© 2014 IBM Corporation
Dynamic Mobile Apps
with WebSockets and MQTT
The Compelling Experience


What makes an application a delight to use?

-  Data arrives when you need it, not when you ask for it
-  The app provides a collaborative, social experience
-  Services are integrated seamlessly together

1
HTML5 WebSocket for Real-time
“A conversation on the web”
"   WebSocket is bidirectional
•  HTTP is request/response, WebSocket is a conversation
"   WebSocket is an HTML5 standard
•  Cross-domain communication
•  Supported by all major browsers
2
http://caniuse.com/websockets
MQTT for Mobile Messaging
"   What is it?
•  Publish/subscribe messaging protocol designed for mobile and
telemetry devices
•  Open (royalty-free), simple, lightweight, easy to implement
•  Allows for decoupled applications (“Internet of Things”)
•  Quality of service for assured message delivery
•  MQTT clients connect to an MQTT broker
"   Where is it?
•  Connected vehicles (ex. Sprint Velocity)
•  Connected cities (ex. NYPD ESU)
•  Connected people (ex. Facebook Messenger)
•  ...and everywhere else

3
Why MQTT?
"   Publish/subscribe messaging
•  Transmit information one to many
•  Subscribe to interesting topics
•  Distribute small data packets in huge volumes
"   Quality of Service (QoS) for assured messaging
•  “At most once”, “At least once”, “Exactly once”
"   Simple API
•  3 verbs: Connect, Publish, Subscribe (+ Receive)
•  Useful features: Last Will and Testament, Retain
•  Clients everywhere (40+)
–  JavaScript, C, C++, Python, Node.js, Java, Ruby, etc.
"   Lightweight
•  2-byte header, low latency
•  Mobile (LTE) = ~100ms, Browser (Wifi) = ~50ms (RTT)
4
Quick Demo – Whiteboard









bit.ly/impactwb
5
Compelling Experience
"   Real-time Monitoring (RaceTracker)"
"   Scalable Group Chat (Chatterbox)"
"   Cross-platform MMOG (Starfighter)!
"Agenda (for each demo)"
1.  Problem"
2.  Scenario / Architecture"
3.  Messaging design"
4.  Play time"
5.  "What else is possible?""
6
Fire up your laptops!
RaceTracker
RaceTracker
"   Problem – Marathons are crowded
•  Me: “Meet me at mile 17.3 with Gatorade around... 9:00-9:30”
•  Wife: “...could you be more specific?”
"   Solution – “RaceTracker”
1.  Publish location from iPhone
2.  Calculate speed/stats in real time
3.  Display runner info in a mobile app
4.  Live-tweet the race
"   Challenges
•  Network congestion (QoS!)
•  Wiring applications (pub/sub!)
8
Scenario
9
BlueMix
Runner Viewer Analytics Tweeter
Broker
10
OwnTracks (iOS / Android)
•  Open-source "location diary"
•  Publishes MQTT location data at interval
•  http://owntracks.org
"   Pubs
•  Location Data (retained)
–  RaceTracker/<race>/Person/<runner>
•  {
  "_type":"location","tst":"1392569738",

"lat":"30.3019","lon":"-­‐97.7278",
  "batt":"30","acc":"5"}

"   Subs
•  [nothing]
Runner
11
Node.js runtime in BlueMix
•  Performs speed calculations on runner data, maintains course
state, outputs events ("runner X crossed mile 5")
"   Pubs
•  Course Data (retained)
–  RaceTracker/<race>/Marker/<type>
•  {
  "id":"start",
  "lon":30.30214,
  "lat":-­‐97.77801
  }

–  RaceTracker/<race>/Marker/<type>/text
•  {
  "text":"Crossed
  at
  7:38
  AM
  with
  a
  split
  of
  8:28"
  }

–  RaceTracker/<race>/Course
•  "-­‐97.73911714,30.277803
  &
  -­‐979780987,30.28985
  &
  <lon>,<lat>
  &"

•  Events (QoS 2)
–  RaceTracker/<race>/Person/<runner>/event
•  {
  "type":"split",
  "splitTime":"10:42:13",
  "splitMarker":"mile
  2",

"splitString":"9:45"
  }

•  {
  "type":"finish",
  "time":"11:43:13",
  "totalTime":"4:15:13"
  }

Analytics
Analytics
12
"   Pubs (cont.)
•  Live Analytics (retained)
–  RaceTracker/<race>/Person/<runner>/text
•  {
  "text":
  "Pace:
  (about)
  9:18
  min/mile"
  }

"   Subs
•  Location Data
–  RaceTracker/<race>/Person/+
•  {
  "_type":"location","tst":"1392569738",

"lat":"30.3019","lon":"-­‐97.7278",
  "batt":"30","acc":"5"}

Analytics
13
HTML5 Map UI
•  Course data, analytics, and runners are displayed on a map
and updated in real-time through MQTT over WebSockets
•  Uses OpenLayers JavaScript library with ESRI imagery
"   Pubs

•  [Nothing]
"   Subs
•  Location Data
–  RaceTracker/<race>/Person/+
•  Live Analytics
–  RaceTracker/<race>/Person/+/text
–  RaceTracker/<race>/Marker/+/text
•  Course Data
–  RaceTracker/<race>/Marker/+ RaceTracker/<race>/Course
Viewer
Play time










bit.ly/IBMRaceTracker


14
What else is possible?
"   This is a simple messaging model (flows 1 direction)
•  “But WebSocket is bidirectional!”
"   Future Ideas:
•  Voice chat to runner
–  Audio encouragement
•  Augment runner app with live leaderboard
–  Google Glass = augmented reality race
–  “Arnaud Mathieu is 0.23 miles ahead of you!”
"   A decoupled application with MQTT allows for easy extension
and integration of new features
"   What else is possible?
15
Chatterbox

Chatterbox
"   Problem
•  Need scalable chat that works anywhere you are.
–  2G in the country, LTE in the city, Wifi at Impact!
–  Reliability is key
•  Need scalable chat that works on any device
–  Think desktop, mobile... wearable, etc.
"   Solution – “Chatterbox”
•  MQTT HTML5 ßà MQTT native iOS
•  Assured messaging with QoS
•  Text, picture, audio, video chat
"   Challenges
•  Cross-platform messaging (MQTT Paho clients!)
•  Constrained networks (MQTT durable subscriber!)

17
Scenario
18
Broker
Chatterbox
HTML5 - Desktop
Chatterbox
HTML5 - Mobile
Chatterbox
iOS
19
Web App / Native App (iOS)
•  All clients use same "Chatterbox" JSON API
"   Pubs
•  Room Data (retained)
–  chatterbox/Room/<room_id>
•  {
  "id":"IBMIMP5116",
  "name":"IBM
  Impact",
  "password":""
  }

•  Presence (retained)
–  chatterbox/Room/<room_id>/User/<uuid>
•  {
  "displayName":"Bryan
  Boyd",
  "color":"green",
  "uuid":<uuid>
  }
•  Chat Data
–  chatterbox/Room/<room_id>/Chat
•  {
  "name":"Bryan
  Boyd",
  "uuid":<uuid>,
  "format":"text",

"data":"Hello
  world!",
  "index":0,
  "max":1,
  "id":"b4ps8fjqgg",

"timestamp":1398875852255
  }
Chatterbox
20
"   Subs
•  Room Data (retained)
–  chatterbox/Room/+
•  Presence (retained)
–  chatterbox/Room/<room_id>/User/+
•  Chat Data
–  chatterbox/Room/<room_id>/Chat
Image / Audio / Video
•  Split, send as QoS 1, reconstruct message at subscribers




  {
  "name":"Bryan
  Boyd",
  "uuid":<uuid>,
  "id":"b4ps8fjqgg",
  "timestamp":
  ...







  "format":"data:audio/wav;base64",
  "index":1,"max":6,
  "data":"UklGriDAAQZa...





  "index":7,"max":17,
  "data":"whW+fd+JsGg...





  "format":"data:video/mp4;base64",
  "index":9,"max":31,
  "data":"8F/yzUBAQY...

Chatterbox
Play time








[see Arnaud for free tablets]
or
bit.ly/ibmchatterbox

(use Chrome, accept camera/microphone prompts)
21
What else is possible?
"   Even more collaboration
•  Broadcast streaming audio, video
•  Screen share, drawing
•  Record MQTT messages to “archive” a collaboration and play
back in real time
"   Integrate social media
•  Link twitter account
•  Type “:tweet: <chat>” to publish a tweet
"   What else is possible?
22
Starfighter
Starfighter
"   Problem
•  Quickly build a massively multiplayer game
•  Need low latency from client to client
•  To scale, we need to intelligently deliver the right data to the
right place at the right time
"   Solution – “Starfighter”
•  MMOG, IoT-style...
•  Every ship is a MQTT client
–  Humans: HTML5, Bots: Node.js
•  Every action is a message
–  Shoot / Move / Hit
•  Client-to-Broker-to-Client for low latency
"   Challenges
•  Data management (dynamic subscriptions!)
24
Scenario
25
Broker
Player
 AI Bot
 Viewer
BlueMix
BlueMix
Scoring
Mobile-ready App (HTML5)
26
"   Pubs
•  "Telemetry" – 16 msg/sec
–  starfighter/players/ship/<z>/<x>/<y>/<uuid>
{
  "uuid":"gqds2na46a","time":1398962284414,



  "name":"@bryanboyd","type":"ship",



  "worldPos":
  {"x":"10022.6","y":"2698.2"},



  "velocity":
  {"x":"0.1","y":"185.8"},
  "angle":"8.9",



  "shield":"1.0000",
  "status":"NORMAL",
  "score":0



  "lastHitTime":1398962247380,
  "lastUpdate":1398962261510
  }

•  Gunfire
–  starfighter/players/bullet/<z>/<x>/<y>/<uuid>
•  {
  "uuid":"gqds2na46a",
  "action":"shoot",
  "bullets":3
  }
•  Events
–  starfighter/players/event/<z>/<x>/<y>/<uuid>
•  {
  "uuid":"gqds2na46a",
  "name":"@bryanboyd",
  action:"hit",

"damage":0.03,
  "by":"u6xnd"
  }

•  {
  "uuid":"gqds2na46a",
  "name":"@bryanboyd",
  action:"destroyed",

"bonus":500,
  "by":"u6xnd"
  }
Mobile-ready App (HTML5)
27
"   Subs
•  "Telemetry"
–  starfighter/players/ship/<z>/<x>/<y>/+
•  Gunfire
–  starfighter/players/bullet/<z>/<x>/<y>/+
•  Events
–  starfighter/players/event/<z>/<x>/<y>/+
How does this scale? Not well.
-  10 players x 16 msgs/sec telemetry is okay
-  100 players x 16 msgs/sec telemetry is not
-  10000 players x 16 msgs/sec...
28
"   Idea:
•  Map ship x,y coord to a map region
•  Include region in the topic
•  Publish multiple feeds at different rates:
–  z = 0, 1 msg/sec
–  z = N, 2n msg/sec
...
–  z = 4, 16 msg/sec
–  Total = (2z_max – 1)
•  As your ship changes regions, change
the publishing topic
Location Topics
3210
1
2
3
0 1
0
1
0
0
z = 0
z = 1
z = 2
29
"   Idea
•  Which feeds do I need? (find z)
–  smallest map region that encompasses viewport
•  Where am I? (find x, y)
•  Subscribe to z/x/y and the
neighboring regions
•  As your ship changes regions,
subscribe to the new topics and
unsubscribe from the old
"   Benefits
•  Viewer just subscribes to z = 0, gets N msgs/sec
•  Player gets fine-grained data about neighboring players to draw
smoothly... no more "lag kills"
Dynamic Subscriptions
Hackathon-ready
"   To build an AI...
•  Pick a random position and vector
•  Publish telemetry, update position over time, and fire away
•  Subscribe to topics for local region
•  If a player gets within X dist, update vector to intercept
" Node.js bots in BlueMix
30
BlueMix
Play time
31








[see Arnaud for free tablets]
or
bit.ly/playstarfighter

optimized for Google Chrome
What else is possible?
"   Other scenarios:
•  Fleet management
–  Track vehicle movements and inventory in real time
–  Provide feeds of different granularity based on map region
•  Online gaming – poker, horse betting
–  Pub/sub is good for a gaming table, real-time race tracking,
assured messaging for placing bets
•  Collaboration
–  Many users can control and affect the same virtual space
"   What else is possible?
32
Takeaways
Takeaways
"   WebSockets – extending real-time communication to browsers
"   MQTT – scalable, reliable, fast messaging everywhere
•  Scalable – pub/sub, tiny headers
•  Reliable – quality of service for assured messaging
•  Fast – with the right broker, low latency at scale
•  Everywhere – Eclipse Paho clients


A great protocol needs a great broker...

34
IBM MessageSight
"   Secure messaging for Mobile and Internet of Things
•  MQTT Broker (TCP + WebSocket), JMS
"   Mobile engineered – very fast, reliable messaging
"   Massive scale – a million connections, millions of msgs/sec
"   Simple configuration – secure messaging topics and
endpoints with policies
35
Scaling with IBM MessageSight
"   1 million concurrent connections, millions of msgs/sec
"   What we can do:
•  RaceTracker
–  Track the Boston, NYC, and Chicago marathons at the same time
•  Chatterbox
–  Run low-latency, secure, on-premise chat for your entire enterprise
•  Starfighter
–  Thousands of players can collaborate simultaneously
–  Monitor and control tens of thousands of sensors

36
In conclusion...
37
"   WebSocket for bidirectional communication
"   MQTT for efficient mobile-to-mobile publish/subscribe
"   IBM MessageSight for scalability, security, and simplicity




With real-time, scalable mobile messaging...

what kind of compelling experiences can you create?
m2m.demos.ibm.com
Bryan Boyd
bboyd@us.ibm.com
@bryanboyd
Resources – m2m / IoT demos
References


"   Demo site: http://m2m.demos.ibm.com/
"   M2M Community
https://www.ibm.com/developerworks/community/blogs/c565c720-
fe84-4f63-873f-607d87787327/entry/mobile_messaging?lang=en
"   Download free virtual image for Development:
https://www.ibmdw.net/messaging/messagesight/
" MQTT.org: http://mqtt.org/
"   Eclipse Paho project: http://www.eclipse.org/paho/
"   IBM Messaging community:
http://www.ibm.com/developerworks/connect/IBMmessaging
"   IBM Messaging media:
http://www.youtube.com/user/IBMmessagingMedia?feature=watch
"   IBM MessageSight: http://www.ibm.com/messagesight
"   IBM and Sprint Velocity Drive Connected Car Into The Future:
http://www.ibm.com/press/us/en/pressrelease/41441.wss
Questions?
We Value Your Feedback
"   Don’t forget to submit your Impact session and speaker
feedback! Your feedback is very important to us – we use it to
continually improve the conference.
"   Use the Conference Mobile App or the online Agenda Builder to
quickly submit your survey
•  Navigate to “Surveys” to see a view of surveys for sessions
you’ve attended
41
Thank You
Legal Disclaimer
•  © IBM Corporation 2014. All Rights Reserved.
•  The information contained in this publication is provided for informational purposes only. While efforts were made to verify the completeness and accuracy of the information contained in
this publication, it is provided AS IS without warranty of any kind, express or implied. In addition, this information is based on IBM’s current product plans and strategy, which are subject
to change by IBM without notice. IBM shall not be responsible for any damages arising out of the use of, or otherwise related to, this publication or any other materials. Nothing
contained in this publication is intended to, nor shall have the effect of, creating any warranties or representations from IBM or its suppliers or licensors, or altering the terms and
conditions of the applicable license agreement governing the use of IBM software.
•  References in this presentation to IBM products, programs, or services do not imply that they will be available in all countries in which IBM operates. Product release dates and/or
capabilities referenced in this presentation may change at any time at IBM’s sole discretion based on market opportunities or other factors, and are not intended to be a commitment to
future product or feature availability in any way. Nothing contained in these materials is intended to, nor shall have the effect of, stating or implying that any activities undertaken by you
will result in any specific sales, revenue growth or other results.
•  If the text contains performance statistics or references to benchmarks, insert the following language; otherwise delete:
Performance is based on measurements and projections using standard IBM benchmarks in a controlled environment. The actual throughput or performance that any user will
experience will vary depending upon many factors, including considerations such as the amount of multiprogramming in the user's job stream, the I/O configuration, the storage
configuration, and the workload processed. Therefore, no assurance can be given that an individual user will achieve results similar to those stated here.
•  If the text includes any customer examples, please confirm we have prior written approval from such customer and insert the following language; otherwise delete:
All customer examples described are presented as illustrations of how those customers have used IBM products and the results they may have achieved. Actual environmental costs
and performance characteristics may vary by customer.
•  Please review text for proper trademark attribution of IBM products. At first use, each product name must be the full name and include appropriate trademark symbols (e.g., IBM Lotus®
Sametime® Unyte™). Subsequent references can drop “IBM” but should include the proper branding (e.g., Lotus Sametime Gateway, or WebSphere Application Server). Please refer
to http://www.ibm.com/legal/copytrade.shtml for guidance on which trademarks require the ® or ™ symbol. Do not use abbreviations for IBM product names in your presentation. All
product names must be used as adjectives rather than nouns. Please list all of the trademarks that you use in your presentation as follows; delete any not included in your presentation.
IBM, the IBM logo, Lotus, Lotus Notes, Notes, Domino, Quickr, Sametime, WebSphere, UC2, PartnerWorld and Lotusphere are trademarks of International Business Machines
Corporation in the United States, other countries, or both. Unyte is a trademark of WebDialogs, Inc., in the United States, other countries, or both.
•  If you reference Adobe® in the text, please mark the first use and include the following; otherwise delete:
Adobe, the Adobe logo, PostScript, and the PostScript logo are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States, and/or other countries.
•  If you reference Java™ in the text, please mark the first use and include the following; otherwise delete:
Java and all Java-based trademarks are trademarks of Sun Microsystems, Inc. in the United States, other countries, or both.
•  If you reference Microsoft® and/or Windows® in the text, please mark the first use and include the following, as applicable; otherwise delete:
Microsoft and Windows are trademarks of Microsoft Corporation in the United States, other countries, or both.
•  If you reference Intel® and/or any of the following Intel products in the text, please mark the first use and include those that you use as follows; otherwise delete:
Intel, Intel Centrino, Celeron, Intel Xeon, Intel SpeedStep, Itanium, and Pentium are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and
other countries.
•  If you reference UNIX® in the text, please mark the first use and include the following; otherwise delete:
UNIX is a registered trademark of The Open Group in the United States and other countries.
•  If you reference Linux® in your presentation, please mark the first use and include the following; otherwise delete:
Linux is a registered trademark of Linus Torvalds in the United States, other countries, or both. Other company, product, or service names may be trademarks or service marks of others.
•  If the text/graphics include screenshots, no actual IBM employee names may be used (even your own), if your screenshots include fictitious company names (e.g., Renovations, Zeta
Bank, Acme) please update and insert the following; otherwise delete: All references to [insert fictitious company name] refer to a fictitious company and are used for illustration
purposes only.

More Related Content

What's hot

Prometheus design and philosophy
Prometheus design and philosophy   Prometheus design and philosophy
Prometheus design and philosophy Docker, Inc.

Apache Kafka Architecture & Fundamentals Explained
Apache Kafka Architecture & Fundamentals ExplainedApache Kafka Architecture & Fundamentals Explained
Apache Kafka Architecture & Fundamentals Explainedconfluent

Apache Kafka in the Telco Industry (OSS, BSS, OTT, IMS, NFV, Middleware, Main...
Apache Kafka in the Telco Industry (OSS, BSS, OTT, IMS, NFV, Middleware, Main...Apache Kafka in the Telco Industry (OSS, BSS, OTT, IMS, NFV, Middleware, Main...
Apache Kafka in the Telco Industry (OSS, BSS, OTT, IMS, NFV, Middleware, Main...Kai Wähner

Introduction To RabbitMQ
Introduction To RabbitMQIntroduction To RabbitMQ
Introduction To RabbitMQKnoldus Inc.

The RabbitMQ Message Broker
The RabbitMQ Message BrokerThe RabbitMQ Message Broker
The RabbitMQ Message BrokerMartin Toshev

Custom DevOps Monitoring System in MelOn (with InfluxDB + Telegraf + Grafana)
Custom DevOps Monitoring System in MelOn (with InfluxDB + Telegraf + Grafana)Custom DevOps Monitoring System in MelOn (with InfluxDB + Telegraf + Grafana)
Custom DevOps Monitoring System in MelOn (with InfluxDB + Telegraf + Grafana)Seungmin Yu

Monitoring With Prometheus
Monitoring With PrometheusMonitoring With Prometheus
Monitoring With PrometheusKnoldus Inc.

Azure as a Chatbot Service: From Purpose To Production With A Cloud Bot Archi...
Azure as a Chatbot Service: From Purpose To Production With A Cloud Bot Archi...Azure as a Chatbot Service: From Purpose To Production With A Cloud Bot Archi...
Azure as a Chatbot Service: From Purpose To Production With A Cloud Bot Archi...Paul Prae

Spring Framework Petclinic sample application
Spring Framework Petclinic sample applicationSpring Framework Petclinic sample application
Spring Framework Petclinic sample applicationAntoine Rey

Highlights of WSO2 API Manager 4.0.0
Highlights of WSO2 API Manager 4.0.0Highlights of WSO2 API Manager 4.0.0
Highlights of WSO2 API Manager 4.0.0WSO2

API Management Within a Microservices Architecture
API Management Within a Microservices Architecture API Management Within a Microservices Architecture
API Management Within a Microservices Architecture Nadeesha Gamage

API Security Best Practices & Guidelines
API Security Best Practices & GuidelinesAPI Security Best Practices & Guidelines
API Security Best Practices & GuidelinesPrabath Siriwardena

Designing APIs with OpenAPI Spec
Designing APIs with OpenAPI SpecDesigning APIs with OpenAPI Spec
Designing APIs with OpenAPI SpecAdam Paxton


What's hot (20)

Prometheus design and philosophy
Prometheus design and philosophy   Prometheus design and philosophy
Prometheus design and philosophy

Apache Kafka Architecture & Fundamentals Explained
Apache Kafka Architecture & Fundamentals ExplainedApache Kafka Architecture & Fundamentals Explained
Apache Kafka Architecture & Fundamentals Explained

Apache Kafka in the Telco Industry (OSS, BSS, OTT, IMS, NFV, Middleware, Main...
Apache Kafka in the Telco Industry (OSS, BSS, OTT, IMS, NFV, Middleware, Main...Apache Kafka in the Telco Industry (OSS, BSS, OTT, IMS, NFV, Middleware, Main...
Apache Kafka in the Telco Industry (OSS, BSS, OTT, IMS, NFV, Middleware, Main...

Introduction To RabbitMQ
Introduction To RabbitMQIntroduction To RabbitMQ
Introduction To RabbitMQ

How to Send IDOC to SAP using MuleSoft
How to Send IDOC to SAP using MuleSoftHow to Send IDOC to SAP using MuleSoft
How to Send IDOC to SAP using MuleSoft

Prometheus 101
Prometheus 101Prometheus 101
Prometheus 101

Siddhi - cloud-native stream processor
Siddhi - cloud-native stream processorSiddhi - cloud-native stream processor
Siddhi - cloud-native stream processor

The RabbitMQ Message Broker
The RabbitMQ Message BrokerThe RabbitMQ Message Broker
The RabbitMQ Message Broker

Custom DevOps Monitoring System in MelOn (with InfluxDB + Telegraf + Grafana)
Custom DevOps Monitoring System in MelOn (with InfluxDB + Telegraf + Grafana)Custom DevOps Monitoring System in MelOn (with InfluxDB + Telegraf + Grafana)
Custom DevOps Monitoring System in MelOn (with InfluxDB + Telegraf + Grafana)

Apigee Demo: API Platform Overview
Apigee Demo: API Platform OverviewApigee Demo: API Platform Overview
Apigee Demo: API Platform Overview

Monitoring With Prometheus
Monitoring With PrometheusMonitoring With Prometheus
Monitoring With Prometheus

Spring Cloud Gateway
Spring Cloud GatewaySpring Cloud Gateway
Spring Cloud Gateway

Azure as a Chatbot Service: From Purpose To Production With A Cloud Bot Archi...
Azure as a Chatbot Service: From Purpose To Production With A Cloud Bot Archi...Azure as a Chatbot Service: From Purpose To Production With A Cloud Bot Archi...
Azure as a Chatbot Service: From Purpose To Production With A Cloud Bot Archi...

Spring Framework Petclinic sample application
Spring Framework Petclinic sample applicationSpring Framework Petclinic sample application
Spring Framework Petclinic sample application

Highlights of WSO2 API Manager 4.0.0
Highlights of WSO2 API Manager 4.0.0Highlights of WSO2 API Manager 4.0.0
Highlights of WSO2 API Manager 4.0.0

API Management Within a Microservices Architecture
API Management Within a Microservices Architecture API Management Within a Microservices Architecture
API Management Within a Microservices Architecture

Message Broker System and RabbitMQ
Message Broker System and RabbitMQMessage Broker System and RabbitMQ
Message Broker System and RabbitMQ

RabbitMQ.ppt
RabbitMQ.pptRabbitMQ.ppt
RabbitMQ.ppt

API Security Best Practices & Guidelines
API Security Best Practices & GuidelinesAPI Security Best Practices & Guidelines
API Security Best Practices & Guidelines

Designing APIs with OpenAPI Spec
Designing APIs with OpenAPI SpecDesigning APIs with OpenAPI Spec
Designing APIs with OpenAPI Spec


Viewers also liked

Low Latency Mobile Messaging using MQTT
Low Latency Mobile Messaging using MQTTLow Latency Mobile Messaging using MQTT
Low Latency Mobile Messaging using MQTTHenrik Sjöstrand

MQTT - A practical protocol for the Internet of Things
MQTT - A practical protocol for the Internet of ThingsMQTT - A practical protocol for the Internet of Things
MQTT - A practical protocol for the Internet of ThingsBryan Boyd

Windows 7 Kynning
Windows 7 KynningWindows 7 Kynning
Windows 7 KynningW7ISL

Contextual Retail Engagement and Operations Enabled through MQTT, IBM Bluemix...
Contextual Retail Engagement and Operations Enabled through MQTT, IBM Bluemix...Contextual Retail Engagement and Operations Enabled through MQTT, IBM Bluemix...
Contextual Retail Engagement and Operations Enabled through MQTT, IBM Bluemix...Rahul Gupta

Spring Boot & WebSocket
Spring Boot & WebSocketSpring Boot & WebSocket
Spring Boot & WebSocketMing-Ying Wu

Connecting Devices to the IBM IoT via MQTT - Session 1231 @IBMInsight2015
Connecting Devices to the IBM IoT via MQTT - Session 1231 @IBMInsight2015Connecting Devices to the IBM IoT via MQTT - Session 1231 @IBMInsight2015
Connecting Devices to the IBM IoT via MQTT - Session 1231 @IBMInsight2015Markus Van Kempen

Passive infrared sensor technology(pir)
Passive infrared sensor technology(pir)Passive infrared sensor technology(pir)
Passive infrared sensor technology(pir)Umar Shuaib

Cassiopeia Ltd - ESP8266+Arduino workshop
Cassiopeia Ltd - ESP8266+Arduino workshopCassiopeia Ltd - ESP8266+Arduino workshop
Cassiopeia Ltd - ESP8266+Arduino workshoptomtobback

ULTRASONIC
ULTRASONICULTRASONIC
ULTRASONICpraeye

ESP8266 and IOT
ESP8266 and IOTESP8266 and IOT
ESP8266 and IOTdega1999

CoAP Course for m2m and Internet of Things scenarios
CoAP Course for m2m and Internet of Things scenariosCoAP Course for m2m and Internet of Things scenarios
CoAP Course for m2m and Internet of Things scenarioscarlosralli

NodeMCU ESP8266 workshop 1
NodeMCU ESP8266 workshop 1NodeMCU ESP8266 workshop 1
NodeMCU ESP8266 workshop 1Andy Gelme

Energy saving using pir sensor
Energy saving using pir sensorEnergy saving using pir sensor
Energy saving using pir sensorHimani Harbola

Real Time Vehicle Monitoring Using Raspberry Pi
Real Time Vehicle Monitoring Using Raspberry Pi Real Time Vehicle Monitoring Using Raspberry Pi
Real Time Vehicle Monitoring Using Raspberry Pi Albin George

Distance Measurement by Ultrasonic Sensor
Distance Measurement by Ultrasonic SensorDistance Measurement by Ultrasonic Sensor
Distance Measurement by Ultrasonic SensorEdgefxkits & Solutions

Internet of things using Raspberry Pi
Internet of things using Raspberry PiInternet of things using Raspberry Pi
Internet of things using Raspberry PiYash Gajera

SOC presentation- Building a Security Operations Center
SOC presentation- Building a Security Operations CenterSOC presentation- Building a Security Operations Center
SOC presentation- Building a Security Operations CenterMichael Nickle

Ultrasonic based distance measurement system
Ultrasonic based distance measurement systemUltrasonic based distance measurement system
Ultrasonic based distance measurement systemMrinal Sharma


Viewers also liked (20)

Low Latency Mobile Messaging using MQTT
Low Latency Mobile Messaging using MQTTLow Latency Mobile Messaging using MQTT
Low Latency Mobile Messaging using MQTT

MQTT - A practical protocol for the Internet of Things
MQTT - A practical protocol for the Internet of ThingsMQTT - A practical protocol for the Internet of Things
MQTT - A practical protocol for the Internet of Things

Windows 7 Kynning
Windows 7 KynningWindows 7 Kynning
Windows 7 Kynning

Contextual Retail Engagement and Operations Enabled through MQTT, IBM Bluemix...
Contextual Retail Engagement and Operations Enabled through MQTT, IBM Bluemix...Contextual Retail Engagement and Operations Enabled through MQTT, IBM Bluemix...
Contextual Retail Engagement and Operations Enabled through MQTT, IBM Bluemix...

Spring Boot & WebSocket
Spring Boot & WebSocketSpring Boot & WebSocket
Spring Boot & WebSocket

Connecting Devices to the IBM IoT via MQTT - Session 1231 @IBMInsight2015
Connecting Devices to the IBM IoT via MQTT - Session 1231 @IBMInsight2015Connecting Devices to the IBM IoT via MQTT - Session 1231 @IBMInsight2015
Connecting Devices to the IBM IoT via MQTT - Session 1231 @IBMInsight2015

Spark
SparkSpark
Spark

Passive infrared sensor technology(pir)
Passive infrared sensor technology(pir)Passive infrared sensor technology(pir)
Passive infrared sensor technology(pir)

Cassiopeia Ltd - ESP8266+Arduino workshop
Cassiopeia Ltd - ESP8266+Arduino workshopCassiopeia Ltd - ESP8266+Arduino workshop
Cassiopeia Ltd - ESP8266+Arduino workshop

ULTRASONIC
ULTRASONICULTRASONIC
ULTRASONIC

ESP8266 and IOT
ESP8266 and IOTESP8266 and IOT
ESP8266 and IOT

CoAP Course for m2m and Internet of Things scenarios
CoAP Course for m2m and Internet of Things scenariosCoAP Course for m2m and Internet of Things scenarios
CoAP Course for m2m and Internet of Things scenarios

NodeMCU ESP8266 workshop 1
NodeMCU ESP8266 workshop 1NodeMCU ESP8266 workshop 1
NodeMCU ESP8266 workshop 1

Energy saving using pir sensor
Energy saving using pir sensorEnergy saving using pir sensor
Energy saving using pir sensor

Real Time Vehicle Monitoring Using Raspberry Pi
Real Time Vehicle Monitoring Using Raspberry Pi Real Time Vehicle Monitoring Using Raspberry Pi
Real Time Vehicle Monitoring Using Raspberry Pi

Enterprise, Architecture and IoT
Enterprise, Architecture and IoTEnterprise, Architecture and IoT
Enterprise, Architecture and IoT

Distance Measurement by Ultrasonic Sensor
Distance Measurement by Ultrasonic SensorDistance Measurement by Ultrasonic Sensor
Distance Measurement by Ultrasonic Sensor

Internet of things using Raspberry Pi
Internet of things using Raspberry PiInternet of things using Raspberry Pi
Internet of things using Raspberry Pi

SOC presentation- Building a Security Operations Center
SOC presentation- Building a Security Operations CenterSOC presentation- Building a Security Operations Center
SOC presentation- Building a Security Operations Center

Ultrasonic based distance measurement system
Ultrasonic based distance measurement systemUltrasonic based distance measurement system
Ultrasonic based distance measurement system


Similar to Dynamic Apps with WebSockets and MQTT - IBM Impact 2014

MongoDB In Production At Sailthru
MongoDB In Production At SailthruMongoDB In Production At Sailthru
MongoDB In Production At Sailthruibwhite

Mongo at Sailthru (MongoNYC 2011)
Mongo at Sailthru (MongoNYC 2011)Mongo at Sailthru (MongoNYC 2011)
Mongo at Sailthru (MongoNYC 2011)ibwhite

Building and Scaling the Internet of Things with MongoDB at Vivint
Building and Scaling the Internet of Things with MongoDB at Vivint Building and Scaling the Internet of Things with MongoDB at Vivint
Building and Scaling the Internet of Things with MongoDB at Vivint MongoDB

7° Sessione - L’intelligenza artificiale a supporto della ricerca, servizi di...
7° Sessione - L’intelligenza artificiale a supporto della ricerca, servizi di...7° Sessione - L’intelligenza artificiale a supporto della ricerca, servizi di...
7° Sessione - L’intelligenza artificiale a supporto della ricerca, servizi di...Jürgen Ambrosi

Online games: a real-time problem for the network
Online games: a real-time problem for the networkOnline games: a real-time problem for the network
Online games: a real-time problem for the networkJose Saldana

Mobile Web Development with HTML5
Mobile Web Development with HTML5Mobile Web Development with HTML5
Mobile Web Development with HTML5Roy Clarkson

Android slides
Android slidesAndroid slides
Android slidesaazimmolvi

Mobile Interfaces to Mainframe Applications - Architecture Considerations
Mobile Interfaces to Mainframe Applications - Architecture ConsiderationsMobile Interfaces to Mainframe Applications - Architecture Considerations
Mobile Interfaces to Mainframe Applications - Architecture ConsiderationsVirtel - SysperTec

Building the IOT Platform as a Service
Building the IOT Platform as a ServiceBuilding the IOT Platform as a Service
Building the IOT Platform as a ServiceJesus Rodriguez

OpenStack Folsom Summit: Melange overview
OpenStack Folsom Summit: Melange overviewOpenStack Folsom Summit: Melange overview
OpenStack Folsom Summit: Melange overviewtroytoman

Comunicando nuestras apps con el mundo exterior
Comunicando nuestras apps con el mundo exteriorComunicando nuestras apps con el mundo exterior
Comunicando nuestras apps con el mundo exteriorRoberto Luis Bisbé

Cracking the nut, solving edge ai with apache tools and frameworks
Cracking the nut, solving edge ai with apache tools and frameworksCracking the nut, solving edge ai with apache tools and frameworks
Cracking the nut, solving edge ai with apache tools and frameworksTimothy Spann

Microsoft Io TechCamp Frankfurt am Main 2015
Microsoft Io TechCamp Frankfurt am Main 2015Microsoft Io TechCamp Frankfurt am Main 2015
Microsoft Io TechCamp Frankfurt am Main 2015Damir Dobric

Nodejs and WebSockets
Nodejs and WebSocketsNodejs and WebSockets
Nodejs and WebSocketsGonzalo Ayuso

Breaking through silos - From multi to true crossplatform using the cloud
Breaking through silos - From multi to true crossplatform using the cloudBreaking through silos - From multi to true crossplatform using the cloud
Breaking through silos - From multi to true crossplatform using the cloudChristof Wegmann


Similar to Dynamic Apps with WebSockets and MQTT - IBM Impact 2014 (20)

MongoDB In Production At Sailthru
MongoDB In Production At SailthruMongoDB In Production At Sailthru
MongoDB In Production At Sailthru

Mongo at Sailthru (MongoNYC 2011)
Mongo at Sailthru (MongoNYC 2011)Mongo at Sailthru (MongoNYC 2011)
Mongo at Sailthru (MongoNYC 2011)

Building and Scaling the Internet of Things with MongoDB at Vivint
Building and Scaling the Internet of Things with MongoDB at Vivint Building and Scaling the Internet of Things with MongoDB at Vivint
Building and Scaling the Internet of Things with MongoDB at Vivint

7° Sessione - L’intelligenza artificiale a supporto della ricerca, servizi di...
7° Sessione - L’intelligenza artificiale a supporto della ricerca, servizi di...7° Sessione - L’intelligenza artificiale a supporto della ricerca, servizi di...
7° Sessione - L’intelligenza artificiale a supporto della ricerca, servizi di...

Online games: a real-time problem for the network
Online games: a real-time problem for the networkOnline games: a real-time problem for the network
Online games: a real-time problem for the network

Coding serbia
Coding serbiaCoding serbia
Coding serbia

Mobile Web Development with HTML5
Mobile Web Development with HTML5Mobile Web Development with HTML5
Mobile Web Development with HTML5

Android slides
Android slidesAndroid slides
Android slides

Android slides
Android slidesAndroid slides
Android slides

Android slides
Android slidesAndroid slides
Android slides

Android slides
Android slidesAndroid slides
Android slides

Mobile Interfaces to Mainframe Applications - Architecture Considerations
Mobile Interfaces to Mainframe Applications - Architecture ConsiderationsMobile Interfaces to Mainframe Applications - Architecture Considerations
Mobile Interfaces to Mainframe Applications - Architecture Considerations

Building the IOT Platform as a Service
Building the IOT Platform as a ServiceBuilding the IOT Platform as a Service
Building the IOT Platform as a Service

OpenStack Folsom Summit: Melange overview
OpenStack Folsom Summit: Melange overviewOpenStack Folsom Summit: Melange overview
OpenStack Folsom Summit: Melange overview

Comunicando nuestras apps con el mundo exterior
Comunicando nuestras apps con el mundo exteriorComunicando nuestras apps con el mundo exterior
Comunicando nuestras apps con el mundo exterior

Cracking the nut, solving edge ai with apache tools and frameworks
Cracking the nut, solving edge ai with apache tools and frameworksCracking the nut, solving edge ai with apache tools and frameworks
Cracking the nut, solving edge ai with apache tools and frameworks

Microsoft Io TechCamp Frankfurt am Main 2015
Microsoft Io TechCamp Frankfurt am Main 2015Microsoft Io TechCamp Frankfurt am Main 2015
Microsoft Io TechCamp Frankfurt am Main 2015

Android..imp google
Android..imp googleAndroid..imp google
Android..imp google

Nodejs and WebSockets
Nodejs and WebSocketsNodejs and WebSockets
Nodejs and WebSockets

Breaking through silos - From multi to true crossplatform using the cloud
Breaking through silos - From multi to true crossplatform using the cloudBreaking through silos - From multi to true crossplatform using the cloud
Breaking through silos - From multi to true crossplatform using the cloud


Recently uploaded

Cyaniclab : Software Development Agency Portfolio.pdf
Cyaniclab : Software Development Agency Portfolio.pdfCyaniclab : Software Development Agency Portfolio.pdf
Cyaniclab : Software Development Agency Portfolio.pdfCyanic lab

Field Employee Tracking System| MiTrack App| Best Employee Tracking Solution|...
Field Employee Tracking System| MiTrack App| Best Employee Tracking Solution|...Field Employee Tracking System| MiTrack App| Best Employee Tracking Solution|...
Field Employee Tracking System| MiTrack App| Best Employee Tracking Solution|...informapgpstrackings

Facemoji Keyboard released its 2023 State of Emoji report, outlining the most...
Facemoji Keyboard released its 2023 State of Emoji report, outlining the most...Facemoji Keyboard released its 2023 State of Emoji report, outlining the most...
Facemoji Keyboard released its 2023 State of Emoji report, outlining the most...rajkumar669520

Designing for Privacy in Amazon Web Services
Designing for Privacy in Amazon Web ServicesDesigning for Privacy in Amazon Web Services
Designing for Privacy in Amazon Web ServicesKrzysztofKkol1

iGaming Platform & Lottery Solutions by Skilrock
iGaming Platform & Lottery Solutions by SkilrockiGaming Platform & Lottery Solutions by Skilrock
iGaming Platform & Lottery Solutions by SkilrockSkilrock Technologies

De mooiste recreatieve routes ontdekken met RouteYou en FME
De mooiste recreatieve routes ontdekken met RouteYou en FMEDe mooiste recreatieve routes ontdekken met RouteYou en FME
De mooiste recreatieve routes ontdekken met RouteYou en FMEJelle | Nordend

TROUBLESHOOTING 9 TYPES OF OUTOFMEMORYERROR
TROUBLESHOOTING 9 TYPES OF OUTOFMEMORYERRORTROUBLESHOOTING 9 TYPES OF OUTOFMEMORYERROR
TROUBLESHOOTING 9 TYPES OF OUTOFMEMORYERRORTier1 app

Crafting the Perfect Measurement Sheet with PLM Integration
Crafting the Perfect Measurement Sheet with PLM IntegrationCrafting the Perfect Measurement Sheet with PLM Integration
Crafting the Perfect Measurement Sheet with PLM IntegrationWave PLM

Beyond Event Sourcing - Embracing CRUD for Wix Platform - Java.IL
Beyond Event Sourcing - Embracing CRUD for Wix Platform - Java.ILBeyond Event Sourcing - Embracing CRUD for Wix Platform - Java.IL
Beyond Event Sourcing - Embracing CRUD for Wix Platform - Java.ILNatan Silnitsky

Abortion ^Clinic ^%[+971588192166''] Abortion Pill Al Ain (?@?) Abortion Pill...
Abortion ^Clinic ^%[+971588192166''] Abortion Pill Al Ain (?@?) Abortion Pill...Abortion ^Clinic ^%[+971588192166''] Abortion Pill Al Ain (?@?) Abortion Pill...
Abortion ^Clinic ^%[+971588192166''] Abortion Pill Al Ain (?@?) Abortion Pill...Abortion Clinic

OpenFOAM solver for Helmholtz equation, helmholtzFoam / helmholtzBubbleFoam
OpenFOAM solver for Helmholtz equation, helmholtzFoam / helmholtzBubbleFoamOpenFOAM solver for Helmholtz equation, helmholtzFoam / helmholtzBubbleFoam
OpenFOAM solver for Helmholtz equation, helmholtzFoam / helmholtzBubbleFoamtakuyayamamoto1800

A Python-based approach to data loading in TM1 - Using Airflow as an ETL for TM1
A Python-based approach to data loading in TM1 - Using Airflow as an ETL for TM1A Python-based approach to data loading in TM1 - Using Airflow as an ETL for TM1
A Python-based approach to data loading in TM1 - Using Airflow as an ETL for TM1KnowledgeSeed

How Does XfilesPro Ensure Security While Sharing Documents in Salesforce?
How Does XfilesPro Ensure Security While Sharing Documents in Salesforce?How Does XfilesPro Ensure Security While Sharing Documents in Salesforce?
How Does XfilesPro Ensure Security While Sharing Documents in Salesforce?XfilesPro

Into the Box 2024 - Keynote Day 2 Slides.pdf
Into the Box 2024 - Keynote Day 2 Slides.pdfInto the Box 2024 - Keynote Day 2 Slides.pdf
Into the Box 2024 - Keynote Day 2 Slides.pdfOrtus Solutions, Corp

Breaking the Code : A Guide to WhatsApp Business API.pdf
Breaking the Code : A Guide to WhatsApp Business API.pdfBreaking the Code : A Guide to WhatsApp Business API.pdf
Breaking the Code : A Guide to WhatsApp Business API.pdfMeon Technology

Prosigns: Transforming Business with Tailored Technology Solutions
Prosigns: Transforming Business with Tailored Technology SolutionsProsigns: Transforming Business with Tailored Technology Solutions
Prosigns: Transforming Business with Tailored Technology SolutionsProsigns

Gamify Your Mind; The Secret Sauce to Delivering Success, Continuously Improv...
Gamify Your Mind; The Secret Sauce to Delivering Success, Continuously Improv...Gamify Your Mind; The Secret Sauce to Delivering Success, Continuously Improv...
Gamify Your Mind; The Secret Sauce to Delivering Success, Continuously Improv...Shahin Sheidaei

Paketo Buildpacks : la meilleure façon de construire des images OCI? DevopsDa...
Paketo Buildpacks : la meilleure façon de construire des images OCI? DevopsDa...Paketo Buildpacks : la meilleure façon de construire des images OCI? DevopsDa...
Paketo Buildpacks : la meilleure façon de construire des images OCI? DevopsDa...Anthony Dahanne

SOCRadar Research Team: Latest Activities of IntelBroker
SOCRadar Research Team: Latest Activities of IntelBrokerSOCRadar Research Team: Latest Activities of IntelBroker
SOCRadar Research Team: Latest Activities of IntelBrokerSOCRadar

top nidhi software solution freedownload
top nidhi software solution freedownloadtop nidhi software solution freedownload
top nidhi software solution freedownloadvrstrong314


Recently uploaded (20)

Cyaniclab : Software Development Agency Portfolio.pdf
Cyaniclab : Software Development Agency Portfolio.pdfCyaniclab : Software Development Agency Portfolio.pdf
Cyaniclab : Software Development Agency Portfolio.pdf

Field Employee Tracking System| MiTrack App| Best Employee Tracking Solution|...
Field Employee Tracking System| MiTrack App| Best Employee Tracking Solution|...Field Employee Tracking System| MiTrack App| Best Employee Tracking Solution|...
Field Employee Tracking System| MiTrack App| Best Employee Tracking Solution|...

Facemoji Keyboard released its 2023 State of Emoji report, outlining the most...
Facemoji Keyboard released its 2023 State of Emoji report, outlining the most...Facemoji Keyboard released its 2023 State of Emoji report, outlining the most...
Facemoji Keyboard released its 2023 State of Emoji report, outlining the most...

Designing for Privacy in Amazon Web Services
Designing for Privacy in Amazon Web ServicesDesigning for Privacy in Amazon Web Services
Designing for Privacy in Amazon Web Services

iGaming Platform & Lottery Solutions by Skilrock
iGaming Platform & Lottery Solutions by SkilrockiGaming Platform & Lottery Solutions by Skilrock
iGaming Platform & Lottery Solutions by Skilrock

De mooiste recreatieve routes ontdekken met RouteYou en FME
De mooiste recreatieve routes ontdekken met RouteYou en FMEDe mooiste recreatieve routes ontdekken met RouteYou en FME
De mooiste recreatieve routes ontdekken met RouteYou en FME

TROUBLESHOOTING 9 TYPES OF OUTOFMEMORYERROR
TROUBLESHOOTING 9 TYPES OF OUTOFMEMORYERRORTROUBLESHOOTING 9 TYPES OF OUTOFMEMORYERROR
TROUBLESHOOTING 9 TYPES OF OUTOFMEMORYERROR

Crafting the Perfect Measurement Sheet with PLM Integration
Crafting the Perfect Measurement Sheet with PLM IntegrationCrafting the Perfect Measurement Sheet with PLM Integration
Crafting the Perfect Measurement Sheet with PLM Integration

Beyond Event Sourcing - Embracing CRUD for Wix Platform - Java.IL
Beyond Event Sourcing - Embracing CRUD for Wix Platform - Java.ILBeyond Event Sourcing - Embracing CRUD for Wix Platform - Java.IL
Beyond Event Sourcing - Embracing CRUD for Wix Platform - Java.IL

Abortion ^Clinic ^%[+971588192166''] Abortion Pill Al Ain (?@?) Abortion Pill...
Abortion ^Clinic ^%[+971588192166''] Abortion Pill Al Ain (?@?) Abortion Pill...Abortion ^Clinic ^%[+971588192166''] Abortion Pill Al Ain (?@?) Abortion Pill...
Abortion ^Clinic ^%[+971588192166''] Abortion Pill Al Ain (?@?) Abortion Pill...

OpenFOAM solver for Helmholtz equation, helmholtzFoam / helmholtzBubbleFoam
OpenFOAM solver for Helmholtz equation, helmholtzFoam / helmholtzBubbleFoamOpenFOAM solver for Helmholtz equation, helmholtzFoam / helmholtzBubbleFoam
OpenFOAM solver for Helmholtz equation, helmholtzFoam / helmholtzBubbleFoam

A Python-based approach to data loading in TM1 - Using Airflow as an ETL for TM1
A Python-based approach to data loading in TM1 - Using Airflow as an ETL for TM1A Python-based approach to data loading in TM1 - Using Airflow as an ETL for TM1
A Python-based approach to data loading in TM1 - Using Airflow as an ETL for TM1

How Does XfilesPro Ensure Security While Sharing Documents in Salesforce?
How Does XfilesPro Ensure Security While Sharing Documents in Salesforce?How Does XfilesPro Ensure Security While Sharing Documents in Salesforce?
How Does XfilesPro Ensure Security While Sharing Documents in Salesforce?

Into the Box 2024 - Keynote Day 2 Slides.pdf
Into the Box 2024 - Keynote Day 2 Slides.pdfInto the Box 2024 - Keynote Day 2 Slides.pdf
Into the Box 2024 - Keynote Day 2 Slides.pdf

Breaking the Code : A Guide to WhatsApp Business API.pdf
Breaking the Code : A Guide to WhatsApp Business API.pdfBreaking the Code : A Guide to WhatsApp Business API.pdf
Breaking the Code : A Guide to WhatsApp Business API.pdf

Prosigns: Transforming Business with Tailored Technology Solutions
Prosigns: Transforming Business with Tailored Technology SolutionsProsigns: Transforming Business with Tailored Technology Solutions
Prosigns: Transforming Business with Tailored Technology Solutions

Gamify Your Mind; The Secret Sauce to Delivering Success, Continuously Improv...
Gamify Your Mind; The Secret Sauce to Delivering Success, Continuously Improv...Gamify Your Mind; The Secret Sauce to Delivering Success, Continuously Improv...
Gamify Your Mind; The Secret Sauce to Delivering Success, Continuously Improv...

Paketo Buildpacks : la meilleure façon de construire des images OCI? DevopsDa...
Paketo Buildpacks : la meilleure façon de construire des images OCI? DevopsDa...Paketo Buildpacks : la meilleure façon de construire des images OCI? DevopsDa...
Paketo Buildpacks : la meilleure façon de construire des images OCI? DevopsDa...

SOCRadar Research Team: Latest Activities of IntelBroker
SOCRadar Research Team: Latest Activities of IntelBrokerSOCRadar Research Team: Latest Activities of IntelBroker
SOCRadar Research Team: Latest Activities of IntelBroker

top nidhi software solution freedownload
top nidhi software solution freedownloadtop nidhi software solution freedownload
top nidhi software solution freedownload


Dynamic Apps with WebSockets and MQTT - IBM Impact 2014

  • 1. © 2014 IBM Corporation Dynamic Mobile Apps with WebSockets and MQTT
  • 2. The Compelling Experience What makes an application a delight to use? -  Data arrives when you need it, not when you ask for it -  The app provides a collaborative, social experience -  Services are integrated seamlessly together 1
  • 3. HTML5 WebSocket for Real-time “A conversation on the web” "   WebSocket is bidirectional •  HTTP is request/response, WebSocket is a conversation "   WebSocket is an HTML5 standard •  Cross-domain communication •  Supported by all major browsers 2 http://caniuse.com/websockets
  • 4. MQTT for Mobile Messaging "   What is it? •  Publish/subscribe messaging protocol designed for mobile and telemetry devices •  Open (royalty-free), simple, lightweight, easy to implement •  Allows for decoupled applications (“Internet of Things”) •  Quality of service for assured message delivery •  MQTT clients connect to an MQTT broker "   Where is it? •  Connected vehicles (ex. Sprint Velocity) •  Connected cities (ex. NYPD ESU) •  Connected people (ex. Facebook Messenger) •  ...and everywhere else 3
  • 5. Why MQTT? "   Publish/subscribe messaging •  Transmit information one to many •  Subscribe to interesting topics •  Distribute small data packets in huge volumes "   Quality of Service (QoS) for assured messaging •  “At most once”, “At least once”, “Exactly once” "   Simple API •  3 verbs: Connect, Publish, Subscribe (+ Receive) •  Useful features: Last Will and Testament, Retain •  Clients everywhere (40+) –  JavaScript, C, C++, Python, Node.js, Java, Ruby, etc. "   Lightweight •  2-byte header, low latency •  Mobile (LTE) = ~100ms, Browser (Wifi) = ~50ms (RTT) 4
  • 6. Quick Demo – Whiteboard bit.ly/impactwb 5
  • 7. Compelling Experience "   Real-time Monitoring (RaceTracker)" "   Scalable Group Chat (Chatterbox)" "   Cross-platform MMOG (Starfighter)! "Agenda (for each demo)" 1.  Problem" 2.  Scenario / Architecture" 3.  Messaging design" 4.  Play time" 5.  "What else is possible?"" 6 Fire up your laptops!
  • 9. RaceTracker "   Problem – Marathons are crowded •  Me: “Meet me at mile 17.3 with Gatorade around... 9:00-9:30” •  Wife: “...could you be more specific?” "   Solution – “RaceTracker” 1.  Publish location from iPhone 2.  Calculate speed/stats in real time 3.  Display runner info in a mobile app 4.  Live-tweet the race "   Challenges •  Network congestion (QoS!) •  Wiring applications (pub/sub!) 8
  • 11. 10 OwnTracks (iOS / Android) •  Open-source "location diary" •  Publishes MQTT location data at interval •  http://owntracks.org "   Pubs •  Location Data (retained) –  RaceTracker/<race>/Person/<runner> •  {  "_type":"location","tst":"1392569738",   "lat":"30.3019","lon":"-­‐97.7278",  "batt":"30","acc":"5"}   "   Subs •  [nothing] Runner
  • 12. 11 Node.js runtime in BlueMix •  Performs speed calculations on runner data, maintains course state, outputs events ("runner X crossed mile 5") "   Pubs •  Course Data (retained) –  RaceTracker/<race>/Marker/<type> •  {  "id":"start",  "lon":30.30214,  "lat":-­‐97.77801  }   –  RaceTracker/<race>/Marker/<type>/text •  {  "text":"Crossed  at  7:38  AM  with  a  split  of  8:28"  }   –  RaceTracker/<race>/Course •  "-­‐97.73911714,30.277803  &  -­‐979780987,30.28985  &  <lon>,<lat>  &"   •  Events (QoS 2) –  RaceTracker/<race>/Person/<runner>/event •  {  "type":"split",  "splitTime":"10:42:13",  "splitMarker":"mile  2",   "splitString":"9:45"  }   •  {  "type":"finish",  "time":"11:43:13",  "totalTime":"4:15:13"  }   Analytics
  • 13. Analytics 12 "   Pubs (cont.) •  Live Analytics (retained) –  RaceTracker/<race>/Person/<runner>/text •  {  "text":  "Pace:  (about)  9:18  min/mile"  }   "   Subs •  Location Data –  RaceTracker/<race>/Person/+ •  {  "_type":"location","tst":"1392569738",   "lat":"30.3019","lon":"-­‐97.7278",  "batt":"30","acc":"5"}   Analytics
  • 14. 13 HTML5 Map UI •  Course data, analytics, and runners are displayed on a map and updated in real-time through MQTT over WebSockets •  Uses OpenLayers JavaScript library with ESRI imagery "   Pubs   •  [Nothing] "   Subs •  Location Data –  RaceTracker/<race>/Person/+ •  Live Analytics –  RaceTracker/<race>/Person/+/text –  RaceTracker/<race>/Marker/+/text •  Course Data –  RaceTracker/<race>/Marker/+ RaceTracker/<race>/Course Viewer
  • 16. What else is possible? "   This is a simple messaging model (flows 1 direction) •  “But WebSocket is bidirectional!” "   Future Ideas: •  Voice chat to runner –  Audio encouragement •  Augment runner app with live leaderboard –  Google Glass = augmented reality race –  “Arnaud Mathieu is 0.23 miles ahead of you!” "   A decoupled application with MQTT allows for easy extension and integration of new features "   What else is possible? 15
  • 18. Chatterbox "   Problem •  Need scalable chat that works anywhere you are. –  2G in the country, LTE in the city, Wifi at Impact! –  Reliability is key •  Need scalable chat that works on any device –  Think desktop, mobile... wearable, etc. "   Solution – “Chatterbox” •  MQTT HTML5 ßà MQTT native iOS •  Assured messaging with QoS •  Text, picture, audio, video chat "   Challenges •  Cross-platform messaging (MQTT Paho clients!) •  Constrained networks (MQTT durable subscriber!) 17
  • 20. 19 Web App / Native App (iOS) •  All clients use same "Chatterbox" JSON API "   Pubs •  Room Data (retained) –  chatterbox/Room/<room_id> •  {  "id":"IBMIMP5116",  "name":"IBM  Impact",  "password":""  }   •  Presence (retained) –  chatterbox/Room/<room_id>/User/<uuid> •  {  "displayName":"Bryan  Boyd",  "color":"green",  "uuid":<uuid>  } •  Chat Data –  chatterbox/Room/<room_id>/Chat •  {  "name":"Bryan  Boyd",  "uuid":<uuid>,  "format":"text",   "data":"Hello  world!",  "index":0,  "max":1,  "id":"b4ps8fjqgg",   "timestamp":1398875852255  } Chatterbox
  • 22. Play time [see Arnaud for free tablets] or bit.ly/ibmchatterbox (use Chrome, accept camera/microphone prompts) 21
  • 23. What else is possible? "   Even more collaboration •  Broadcast streaming audio, video •  Screen share, drawing •  Record MQTT messages to “archive” a collaboration and play back in real time "   Integrate social media •  Link twitter account •  Type “:tweet: <chat>” to publish a tweet "   What else is possible? 22
  • 25. Starfighter "   Problem •  Quickly build a massively multiplayer game •  Need low latency from client to client •  To scale, we need to intelligently deliver the right data to the right place at the right time "   Solution – “Starfighter” •  MMOG, IoT-style... •  Every ship is a MQTT client –  Humans: HTML5, Bots: Node.js •  Every action is a message –  Shoot / Move / Hit •  Client-to-Broker-to-Client for low latency "   Challenges •  Data management (dynamic subscriptions!) 24
  • 26. Scenario 25 Broker Player AI Bot Viewer BlueMix BlueMix Scoring
  • 27. Mobile-ready App (HTML5) 26 "   Pubs •  "Telemetry" – 16 msg/sec –  starfighter/players/ship/<z>/<x>/<y>/<uuid> {  "uuid":"gqds2na46a","time":1398962284414,      "name":"@bryanboyd","type":"ship",      "worldPos":  {"x":"10022.6","y":"2698.2"},      "velocity":  {"x":"0.1","y":"185.8"},  "angle":"8.9",      "shield":"1.0000",  "status":"NORMAL",  "score":0      "lastHitTime":1398962247380,  "lastUpdate":1398962261510  }   •  Gunfire –  starfighter/players/bullet/<z>/<x>/<y>/<uuid> •  {  "uuid":"gqds2na46a",  "action":"shoot",  "bullets":3  } •  Events –  starfighter/players/event/<z>/<x>/<y>/<uuid> •  {  "uuid":"gqds2na46a",  "name":"@bryanboyd",  action:"hit",   "damage":0.03,  "by":"u6xnd"  }   •  {  "uuid":"gqds2na46a",  "name":"@bryanboyd",  action:"destroyed",   "bonus":500,  "by":"u6xnd"  }
  • 28. Mobile-ready App (HTML5) 27 "   Subs •  "Telemetry" –  starfighter/players/ship/<z>/<x>/<y>/+ •  Gunfire –  starfighter/players/bullet/<z>/<x>/<y>/+ •  Events –  starfighter/players/event/<z>/<x>/<y>/+ How does this scale? Not well. -  10 players x 16 msgs/sec telemetry is okay -  100 players x 16 msgs/sec telemetry is not -  10000 players x 16 msgs/sec...
  • 29. 28 "   Idea: •  Map ship x,y coord to a map region •  Include region in the topic •  Publish multiple feeds at different rates: –  z = 0, 1 msg/sec –  z = N, 2n msg/sec ... –  z = 4, 16 msg/sec –  Total = (2z_max – 1) •  As your ship changes regions, change the publishing topic Location Topics 3210 1 2 3 0 1 0 1 0 0 z = 0 z = 1 z = 2
  • 30. 29 "   Idea •  Which feeds do I need? (find z) –  smallest map region that encompasses viewport •  Where am I? (find x, y) •  Subscribe to z/x/y and the neighboring regions •  As your ship changes regions, subscribe to the new topics and unsubscribe from the old "   Benefits •  Viewer just subscribes to z = 0, gets N msgs/sec •  Player gets fine-grained data about neighboring players to draw smoothly... no more "lag kills" Dynamic Subscriptions
  • 31. Hackathon-ready "   To build an AI... •  Pick a random position and vector •  Publish telemetry, update position over time, and fire away •  Subscribe to topics for local region •  If a player gets within X dist, update vector to intercept " Node.js bots in BlueMix 30 BlueMix
  • 32. Play time 31 [see Arnaud for free tablets] or bit.ly/playstarfighter optimized for Google Chrome
  • 33. What else is possible? "   Other scenarios: •  Fleet management –  Track vehicle movements and inventory in real time –  Provide feeds of different granularity based on map region •  Online gaming – poker, horse betting –  Pub/sub is good for a gaming table, real-time race tracking, assured messaging for placing bets •  Collaboration –  Many users can control and affect the same virtual space "   What else is possible? 32
  • 35. Takeaways "   WebSockets – extending real-time communication to browsers "   MQTT – scalable, reliable, fast messaging everywhere •  Scalable – pub/sub, tiny headers •  Reliable – quality of service for assured messaging •  Fast – with the right broker, low latency at scale •  Everywhere – Eclipse Paho clients A great protocol needs a great broker... 34
  • 36. IBM MessageSight "   Secure messaging for Mobile and Internet of Things •  MQTT Broker (TCP + WebSocket), JMS "   Mobile engineered – very fast, reliable messaging "   Massive scale – a million connections, millions of msgs/sec "   Simple configuration – secure messaging topics and endpoints with policies 35
  • 37. Scaling with IBM MessageSight "   1 million concurrent connections, millions of msgs/sec "   What we can do: •  RaceTracker –  Track the Boston, NYC, and Chicago marathons at the same time •  Chatterbox –  Run low-latency, secure, on-premise chat for your entire enterprise •  Starfighter –  Thousands of players can collaborate simultaneously –  Monitor and control tens of thousands of sensors 36
  • 38. In conclusion... 37 "   WebSocket for bidirectional communication "   MQTT for efficient mobile-to-mobile publish/subscribe "   IBM MessageSight for scalability, security, and simplicity With real-time, scalable mobile messaging... what kind of compelling experiences can you create?
  • 40. References     "   Demo site: http://m2m.demos.ibm.com/ "   M2M Community https://www.ibm.com/developerworks/community/blogs/c565c720- fe84-4f63-873f-607d87787327/entry/mobile_messaging?lang=en "   Download free virtual image for Development: https://www.ibmdw.net/messaging/messagesight/ " MQTT.org: http://mqtt.org/ "   Eclipse Paho project: http://www.eclipse.org/paho/ "   IBM Messaging community: http://www.ibm.com/developerworks/connect/IBMmessaging "   IBM Messaging media: http://www.youtube.com/user/IBMmessagingMedia?feature=watch "   IBM MessageSight: http://www.ibm.com/messagesight "   IBM and Sprint Velocity Drive Connected Car Into The Future: http://www.ibm.com/press/us/en/pressrelease/41441.wss
  • 42. We Value Your Feedback "   Don’t forget to submit your Impact session and speaker feedback! Your feedback is very important to us – we use it to continually improve the conference. "   Use the Conference Mobile App or the online Agenda Builder to quickly submit your survey •  Navigate to “Surveys” to see a view of surveys for sessions you’ve attended 41
  • 44. Legal Disclaimer •  © IBM Corporation 2014. All Rights Reserved. •  The information contained in this publication is provided for informational purposes only. While efforts were made to verify the completeness and accuracy of the information contained in this publication, it is provided AS IS without warranty of any kind, express or implied. In addition, this information is based on IBM’s current product plans and strategy, which are subject to change by IBM without notice. IBM shall not be responsible for any damages arising out of the use of, or otherwise related to, this publication or any other materials. Nothing contained in this publication is intended to, nor shall have the effect of, creating any warranties or representations from IBM or its suppliers or licensors, or altering the terms and conditions of the applicable license agreement governing the use of IBM software. •  References in this presentation to IBM products, programs, or services do not imply that they will be available in all countries in which IBM operates. Product release dates and/or capabilities referenced in this presentation may change at any time at IBM’s sole discretion based on market opportunities or other factors, and are not intended to be a commitment to future product or feature availability in any way. Nothing contained in these materials is intended to, nor shall have the effect of, stating or implying that any activities undertaken by you will result in any specific sales, revenue growth or other results. •  If the text contains performance statistics or references to benchmarks, insert the following language; otherwise delete: Performance is based on measurements and projections using standard IBM benchmarks in a controlled environment. The actual throughput or performance that any user will experience will vary depending upon many factors, including considerations such as the amount of multiprogramming in the user's job stream, the I/O configuration, the storage configuration, and the workload processed. Therefore, no assurance can be given that an individual user will achieve results similar to those stated here. •  If the text includes any customer examples, please confirm we have prior written approval from such customer and insert the following language; otherwise delete: All customer examples described are presented as illustrations of how those customers have used IBM products and the results they may have achieved. Actual environmental costs and performance characteristics may vary by customer. •  Please review text for proper trademark attribution of IBM products. At first use, each product name must be the full name and include appropriate trademark symbols (e.g., IBM Lotus® Sametime® Unyte™). Subsequent references can drop “IBM” but should include the proper branding (e.g., Lotus Sametime Gateway, or WebSphere Application Server). Please refer to http://www.ibm.com/legal/copytrade.shtml for guidance on which trademarks require the ® or ™ symbol. Do not use abbreviations for IBM product names in your presentation. All product names must be used as adjectives rather than nouns. Please list all of the trademarks that you use in your presentation as follows; delete any not included in your presentation. IBM, the IBM logo, Lotus, Lotus Notes, Notes, Domino, Quickr, Sametime, WebSphere, UC2, PartnerWorld and Lotusphere are trademarks of International Business Machines Corporation in the United States, other countries, or both. Unyte is a trademark of WebDialogs, Inc., in the United States, other countries, or both. •  If you reference Adobe® in the text, please mark the first use and include the following; otherwise delete: Adobe, the Adobe logo, PostScript, and the PostScript logo are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States, and/or other countries. •  If you reference Java™ in the text, please mark the first use and include the following; otherwise delete: Java and all Java-based trademarks are trademarks of Sun Microsystems, Inc. in the United States, other countries, or both. •  If you reference Microsoft® and/or Windows® in the text, please mark the first use and include the following, as applicable; otherwise delete: Microsoft and Windows are trademarks of Microsoft Corporation in the United States, other countries, or both. •  If you reference Intel® and/or any of the following Intel products in the text, please mark the first use and include those that you use as follows; otherwise delete: Intel, Intel Centrino, Celeron, Intel Xeon, Intel SpeedStep, Itanium, and Pentium are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. •  If you reference UNIX® in the text, please mark the first use and include the following; otherwise delete: UNIX is a registered trademark of The Open Group in the United States and other countries. •  If you reference Linux® in your presentation, please mark the first use and include the following; otherwise delete: Linux is a registered trademark of Linus Torvalds in the United States, other countries, or both. Other company, product, or service names may be trademarks or service marks of others. •  If the text/graphics include screenshots, no actual IBM employee names may be used (even your own), if your screenshots include fictitious company names (e.g., Renovations, Zeta Bank, Acme) please update and insert the following; otherwise delete: All references to [insert fictitious company name] refer to a fictitious company and are used for illustration purposes only.
