1. ingraph: Live Queries on Graphs
Gábor Szárnyas
GraphConnect 2017

2. Live Graph Queries

3. Railway operation model

4. Railway operation model

5. Railway operation model

6. Railway operation model

7. Railway operation model
Proximity detection

8. Railway operation model
Proximity detection

9. Railway operation model
Proximity detection

10. Railway operation model
Trailing the switch
Proximity detection

11. Railway operation model

12. Railway operation model

13. Railway operation model
c d e
g
fdiv
2
a b
1

14. Railway operation model
c d e
g
fdiv
2
NEXT NEXT
STRAIGHT TOP
ON
a b
1
NEXT
ON
NEXT

15. Proximity detection
Proximity detection
≤ 𝟏 segment

16. Proximity detection
seg1
NEXT: 1..2
t1
ON
Proximity detection
seg2
t2
ON
≤ 𝟏 segment

17. Proximity detection
seg1
NEXT: 1..2
t1
ON
MATCH
(t1:Train)-[:ON]->(seg1:Segment)
-[:NEXT*1..2]->(seg2:Segment)
<-[:ON]-(t2:Train)
RETURN t1, t2, seg1, seg2
Proximity detection
seg2
t2
ON
≤ 𝟏 segment

18. Proximity detection
seg1
NEXT: 1..2
t1
ON
MATCH
(t1:Train)-[:ON]->(seg1:Segment)
-[:NEXT*1..2]->(seg2:Segment)
<-[:ON]-(t2:Train)
RETURN t1, t2, seg1, seg2
Proximity detection
seg2
t2
ON
≤ 𝟏 segment

19. Trailing the switch

20. Trailing the switch
seg div
t
STRAIGHT
ON

21. Trailing the switch
seg div
t
STRAIGHT
ON
MATCH (t:Train)-[:ON]->(seg:Segment)
<-[:STRAIGHT]-(sw:Switch)
WHERE sw.position = 'diverging'
RETURN t.number, sw

22. Trailing the switch
seg div
t
STRAIGHT
ON
MATCH (t:Train)-[:ON]->(seg:Segment)
<-[:STRAIGHT]-(sw:Switch)
WHERE sw.position = 'diverging'
RETURN t.number, sw

23. Trailing the switch
seg div
t
STRAIGHT
ON
MATCH (t:Train)-[:ON]->(seg:Segment)
<-[:STRAIGHT]-(sw:Switch)
WHERE sw.position = 'diverging'
RETURN t.number, sw
Evaluate
continuously

24. Batch vs. live queries

25. Batch vs. live queries
1. Client selects a query
2. Results are calculated
Batch queries
Results obtained on demand

26. Batch vs. live queries
1. Client selects a query
2. Results are calculated
1. Client registers queries
2. Graph is changed
3. Results are maintained
4. Goto 2
Batch queries Live queries
Results always available
Clients receive notifications
Results obtained on demand

27. Batch vs. live queries
1. Client selects a query
2. Results are calculated
1. Client registers queries
2. Graph is changed
3. Results are maintained
4. Goto 2
Batch queries Live queries
Results always available
Clients receive notifications
Results obtained on demand
Incremental query evaluation

28. Incremental query engines
CLIPS C NASA
Drools Java Red Hat
VIATRA Java/EMF BME & IncQuery Labs

29. Incremental query engines
CLIPS C NASA
Drools Java Red Hat
VIATRA Java/EMF BME & IncQuery Labs
INSTANS LISP/RDF Aalto University
i3QL Scala TU Darmstadt
IncQuery-D Scala/RDF BME

30. Incremental query engines
CLIPS C NASA
Drools Java Red Hat
VIATRA Java/EMF BME & IncQuery Labs
INSTANS LISP/RDF Aalto University
i3QL Scala TU Darmstadt
IncQuery-D Scala/RDF BME
No implementations for property graphs yet

31. ingraph
 PoC query engine
 Goals:
o Provide incremental query evaluation for graphs
o Parallel & distributed operation to allow scalability

32. ingraph
 PoC query engine
 Goals:
o Provide incremental query evaluation for graphs
o Parallel & distributed operation to allow scalability
ingraphClient

33. ingraph
 PoC query engine
 Goals:
o Provide incremental query evaluation for graphs
o Parallel & distributed operation to allow scalability
ingraphClient
register queries

34. ingraph
 PoC query engine
 Goals:
o Provide incremental query evaluation for graphs
o Parallel & distributed operation to allow scalability
ingraphClient
register queries
query results

35. ingraph
 PoC query engine
 Goals:
o Provide incremental query evaluation for graphs
o Parallel & distributed operation to allow scalability
ingraphClient
register queries
query results
update graph

36. ingraph
 PoC query engine
 Goals:
o Provide incremental query evaluation for graphs
o Parallel & distributed operation to allow scalability
ingraphClient
register queries
query results
change notifications
update graph

37. Under the Hood
