Engineers guide to data analysis
- 1. Engineer’s guide to Data Analysis Avishai Ish-Shalom github.com/avishai-ish-shalom@nukembergnukemberg@wix.com
- 2. Wix in numbers ~ 400 Engineers ~ 1400 employees ~ 100M Sites ~ 250 micro services
- 3. IaaS (Insult as a Service) ▪ Thin API, written in Flask (python) ▪ CouchDB ▪ Apache proxy ▪ StatsD, Graphite, ELK
- 5. Graphite ▪ Metrics collector, storage and UI ▪ Math functions ▪ Common ▪ De-facto standard
- 6. Oops, I think something is broken
- 7. What is this “metric” you speak of?
- 8. A metric is ▪ Numeric data ▪ Often with timestamp (time series) ▪ A “measurement” of something ▪ Discrete
- 9. Where do metrics come from? ▪ Events with numeric data ▪ Counting/aggregating ▪ Sampling
- 10. Sampling
- 11. Sampling
- 12. Events ▪ Data about something that happened ▪ timestamp (time series data) ▪ Has properties - numeric and non- numeric { “timestamp”: “2016-11- 15T18:43:39+00:00”, “host”: “test01.example.net”, “status”: “ok”, “latency”: 14.31 }
- 13. 10000 events/sec x 0.5kb/event = How much data? 400GB a day
- 14. Telemetry is a big data problem
- 15. Aggregates are lossy compression We must decide in advance how we’ll use the metric
- 16. Aggregates ▪ Max, Min, Sum, Average, etc ▪ Last, random point ▪ Percentiles (quantiles) ▪ Historgrams, reverse quantiles ▪ Each is suitable for a particular use case
- 17. Averages are mean to me
- 18. Percentiles p99 - The sampled value that is larger than other 99% of samples ▪ O(n) memory complexity ▪ O(n*log n) computation complexity ▪ Some shortcuts for p50 (median), p100 (max), p0 (min) Use when clients experience individual values
- 19. Percentiles ▪ Precentiles are not additive ▪ You cannot average percentiles Example: s1 (100 points) = [0, 0, ....., 100, 100] => p99 = 100 s2 (100 points) = [0, 0, …., 50, 50] => p99 = 50 p99(s1 : s2) = 50, avg(p99(s1), p99(s2)) = 75
- 20. Histograms Distribution visualization of sample ▪ Count of events in each bin ▪ Beans are usually evenly spaced ▪ Use logarithmically spaced bins for long tails ▪ Additive
- 21. Histograms :-( So why aren’t we all using this? ▪ Storage ▪ Have to decide on bins schema ▪ Not many tools support this
- 22. Choosing the right aggregate ▪ Percentiles/histograms for latency ▪ Max/min for latency and sizes ▪ Histogram analysis for sizes and latency ▪ Sums/averages for capacity and money ▪ Aggregate per domain ▪ Look for deviations
- 23. Resolution ▪ Humans need ~5 data points to see a trend ▪ Hides faster changes ▪ Rollups/downscaling is hard ▪ Multi tier FTW!
- 24. It ain't what you don’t know that gets you into trouble. It's what you know for sure that just ain’t so. “ “
- 25. Peak Erasure/Spike erosion ■ When lowering resolution, data points are aggregated ■ Default aggregation is average ■ Peaks are erased ■ This can happen in storage or visualization
- 26. Peak Erasure/Spike erosion ■ Storages down-sample to save space ■ Aggregation function may be configurable ■ Metric collectors aggregate too ○ carbon-cache uses last value ○ StatsD - gauges, timers, counters
- 27. Counters vs Gauges Behaviour in low res time window ■ Low res sampling erases fast changes ■ “Round numbers” syndrom ■ Counters smear changes, but don’t erase them TLDR: use counters when possible
- 28. Mixed modes Aggregating multiple modes reduces usability of aggregates ■ Different transaction types differ in latencies/sizes ■ Errors, successes have very different latencies/sizes ■ Makes your graphs weird TLDR: use separate metrics for different things
- 30. Visualization ■ Timeframe ■ No more than 3 series ■ Be weary of multiple Y scales, but scale if needed ■ Only related series on the same graph ■ Never mix X scales ■ Visual references: bounds, Y min/max values, legend
- 31. Metric design ■ Choose your aggregates wisely ■ Decide on a proper resolution, sampling rate, aggregation time windows ■ Explore the distribution ■ Separate known modes to independent metrics
- 32. Separate signal from noise ■ Use low-pass filters to smooth ■ Trend changes ■ Timeshifts ■ Filter out outliers
- 33. Working with clusters ■ Most-deviant/outliers ■ Max/Min ■ Sum (capacity) ■ Pre-aggregate percentiles
