Paper: Fault Interaction and its Repercussions Authors: Nicholas DiGiuseppe and James A. Jones Seesion: Research Track 1: Faults and Regression Testing

1. Fault Interaction and its
Repercussions
Nicholas DiGiuseppe James A. Jones
UC Irvine
Spider Lab

2. Fault Interaction Defined
4 Types of Interaction
Pass/Fail Independence
Obfuscation
Synergy
Multi-Type

3. Fault Interaction Defined
4 Types of Interaction
Pass/Fail Independence
Obfuscation
Synergy
Multi-Type

4. Fault Interaction Defined
4 Types of Interaction
Pass/Fail Independence
Obfuscation
Synergy
Multi-Type

5. Fault Interaction Defined
4 Types of Interaction
Pass/Fail Independence
Obfuscation
Synergy
Multi-Type

6. We Need More Fault Understanding
Conferences:
ASE, FSE, ICSE, ICSM, ICST, ISSTA
Years: 2008–2009
27 Fault Localization = 2.25 per conference per year
4 Fault Behavior = 0.333 per conference per year

7. Motivating Example
X = input [0] - 2
Y = input [0] - 2
If (X == Y)
print 1
else
print 0
Expected Actual Pass/Fail
Results Results Status
Test Case 1: input [0,0] 1 1 Pass
Test Case 2: input [2,0] 0 1 Fail

8. Motivating Example
X = input [0] - 2
Y = input [1] / 2
If (X == Y)
print 1
else
print 0
Expected Actual Pass/Fail
Results Results Status
Test Case 1: input [0,0] 1 0 Fail
Test Case 2: input [2,0] 0 1 Fail

9. Motivating Example
X = input [0] * 2
Y = input [1] / 2
If (X == Y)
print 1
else
print 0
Expected Actual Pass/Fail
Results Results Status
Test Case 1: input [0,0] 1 1 Pass
Test Case 2: input [2,0] 0 0 Pass

10. Our Experiment
Flex Gzip Replace Schedule Sed Space Total
1 Fault 21 20 25 20 20 33 139
2 Faults 189 182 185 165 188 200 1109
3 Faults 502 505 598 500 660 200 2965
4 Faults 1000 1000 700 500 950 200 4350
5 Faults 1000 1000 700 500 950 200 4350
17 Faults 1000 1000 700 500 950 200 4350
Total Versions 14,712 14,707 10,608 7,685 14,168 3,233 65,113
Size of Test Suite 527 214 5,542 2,650 363 13,527 22,733
Number of 7,753,224 3,147,298 58,798,536 17,673,600 6,253,984 43,732,791 138,239,433
Executions

11. Our Experiment
Flex Gzip Replace Schedule Sed Space Total
1 Fault 21 20 25 20 20 33 139
2 Faults 189 182 185 165 188 200 1109
3 Faults 502 505 598 500 660 200 2965
4 Faults 1000 1000 700 500 950 200 4350
5 Faults 1000 1000 700 500 950 200 4350
17 Faults 1000 1000 700 500 950 200 4350
Total Versions
Total Versions
14,712 14,707 10,608 65,113
7,68514,168 3,233 65,113
Size of Test Suite 527 214 5,542 2,650 363 13,527 22,733
Number of Executions 138,239,433
Number of
Executions
7,753,224 3,147,298 58,798,536 17,673,600 6,253,984 43,732,791 138,239,433

12. a Results
1.0
1.0
Obfuscation Multi Type 1.0
0.8
0.8 0.8
Percentage of Interaction
Percentage of Interaction
Percentage of Interaction
0.6
0.6 Synergy Independence 0.6
0.4
0.4 0.4
0.2
0.2 0.2
0.0
0.0 0.0
00 11 22 33 44 55 66 77 88 99 10 11 12 13 14 15 16 17
10 11 12 13 14 15 16 17 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
The Quantity of Faults
The Quantity of Faults The Quantity of Faults
1.0 1.0
0.8 0.8
Percentage of Interaction
Percentage of Interaction
0.6 0.6
0.4 0.4
0.2 0.2
0.0 0.0
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
The Quantity of Faults The Quantity of Faults
1.0 1.0
0.8 0.8
Percentage of Interaction
Percentage of Interaction
0.6 0.6
0.4 0.4
0.2 0.2
0.0 0.0
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
The Quantity of Faults The Quantity of Faults

13. Impact of Fault Interaction
Regression Testing
Fault Localization Two Faults Fix a Fault One Fault
Test 1 Pass Fail
Test 2 Pass Pass
Test 3 Fail Pass
Time
Failure Clustering
Run Test Fix Faults
Suite in Clusters
Cluster Assign Clusters
Failures to Developers

14. Results Continued
Gzip Flex Replace Schedule Sed Space
LoEC 2013 4020 242 150 2253 3651
Branches 1727 2680 182 66 2554 1190
Methods 514 1261 63 41 416 717
Data Dep 45,291 143,075 2005 1327 94,614 29,883
Control Dep 26,766 61,279 1444 1074 21,991 25,047
Total Dep 72,057 204,354 3449 2401 116,605 54,930
LoEC: 1.165 1.5 3.818 2.273 1.893 3.068
Branches
LoEC: Methods 3.916 3.188 3.841 3.659 5.416 5.092
LoEC: Data 0.044 0.028 0.121 0.113 0.024 0.122
Dep
LoEC: Control 0.075 0.066 0.168 0.140 0.103 0.146
Dep
LoEC: Total 0.028 0.020 0.070 0.062 0.019 0.067
Dep

15. Conclusions
Defined Fault Interaction
Demonstrated that Fault Interaction is prominent (primarily
fault obfuscation)
Demonstrated that Fault Interaction can have a real
impact on practice and research
Demonstrated that the size of a program affects Fault
Interaction

16. Conclusions
Take Home Message
Fault Interaction is prevalent
Fault Obfuscation is prevalent
We need to adapt our techniques

17. Thank You!
This work was partially funded by:
University of California, Irvine
