This document presents research on optimal storage volumes for rainwater catchment systems in Alaska. The researchers modeled systems in 12 Alaskan communities factoring in water usage, roof catchment area, climate and temperature thresholds. They found that storage needs varied significantly based on these location-specific characteristics. Optimal storage was defined as the minimum tank volume needed to meet water demands during the operational season while maintaining at least a 5% reserve. The results provide guidelines to help design effective rainwater catchment systems tailored to local conditions in Alaska.
The document describes the water quality monitoring equipment, procedures, and sampling methods used at Soaring Eagle Dairy to assess annual nutrient and sediment losses. Key monitoring equipment included an H-flume to measure surface water runoff volume, a pressure transducer and datalogger to record water levels, and an automated refrigerated sampler to collect water samples during runoff events. Samples were analyzed for parameters like suspended sediment, nitrogen, phosphorus, and more. Regular maintenance was needed to keep equipment functioning properly throughout the year.
