1. GIT: A BRIEF INTRODUCTION
Randal L. Schwartz, merlyn@stonehenge.com
Version 5.1.7 on 20 July 2017
This document is copyright 2006-2017 by Randal L. Schwartz, Stonehenge Consulting Services, Inc.
This work is licensed under Creative Commons Attribution-Noncommercial-Share Alike 3.0 Unported License
http://creativecommons.org/licenses/by-nc-sa/3.0/

2. ABOUT ME
➤ Been tracking git since it was created (April 2005)
➤ Took Linus to lunch when he moved to Portland: “What are you working on?”
➤ Used git on everything from individual tasks to large teams
➤ Formerly participated in the mailing list
➤ But it’s too noisy now
➤ Provided some patches to git, and suggestions for user interface changes
➤ Still build git every day from master
➤ Gave the first Google TechTalk (October 2007) that talked about what Git actually is
➤ Linus spoke six months earlier about what Git isn’t

3. WHAT IS GIT?
➤ Git manages changes to a tree of files over time
➤ Git is optimized for:
➤ Distributed development
➤ Large file counts
➤ Complex merges
➤ Making trial branches
➤ Being very fast
➤ Being robust

4. BUT NOT FOR...
➤ Tracking file permissions and ownership
➤ Tracking individual files with separate history
➤ Making things painful

5. WHY GIT?
➤ Essential to Linux kernel development
➤ Created in 2005 as a replacement when BitKeeper suddenly became “unavailable”
➤ Now used by millions of projects
➤ Everyone can:
➤ Clone the tree
➤ Make and test local changes
➤ Submit the changes as patches via mail
➤ OR submit them as a published repository
➤ Track the upstream to revise if needed

6. HOW DOES GIT DO IT?
➤ Universal public identifiers
➤ Computed from the constituent bits, so they can be verified
➤ Multi-protocol transport: HTTP, SSH, GIT
➤ Efficient object storage
➤ Everyone has entire repo (disk is cheap)
➤ Easy branching and merging
➤ Common ancestors are computable
➤ Patches (and repo updates) can be transported or mailed
➤ Binary “patches” are supported

7. THE SHA1 IS KING
➤ Every object has a SHA1 to uniquely identify it
➤ Objects consist of:
➤ Blobs (the contents of a file)
➤ Trees (directories of blobs or other trees)
➤ Commits:
➤ A tree
➤ Plus zero or more parent commits
➤ Plus a message about why
➤ And tags

8. TAGS
➤ An object (usually a commit)
➤ Plus an optional subject (if anything else is given)
➤ Plus an optional payload to sign it off
➤ Plus an optional GPG signature
➤ Designed to be immobile
➤ Changes not tracked after cloning
➤ Use a branch if you want to move around

9. OBJECTS LIVE IN THE REPO
➤ Git efficiently creates new objects
➤ Objects are generally added, not destroyed
➤ Unreferenced objects will garbage collect
➤ Objects start “loose”, but can be “packed”
➤ Packs represent objects as deltas
➤ Packs are also created for push and pull

10. COMMITS RULE THE REPO
➤ One or more commits form the head of object chains
➤ Typically one head called “master”
➤ Nothing special about the name “master” though
➤ Others can be made at will (“branches”)
➤ Usually one commit in the repo that has no parent commit (“root” commit)

11. REACHING OUT
➤ From a commit, reaching the components:
➤ Chase down the tree object to get to directories and files as they existed at this
commit time
➤ Chase down the parent objects to get to earlier commits and their respective trees
➤ Do this recursively, and you have all of history
➤ And the SHA1 depends on all of that!

12. THE GIT REPO
➤ A “working tree” has a “.git” dir at the top level
➤ Unlike CVS, SVN: no deeper pollution
➤ This makes it friendly to recursive greps
➤ Even though “git grep” is also provided

13. THE .GIT DIR CONTAINS:
➤ config – Configuration file (.ini style)
➤ objects/* – The object repository
➤ refs/heads/* – branches (like “master”)
➤ refs/tags/* - tags
➤ logs/* - logs
➤ refs/remotes/* - tracking others
➤ index – the “index cache” (described shortly)
➤ HEAD – points to one of the branches (the “current branch”, where commits go)

14. THE INDEX (OR “CACHE”)
➤ A directory of blob objects
➤ Represents the “next commit”
➤ “Add files” to put current contents in
➤ “Commit” takes the current index and makes it a real commit object
➤ Diff between HEAD and index:
➤ changed things not yet committed
➤ Diff between index and working dir:
➤ changed things not yet added
➤ untracked things

15. WHAT’S IN A NAME?
➤ Git doesn’t record explicit renaming
➤ Nor expect you to declare it
➤ Exact renaming determined by SHA1
➤ Copy-paste-edits detected by similarity
➤ Computer better than you at that
➤ Explicit tracking will be wrong sometimes
➤ Being wrong breaks merges

16. GIT SPEAKS AND LISTENS
➤ Many protocols to transfer between repos
➤ http, https, git, ssh, local files
➤ In the core, git also has:
➤ import/export with CVS, SVN
➤ I use SVN import to have entire history of an SVN project at 30K feet
➤ Third party solutions handle others
➤ Git core also includes cvs-server
➤ A git repository can act like a CVS repository for legacy clients or humans

17. GETTING GIT
➤ Get the latest: https://git-scm.com/downloads
➤ Linux packages also exist
➤ Track the git-developer archive:
➤ git clone https://github.com/git/git
➤ Maintenance releases are very stable
➤ I install mine “prefix=/opt/git”
➤ add /opt/git/bin to PATH

18. GIT COMMANDS
➤ All git commands start with “git”
➤ “git MUMBLE-FOO bar” can also be written as “git-MUMBLE-FOO bar”
➤ This allows a single entry “git” to be added to the /usr/local/bin path
➤ This works for internal calls as well
➤ Manpages are still under “git-MUMBLE-FOO”
➤ Unless you use “git help MUMBLE-FOO”
➤ Or “git MUMBLE-FOO --help”

19. PORCELAIN AND PLUMBING
➤ Low-level git operations are called “plumbing”
➤ Higher level actions are called “porcelain”
➤ The git distro includes both
➤ Use porcelain from command line
➤ But don’t script with it
➤ Future releases might change things
➤ Past releases have definitely changed things
➤ Use plumbing for scripts
➤ Intended to be upward compatible (or at least versioned)
➤ Strangely, the --porcelain flag often enables plumbing mode (WTF?)

20. CREATING A REPO
➤ git init
➤ Creates a .git in the current dir
➤ Optional: edit .gitignore
➤ “git add .” to add all files (except .git!)
➤ Then “git commit” for the initial commit
➤ Creates current branch named “master”
➤ The name “master” is otherwise unspecial
➤ Could also do this on a tarball, once unpacked

21. CLONING
➤ Creates a git repo from an existing repo
➤ Generally creates a subdirectory
➤ Your workfiles and .git are in there
➤ Clone repo identified as “origin”
➤ But the name is otherwise unspecial
➤ Remote branches are “tracked”
➤ On fetch operations, the remote branch heads are copied to origin/$branchname
➤ Remote “HEAD” branch checked out as your initial “master” branch as well

22. COMMITTING
➤ Your work product is more commits
➤ These are always on a “branch”
➤ A branch is just a named commit
➤ When you commit, the former branch head becomes the parent
➤ The branch head moves to be the new commit
➤ Thus, you’re creating a directed acyclic graph
➤ ... rooted in branch heads
➤ A merge is just a commit with multiple parents

23. TYPICAL WORK FLOW
➤ Edit edit edit
➤ git add files/you/have changed/now
➤ This adds the files to the index
➤ “git add .” for adding all interesting files (except ignored files)
➤ “git add -p” selects patch by patch (my favorite)
➤ git status
➤ Tells you differences between HEAD, index, and working directory

24. MAKING THE COMMIT
➤ “git commit” pops you into a text editor for the commit message
➤ Good commit message rules:
➤ Separate subject from body with a blank line
➤ Limit the subject line to 50 characters
➤ Capitalize the subject line
➤ Do not end the subject line with a period
➤ Use the imperative mood in the subject line
➤ Wrap the body at 72 characters
➤ Use the body to explain what and why vs. how
➤ Current branch is moved forward

25. BUT WHICH BRANCH?
➤ Git encourages branching
➤ A branch is just 41 text bytes!
➤ Typical work flow:
➤ Think of something to do
➤ git checkout -b topic-name master
➤ work work work, commit to topic-name
➤ When your thing is done:
➤ git checkout master
➤ git merge topic-name
➤ git branch -d topic-name

26. WORKING IN PARALLEL
➤ You can have multiple topics active:
➤ git checkout -b topic1 master
➤ work work; commit; work work; commit
➤ git checkout -b topic2 master
➤ work work work; commit
➤ git checkout topic1; work work; commit
➤ Decide how to bring them together
➤ Merge: parallel histories
➤ Rebase: serial histories
➤ Each has pros and cons

27. THE MERGE
➤ git checkout master
➤ git merge topic1; git branch -d topic1
➤ This should be trivial (“fast forward”) merge
➤ git merge topic2
➤ Conflicts may arise:
➤ overlapping changes in text edits
➤ files renamed two different ways
➤ You need to resolve, and continue:
➤ git commit -a -m “describe the merge fix here”

28. THE REBASE
➤ Rewrites commits
➤ Breaks SHA1s: commits are lost!
➤ Don’t rebase if you’ve published commits!
➤ git checkout topic2; git rebase master
➤ topic2’s commits rewritten on top of master
➤ May result in merge conflicts:
➤ git rebase --continue or --abort or --skip
➤ git rebase -i (interactive) is helpful
➤ When rebased, merge is a fast forward:
➤ git checkout master; git merge topic2

29. READ THE HISTORY
➤ git log
➤ print the changes
➤ git log -p
➤ print the changes, including a diff between revisions
➤ git log --stat
➤ Summarize the changes with a diffstat
➤ git log -- file1 file2 dir3
➤ Show changes only for listed files or subdirs

30. WHAT’S THE DIFFERENCE?
➤ git diff
➤ Diff between index and working tree
➤ These are things you should “git add”
➤ “git commit -a” will also make this list empty
➤ git diff HEAD
➤ Difference between HEAD and working tree
➤ “git commit -a” will make this empty
➤ git diff --cached
➤ between HEAD and index
➤ “git commit” (without -a) makes this empty

31. OTHER DIFFS
➤ git diff OTHERBRANCH
➤ Other branch and working tree
➤ git diff BRANCH1 BRANCH2
➤ Difference between two branch heads
➤ git diff BRANCH1...BRANCH2
➤ changes only on branch2 relative to common ancestor
➤ git diff --stat (other options)
➤ Nice summary of changes
➤ git diff --dirstat (other options)
➤ Summarize directory changes

32. BARKING UP THE TREE
➤ Most commands take “tree-ish” args
➤ SHA1 picks something absolutely
➤ Can be abbreviated if not ambiguous
➤ HEAD, some-branch-name, some-tag-name, some-origin-name
➤ Optionally followed by @{historical}
➤ “historical” can be:
➤ yesterday, 2011-11-22, etc (date ref)
➤ 1, 2, 3, etc (prior version of this ref)
➤ “upstream”, “u” (upstream version of local)

33. MEET THE PARENTS
➤ Any of those on the prior slide, followed by:
➤ ^n - “the n-th parent of an item” (default 1)
➤ ~n - n ^1’s (so ~3 is ^1^1^1)
➤ :path - pick the object from the tree
➤ ^{/some text here} - first parent with a commit message matching the text

34. RANGES
➤ $tree1 - all commits reachable from $tree1 back to the root
➤ ^$tree1 $tree2 - all commits from $tree2 MINUS all commits from $tree1
➤ Common enough that it can be written $tree1..$tree2 (“from $tree1 to $tree2”)
➤ $tree1…$tree2 is $m..$tree1 with $m..$tree2, where $m is the merge base
➤ Omitting either operand in .. or … defaults to HEAD
➤ $tree1.. - all commits on current branch since $tree1
➤ ..$tree2 - all commits introduced on $tree2 since this branch forked

35. RANGE EXAMPLES
➤ git diff HEAD^ HEAD
➤ most recent change on current branch
➤ Also: git diff HEAD~ HEAD
➤ git diff HEAD~3 HEAD
➤ What damage did last three edits do?

36. SEEING THE CHANGES
➤ gitk mytopic origin
➤ Tk widget display of history
➤ Shows changes back to common ancestor
➤ gitk --all
➤ show everything
➤ To skip the tags: gitk HEAD --branches --remotes
➤ gitk from..to
➤ Just the changes in “to” that aren’t in “from”
➤ git show-branch from..to
➤ Same thing for the Tk-challenged

37. PLAYING WELL WITH OTHERS
➤ git clone creates “tracking” branches
➤ Typically named “origin/master” etc
➤ To share your work, first get up to date:
➤ git fetch origin
➤ Now rebase your changes on upstream:
➤ git rebase origin/master
➤ Or fetch/rebase in one step
➤ git pull --rebase
➤ To push upstream:
➤ git push

38. RESETTING
➤ git reset --soft
➤ Makes all files “updated but not checked in”
➤ git reset --hard # DANGER
➤ Forces working dir to look like last commit
➤ git reset --hard HEAD~3
➤ Tosses most recent 3 commits
➤ use “git revert” instead if you’ve published
➤ git checkout HEAD some/lost/file
➤ Recover the version of some/lost/file from the last commit

39. IGNORING THINGS
➤ Every directory can contain a .gitignore
➤ lines starting with “!” mean “not”
➤ lines without “/” are checked against basename
➤ otherwise, shell glob via fnmatch(3)
➤ Leading / means “the current directory”
➤ Checked into the repository and tracked
➤ Every repository can contain a .git/info/exclude
➤ Both of these work together
➤ But .git/info/exclude won’t be cloned

40. CONFIGURATION
➤ Many commands have configurations
➤ git config name value
➤ set name to value
➤ name can contain periods for sub-items
➤ git config name
➤ get current value
➤ git config --global name [value]
➤ Same, but with ~/.gitconfig
➤ This applies to all git repos for a user

41. THE STASH
➤ Creates temporary commits to represent:
➤ current index (git add ...)
➤ current working directory (git add .)
➤ Can rebase those onto new index later
➤ Many uses, such as pull into dirty workdir:
➤ git stash; git pull ...; git stash pop
➤ Might result in conflicts, of course
➤ Multiple stashes can be in play
➤ “git stash list” to show them

42. OTHER USEFUL PORCELAIN
➤ git archive: export a tree as a tar/zip
➤ git bisect: find the offensive commit
➤ git cherry-pick: selective merging
➤ git mv: rename a file/dir with the right index manipulations
➤ git rm: ditto for delete
➤ git push: write to an upstream
➤ git revert: add a commit that undoes a previous commit
➤ git blame: who wrote this?

43. COMMIT ADVICE
➤ Split changes into small logical steps
➤ Ideally ones that pass the test suite again
➤ This helps for “blame” and “bisect”.
➤ Easier to squash commits later than to break up
➤ “git rebase -i” can squash, omit, reorder

44. PICKING FROM BRANCHES
➤ Two main tools: “merge” and “cherry-pick”
➤ Merge brings in all commits
➤ Scales well for large workflows
➤ Cherry-pick brings in one or more
➤ Great when a single patch is needed

45. GIT.GIT’S WORKFLOW
➤ Four branches:
➤ maint: fixes to existing releases
➤ master: next release
➤ next: testing for next master
➤ pu: experimental features
➤ Each one is a descendent of the one above
➤ Commit to the oldest branch needing patch
➤ Then merge it upward:
➤ maint to master to next to pu

46. TOPIC BRANCHES
➤ Most features require several iterations
➤ Commit these to topic branches during design
➤ Easier to rehack or abandon this way
➤ Fork topic from the oldest main branch
➤ Refresh-merge from that branch if needed
➤ But don’t do that routinely
➤ Rebase topic branch if forked from wrong branch
➤ More details at “man 7 gitworkflows”

47. TESTING INTEGRATION
➤ Merge from base branch to topic branch
➤ ... on a new throw-away branch
➤ This branch is never merged back in
➤ Just for testing
➤ Can be published publicly, if you make it clear that it’s just for testing
➤ Otherwise, typically used only locally
➤ If integration fails, fix, and cherry-pick those back to the topic branch before final
merge

48. TIME TO “GIT” DIRTY
➤ Make a git repository:
➤ mkdir git-tutorial
➤ cd git-tutorial
➤ git init
➤ git config user.name “Randal Schwartz”
➤ git config user.email merlyn@stonehenge.com
➤ Add some content:
➤ echo "Hello World" >hello
➤ echo "Silly example" >example

49. WHAT’S UP?
➤ git status
➤ git add example hello
➤ git status
➤ git diff --cached

50. “GIT ADD” TIMING
➤ Change the content of “hello”
➤ echo "It's a new day for git" >>hello
➤ git status
➤ git diff
➤ Now commit the index (with old hello)
➤ git commit -m initial
➤ git status
➤ git diff
➤ git diff HEAD

51. GIT COMMIT -A
➤ Note that we committed the version of “hello” at the time we added it!
➤ Fix this by adding -a nearly always:
➤ git commit -a -m update
➤ git status

52. WHAT HAPPENED?
➤ Ask for logs:
➤ git log
➤ git log -p
➤ git log --stat --summary
➤ Tag, you’re it:
➤ git tag my-first-tag
➤ Now we can always get back to that version later

53. SHARING THE WORK
➤ Create the clone:
➤ cd ..
➤ git clone git-tutorial my-git
➤ cd my-git
➤ The git clone will often have some sort of transport path, like git: or rsync: or http:
➤ See what we’ve got:
➤ git log -p
➤ Note that we have the entire history
➤ And that the SHA1s are identical

54. BRANCHING OUT
➤ Create branch “my-branch”
➤ git checkout -b my-branch
➤ git status
➤ Make some changes:
➤ echo "Work, work, work" >>hello
➤ git commit -a -m 'Some work.'

55. CONFLICTS
➤ Switch back, and make other changes:
➤ git checkout master
➤ echo "Play, play, play" >>hello
➤ echo "Lots of fun" >>example
➤ git commit -a -m 'Some fun.'
➤ We now have conflicting commits

56. SEEING THE DAMAGE
➤ In an X11 display:
➤ gitk --all
➤ The --all means “all heads, branches, tags”
➤ For the X11 challenged:
➤ git show-branch --all
➤ git log --pretty=oneline —abbrev-commit --graph --decorate --all
➤ Handy for a mail message

57. MERGING
➤ We’re on “master”, and we want to merge in the changes from my-branch
➤ Select the merge:
➤ git merge my-branch
➤ This fails, because we have a conflict in “hello”
➤ See this with:
➤ git status
➤ Edit “hello”, and commit:
➤ git commit -a -m “Merge work in my-branch”

58. DID IT WORK?
➤ Verify the merge with:
➤ gitk --all
➤ git show-branch --all
➤ See changes back to the common ancestor:
➤ gitk master my-branch
➤ git show-branch master my-branch
➤ Note that master is only one edit from my-branch now (the merge patch-up)
➤ “git show” handy with merges:
➤ git show HEAD

59. MERGING THE UPSTREAM
➤ Master is now updated with my-branch changes
➤ But my-branch is now lagging
➤ We can merge back the other way:
➤ git checkout my-branch
➤ git merge master
➤ This will succeed as a “fast forward”
➤ This means that the merge-from branch already has all of our change history
➤ So it’s just adding linear history to the end

60. UPSTREAM CHANGES
➤ Let’s change origin a bit
➤ cd ../git-tutorial
➤ echo "some upstream change" >>other
➤ git add other
➤ git commit -a -m "upstream change"
➤ And now fetch it downstream
➤ cd ../my-git
➤ git fetch
➤ gitk --all
➤ git diff master..origin/master

61. MERGE IT IN
➤ Explicit merging
➤ git checkout master
➤ git merge origin/master
➤ Implicit fetch/merge
➤ git pull
➤ Eliminating the bushy tree
➤ git pull --rebase
➤ (Fails in our example.. sigh.)

62. SPLITTING UP A PATCH
➤ Sometimes, your changes are logically separate
➤ echo “this change” >>hello
➤ echo “unrelated change” >>example
➤ Now make two commits:
➤ git add -p # interactively select hello change
➤ git commit -m “fixed hello” # not -a!
➤ git commit -a -m “fixed example”

63. FIXING A COMMIT
➤ Oops, left out something on that last one
➤ echo "another unrelated" >>example
➤ Now “amend” the patch:
➤ git commit -a --amend
➤ This replaces the commit
➤ Be careful that you haven’t pushed it!

64. FOR FURTHER INFO
➤ See “Git (software)” in Wikipedia
➤ And the git homepage http://git-scm.com/
➤ Git wiki at https://git.wiki.kernel.org/
➤ Wonderful (but dated) Pro Git book: https://git-scm.com/book/en/v2
➤ Get on the mailing list
➤ Helpful people there
➤ You can submit bugs, patches, ideas
➤ And the #git IRC channel (on Freenode)
➤ Now “git” to it!
