Efficient Road Mapping Using Laser Scanner Technology
1. 3rd Annual
Optech ILRIS-3D Users Meeting
Rome, Italy - June 6-7, 2007
Efficient Road Mapping
Modeling of Highways, Roads and Pavements
using Laser Scanner Technology
Michael Xinogalos
Surveying Engineer NTUA
ASTROLABE ENGINEERING / JGC
2. Applications
• Highway survey and modeling (“as –built”
record, background for design and construction)
• Airport tarmac modeling and evaluation
(maintenance)
• Road intersection survey, design of
interventions to improve safety, 3D modeling
and integration, video simulations (evaluation
of proposed measures)
3. “Korinthos – Tripoli” Highway
• Location: Central Peloponnesos, Greece
• Self Financing Project: Construction of a new highway
section / Reconstruction and Maintenance of an existing
highway section – J/V MOREAS
• Existing Highway: Dual Carriageway, 2-3 lanes & shoulder
4. “Korinthos – Tripoli” Highway
Existing highway survey requirements
• Detail “as built” survey of all highway features (pavement,
structures, slopes, signage, poles, etc.)
• Efficient archiving of “as built” situation for future reference
• Positional accuracy of georeferenced points: 2-3 cm
• 3D model (TIN) for highway reconstruction design
• Background survey maps (scale 1:500)
• No traffic closure or delay
• Efficient safety plan
• Permits from local traffic authorities
5. “Korinthos – Tripoli” Highway
Project tasks (1/4)
• Establishment of geodetic infrastructure networks (triangulation,
leveling, polygonometry), also necessary for construction
• Static (stop & scan) laser scanning with Optech ILRIS36D
• Scanner carried by a vehicle moving or standing always on the
shoulder lane, protected by a traffic regulation trailing vehicle
• Scanning from both sides of the highway, distance between scanning
positions 50-80m
6. “Korinthos – Tripoli” Highway
Project tasks (2/4)
• Critical issue for horizontal objects: lifting the scanner (better scanning
angle, improved object visibility, lower scanning resolution and / or
fewer scanning positions required)
• Lifting device used: Genie Super Hoist (5.6m, 113 kg capacity, CO2)
• Custom modifications: Trailer integration, 5/8 bolt, longer ethernet and
power cables, stabilizers, fuel generator & UPS, etc.
7. “Korinthos – Tripoli” Highway
Project tasks (3/4)
• Scanning resolution: 55mm @ 25m horizontal / 20mm @ 25m vertical
• Pan-tilt base overlap set to maximum (20% overlap, 15 frames/3600)
• Primary georeferencing: with conic targets (standard traffic cones:
easy to install, measure and model), 1 cone (anchor point) per scan
position required for sequential georeferencing (Polyworks IMAlign -
IMInspect)
8. “Korinthos – Tripoli” Highway
Project tasks (4/4)
• Georeferencing refinement for elevations: using additional points
measured with GPS on the shoulder lane white lines every 50-80m
(Polyworks IMInspect)
• Feature collection from pointclouds (Polyworks IMInspect)
• 3D Modeling (TIN) from features and survey map creation (Autodesk
Civil 3D)
• Archiving for future reference: Subsampled pointclouds (5cm) per km
(Polyworks IMView)
12. Athens International Airport
Evaluation of tarmac deformations at the 4 airplane
maneuver areas on either side of the E & W air-corridors
13. Athens International Airport
Survey requirements
• Positional accuracy: 1cm
• Resolution: 5cm
• Data capture for each area within 6 hours
• Tarmac 3D modeling
• Elevation maps (contour spacing: 2cm)
• Cross-section level analysis
14. Athens International Airport
Project tasks
• 6 to 9 scan positions per area (scanner on top of a car, tripod mounted),
20% pan-tilt base overlap, distance between scans <50m
• Georeference using conic and circular targets, measured from the
airport’s geodetic control points
• Creation of an aligned and georeferenced pointcloud for each area
(Polyworks IMAlign and IMInspect)
15. Athens International Airport
Project tasks
• Subsampling (3cm) and triangulation of data points (Polyworks
IMInspect), optimization and decimation of TIN model from 3 million
triangles to <5000 triangles (Polyworks IMEdit, IMCompress)
16. Athens International Airport
Project tasks
• Creation of elevation map (contour spacing 2cm) (Autodesk Civil 3D)
17. Athens International Airport
Project tasks
• Cross section based analysis (ODOS software), reports
• Evaluation of the results by the AIA authorities
18. Evaluation of safety improvement measures
in road intersections
Ministry of Public Works – Maintenance Department
Current intersection layout – orthophoto from pointcloud
Design of improvement measures – 3D modeling
19. Evaluation of safety improvement measures
in road intersections
Ministry of Public Works – Maintenance Department
General layout fly-through
Current layout Proposed layout
20. Evaluation of safety improvement measures
in road intersections
Ministry of Public Works – Maintenance Department
Driving simulation – Direction from Messolongi to Antirrio
Current layout Proposed layout
21. Conclusions
Static Laser Scanning can be an efficient road mapping tool for
projects that require:
• high accuracy
• significant level of detail
• total object recording for archiving and future reference
• 3D modeling and motion simulation
• safe data collection
Disadvantages:
• productivity for long objects (e.g. highways) cannot exceed 500 to 800m of
surveyed road per day (portability and scanning height are critical factors)
• significant post processing work is needed, decimation is required to export
data to transportation design software
Mobile scanning systems with improved functionality will
provide a much faster and efficient alternative in the near future
