user names
•
•
•
•
First.last
FirstinitialLast
Handle/username
NameBirthYear (or other “significant” number)
‒ Who’s your email provider?
•
Gmail, Yahoo, Hotmail, AOL

36. Attack Examples: GameCenter
• Cracking Email Hashes
‒ PowerShell Script to Guess Email user names
• kfosaaen@example.com
• k.fosaaen@example.com
• karlfosaaen@example.com
• karl.fosaaen@example.com
• karl.f@example.com
• karlf@example.com
‒ Append the top 500 email domains to the
end and SHA1 each one

37. Attack Examples: GameCenter
• Cracking Email Hashes
‒ PowerShell Script to SHA1 hash the guessed
emails
•
This was basic, but worked well
‒ Use the email guesses as a dictionary for
Hashcat
•
The rule set can be customized to make cracking
easier

38. Attack Examples: GameCenter
• Final Numbers:
‒ 225 friends added* (as of 10/16/13)
*Records collection stopped after 45 friends
‒ 1,635 records gathered
• 1,534 after Unicode removal
• 14,377 available to me currently
‒ 300 email hashes cracked (19.5%)
Records Example:
SHA1 Email Hash
: username : First Name : last Name
591542B50A99EAA8E41136305075F9FF708F1992:bubblefish:Deb:Morgan

39. Attack Examples: Passbook
Passbook

40. Attack Examples: Passbook
• Multiple Apps are now available with Passbook
• Mostly used to store loyalty cards, coupons, and
boarding passes
‒ Gift cards are now getting adopted
• Can actually be pretty convenient to use

41. Attack Examples: Passbook
• Passes are sent as .pkpass files
‒ .pkpass is just a renamed .zip file
‒ Required contents:
• manifest.json
• pass.json
• Signature
•
•
A signature file for integrity
Prevents file replacement and a re-zip

42. Attack Examples: Passbook
• Creating your own
‒ Join the Apple Developer Program ($99)
‒ Create a pass.json file to match your info
• The teamIdentifier and passTypeIdentifier
fields need to match your Apple cert info
• Make the pass details what you want
•
•
Boarding pass, coupon, etc.
Add images
‒ Use the signpass application (from Apple) to
generate the new .pkpass file
‒ Can be done in Windows and Linux

43. Attack Examples: Passbook
• Deployment
‒ Can be done via email or web server

44. Attack Examples: Passbook
• Common Application Issues:
• Failure to securely deliver .pkpass files
• No HTTPs or certificate pinning
• Failure to validate pass information on
backend systems
•
Do you really have $1,000 on that gift
card?

45. Attack Examples: Passbook
• Attack overview – Proxy method
‒ Set up your intercepting proxy
‒ Request a Passbook pass from the app
•
Look for the “Add to Passbook” button
‒ Intercept the request for the pass
•
Usually to a third party site
‒ Request and save the pass in your browser
‒ Modify your pass
‒ Re-sign and use your new and improved pass

46. Attack Examples: Passbook
• Attack overview – Easier way
‒ Add your pass to Passbook
‒ Send yourself the pass from the Passbook app
‒ Modify your pass
‒ Re-sign and use your new and improved pass
=

47. Attack Examples: Passbook
• Delta Boarding Passes
‒ One of many Passbook apps, but it’s the one
that I use the most
‒ Main Delta App does not do certificate
pinning

48. Attack Examples: Passbook
• Delta Boarding Passes
‒ Request for Passbook pass

49. Attack Examples: Passbook
• Attack overview – Easier way

50. Attack Examples: Passbook
• Attack overview – Easier way

51. Attack Examples: Passbook
• Delta Boarding Passes
‒ Extracted pkpass file
‒ Extracted Sky Priority pkpass file

52. Attack Examples: Passbook
• Delta Boarding Passes
‒ Modify the pass.json file
‒ And include the footer images in the directory

53. Attack Examples: Passbook
• Delta Boarding Passes
‒ Run the Signpass utility and email yourself the
pass

54. Attack Examples: Passbook
• Modified and Original Delta Boarding Passes

55. Conclusions
•Fixes
•
•
•
Certificate pinning
Better input validation
Limiting data leakage from apps

56. Hacking iOS Game Center and Passbook
• Questions?
• Karl Fosaaen
‒ Senior Security Consultant at NetSPI
‒ Twitter: @kfosaaen
